  1. WebAssembly is a binary instruction format for a stack-based virtual

    machine [...] enabling deployment on the web for client and server applications.
  2. How does it look (module ;; Wasm is all about

    modules... (func $my_add_function (param $lhs i32) (param $rhs i32) (result i32) get_local $lhs get_local $rhs i32.add) (export "add" ;; ... that export things (func $my_add_function))) 0061736d 01000000 01070160 027f7f01 7f030201 00070701 03616464 00000a09 01070020 0020016a 0b
  3. // No <script type="wasm"> _yet_ const request = fetch("my-module.wasm"); const

    { instance, module } = await ( WebAssembly.instantiateStreaming(request) ); instance.exports.add(7, 4); // Boom How does it look (from JS)
  4. Use Case: Portability / Extend the Web "Alfred, I want

    a triple-shot americano with milk" Small Medium Large Single Shot Double Shot Triple Shot Americano Cappuccino Espresso Latte Mocha Milk Cream Picovoice
  5. Use Cases: there are more! Web-as-a-Platform: "Bring your C/C++ application

    to the Web" Polyglot Web "Bring your favourite language to the Web" Beyond the Web Node.js Serverless Blockchain/Cryptocurrencies
  6. Systems Programming Ring 3 Ring 2 Ring 1 Ring 0

    Kernel Device drivers Applications Device drivers Least privileged Most privileged Chrislb, CC BY-SA 3.0. Hertzsprung, CC BY-SA 3.0. Virtual Machines ‐ Ravi, Nair. SimonWaldherr, CC BY-SA 4.0
  7. Systems Programming for Everyone Ring 3 Ring 2 Ring 1

    Ring 0 Kernel Device drivers Applications Device drivers Least privileged Most privileged Expressiveness and Abstraction Safety and Reliability Tooling and Ecosystem Community and Resources Chrislb, CC BY-SA 3.0. Hertzsprung, CC BY-SA 3.0. Virtual Machines ‐ Ravi, Nair. SimonWaldherr, CC BY-SA 4.0
  8. Expressiveness and Abstraction #[derive(Deserialize)] struct IceCream { cone: String, #[serde(rename

    = "scoops")] scoop_flavors: Vec<String> } let data = r#"{"cone": "waffle", "scoops": ["vanilla", "lemon"]}"#; serde_json::from_str(data)? .scoop_flavors .iter() .for_each(|flavor| { println!("{}", &flavor); });
  9. Safety and Reliability let file = match File::open(file_path) { Ok(file)

    => file, Err(e) => return MyError::IOError }; let contents = match file.read_to_string() { Ok(text) => text, Err(e) => return MyError::EncodingError }; let pairs = vec![(0, 1), (2, 3), (4, 5)]; let first_pair = &pairs[0]; // Cannot move out of `pairs` because it is borrowed let map : HashMap<u32, u32> = pairs.into_iter().collect(); println!("First pair was {:?}", first_pair);
  10. Tooling and Ecosystem $ cargo new commitconf && cd commitconf

    Created binary (application) `commitconf` project $ echo 'lazy_static = "1.2.0"' >> Cargo.toml $ cargo run Updating crates.io index Compiling lazy_static v1.2.0 Compiling commitconf v0.1.0 Finished dev [unoptimized + debuginfo] target in 6.17s Running `target/debug/commitconf` Hello, world! $ cargo test # Run tests (with #[test] !!) $ cargo doc # Generate docs $ cargo fmt # Formatter / prettifier $ cargo clippy # Linter $ cargo build --target=aarch64-linux-android # X-compiling
  11. Community and Resources  Docs.rs Embedded Rust, Aaron Power, CC

    BY 4.0. rustwasm logo, MIT. Lucy, rust-artwork, CC BY 4.0
  12. pub fn add(x: usize, y: usize) -> usize { x

    + y } $ cargo build myWasmInstance.exports.add(2, 3); // 5! The Dream
  13. pub fn add(x: usize, y: usize) -> usize { x

    + y // Not quite } $ cargo build myWasmInstance.exports.add(2, 3); // 5! The Dream
  14. This is also part of our dream, right? // (In

    JS) typeof bid_farewell("Ferris") ? pub fn bid_farewell(name: String) -> String { format!("Farewell {}", &name) } // (In JS) typeof my_favourite_numbers() ??? pub fn my_favourite_numbers() -> Vec<u32> { vec![9, 42, 345234987629] } Complex Types
  15. Memory is the Polyfill var memory = new Uint8Array( myWasmInstance.exports.memory.buffer

    ); console.log( memory.slice(address, address + length) ); memory[address] = 0x42; Based on Lin Clark, CC BY-SA 3.0
  16. #[wasm_bindgen] pub fn add(x: usize, y: usize) -> usize {

    x + y } #[wasm_bindgen] pub fn bid_farewell(name: String) -> String { format!("Farewell {}", name) } #[wasm_bindgen] pub fn my_favourite_numbers() -> Vec<u32> { vec![9, 42, 345234987629] } wasm-bindgen to the rescue
  17. #[wasm_bindgen] pub fn add(x: usize, y: usize) -> usize {

    x + y } $ cargo build myWasmInstance.exports.add(2, 3); // 5! The Dream (take #2)
  18. #[wasm_bindgen] pub fn add(x: usize, y: usize) -> usize {

    x + y } $ cargo build # Not quite myWasmInstance.exports.add(2, 3); // 5! The Dream (take #2)
  19. #[wasm_bindgen] pub fn add(x: usize, y: usize) -> usize {

    x + y } $ wasm-pack build myWasmInstance.exports.add(2, 3); // 5! The Dream (final take)
  20. Getting started with wasm-pack use wasm_bindgen::prelude::*; cfg_if! { // When

    the `wee_alloc` feature is enabled, use `wee_alloc` as the global // allocator. if #[cfg(feature = "wee_alloc")] { extern crate wee_alloc; #[global_allocator] static ALLOC: wee_alloc::WeeAlloc = wee_alloc::WeeAlloc::INIT; } } #[wasm_bindgen] extern { fn alert(s: &str); } #[wasm_bindgen] pub fn greet() { alert("Hello, hello-world!"); } 00:00
  21. // webpack.config.js module.exports = { entry: "./index.js" }; // index.js

    import("./pkg") .then(m => m.greet()); <!-- index.html --> <body> <script src="./main.js"></script> </body> Hello World
  22. Parsing Exif Metadata }); } Ok(parsed_fields) } /// Attempts to

    parse a Tiff field value (it does not accept all Tiff value types) fn parse_exif_field_value(value: ExifValue) -> Option<String> { let parsed = match value { ExifValue::Ascii(slices) => slices .into_iter() .filter_map(|b| std::str::from_utf8(&b).ok()) .fold(String::new(), |mut acc, piece| { acc += piece; acc }), _ => return None, }; Some(parsed) } 00:00
  23. import pkg from "./pkg"; let reader = new FileReader(); reader.onload

    = e => { let data = new Uint8Array(e.target.result); pkg.get_exif(data, (tag, value) => { // ... }); }; reader.readAsArrayBuffer(file); Exif in Wasm
  24. What if I want to use my WebAssembly from Node.js?

    Or if I prefer not to use a bundler? [1] What happens if I try to open a file in Rust: File::open("...")? [2] What types does wasm-bindgen support? How are types converted to JS and viceversa? [3] What is wasm-bindgen polyfilling, i.e. how will Wasm evolve in the future? [4] [5] Are there other ways to target Wasm in Rust? [6] Frinkiac
  25. Further Reading The Rust and WebAssembly Book The wasm-bindgen Guide

    The section on web-sys The wasm-pack site and book The Rust and WebAssembly blog API documentation: wasm-bindgen, js-sys and web-sys The Rust documentation MadRust
