MATLAB Tutorial

MATLAB Graphics and using oscilloscope with MATLAB

Transcript

1. MATLAB Tutorial Thomasy
2. Outline • MATLAB Graphics • Writing MATLAB Program
3. Graphics Basics • XY Plot – plot: Graph 2-D data with linear scales for both axes – plot3: Graph 3-D data with linear scales for both axes – loglog: Graph with logarithmic scales for both axes – semilogx: Graph with a logarithmic scale for the x-axis and a linear scale for the y-axis – semilogy: Graph with a logarithmic scale for the y-axis and a linear scale for the x-axis – plotyy: Graph with y-tick labels on the left and right side • XY Plot example – x = 0:0.05:5; – y = sin(x.^2); – plot(x,y); – xlabel('Time') – ylabel('Amplitude') Fig 1. XY Plot
4. Bar Chart • bar(Y) draws one bar for each element in Y. – x = -2.9:0.2:2.9; – bar(x,exp(-x.*x)); Fig 2. Bar Chart
5. Stem Chart • Plot discrete sequence data • stem(Y) plots the data sequence, Y, as stems that extend from a baseline along the x-axis. The data values are indicated by circles terminating each stem. • Example – x = 0:0.1:4; – y = sin(x.^2).*exp(-x); – stem(x,y) Fig 3. Stem Chart
6. Scatter Plot • scatter(X,Y) displays circles at the locations specified by the vectors X and Y. This type of graph is also known as a bubble plot. • Example – load count.dat – scatter(count(:,1),count(:,2),'r*') – xlabel('Number of Cars on Street A'); – ylabel('Number of Cars on Street B'); Fig 4. Scatter Plot
7. Polar Plot • The polar function accepts polar coordinates, plots them in a Cartesian plane, and draws the polar grid on the plane. • Example – t = 0:0.01:2*pi; – polar(t,abs(sin(2*t).*cos(2*t))); Fig 5. Polar Plot
8. Ezplot • Easy-to-use function plotter • Example – ezplot('sin(x)') – ezplot('sin(x).^2 + cos(y).^2 = 1') Fig 6. Plot sin(x)^2 + cos(y)^2 = 1 Fig 7. Plot sin(x)
9. 3D Plot • mesh(X,Y,Z) draws a wireframe mesh with color determined by Z, so color is proportional to surface height. – z=peaks(25); – mesh(z); • surf(Z) creates a three-dimensional shaded surface from the z omponents in matrix Z. – z=peaks(25); – surf(z); • ezsurf() • ezmesh() Fig 8. Mesh Plot
10. Ezplot3 • Easy-to-use 3-D parametric curve plotter • Three dimension version of ezplot. – ezplot3('t*sin(t)', 'cos(t)', 't', [0,12*pi]) Fig 9. 3D plot
11. Tips and Tricks • Use “fx” – Find functions • Scalar multiplication – .* – ./ • Reading online manuals – http://www.mathworks.com/help/matlab/index.html
12. MATLAB FFT for Signal Analyze • Tools: Aglient Toolbox + Aglient IO Library. • MATLAB + Aglient https://www.mathworks.com/products/instrument/supported/agilent.html Fig 11. Aglient Toolbox for Excel Fig 10. Aglient Toolbox for Word
13. MATLAB FFT for Signal Analyze • Use Excel to retrieve data from the oscilloscope and export CSV file. Table 1. Retrieved Data from the oscilloscope Fig 13. Dialog for Retrieving Data from the Oscilloscope -80.4 mV, 平均電壓 (1) 2.51 V, RMS 電壓 (1) 7.6 V, 峰值對峰值電壓 (1) 2.49 V, 最大電壓 (1) -3.7 V, 最小電壓 (1) 3 us, 上升時間 (1) 3 us, 下降時間 (1) 1.908 ms, 正脈衝寬度 (1) 1.908 ms, 負脈衝寬度 (1) 3.816 ms, 週期 (1) 262.05 Hz, 頻率 (1) 50 %, 占空比 (1) Fig 12. Plot Data from the Oscilloscope Fig 14. Output waveform
14. MATLAB FFT for Signal Analyze • Fast Fourier transform • A common use of Fourier transforms is to find the frequency components of a signal buried in a noisy time domain signal. • http://www.mathworks.com/help /matlab/ref/fft.html • https://www.youtube.com/watch ?v=Ko57FiBVkVY Fig 15. FFT from the Oscilloscope Fig 17. FFT Analyze using MATLAB Fig 16. Import CSV File into MATLAB
15. Fig 10. FFT from the Oscilloscope
16. Fig 20. FFT from the Oscilloscope Fig 19. Fourier Expansion of Square Wave
17. Writing MATLAB Program • Call by function name / file name Fig 22. Play sound using square wave Fig 23. Play sound using sine wave Fig 21. Play single tone
