GoGetCommunity - Continuous profiling Go application

I use profiles to better describe post mortems, to enrich observability and monitoring signals with concrete information from the binary itself. They are the perfect bridge between ops and developers when somebody reaches out to me asking why this application eats all that memory I can translate that to a function that I can check out in my editor. I find myself looking for outages that happened in the past because cloud providers and Kubernetes increased my resiliency budget the application gets restarted when it reaches a certain threshold and the system keeps running, but that leak is still a problem that as to be fixed. Having profiles well organized and easy to retrieve is a valuable source of information and you never know when you will need them. That's why continuous profiling is important today more than ever. I use Profefe to collect and store profiles from all my applications continuously. It is an open-source project that exposes a friendly API and an interface to concrete storage of your preference like badger, S3, Minio, and counting. I will describe to you how to project works, how I use it with Kubernetes, and how I analyze the collected profiles.

Gianluca Arbezzano

May 21, 2020
Tweet

More Decks by Gianluca Arbezzano

Other Decks in Programming

Transcript

  1. $ go tool pprof http://localhost:14271/debug/pprof/allocs?debug=1 Fetching profile over HTTP from

    http://localhost:14271/debug/pprof/allocs?debug=1 Saved profile in /home/gianarb/pprof/pprof.alloc_objects.alloc_space.inuse_objects.inuse_space.001.pb.gz Type: inuse_space Entering interactive mode (type "help" for commands, "o" for options) (pprof) text Showing nodes accounting for 1056.92kB, 100% of 1056.92kB total Showing top 10 nodes out of 21 flat flat% sum% cum cum% 544.67kB 51.53% 51.53% 544.67kB 51.53% github.com/jaegertracing/jaeger/vendor/google.golang.org/grpc/internal/transport.newBufWriter 512.25kB 48.47% 100% 512.25kB 48.47% time.startTimer 0 0% 100% 512.25kB 48.47% github.com/jaegertracing/jaeger/cmd/agent/app/processors.(*ThriftProcessor).processBuffer 0 0% 100% 512.25kB 48.47% github.com/jaegertracing/jaeger/cmd/agent/app/processors.NewThriftProcessor.func2 0 0% 100% 512.25kB 48.47% github.com/jaegertracing/jaeger/cmd/agent/app/reporter.(*MetricsReporter).EmitBatch 0 0% 100% 512.25kB 48.47% github.com/jaegertracing/jaeger/cmd/agent/app/reporter/grpc.(*Reporter).EmitBatch 0 0% 100% 512.25kB 48.47% github.com/jaegertracing/jaeger/cmd/agent/app/reporter/grpc.(*Reporter).send 0 0% 100% 512.25kB 48.47% github.com/jaegertracing/jaeger/proto-gen/api_v2.(*collectorServiceClient).PostSpans 0 0% 100% 512.25kB 48.47% github.com/jaegertracing/jaeger/thrift-gen/jaeger.(*AgentProcessor).Process 0 0% 100% 512.25kB 48.47% github.com/jaegertracing/jaeger/thrift-gen/jaeger.(*agentProcessorEmitBatch).Process
  2. About Me
 Gianluca Arbezzano • Work for Packet, Sr. Staff

    Software Engineer • www.gianarb.it / @gianarb What I like: • I make dirty hacks that look awesome • I grow my vegetables • Travel for fun and work
  3. The common why is by bothering who
 better knows

    where the applications run,
 their IP and ask for them …
  4. It is not a SWE’s fault. They do not have

    a good way
 to retrieve what they need
 to be effective at their work.
  5. Let’s summarize issues • Developer are usually the profile stakeholder

    • Production is not always a comfortable place to interact with • You do not know when you will need a profile, it can be from 2 weeks ago • Cloud and Kubernetes increased the amount of noise. A lot more binaries,
 they go up and down continuously. Containers that OOMs gets restarted transparency, there is a lot of postmortem analysis going on
  6. • Too many applications to re-instrument with the sdk •

    Our services already expose pprof http handler by default The pull based solution was easier to implement for us:
  7. • Retrieve list of candidates (pods, EC2, containers) and their

    IP • Filter them if needed (scalability via partitioning): you can use labels for this purpose. • Override or configure the gathering as needed (override pprof port, or path or add more labels to the profile as the go runtime version) Requirements
  8. Cool things: Merge profile go tool pprof 'http://repo.pprof.cluster.local:10100/api/0/profiles/merge? service=auth&type=cpu&from=2019-05-30T11:49:00&to=2019-05-30T12:49:00&labels=version=1.0.0' Fetching

    profile over HTTP from http://localhost:10100/api/0/profiles... Type: cpu Entering interactive mode (type "help" for commands, "o" for options) (pprof) top Showing nodes accounting for 43080ms, 99.15% of 43450ms total Dropped 53 nodes (cum <= 217.25ms) Showing top 10 nodes out of 12 flat flat% sum% cum cum% 42220ms 97.17% 97.17% 42220ms 97.17% main.load 860ms 1.98% 99.15% 860ms 1.98% runtime.nanotime 0 0% 99.15% 21050ms 48.45% main.bar 0 0% 99.15% 21170ms 48.72% main.baz
  9. Analyze pprof Profiles • Easy correlation with other metrics such

    as mem/cpu usage • All those profiles contains useful information • Cross service utilization for performance optimization • Give me the top 10 cpu intensive function in all system • Building bridges between dev and ops
