OpenJDK tools for fun and profit (BaselOne 2017)

Slides from of the "OpenJDK tools for fun and profit" talk give at BaselOne 2017 (http://baselone.ch/home2017/)

Transcript

1. #BaselOne17
2. OpenJDK tools for fun and proft by Dmitry Vyazelenko @ BaselOne 2017
3. About me • Senior Software Engineer @ Canoo Engineering AG, Switzerland • Disorganizer at JCrete Unconference, www.jcrete.org • Contacts: vyazelenko.com, @DVyazelenko
4. Agenda • JOL • JMH • JCStress • JITWatch
5. JOL
6. JOL (Java Object Layout) is the tiny toolbox to analyze object layout schemes in JVMs. These tools are using Unsafe, JVMTI, and Serviceability Agent (SA) heavily to decoder the actual object layout, footprint, and references. This makes JOL much more accurate than other tools relying on heap dumps, specifcation assumptions, etc. http://openjdk.java.net/projects/code-tools/jol/
7. Getting started • Maven dependency: <dependency> <groupId>org.openjdk.jol</groupId> <artifactId>jol-core</artifactId> <version>put-the-version-here</version> </dependency> • Build from source: hg clone http://hg.openjdk.java.net/code-tools/jol/ jol • Java version: 6+
8. Command Line Usage java -jar jol-cli/target/jol-cli.jar help Usage: jol-cli.jar <mode> [optional arguments]* Available modes: estimates: Simulate the class layout in different VM modes. externals: Show the object externals: the objects reachable from a given instance. footprint: Estimate the footprint of all objects reachable from a given instance heapdump: Consume the heap dump and estimate the savings in different layout strategies. heapdumpstats: Consume the heap dump and print the most frequent instances. idealpack: Compute the object footprint under different field layout strategies. internals: Show the object internals: field layout and default contents, object header shapes: Dump the object shapes present in JAR files or heap dumps. string-compress: Consume the heap dumps and figures out the savings attainable with compressed strings.
9. java -jar jol-cli/target/jol-cli.jar internals java.lang.Boolean # Running 64-bit HotSpot VM. # Using compressed oop with 3-bit shift. # Using compressed klass with 3-bit shift. # Objects are 8 bytes aligned. # Field sizes by type: 4, 1, 1, 2, 2, 4, 4, 8, 8 [bytes] # Array element sizes: 4, 1, 1, 2, 2, 4, 4, 8, 8 [bytes] Instantiated the sample instance via public java.lang.Boolean(boolean) java.lang.Boolean object internals: OFFSET SIZE TYPE DESCRIPTION VALUE 0 4 (object header) 01 00 00 00 (00000001 00000000 00000000 00000000) (1) 4 4 (object header) 00 00 00 00 (00000000 00000000 00000000 00000000) (0) 8 4 (object header) 85 20 00 f8 (10000101 00100000 00000000 11111000) (-134209403) 12 1 boolean Boolean.value false 13 3 (loss due to the next object alignment) Instance size: 16 bytes Space losses: 0 bytes internal + 3 bytes external = 3 bytes total
10. package org.openjdk.jol.samples; import org.openjdk.jol.info.ClassLayout; import org.openjdk.jol.vm.VM; import static java.lang.System.out; public class JOLSample_02_Alignment { public static void main(String[] args) throws Exception { out.println(VM.current().details()); out.println(ClassLayout.parseClass(A.class).toPrintable()); } public static class A { long f; } } Alignment
11. Alignment # Running 64-bit HotSpot VM. # Using compressed oop with 3-bit shift. # Using compressed klass with 3-bit shift. # Objects are 8 bytes aligned. # Field sizes by type: 4, 1, 1, 2, 2, 4, 4, 8, 8 [bytes] # Array element sizes: 4, 1, 1, 2, 2, 4, 4, 8, 8 [bytes] org.openjdk.jol.samples.JOLSample_02_Alignment$A object internals: OFFSET SIZE TYPE DESCRIPTION VALUE 0 12 (object header) N/A 12 4 (alignment/padding gap) 16 8 long A.f N/A Instance size: 24 bytes Space losses: 4 bytes internal + 0 bytes external = 4 bytes total
12. package org.openjdk.jol.samples; import org.openjdk.jol.info.ClassLayout; import org.openjdk.jol.vm.VM; import static java.lang.System.out; public class JOLSample_07_Exceptions { public static void main(String[] args) throws Exception { out.println(VM.current().details()); out.println(ClassLayout.parseClass(Throwable.class).toPrintable()); } } Throwable
13. Throwable java.lang.Throwable object internals: OFFSET SIZE TYPE DESCRIPTION VALUE 0 12 (object header) N/A 12 4 (alignment/padding gap) 16 4 java.lang.String Throwable.detailMessage N/A 20 4 java.lang.Throwable Throwable.cause N/A 24 4 java.lang.StackTraceElement[] Throwable.stackTrace N/A 28 4 java.util.List Throwable.suppressedExceptions N/A Instance size: 32 bytes Space losses: 4 bytes internal + 0 bytes external = 4 bytes total
14. package org.openjdk.jol.samples; import org.openjdk.jol.info.ClassLayout; import org.openjdk.jol.vm.VM; import static java.lang.System.out; public class JOLSample_08_Class { public static void main(String[] args) throws Exception { out.println(VM.current().details()); out.println(ClassLayout.parseClass(Class.class).toPrintable()); } } Class
15. Class java.lang.Class object internals: OFFSET SIZE TYPE DESCRIPTION VALUE 0 12 (object header) N/A 12 4 java.lang.reflect.Constructor Class.cachedConstructor N/A 16 4 java.lang.Class Class.newInstanceCallerCache N/A 20 4 java.lang.String Class.name N/A 24 4 (alignment/padding gap) 28 4 java.lang.ref.SoftReference Class.reflectionData N/A 32 4 sun.reflect.generics.repository.ClassRepository Class.genericInfo N/A 36 4 java.lang.Object[] Class.enumConstants N/A 40 4 java.util.Map Class.enumConstantDirectory N/A 44 4 java.lang.Class.AnnotationData Class.annotationData N/A 48 4 sun.reflect.annotation.AnnotationType Class.annotationType N/A 52 4 java.lang.ClassValue.ClassValueMap Class.classValueMap N/A 56 32 (alignment/padding gap) 88 4 int Class.classRedefinedCount N/A 92 4 (loss due to the next object alignment) Instance size: 96 bytes Space losses: 36 bytes internal + 4 bytes external = 40 bytes total
16. public class CollectionLayout { public static void main(String[] args) { int[] array = new int[1_000_000]; ArrayList<Integer> arrayList = new ArrayList<>(array.length); LinkedList<Integer> linkedList = new LinkedList<>(); HashSet<Integer> hashSet = new HashSet<>(); for (int i = 0; i < array.length; i++) { array[i] = i; Integer value = new Integer(i); arrayList.add(value); linkedList.add(value); hashSet.add(value); } System.out.println(GraphLayout.parseInstance(array).toFootprint()); System.out.println(GraphLayout.parseInstance(arrayList).toFootprint()); System.out.println(GraphLayout.parseInstance(linkedList).toFootprint()); System.out.println(GraphLayout.parseInstance(hashSet).toFootprint()); } } Collections
17. Collections [I@39ed3c8dd footprint: COUNT AVG SUM DESCRIPTION 1 4000016 4000016 [I 1 4000016 (total) java.util.ArrayList@71dac704d footprint: COUNT AVG SUM DESCRIPTION 1 4000016 4000016 [Ljava.lang.Object; 1000000 16 16000000 java.lang.Integer 1 24 24 java.util.ArrayList 1000002 20000040 (total) java.util.LinkedList@6a213a91d footprint: COUNT AVG SUM DESCRIPTION 1000000 16 16000000 java.lang.Integer 1 32 32 java.util.LinkedList 1000000 24 24000000 java.util.LinkedList$Node 2000001 40000032 (total) java.util.HashSet@1b5b7e1bd footprint: COUNT AVG SUM DESCRIPTION 1 8388624 8388624 [Ljava.util.HashMap$Node; 1000000 16 16000000 java.lang.Integer 1 16 16 java.lang.Object 1 48 48 java.util.HashMap 1000000 32 32000000 java.util.HashMap$Node 1 16 16 java.util.HashSet 2000004 56388704 (total) Collection Overhead in bytes ArrayList 4 LinkedList 24 HashMap 40
18. public class JOLSample_15_IdentityHashCode { public static void main(String[] args) throws Exception { out.println(VM.current().details()); final A a = new A(); ClassLayout layout = ClassLayout.parseInstance(a); out.println("**** Fresh object"); out.println(layout.toPrintable()); out.println("hashCode: " + Integer.toHexString(a.hashCode())); out.println(); out.println("**** After identityHashCode()"); out.println(layout.toPrintable()); } public static class A { } } Object header
19. **** Fresh object org.openjdk.jol.samples.JOLSample_15_IdentityHashCode$A object internals: OFFSET SIZE TYPE DESCRIPTION VALUE 0 4 (object header) 01 00 00 00 (00000001 00000000 00000000 00000000) (1) 4 4 (object header) 00 00 00 00 (00000000 00000000 00000000 00000000) (0) 8 4 (object header) 80 12 01 f8 (10000000 00010010 00000001 11111000) (-134147456) 12 4 (loss due to the next object alignment) Instance size: 16 bytes Space losses: 0 bytes internal + 4 bytes external = 4 bytes total hashCode: 4459eb14 **** After identityHashCode() org.openjdk.jol.samples.JOLSample_15_IdentityHashCode$A object internals: OFFSET SIZE TYPE DESCRIPTION VALUE 0 4 (object header) 01 14 eb 59 (00000001 00010100 11101011 01011001) (1508578305) 4 4 (object header) 44 00 00 00 (01000100 00000000 00000000 00000000) (68) 8 4 (object header) 80 12 01 f8 (10000000 00010010 00000001 11111000) (-134147456) 12 4 (loss due to the next object alignment) Instance size: 16 bytes Space losses: 0 bytes internal + 4 bytes external = 4 bytes total Object header
20. JMH
21. Why benchmark? • Assess performance of a software system or a single component • Compare performance of diferent algorithms/implementations • Investigate impact of confguration and/or environment changes on a performance of your system
22. –Dr. Clif Click “Without exception every microbenchmark I've seen has had serious faws” http://www.azulsystems.com/presentations/art-of-java-benchmarking
23. public class ListGetBenchmarkBroken { private static final int ITERATIONS = 1_000_000_000; public static void main(String[] args) { List<Integer> list = Arrays.asList(1, 2, 3, 4, 5, 6, 7, 8, 9, 10); long startTime = System.nanoTime(); for (int i = 0; i < ITERATIONS; i++) { list.get(3); } long endTime = System.nanoTime(); long duration = endTime - startTime; System.out.println("Executed in " + TimeUnit.NANOSECONDS.toMillis(duration) + "ms, " + +((double) duration / ITERATIONS) + " ns/op"); } } Executed in 6ms, 0.006736898 ns/op
25. JMH • OpenJDK project: http://openjdk.java.net/projects/code-tools/jmh/ • Java harness for building, running, and analyzing nano/micro/milli/macro benchmarks written in Java and other languages targeting the JVM • De-facto standard for writing benchmarks on JVM • JEP 230: Microbenchmark Suite (Status: Candidate)
26. JMH features • Benchmark code generation and runtime: Annotation-based benchmarks Parameters and state Support for multi-threaded benchmarks Blackhole, compiler control etc… • Command line and API for running benchmarks • Built-in proflers
27. Benchmark Mode Cnt Score Error Units ListGetBenchmarkJMH.baseline avgt 200 0.282 ± 0.003 ns/op ListGetBenchmarkJMH.get avgt 200 3.985 ± 0.024 ns/op @BenchmarkMode(Mode.AverageTime) @OutputTimeUnit(TimeUnit.NANOSECONDS) @State(Scope.Benchmark) public class ListGetBenchmarkJMH { private List<Integer> list; private int index; @Setup public void setUp() { list = Arrays.asList(1, 2, 3, 4, 5, 6, 7, 8, 9, 10); index = 3; } @Benchmark public void baseline() { } @Benchmark public Integer get() { return list.get(index); } }
28. Proflers java -jar target/benchmarks.jar -lprof Supported profilers: cl: Classloader profiling via standard MBeans comp: JIT compiler profiling via standard MBeans gc: GC profiling via standard MBeans hs_cl: HotSpot (tm) classloader profiling via implementation-specific MBeans hs_comp: HotSpot (tm) JIT compiler profiling via implementation-specific MBeans hs_gc: HotSpot (tm) memory manager (GC) profiling via implementation-specific MBeans hs_rt: HotSpot (tm) runtime profiling via implementation-specific MBeans hs_thr: HotSpot (tm) threading subsystem via implementation-specific MBeans pauses: Pauses profiler perf: Linux perf Statistics perfasm: Linux perf + PrintAssembly Profiler perfnorm: Linux perf statistics, normalized by operation count safepoints: Safepoints profiler stack: Simple and naive Java stack profiler Unsupported profilers: xperfasm: <none>
29. public class JMHSample_36_BranchPrediction { @Benchmark @OperationsPerInvocation(COUNT) public void sorted(Blackhole bh1, Blackhole bh2) { for (byte v : sorted) { if (v > 0) { bh1.consume(v); } else { bh2.consume(v); } } } @Benchmark @OperationsPerInvocation(COUNT) public void unsorted(Blackhole bh1, Blackhole bh2) { for (byte v : unsorted) { if (v > 0) { bh1.consume(v); } else { bh2.consume(v); } } } }
30. sorted unsorted Unit 2.403 ± 0.008 7.007 ± 0.034 ns/op CPI 0.266 ± 0.005 0.770 ± 0.004 #/op L1-dcache-load-misses 0.016 ± 0.002 0.017 ± 0.003 #/op L1-dcache-loads 10.977 ± 0.263 11.033 ± 0.184 #/op L1-dcache-stores 4.997 ± 0.114 4.993 ± 0.043 #/op L1-icache-load-misses 0.001 ± 0.001 0.002 ± 0.004 #/op LLC-load-misses ≈ 10⁻⁵ ≈ 10⁻⁴ #/op LLC-loads 0.001 ± 0.001 0.001 ± 0.001 #/op LLC-store-misses ≈ 10⁻⁵ ≈ 10⁻⁵ #/op LLC-stores ≈ 10⁻⁴ ≈ 10⁻⁴ #/op branch-misses ≈ 10⁻⁴ 0.502 ± 0.015 #/op branches 6.474 ± 0.116 6.503 ± 0.084 #/op cycles 8.226 ± 0.163 23.881 ± 0.279 #/op dTLB-load-misses ≈ 10⁻⁵ ≈ 10⁻⁵ #/op dTLB-loads 11.007 ± 0.042 10.991 ± 0.128 #/op dTLB-store-misses ≈ 10⁻⁶ ≈ 10⁻⁵ #/op dTLB-stores 5.006 ± 0.029 4.994 ± 0.050 #/op iTLB-load-misses ≈ 10⁻⁵ ≈ 10⁻⁵ #/op
31. HashMap lookup @BenchmarkMode(Mode.AverageTime) @OutputTimeUnit(TimeUnit.NANOSECONDS) @State(Scope.Benchmark) public class LongKeyMap { private java.util.concurrent.ConcurrentHashMap<Long, Double> chm; private org.jctools.maps.NonBlockingHashMapLong<Double> nbhm; private long key; @Benchmark public Double get_ConcurrentHashMap() { return chm.get(key); } @Benchmark public Double get_NonBlockingHashMapLong() { return nbhm.get(key); } }
32. Benchmark 1.7.0_80 1.8.0_144 9+181 Eclipse OpenJ9 (J9VM - cea1ed7)* LongKeyMap.get_ConcurrentHashMap 11.112 ± 0.107 6.645 ± 0.055 6.685 ± 0.076 59.421 ± 0.999 LongKeyMap.get_NonBlockingHashMapLong 4.562 ± 0.016 4.597 ± 0.078 4.854 ± 0.058 7.747 ± 0.032 HashMap lookup * Using -Xgcpolicy:metronome (see https://github.com/eclipse/openj9/issues/42)
33. @BenchmarkMode(Mode.AverageTime) @OutputTimeUnit(TimeUnit.NANOSECONDS) @State(Scope.Benchmark) public class MapGet { @Benchmark public Integer HashMap_toLowerCase() { return hashMap.get(key.toLowerCase()); } @Benchmark public Integer TreeMap() { return treeMap.get(key); } @Benchmark public Integer IgnoreCaseMap() { Integer val = ignoreCaseMap.get(key); if (val == null) { val = ignoreCaseMap.get(key.toLowerCase()); if (val != null) { ignoreCaseMap.put(key, val); } } return val; } } HashMap lookup ignore-case
34. Benchmark 1.7.0_80 1.8.0_144 9+181 Unit MapGet.HashMap_toLowerCase 53.327 ± 0.516 51.948 ± 0.260 33.133 ± 0.232 ns/op MapGet.HashMap_toLowerCase: gc.alloc.rate 1049.153 ± 10.037 1076.685 ± 5.367 920.655 ± 6.411 MB/sec MapGet.HashMap_toLowerCase: gc.alloc.rate.norm 88.000 ± 0.001 88.000 ± 0.001 48.000 ± 0.001 B/op MapGet.TreeMap 76.531 ± 1.267 68.769 ± 0.645 95.223 ± 1.106 ns/op MapGet.TreeMap: gc.alloc.rate 0.001 ± 0.001 0.001 ± 0.001 0.001 ± 0.001 MB/sec MapGet.TreeMap: gc.alloc.rate.norm ≈ 10⁻⁴ ≈ 10⁻⁴ ≈ 10⁻⁴ B/op MapGet.IgnoreCaseMap 12.142 ± 0.387 10.688 ± 0.101 11.081 ± 0.174 ns/op MapGet.IgnoreCaseMap: gc.alloc.rate 0.001 ± 0.001 0.001 ± 0.001 0.001 ± 0.001 MB/sec MapGet.IgnoreCaseMap: gc.alloc.rate.norm ≈ 10⁻⁵ ≈ 10⁻⁵ ≈ 10⁻⁵ B/op HashMap lookup ignore-case JEP 254: Compact Strings
35. New vs refection public class CreateNewInstance { @Benchmark public Object find_constructor_allocate() throws Exception { Constructor<?> ctr = klass.getConstructor(Date.class, String.class); return ctr.newInstance(arg1, arg2); } @Benchmark public Object conctructor_allocate() throws Exception { return contructor.newInstance(arg1, arg2); } @Benchmark public Object new_allocate() throws Exception { return new C(arg1, arg2); } }
36. Benchmark 1.7.0_80 1.8.0_144 9+181 CreateNewInstance.find_constructor_allocate 404.127 ± 2.373 86.418 ± 0.360 53.048 ± 0.652 CreateNewInstance.conctructor_allocate 159.547 ± 0.825 18.163 ± 0.164 19.472 ± 0.204 CreateNewInstance.new_allocate 13.713 ± 0.043 12.565 ± 0.192 12.255 ± 0.024 New vs refection
37. JCStress
40. The Java Concurrency Stress tests (jcstress) is an experimental harness and a suite of tests to aid the research in the correctness of concurrency support in the JVM, class libraries, and hardware. http://openjdk.java.net/projects/code-tools/jcstress/
41. Getting started • Maven archetype: mvn archetype:generate \ -DinteractiveMode=false \ -DarchetypeGroupId=org.openjdk.jcstress \ -DarchetypeArtifactId=jcstress-java-test-archetype \ -DarchetypeVersion=0.4 \ -DgroupId=org.sample \ -DartifactId=jcstress-test \ -Dversion=1.0 • Or build from source: hg clone http://hg.openjdk.java.net/code-tools/jcstress/ jcstress • Java version: JDK 9 to build/JDK 8 to run
42. public interface Counter { int increment(); } public class BrokenCounter implements Counter { private int value; @Override public int increment() { return ++value; } } public class AtomicCounter implements Counter { private final AtomicInteger value = new AtomicInteger(); @Override public int increment() { return value.incrementAndGet(); } } Counter
43. Counter public class NaiveCounterTest { private static ExecutorService executor = Executors.newFixedThreadPool(2); private static void test(Counter counter) throws InterruptedException { CountDownLatch startGate = new CountDownLatch(3); CountDownLatch endGate = new CountDownLatch(2); for (int i = 0; i < 2; i++) { executor.submit(() -> { startGate.countDown(); startGate.await(); System.out.println(counter.increment()); endGate.countDown(); return null; }); } startGate.countDown(); endGate.await(); } public static void main(String[] args) throws InterruptedException { test(new BrokenCounter()); test(new AtomicCounter()); } } BrokenCounter 1 2 AtomicCounter 1 2
44. Counter import org.openjdk.jcstress.annotations.*; import org.openjdk.jcstress.infra.results.II_Result; import static org.openjdk.jcstress.annotations.Expect.*; @JCStressTest @Outcome(id = "1, 2", expect = ACCEPTABLE, desc = "actor1 incremented, then actor2.") @Outcome(id = "2, 1", expect = ACCEPTABLE, desc = "actor2 incremented, then actor1.") @Outcome(id = "1, 1", expect = ACCEPTABLE_INTERESTING, desc = "a race on increment") @State public class BrokenCounterTest { Counter counter = new BrokenCounter(); @Actor public void actor1(II_Result r) { r.r1 = counter.increment(); } @Actor public void actor2(II_Result r) { r.r2 = counter.increment(); } }
45. Counter import org.openjdk.jcstress.annotations.*; import org.openjdk.jcstress.infra.results.II_Result; import static org.openjdk.jcstress.annotations.Expect.*; @JCStressTest @Outcome(id = "1, 2", expect = ACCEPTABLE, desc = "actor1 incremented, then actor2.") @Outcome(id = "2, 1", expect = ACCEPTABLE, desc = "actor2 incremented, then actor1.") @Outcome(expect = FORBIDDEN, desc = "Other cases are forbidden.") @State public class AtomicCounterTest { Counter counter = new AtomicCounter(); @Actor public void actor1(II_Result r) { r.r1 = counter.increment(); } @Actor public void actor2(II_Result r) { r.r2 = counter.increment(); } }
46. Counter java -jar target/jcstress.jar -t BrokenCounterTest
47. Counter java -jar target/jcstress.jar -t AtomicCounterTest
48. JITWatch
49. Log analyser / visualiser for Java HotSpot JIT compiler. Inspect inlining decisions, hot methods, bytecode, and assembly. View results in the JavaFX user interface. https://github.com/AdoptOpenJDK/jitwatch
50. Getting started • Build from source: mvn clean compile test exec:java gradlew run • Java version: JDK 7+
51. How to get JIT output • Basic output -XX:+PrintCompilation • JIT log -XX:+UnlockDiagnosticVMOptions -XX:+LogCompilation -XX:LogFile=$LogFilePath • Get the assembly -XX:+PrintAssembly Requires the hsdis (HotSpot disassembler) binary to be added to your JRE. See https://github.com/AdoptOpenJDK/jitwatch/wiki/Building-hsdis
52. DEMO
53. Recap • JOL – toolbox to analyze object layout schemes in JVMs • JMH – Swiss army knife of benchmarking. Gives you powerful tools to write correct benchmarks and investigate performance problems • JCStress – harness for writing concurrency tests and a suit of such tests for JVM (JMM, core libraries, Hotspot, hardware) • JITWatch – log analyser and visualiser for the HotSpot JIT compiler
54. References • Code samples: https://github.com/vyazelenko/BaselOne2017 • JOL: http://openjdk.java.net/projects/code-tools/jol/ • JMH: http://openjdk.java.net/projects/code-tools/jmh/ • JCStress: http://openjdk.java.net/projects/code-tools/jcstress/ • JITWatch: https://github.com/AdoptOpenJDK/jitwatch • Collection of JMH resources by Nitsan Wakart (@nitsanw) • Aleksey Shipilëv’s (@shipilev) blog: shipilev.net/
55. Questions? @DVyazelenko
