OSMC 2018: Logging is coming to Grafana

David
November 06, 2018

OSMC 2018: Logging is coming to Grafana

A preview of Grafana's upcoming log aggregation solution. Also show-casing the new Explore UI for Prometheus.

David

November 06, 2018
Tweet

More Decks by David

Other Decks in Technology

Transcript

  1. I’m David All things UX at Grafana Labs If you

    click and are stuck, reach out to me. [email protected] Twitter: @davkals
  2. Datasource updates • New: MS SQL Server • New: Google

    Stackdriver • New: Flux (Influx, BETA) • ElasticSearch alerting • Postgres query builder
  3. Provisioning API Define data sources and dashboards in files Auto-reload

    on change Allows version control of files http://docs.grafana.org/administration/provisioning/
  4. Grafana is now fully CI’ed With ARM and Windows builds

    Test new features that are in master: docker run -d --name=grafana -p 3000:3000 grafana/grafana:master https://hub.docker.com/r/grafana/grafana/
  5. Explore UI wireframes rate(http_requests_total[5m]) GRAPH TABLE BOTH Last 1 hour,

    Refresh: 10s RUN 1 - rate(http_requests_total[5m]) . . . rate(http_requests_total[5m]) 1 - rate(http_requests_total[5m]) 4.2s 3.2s rate(http_requests_total[5m]) GRAPH TABLE BOTH Last 1 hour, Refresh: 10s RUN 1 - rate(http_requests_total[5m]) . . . rate(http_requests_total[5m]) 1 - rate(http_requests_total[5m]) 4.2s 3.2s First tab Second tab 3rd tab My tab ╳
  6. Extended Explore to have metrics and logs side-by-side rate(http_requests_total{job=”app1”}[5m]) GRAPH

    TABLE BOTH Last 1 hour, Refresh: 10s RUN 1 - rate(http_requests_total{job=”app1”}[5m]) rate(http_requests_total[5m]) 1 - rate(http_requests_total[5m]) 4.2s 3.2s {job=”app1”} DATASOURCE Last 1 hour, Refresh: 10s RUN 4.2s LOGS level=info ts=2018-11-05T17:13:48.774738335Z caller=main.go:244 msg="Starting Prometheus" version="(version=2.4.2, branch=master, revision=3e6b9d43c36921e318a8722772160be4184ddad5)" level=info ts=2018-11-05T17:13:48.775413199Z caller=main.go:245 build_context="(go=go1.10.3, [email protected], date=20181011-08:29:54)" level=info ts=2018-11-05T17:13:48.77545838Z caller=main.go:246 host_details=(darwin) level=info ts=2018-11-05T17:13:48.775499098Z caller=main.go:247 fd_limits="(soft=256, hard=unlimited)" level=info ts=2018-11-05T17:13:48.775545138Z caller=main.go:248 vm_limits="(soft=unlimited, hard=unlimited)" level=info ts=2018-11-05T17:13:48.777071286Z caller=main.go:562 msg="Starting TSDB ..." level=info ts=2018-11-05T17:13:48.778020546Z caller=web.go:399 component=web msg="Start listening for connections" address=0.0.0.0:9090 level=info ts=2018-11-05T17:13:48.807390226Z caller=repair.go:35 component=tsdb msg="found healthy block" mint=1539583200000 maxt=1539648000000 ulid=01CT0XT8W5N1E07K3ZQ5PGPFHM level=info ts=2018-11-05T17:13:48.807946341Z caller=repair.go:35 component=tsdb msg="found healthy block" mint=1539648000000 maxt=1539712800000 ulid=01CT0XT9051Q2D6Q4FD1CN52BG level=info ts=2018-11-05T17:13:48.808972634Z caller=repair.go:35 component=tsdb msg="found healthy block" mint=1539712800000 maxt=1539777600000 ulid=01CT18NCBATPKCZ9PVFPMSEZD6
  7. Service Discovery for Grafana Logging • Prometheus-style service discovery of

    logging targets • Labels are indexed as metadata, e.g.: {job=”app1”} • Relabeling rules
  8. Logging TODOs • Dedup logic • Pattern engine that emits

    time series • Triggers/webhooks • Cost-effective
  9. Enable Explore UI (BETA: Prometheus) Behind feature flag. To enable,

    edit Grafana config ini file [explore] enabled = true Set up a datasource that supports Explore, e.g., Prometheus. Will be released in 6.0 (Feb 2019)
  10. Explore UI needs to be refined still behind feature flag,

    feedback welcome: @davkals or [email protected] UX improvements on logs and metrics views Unify query editors for Explore and dashboards Performance improvements
  11. Dashboard management: Git integration and custom defaults RFCs waiting for

    feedback: Dashboard changes trigger GitHub PR: https://github.com/grafana/grafana/issues/13823 Reference panels for custom defaults: https://github.com/grafana/grafana/issues/13888
