Software Architecture for Distributed Systems
Topics covered are software architecture basics, distribution, and architecture for distributed systems.
Felix Raab
January 09, 2019
Transcript
30 slides
-
KI UNIVERSITY DISTRIBUTED SYSTEMS “A distributed system is one in
which the failure of a computer you didn’t even know existed can render your own computer unusable.” Leslie Lamport, 1987 -
KI UNIVERSITY DON’T DISTRIBUTE “My First Law of Distributed Object
Design: Don't distribute your objects” Martin Fowler, 2002 -
KI UNIVERSITY TERRIBLE DISTRIBUTED SYSTEMS “Everything about distributed systems is
terrible.” Hillel Wayne, 2018 We’ll come back to that at the end of the talk… -
KI UNIVERSITY BUT WE DON’T LISTEN… Distribute things like never
before!!! https://xkcd.com/1546/ -
▸ The classic way (a good foundation for a monolithic
app): 3-tier, n-tier, … KI UNIVERSITY LAYERED ARCHITECTURE PRESENTATION BUSINESS LOGIC PERSISTENCE Separation of Concerns? Kind of…(technical separation) – but how do you slice it for business-related functionality? -
KI UNIVERSITY DOMAINS… ▸ Structure functionality around business domains ▸
Towards “vertical slices” ▸ Tactical Patterns -
KI UNIVERSITY “ONION” MICROSERVICE ▸ Simple rule: Outside depends on
inside (but not the other way round) ▸ Outside: HTTP, Database (the inputs and outputs of the system). Inside: Domain Concepts (the “business rules”) -
KI UNIVERSITY DISTRIBUTION ▸ Multiple services – sync. point-to-point communication
– what can possibly go wrong? SERVICE A SERVICE B ▸ A lot: Failure, Maintenance, Overloaded, etc. -
KI UNIVERSITY THE FALLACIES OF DISTRIBUTED SYSTEMS ▸ The network
is reliable. ▸ Latency is zero. ▸ Bandwidth is infinite. ▸ The network is secure. ▸ Topology doesn't change. ▸ There is one administrator. ▸ Transport cost is zero. ▸ The network is homogeneous. Source: https://en.wikipedia.org/wiki/Fallacies_of_distributed_computing -
KI UNIVERSITY ROBUSTNESS ▸ Retries (ideally with exponential back-off) ▸
Circuit Breakers (Pattern for broken services not being called again until they recover) -
KI UNIVERSITY TAIL LATENCY AMPLIFICATION SERVICE BACKEND A BACKEND B
BACKEND C ▸ Parallel fan out: A single slow backend can slow everything down. The more backends are involved, the higher the proportion of upstream service requests that will be slow. ▸ Possible solutions: Caching, sending more requests and using the fastest, timeouts, etc. “The Tail at Scale”: https://dl.acm.org/citation.cfm?doid=2408776.2408794 -
KI UNIVERSITY ▸ Service Meshes and Side Car Proxies MANY
SERVICES… Source: https://www.infoq.com/articles/microservices-post-kubernetes -
KI UNIVERSITY TIME TO THINK… ▸ Suppose you built a
monolithic web application where users can publish blog posts. The posts are stored in a database (table). Now you want to add a new feature that recommends blog posts to users. ▸ From an architectural perspective, you want to handle the recommendation feature through a new service. How would you design the service and add it to the existing architecture? (Backend Engineering Interview Question – inspired by Medium Engineering) -
KI UNIVERSITY WHAT ABOUT THIS DESIGN? (1) WEB APP POSTS
TABLE RECO SERVICE CACHE ▸ If web app changes storage of posts, reco service needs to adapt. ▸ Logic based on posts data would need to be re-implemented in reco service. -
KI UNIVERSITY WHAT ABOUT THIS DESIGN? (2) WEB APP POSTS
TABLE RECO SERVICE POSTS SERVICE CACHE ▸ Access posts data through new posts service API, which fully owns all posts data. -
KI UNIVERSITY WHAT ABOUT THIS DESIGN? (3) ▸ Push post
changes to queue, reco service maintains its own data for relevant posts. WEB APP POSTS TABLE QUEUE CACHE RECO SERVICE RECO DATA CACHE -
KI UNIVERSITY OPTION 4 “The hardest part of microservices is
your data”: https://www.youtube.com/watch?v=MrV0DqTqpFU -
KI UNIVERSITY DB SHARING ▸ Sharing a database between (micro)services
can be ok! (while sharing data / tables is often not ok). ▸ Also think about deployment complexity, cloud costs… -
KI UNIVERSITY DESIRABLE GOAL: SERVICE ISOLATION ▸ Isolation of Time
(Async. communication, events) ▸ Isolation of State (Data Ownership, no table sharing, communicate through APIs) ▸ Isolation of Space (Don’t depend on location of other service, support deployment across many machines) ▸ Isolation of Failures (Failure in a service does not bring down whole system) Source: https://corecursive.com/22-big-ball-of-mud-architecture-and-services-with-wade-waldron/ -
KI UNIVERSITY BREAKING UP MONOLITHS ▸ Refactoring, service extraction principles
“How to extract a data-rich service from a monolith”: https://martinfowler.com/articles/extract-data-rich-service.html -
KI UNIVERSITY NOT DISCUSSED ▸ Communication Protocols (JSON, gRPC, …)
▸ Observability (Monitoring, Tracing, …) ▸ Deployment: Containers, Serverless, Lightweight VMs, … ▸ … -
KI UNIVERSITY TLA+ ▸ Specification language for concurrent systems, invented
by Leslie Lamport ▸ Increasingly used in industry to design for reliability and correctness (e.g. by AWS, used for the replication protocol of Azure’s Cosmos DB) https://www.youtube.com/watch?v=tfnldxWlOhM
