Caching With Apollo Android

Caching With Apollo Android

Adam McNeilly

January 24, 2021
Tweet

More Decks by Adam McNeilly

Other Decks in Programming

Transcript

  1. A cache is the storage of data that has been

    requested previously, so that we can serve it faster in the future. @AdamMc331 #ApolloDayMobile 3
  2. Why Do We Cache Data? 1. A faster page load

    leads to better user experience. @AdamMc331 #ApolloDayMobile 4
  3. Why Do We Cache Data? 1. A faster page load

    leads to better user experience. 2. Checking for data on device can save on networking resources. @AdamMc331 #ApolloDayMobile 4
  4. Apollo Has Two Types Of Caches 1. HTTP Cache 2.

    Normalized Cache @AdamMc331 #ApolloDayMobile 7
  5. HTTP Cache The HTTP cache is easier to set up

    but also has more limitations. 1 2 2 https://github.com/apollographql/apollo-android/blob/main/apollo-http-cache/src/main/java/com/ apollographql/apollo/cache/http/internal/DiskLruCache.java#L84 1 https://www.apollographql.com/docs/android/essentials/http-cache/ @AdamMc331 #ApolloDayMobile 8
  6. How It Works 1. The HTTP cache uses a file

    directory on the device. @AdamMc331 #ApolloDayMobile 9
  7. How It Works 1. The HTTP cache uses a file

    directory on the device. 2. With each request, we generate a unique key for the cache. @AdamMc331 #ApolloDayMobile 9
  8. How It Works 1. The HTTP cache uses a file

    directory on the device. 2. With each request, we generate a unique key for the cache. 3. We store the response of that request in the file directory, using that key as the file name. @AdamMc331 #ApolloDayMobile 9
  9. How It Works 1. The HTTP cache uses a file

    directory on the device. 2. With each request, we generate a unique key for the cache. 3. We store the response of that request in the file directory, using that key as the file name. 4. The next time we make that request, Apollo checks to see if there's a file with this cache key, and returns the response from that file if we do. @AdamMc331 #ApolloDayMobile 9
  10. Setup HTTP Cache 1. Create directory for cache. 2. Set

    maximum size for cache. @AdamMc331 #ApolloDayMobile 10
  11. Setup HTTP Cache 1. Create directory for cache. 2. Set

    maximum size for cache. 3. When the maximum size is reached, Apollo begins to remove the oldest entries. @AdamMc331 #ApolloDayMobile 10
  12. Setup HTTP Cache val file = File(applicationContext.cacheDir, "apolloCache") // 1

    MB = 1024 X 1024 X 1 val sizeInMegabytes = BYTES_PER_KILOBYTE * KILOBYTES_PER_MEGABYTE * 1 val cacheStore = DiskLruHttpCacheStore(file, sizeInMegabytes) val apolloCache = ApolloHttpCache(cacheStore) @AdamMc331 #ApolloDayMobile 11
  13. Setting Default Cache Policy val apolloClient = ApolloClient.builder() // ...

    .defaultHttpCachePolicy(HttpCachePolicy.CACHE_FIRST) .build() @AdamMc331 #ApolloDayMobile 14
  14. Setting Cache Policy Per Query val cacheFirstQuery = apolloClient .query(query)

    .toBuilder() .httpCachePolicy(HttpCachePolicy.CACHE_FIRST) .build() @AdamMc331 #ApolloDayMobile 15
  15. Invalidating HTTP Cache // Set expiration policy val oneHourPolicy =

    HttpCachePolicy.CACHE_FIRST.expireAfter(1, TimeUnit.HOURS) val removeAfterRead = HttpCachePolicy.CACHE_FIRST.expireAfterRead() // Clear manually apolloClient.clearHttpCache() @AdamMc331 #ApolloDayMobile 16
  16. What Are The Limitations? 1. If multiple operations request similar

    information, the HTTP cache will store it twice. @AdamMc331 #ApolloDayMobile 17
  17. What Are The Limitations? 1. If multiple operations request similar

    information, the HTTP cache will store it twice. 2. We cannot observe changes to the HTTP cache. @AdamMc331 #ApolloDayMobile 17
  18. What Are The Limitations? 1. If multiple operations request similar

    information, the HTTP cache will store it twice. 2. We cannot observe changes to the HTTP cache. 3. It does not work well with HTTP Post requests. @AdamMc331 #ApolloDayMobile 17
  19. Normalized Cache The normalized cache stores information by ID. This

    allows us to relate responses from different queries to each other. 3 3 https://www.apollographql.com/docs/android/essentials/normalized-cache/ @AdamMc331 #ApolloDayMobile 18
  20. Two Types Of Normalized Caches 1. In Memory 2. SQLite

    Database @AdamMc331 #ApolloDayMobile 19
  21. Creating In Memory Normalized Cache 1. Define eviction policy. 2.

    Create cache factory. @AdamMc331 #ApolloDayMobile 20
  22. Creating In Memory Normalized Cache val evictionPolicy = EvictionPolicy.builder() .maxSizeBytes(...)

    .expireAfterAccess(...) .expireAfterWrite(...) .maxEntries(...) .build() val cacheFactory = LruNormalizedCacheFactory(evictionPolicy) val apolloClient = ApolloClient.builder() .normalizedCache(cacheFactory) .build() @AdamMc331 #ApolloDayMobile 21
  23. Creating SQLite Normalized Cache val cacheFactory = SqlNormalizedCacheFactory(applicationContext, "apollo.db") val

    apolloClient = ApolloClient.builder() .normalizedCache(cacheFactory) .build() @AdamMc331 #ApolloDayMobile 22
  24. Chaining Normalized Caches // Pulling from memory is faster than

    reading from disk. // Chaining caches can give us the best of both approaches - // the speed of RAM while still persisting data. val inMemoryCache = ... val sqliteCache = ... val memoryThenSqliteCache = inMemoryCache.chain(sqliteCache) val apolloClient = ApolloClient.builder() .normalizedCache(memoryThenSqliteCache) .build() @AdamMc331 #ApolloDayMobile 23
  25. ApolloResponseFetchers 1. CACHE_ONLY 2. NETWORK_ONLY 3. CACHE_FIRST 4. NETWORK_FIRST 5.

    CACHE_AND_NETWORK 4 4 https://github.com/apollographql/apollo-android/blob/main/apollo-runtime/src/main/java/com/apollographql/ apollo/fetcher/ApolloResponseFetchers.java @AdamMc331 #ApolloDayMobile 24
  26. Setting Response Fetcher // Default for client val apolloClient =

    ApolloClient.builder() // ... .defaultResponseFetcher(ApolloResponseFetchers.CACHE_FIRST) .build() // Setting per call val cacheFirstQuery = apolloClient .query(query) .toBuilder() .responseFetcher(ApolloResponseFetchers.CACHE_FIRST) .build() @AdamMc331 #ApolloDayMobile 25
  27. Adding Logger To Apollo Client 5 val apolloClient = ApolloClient.builder()

    .logger(ApolloAndroidLogger()) .build() 5 https://github.com/apollographql/apollo-android/releases/tag/v2.5.2 @AdamMc331 #ApolloDayMobile 27
  28. Using Logcat To Verify Experience // App loads up. //

    This is expected. D/ApolloAndroidLogger: Cache MISS for operation CountryListQuery // We click on a country list item. // Was this miss expected? D/ApolloAndroidLogger: Cache MISS for operation CountryDetailQuery @AdamMc331 #ApolloDayMobile 28
  29. This Is Unexpected The country list screen requests the same

    information as the country detail screen. We would expect, using the normalized cache, that the detail screen would be able to find the information it needs. Let's try to find out why. @AdamMc331 #ApolloDayMobile 29
  30. Logcat Error E/ApolloAndroidLogger: Failed to read cache response CacheMissException: Missing

    value: country for Record(key='QUERY_ROOT', fields={...}, ...) According to Apollo, it was unable to find the record we wanted to display on the detail screen. Let's see if we can figure out why it wasn't there. @AdamMc331 #ApolloDayMobile 30
  31. Option 1: Print The Normalized Cache private fun printNormalizedCache() {

    val normalizedCacheDump = apolloClient.apolloStore.normalizedCache().dump() val formattedDump = NormalizedCache.prettifyDump(normalizedCacheDump) Log.d("ApolloNormalizedCache", formattedDump) } @AdamMc331 #ApolloDayMobile 31
  32. Option 1: Print The Normalized Cache D/ApolloNormalizedCache: OptimisticNormalizedCache {} LruNormalizedCache

    {} SqlNormalizedCache { // ... // The record is here! Let's search for Andorra elsewhere in the logs. "countries.0" : { "__typename" : Country "code" : AD "name" : Andorra // ... } // ... } @AdamMc331 #ApolloDayMobile 32
  33. Option 1: Print The Normalized Cache // We found the

    record! This is from the detail query response. "country({"code":"AD"})" : { "__typename" : Country "code" : AD "name" : Andorra "continent" : CacheRecordRef(country({"code":"AD"}).continent) "capital" : Andorra la Vella "emoji" : ! } @AdamMc331 #ApolloDayMobile 33
  34. Option 1: Print The Normalized Cache // Notice the different

    identifiers! "countries.0" : { // ... } "country({"code":"AD"})" : { // ... } @AdamMc331 #ApolloDayMobile 34
  35. Option 2: Database Inspector If you're using Android Studio, and

    using the SqlNormalizedCache, we can leverage the new database inspector. @AdamMc331 #ApolloDayMobile 36
  36. Why Was The Key Different? By default, Apollo uses the

    field path as the key. To change this, we can supply our own CacheKeyResolver. @AdamMc331 #ApolloDayMobile 39
  37. CacheKeyResolver val cacheKeyResolver = object : CacheKeyResolver() { override fun

    fromFieldArguments(...): CacheKey { // This is called when each query is run. We use this to // resolve query arguments to the key that we want to find. } override fun fromFieldRecordSet(...): CacheKey { // This is called when an operation returns. We use this // to resolve the response to the cache key we want // to save. } } @AdamMc331 #ApolloDayMobile 40
  38. Mapping Object IDs To Key override fun fromFieldRecordSet( field: ResponseField,

    recordSet: Map<String, Any> ): CacheKey { val codeProperty = recordSet["code"] as String val typePrefix = recordSet["__typename"] as String return CacheKey.from("$typePrefix.$codeProperty") } @AdamMc331 #ApolloDayMobile 42
  39. Mapping Arguments To Key override fun fromFieldArguments( field: ResponseField, variables:

    Operation.Variables ): CacheKey { // When we are querying for a country, let's create the CacheKey to // see if that country exists already. return if (field.fieldName == "country") { val codeProperty = field.resolveArgument("code", variables) as String val fullId = "Country.$codeProperty" CacheKey.from(fullId) } else { CacheKey.NO_KEY } } @AdamMc331 #ApolloDayMobile 44
  40. Let's Run The App! // When we load the app.

    // This miss is expected. D/ApolloAndroidLogger: Cache MISS for operation CountryListQuery // When we clicked on an item, we hit the cache! D/ApolloAndroidLogger: Cache HIT for operation CountryDetailQuery @AdamMc331 #ApolloDayMobile 45
  41. Important! This will only work if the detail screen is

    requesting the same, or fewer, fields as the main screen. If the cache doesn't have the properties we need, this will go to the network. @AdamMc331 #ApolloDayMobile 46
  42. Responding To Cache Changes We can leverage the coroutine or

    RxJava adapters to any queries that might interract with the cache, to be notified if our data changes: apolloClient .query(query) .toFlow() .collect { response -> // Handle response. } @AdamMc331 #ApolloDayMobile 47
  43. Pulling From Cache And Network This is really helpful when

    paired with the ApolloResponseFetcher.CACHE_AND_NETWORK. It will emit what was in the cache, and the response from the network. apolloClient .query(query) .toBuilder() .responseFetcher(ApolloResponseFetchers.CACHE_AND_NETWORK) .build() .toFlow() .collect { response -> // Will emit twice. } @AdamMc331 #ApolloDayMobile 48
