Everything is better with(out) Bluetooth - Droidcon 2018

Presentation at Droidcon 2018 by Ronaldo Pace and Falko Richter
Everything is better with(out) Bluetooth
Tells the story of struggle to connect to a bluetooth GATT peripheral, discover services, write a message and disconnect under 1 second.

Ronaldo Pace

October 22, 2021
Tweet

Transcript

  1. Everything is better with(out) Bluetooth This presentation is available at

    https://docs.google.com/presentation/d/1RSiDRvHHmfHxmKAp_fOvvw_QdODc5jTjBQDlfm_2hGY/
  2. About us Falko • Full stack tinkerer • Cargo Bike

    Pimper • Chief (technical) Product Manager at SensorbergAndroid/iOS dev • about.me/falkorichter @volkersfreunde Ronaldo • Android Dev • Raspberry Pi enthusiast • Expert Diaper changer • github.com/budius | @ronaldopace
  3. Project Overview • Sensorberg ◦ Smart Spaces — where people

    and buildings interact ◦ Getting into a space is the first interaction ◦ Of course with your phone! ◦ Bluetooth LE really is the only common denominator for a reliable connection ▪ offline capable, fast, reliable* • Interactions currently: ◦ book a meeting room ◦ open a locker ◦ open the entrance ◦ open a garage * let´s talk later about reliablity
  4. Project Overview • Device needed which has BLE, internet &

    can open door hardware ◦ Pi compute Module Platform ◦ Custom board 100% made in Berlin ◦ All based on open source software & hardware
  5. BLE - what you should know • GATT (The Generic

    Attributes (GATT) define a hierarchical data structure that is exposed to connected Bluetooth Low Energy (LE) devices) ◦ Service ▪ Group of Characteristics ◦ Characteristic ▪ Write/ Read /Subscribe ▪ has a UUID • Descriptions availble on bluetooth.com ◦ https://www.bluetooth.com/specifications/gatt ◦ you can also make up your own!
  6. Project Overview - universal bluetooth communication UART/Serial Port Emulation over

    BLE • open source / standard by nordic • https://learn.adafruit.com/introducing-adafruit-bl e-bluetooth-low-energy-friend/uart-service ◦ find (by Service) ◦ connect ◦ discover ◦ subscribe to Rx ◦ write to Tx Request ◦ wait for answer on Rx Response ◦ disconnect https://infocenter.nordicsemi.com/index.jsp?topic=%2Fcom.nordic.infocenter.sdk5.v14.0.0%2Fble_sdk_app_nus_eval. html
  7. Challenge Open a door/locker/garage as fast as possible ~ 0.5

    million bluetooth connects (both platforms) add up to a lot of (potentially wasted) lifetime
  8. How to Bluetooth-LE Scan private val bleScanner = BluetoothAdapter.getDefaultAdapter().bluetoothLeScanner override

    fun onStart() { super.onStart() bleScanner.startScan(callback) // optional scan filters and scan settings } override fun onStop() { bleScanner.stopScan(callback) super.onStop() } private val callback = object : ScanCallback() { override fun onScanResult(callbackType: Int, result: ScanResult) { Log.d("MyApp", "onScanResult: $result. rssi: ${result.rssi} dB") } }
  9. How to Bluetooth-LE GATT communication if (isRightDevice(result)) result.device.connectGatt(context, false, gattCallback)

    private val gattCallback = object : BluetoothGattCallback() { override fun onConnectionStateChange(gatt: BluetoothGatt, status: Int, newState: Int) { if (isConnected(status, newState)) gatt.discoverServices() else gatt.close() } override fun onServicesDiscovered(gatt: BluetoothGatt, status: Int) { val gattCharacteristic = gatt.getService(serviceUuid).getCharacteristic(characteristicWrite) gattCharacteristic.value = "open door" gatt.writeCharacteristic(gattCharacteristic) } override fun onCharacteristicWrite(gatt: BluetoothGatt, characteristic: BluetoothGattCharacteristic, status: Int) { val gattCharacteristic = gatt.getService(serviceUuid).getCharacteristic(characteristicRead) gatt.readCharacteristic(gattCharacteristic) } override fun onCharacteristicRead(gatt: BluetoothGatt, characteristic: BluetoothGattCharacteristic, status: Int) { if(characteristic.value == "door opened") { /* success !!! */ } gatt.disconnect() } }
  10. Everything is better with(out) Bluetooth … scanning • BluetoothAdapter.getDefaultAdapter().startLeScan(scanCallbackV18) •

    Some devices doesn’t support certain scan settings parameters • Some devices doesn’t support scan filters ◦ Some devices say they support scan filters, but result on callback never called • Workaround: ◦ Use Nordic Scanner compat https://github.com/NordicSemiconductor/Android-Scanner-Compat-Library ◦ // disable hardware filtering .setUseHardwareFilteringIfSupported(false)
  11. Everything is better with(out) Bluetooth … scan callback • override

    fun onScanResult(callbackType: Int, result: ScanResult) { • On some devices is called for every scan • on others, only on the first time a BLE device is scanned • Workaround is to startScan/stopScan every second • Starting on Android Nougat Developer Preview 4 > We’ve changed the BLE Scanning behavior starting in DP4. We’ll prevent applications from starting and stopping scans more than 5 times in 30 seconds. For long running scans, we’ll convert them into opportunistic scans. ◦ Sources: ▪ https://web.archive.org/web/20160820074825/https://developer.android.com/preview/support.html#dp4 ▪ https://android-review.googlesource.com/c/platform/packages/apps/Bluetooth/+/215844/15/src/com/android/bluet ooth/gatt/AppScanStats.java#144
  12. Everything is better with(out) Bluetooth … scan callback • override

    fun onScanFailed(errorCode: Int) { // SCAN_FAILED_APPLICATION_REGISTRATION_FAILED // SCAN_FAILED_INTERNAL_ERROR } • Workaround:
  13. Everything is better with(out) Bluetooth … scan callback • private

    val scanCallback = object : ScanCallback() { override fun onScanResult(callbackType: Int, result: ScanResult) { scanResults[result.device.address] = result private fun openClosest() { val scanList = scanResults.values.filter { it.rssi >= threshold }.sortedBy { it.rssi } open(scanList[0]) } • rssi variance ◦ time dependent weighted moving average https://github.com/sensorberg-dev/motionless-average • on device learning of threshold variance ◦ start with a permissive default ◦ adjust with a moving average of the rssi during successful connection ◦ offset a few decibels for actual filtering
  14. Everything is better with(out) Bluetooth … GATT communication • `result.device.connectGatt(...)`

    only works if called from UI-thread ◦ on some devices • override fun onConnectionStateChange(gatt: BluetoothGatt, status: Int, newState: Int) { if (newState != BluetoothGatt.STATE_CONNECTED) // connect again • override fun onCharacteristicWrite(gatt: BluetoothGatt, characteristic: BluetoothGattCharacteristic, status: Int) { override fun onCharacteristicRead(gatt: BluetoothGatt, characteristic: BluetoothGattCharacteristic, status: Int) { ◦ if(status != GATT_SUCCESS) // retry ◦ if (status == 133) ▪ Source code: #define GATT_ERROR 0x0085
  15. Everything is better with(out) Bluetooth … GATT communication • Asynchronous

    callback based API connect discover subscribe write (x N) await Thread { SynchronousGatt(scanResult.device).apply { connectGatt(this@MainActivity, false, 10000) discoverServices(3000) val notify = bluetoothGatt.getService(serviceUuid) .getCharacteristic(characteristicRead).getDescriptor(descriptorNotify) notify.value = enableNotify writeDescriptor(notify, 3000) val writeCharacteristic = bluetoothGatt .getService(serviceUuid).getCharacteristic(characteristicWrite) writeCharacteristic.setValue("open door") writeCharacteristic(writeCharacteristic, 3000) val changed = awaitCharacteristicChange(5000) if (changed.characteristic.getStringValue(0) == "door opened") sucess() disconnect(1000) } }.start()
  16. Everything is better with(out) Bluetooth … after much hacking •

    Scanning: ◦ NordicScannerCompat ◦ ScannerStartStop ◦ ScannerNougat ◦ Averaging algorithms ◦ Did you try turn off and on again? • Communicating: ◦ Synchronous API ◦ Retry on random fail ◦ Retry on random disconnection ◦ Did you try turn off and on again?
  17. Data ~⅓ time is wasted trying to find the right

    device Google is the best manufacturer (74% of access requests under 2.5s) manufacturers ordered by average opening time at least 2 users
  18. Data • Firebase is not enough ◦ not realtime ◦

    no filtering ◦ aggregations are to limited • Elasticsearch to the rescue ◦ account: 2 minutes https://www.elastic.co/cloud/elasticsearch-service/signup ◦ post JSON to your [...].aws.cloud.es.io:9243/{index}/mobile_statistics ◦ simple rules for data integrity ▪ never change a type (String becomes Number, String becomes Object) ▪ lower case all strings / remove spaces ▪ add UUIDs/hashes so you can count devices / users ▪ one index per deployment (production / staging) ◦ leave out personal data ◦ delete indexes (buckets) regularly @POST("/") @Headers("Content-Type: application/json") Call<String> pushStatistics(@Body Stats stats);
  19. Data • hack some visualizations in Kibana • combine visualizations

    to powerful interactive dashboards • metrics to find fragmented devices: ◦ BuildConfig.VERSION_CODE ◦ BuildConfig.VERSION_NAME ◦ BuildConfig.APPLICATION_ID ◦ Build.VERSION.SDK_INT ◦ Build.MODEL ◦ Build.MANUFACTURER
  20. • Hybrid detection and communication ◦ Detection ▪ Bluetooth (“This

    BTLE device is so close, I should connect to it”) ▪ NFC (nfc://connect/to/DF:96:C3:46:84:3A) ▪ Optical?! ▪ (magnetic) tap detection ◦ communication (try all, winner takes it all) ▪ Bluetooth ▪ HTTPS via wifi/cellular ▪ NFC (in the next generation of the hardware) ▪ synchronize with a request ID in backend or on access hub … how to avoid bluetooth
  21. Testing • LEGO train #ftw ◦ get the (not sold

    anymore) powered tracks (no battery) ◦ use two power modules for reliability - it will make the train go reliably slow! ▪ Schwerlastzug 60098 is great • You need to physically test it! ◦ real devices ◦ actual Bluetooth hardware ◦ use your statistics to verify the performance ◦ Long term testing • Parameters ◦ speed ◦ distance to device ◦ additional sensor to detect phone position ◦ power the train from the access hub => full control
  22. Thx & Sensorberg Open Source: • https://github.com/sensorberg-dev/permission-bitte • https://github.com/sensorberg-dev/motionless-average •

    https://github.com/sensorberg-dev/EasyIPC • https://github.com/sensorberg-dev/gradle-scripts • https://github.com/sensorberg-dev/android-sdk • soon: https://github.com/sensorberg-dev/synchronous-gatt We will of course make an SDK from this as well https://www.youtube.com/watch?v=rLuBxsLot5U Another Bluetooth related GDG talkby Falko https://www.youtube.com/watch?v=OSJ8gIPnvDw
