WKWebView in Production

Transcript

1. The 7 Wonders Disappointments of WKWebView (and what to do about them)
2. Loki Meyburg Technical Product Manager
3. In the beginning there was UIWebView
4. What is UIWebView? • Original web rendering component introduced in iOS 2.0 • This is what was historically used to build out hybrid apps or load any web content inside an iOS app
5. Remember this?
6. UIWebView !== Safari • Mobile Safari tends to load pages 2-3x faster than a UIWebView • Changes and fixes applied to Safari usually not ported into UIWebView • UIWebview is clunky, crashy, leaks memory • Scrolling blocks images loading • Different JavaScript engine than Safari (not Nitro)
7. Why does UIWebView not have Nitro? Nitro is excluded because Apple wanted to make hybrid apps less performant and force everybody to use their native platform Excluded due to security reasons. Running a Just-In- Time compiler requires marking pages in RAM as executable - iOS does not allow this out of security concerns (except in Safari) Cynical Answer Real Answer
8. Introducing WKWebView
9. WKWebView Introduced in iOS 8 to give developers a performant webview (“same” performance as Safari) WKWebView's rendering is all done in a separate process owned by the WKWebView
10. WKWebView == WebKit
11. Benefits of WKWebView
12. Better HTML 5 Support
13. WKWebView also gives us… • Significant performance gains in WebGL applications (though supported in UIWebview) • Less "crashy" behaviour when rendering bugs are triggered from HTML/CSS/JavaScript
14. More benefits! • Faster JavaScript and page rendering (thanks Nitro!) • 60fps scrolling • Better communication between Swift and JS (we haven’t experimented with this yet) • Since we are sharing the JS engine with Safari, WKWebView should be better maintained and more reliable
15. How do I implement WKWebView? • Don’t worry, there’s a ton of great documentation!
16. How do I implement WKWebView? • Don’t worry, there’s a ton of great documentation!
17. How do I implement WKWebView? • Don’t worry, there’s a ton of great documentation! • What was formerly a single class (UIWebView) and protocol (UIWebViewDelegate) is now 14 classes and 3 protocols (WKNavigationDelegate, WKScriptMessageHandler, WKUIDelegate) • Other than class docs (and StackOverflow) , no official “How-To WKWebView” from Apple
18. WKWebView Related Classes WKBackForwardList WKBackForwardListItem WKFrameInfo WKNavigation WKNavigationAction WKNavigationResponse WKPreferences WKProcessPool WKScriptMessage WKSecurityOrigin WKUserContentController WKUserScript WKWebViewConfiguration WKWebsiteDataRecord WKWebsiteDataStore WKWindowFeatures WKWebView
19. More code required • Automatically handled by UIWebView • App store links • JS alerts, confirms, inputs • Sharing cookies between web views
20. The 7 Wonders Disappointments of WKWebView
21. Cannot load Local File URLS in iOS 8 #1
22. Cannot Load Local File URLs • This is sorta critical for Mobify’s Hybrid App SDK • UIWebView: • webView!.loadRequest(request)
23. • High-level: copy the files we need to load into a /tmp directory that we can load files from • Alternative: copy files we need to a local webserver running on the device • Fixed in iOS 9 Cannot Load Local File URLs
25. Cannot intercept POST requests #2
26. Cannot intercept POST requests • POST bodies are missing in NSURLRequest sent to delegate methods • Solution: for now leave it -- in line with Android behaviour • Good news: WebKit forums indicate this is a bug and there seems to be a bit of traction
27. Broken UI state preservation #3
28. UI state preservation/restoration broken • WKWebView cannot be archived and doesn’t participate in state/preservation/restoration • Previously used to reduce memory footprint and prevent crashes • Solution: build our own by saving the last known URL
29. WSOD: White Screen of Death #4
30. • Seeing some webviews display about:blank for no reason upon navigating back • Appears to be a memory issue WSOD: White Screen of Death
31. WSOD - Our Solution We poll each webview that we manage and not currently visible (in the view hierarchy)
32. Views Appear Halfway Down #5
33. • Happens when the frame is not set before load completes http://www.openradar.me/22855188 • Had to get creative on this one. • Turns out, duplicate <head> tags are ignored… • … so we create a <head> tag at the beginning JUST to scroll back up Views Appear Halfway Down
34. Our Solution
35. View Doesn’t Render Until Visible #6
36. View Doesn’t Render Until Visible • Big problem for preloading tabs in a tab bar layout • Bigger problem if you rely on Javascript to run in those webviews • Solution is an off-screen “holding pen” for web views not currently visible
37. Our Solution
38. Broken or Self-Signed Certs in iOS 8 #7
39. WKWebView and Certs • Bug in WKWebView where the documented way of doing custom analysis of SSL certificates is broken • webView(_:didReceiveAuthenticationChallenge:completionHandler:) is never called • Important for internal use • No workaround
40. Other Weird Bugs
41. Need to know about these: • When app is sent to background, JS stops executing in ~10sec while native code (and JS in UIWebView) keeps running for ~3 min until completely suspended by OS. • Unlike UIWebView, the webView.URL property is updated to the navigation target before webView:decidePolicyForNavigationAction:decisionHandler in WKWebView. • App store links don’t work by default -- have to intercept requests (http://atmarkplant.com/ios-wkwebview-tips/#applink)
43. Are others using it?
44. Who uses WKWebView? WKWebView is enabled by default in our hybrid app SDK
45. astro.mobify.com
46. Q&A
