Introduction to Apache Lucene

Presentation given at BreizhCamp 2015.

Transcript

1. www.elastic.co Apache Lucene Adrien Grand 1
2. www.elastic.co What is Lucene? • An information retrieval library • Can be used to build search apps • Not a runtine, use Solr or Elasticsearch • Written in Java • Developed at the Apache Software Foundation • Contributors include IBM, Twitter, Elastic, Lucidworks, … 2
3. www.elastic.co History 3 1999: creation on Sourceforge 2001: moved to the ASF May 2006 2.0 release November 2009 3.0 release October 2012 4.0 release February 2015 5.0 release
4. www.elastic.co Activity 4 source https://www.openhub.net/p/lucene
5. www.elastic.co Features • Full-text search • Structured search • Highlighting • Faceting • Suggestions 5
6. www.elastic.co Design • Embeds • an inverted index, for efficient query execution • a document store, to get original data back • a column store, for sorting and analytics 6
7. www.elastic.co More history • Lucene 3.4 Added a faceting module • Lucene 4.0: Added a column store to the index • Lucene 4.1: More efficient structured search • Lucene 4.1: More efficient PK lookups • Lucene 4.1: Built-in compression of the doc store • Lucene 4.5: Column store moved from memory to disk • Lucene 4.8: Checksums on all index files • Lucene 5.1: Better query execution plans with 2-phases iterators 7
8. www.elastic.co Design 8 Segment core 0 name: Breizh camp location: Rennes, France 1 name: Devoxx location: Antwerp, Belgium Document store doc id stored fields breizh camp conference devoxx 1 1 2 1 0 0 0,1 1 Inverted index terms dict doc freq postings Column store 0 1 42 1242 0 1 1000 10 Price Popularity Live docs 0 1 true true
9. www.elastic.co Design • Index divided into immutable segments • To add more documents, add more segments • In-place updates are not supported • To update documents, delete then add 9
10. www.elastic.co Merging • Background merges • Keep the number of segments low for fast search • Reclaim space from deleted documents 10
11. www.elastic.co Merging • Writing/Merging segments is expensive • IndexWriter buffers pending docs in memory • Refresh/Reopen: • Flush in-memory buffer into a segment • Make segment searchable • Commit • Flush in-memory buffer to a segment • “fsync” data to disk 11
12. www.elastic.co Index safety 12 Only data which has been committed is safe. If you need better safety, write the data somewhere else too: other database, transaction log, …
13. www.elastic.co Advices • Don’t give all machine memory to Java • Performance factor #1 is the filesystem cache • Reopen asynchronously, typically every X seconds • Batch writes before committing 13
14. www.elastic.co Pros/cons • Fast search • Cross-field index intersections • On the contrary to many databases! • Powerful combinations of features • Run facets on docs that match a particular query 14 • Not realtime • Yet “near” realtime • No fine-grained updates • Ingestion speed • Yet fast enough for most use-cases • Disk usage: data is duplicated for each access pattern
15. www.elastic.co Backward compatibility • Version N can read indices of version N-1 • Public API: minor versions are backward compatible • IndexWriter, IndexSearcher, Query, Document, … • Unless we discover API is trappy • Internal/Experimental APIs will break • Collector, Scorer, Comparator, … 15
16. www.elastic.co SimpleText 16 IndexWriterConfig iwConfig = new IndexWriterConfig(new WhitespaceAnalyzer()); iwConfig.setCodec(new SimpleTextCodec()); try (Directory dir = FSDirectory.open(new File("/tmp/my_index").toPath()); IndexWriter writer = new IndexWriter(dir, iwConfig)) { Document document = new Document(); document.add(new TextField("name", "Breizh C@mp", Store.YES)); document.add(new TextField("desc", "la conférence des développeurs du Grand Ouest", Store.NO)); document.add(new StoredField("location", "Rennes, France")); document.add(new NumericDocValuesField("founded_year", 2011)); writer.addDocument(document); document = new Document(); document.add(new TextField("name", "Devoxx France", Store.YES)); document.add(new TextField("desc", "la conférence des développeurs passionnés", Store.NO)); document.add(new StoredField("location", "Paris, France")); document.add(new NumericDocValuesField("founded_year", 2012)); writer.addDocument(document); writer.commit(); document = new Document(); document.add(new TextField("name", "Riviera DEV", Store.YES)); document.add(new TextField("desc", "la conférence des développeurs du Sud Est", Store.NO)); document.add(new StoredField("location", "Sophia-Antipolis, France")); document.add(new NumericDocValuesField("founded_year", 2009)); writer.addDocument(document); writer.commit(); }
17. www.elastic.co 17 % ls /tmp/my_index _0.scf _0.si _1.scf _1.si segments_2
18. www.elastic.co 18 % cat _0.si version 6.0.0 number of documents 2 uses compound file true diagnostics 8 key os value Linux key java.vendor value Oracle Corporation key java.version value 1.8.0_25 key lucene.version value 6.0.0 key os.arch value amd64 key source value flush key os.version value 3.13.0-53-generic key timestamp value 1434102490791 attributes 0 files 2 file _0.si file _0.scf id ??hFq? E?q??h?? checksum 00000000001526513595
19. www.elastic.co 19 % cat _0.scf cfs entry for: _0.dat field founded_year type NUMERIC minvalue 2011 pattern 0 0 T 1 T END checksum 00000000003242224815 […]
20. www.elastic.co 20 cfs entry for: _0.fld doc 0 field 0 name name type string value Breizh C@mp field 2 name location type string value Rennes, France doc 1 field 0 name name type string value Devoxx France field 2 name location type string value Paris, France END checksum 00000000002801255432
21. www.elastic.co 21 cfs entry for: _0.pst field desc term Grand doc 0 freq 1 pos 5 term Ouest doc 0 freq 1 pos 6 term conférence doc 0 freq 1 pos 1 doc 1 freq 1 pos 1 […] END checksum 00000000002149012390
22. www.elastic.co 22 Thank you! @jpountz
