System Hardening Using Ansible

Akash Mahajan
November 16, 2016

System Hardening Using Ansible

Ansible offers a flexible approach to building a SecOps pipeline. System hardening can become just another software project. Using it we can do secure application deployment, configuration management and continuous monitoring. Security can be codified & attack surfaces reduced by using Ansible.

Akash Mahajan

November 16, 2016
Tweet

More Decks by Akash Mahajan

Other Decks in Technology

Transcript

  1. 1 Akash Mahajan Founder/Director at Appsecco ALLDAYDEVOPS 2016 SYSTEM HARDENING

    USING ANSIBLE (APPLICATION DEPLOYMENT + CONFIGURATION MANAGEMENT + CONTINUOUS SECURITY)
  2. OWASP TOP 10 - A5 SECURITY MISCONFIGURATION http://cheezburger.com/4834698752 https://www.owasp.org/index.php/Top_10_2013-A5-Security_Misconfiguration AM

    I VULNERABLE TO ‘SECURITY MISCONFIGURATION’? Is any of your software out of date? Are there any un-necessary features enabled/installed? Ports, Services, Accounts, Pages, Privileges Are default accounts and their passwords enabled/ unchanged? Are security settings and libraries not set to secure values?
  3. OWASP TOP 10 - A5 SECURITY MISCONFIGURATION https://www.owasp.org/index.php/Top_10_2013-A5-Security_Misconfiguration EXAMPLE ATTACK

    SCENARIOS Attacker discovers the standard admin pages are on your server, logs in with default passwords, and takes over. Attacker finds due to directory listing and downloads all your compiled Java classes, which she decompiles and reverse engineers to get all your custom code. She then finds a serious access control flaw in your application. App server configuration allows stack traces to be returned to users, potentially exposing underlying flaws. Attackers love the extra information error messages provide. https://twitter.com/SwiftOnSecurity/status/793976943276265472
  4. OWASP TOP 10 - A5 SECURITY MISCONFIGURATION https://www.owasp.org/index.php/Top_10_2013-A5-Security_Misconfiguration PREVENTING SECURITY

    MISCONFIGURATION A repeatable hardening process that makes it fast and easy to deploy a properly locked down environment Dev/QA/Prod should be configured identically but with different passwords used This process should be automated to minimise the effort required to setup a new secure environment. A process for deploying all new software updates and patches in a timely manner to each deployed environment Consider running scans and doing audits periodically to help detect future misconfigurations or missing patches. http://www.failking.com/41473-security-fail.html
  5. OUR SECURITY REQUIREMENTS DERIVED (0/5) A repeatable hardening process Dev/QA/Prod

    should be configured identically but with different passwords used This process should be automated to minimise the effort required to setup a new secure environment. A process for deploying all new software updates and patches in a timely manner to each deployed environment Consider running scans and doing audits periodically to help detect future misconfigurations or missing patches Basically taken from https://www.owasp.org/index.php/Top_10_2013-A5-Security_Misconfiguration
  6. Deploying software once may not be rocket science, but doing

    that repeatedly eliminating human error is Satellite deploying solar panels - From Wikipedia
  7. HOW DO WE DEPLOY SOFTWARE, APPS & CODE? CUSTOM BASH

    SCRIPTS CUSTOM PROGRAMS PROVISIONING TOOLS ➤ rsync ➤ ssh/scp ➤ FTP ➤ curl/wget Many others as well
  8. PROS AND CONS OF THE APPROACHES CUSTOM BASH SCRIPTS CUSTOM

    PROGRAMS PROVISIONING TOOLS ➤ GUI tools discourage automation ➤ For folks like me custom scripts are inherently difficult to ➤ maintain, ➤ track ➤ reuse ➤ Great for programmers and devs ➤ As custom as it can get ➤ Non-programmers find it difficult ➤ Overhead of a programming language and syntax ➤ Meant for provisioning and deploying code, software & applications ➤ Automation is a primary objective ➤ Allows for repeatability in deployment ➤ Reduces human errors
  9. WHAT IS SECURITY HARDENING? Security hardening is the process where

    we identify insecure default configuration present on a system and apply changes that will change the configuration to secure values. The process can be applied to all the layers Network - Enable firewall/security groups with restrictive rule sets Transport - Enable TCP wrappers for a service/subnet matching Application - Enable web server to allow specific IPs to admin panel Kernel Networking parameters - Enable defences for the networking stack
  10. WHY USE ANSIBLE FOR SECURITY HARDENING? ➤ playbook by Nick

    Bluth from the Noun Project ➤ github stargazers, ansible search results ANSIBLE IS MADE FOR SECURITY AUTOMATION Attribute Benefit YAML language Provides a structured way to define applications, systems Modular Makes it deployment friendly Enables Automation Makes it easy to script, program Uses SSH for access Secure by default with encrypted transmission and host authentication Python FOSS Easy to integrate and get started Community Driven Lots of helpful samples and documentation available
  11. ANSIBLE PLAYBOOK + IDEMPOTENT == WIN Ansible uses playbooks to

    execute a series of commands/modules on the target An Ansible playbook is written in YAML which makes it machine readable and provides structure Ansible follows the concept of idempotent, which translates into describing the state that we would like the system to be in All we need to do is express our security assertions in the YAML format in a playbook and we get a codified security document ANSIBLE PLAYBOOK CAN BE A CODIFIED SECURITY DOCUMENT
  12. ANSIBLE PLAYBOOK SNIPPET - MYSQL HARDENING 1. Delete anonymous MySQL

    user 2. Change MySQL root user password 3. Remove test database 1 2 3
  13. The concept that change commands should only be applied when

    they need to be applied, and that it is better to describe the desired state of a system than the process of how to get to that state THE CONCEPT OF IDEMPOTENCY OUR JOB IS NOW TO ENSURE THAT WE NEED TO DEFINE WHAT CONSTITUTES A SECURE AND HARDENED SYSTEM http://docs.ansible.com/ansible/glossary.html#term-idempotency
  14. All playbooks are written in YAML providing us with structure

    that we can learn and train on Since playbooks are text files, we can use Git to do version control on them By using Git or another version control software, managing the playbooks is just like managing any software project. Therefore infrastructure as code but for security STRUCTURED MANUALS (PLAYBOOKS) + GIT == WIN help by Viktor Vorobyev from the Noun Project repository by Nick Bluth from the Noun Project secure document by Creative Stall from the Noun Project VARIABLES ALLOW FOR CREATING GENERIC INSTRUCTION MANUALS
  15. OUR SECURITY REQUIREMENTS DERIVED (2/5) A repeatable hardening process Dev/QA/Prod

    should be configured identically but with different passwords used This process should be automated to minimise the effort required to setup a new secure environment. A process for deploying all new software updates and patches in a timely manner to each deployed environment Consider running scans and doing audits periodically to help detect future misconfigurations or missing patches Basically taken from https://www.owasp.org/index.php/Top_10_2013-A5-Security_Misconfiguration
  16. Various organisations publish best practices CIS Benchmarks DISA-STIG NIST Guidelines

    Linux Distribution specific guidelines Application security specific guidelines HOW DO WE CREATE SECURITY BEST PRACTICES? YOU DON’T NEED TO, BEST PRACTICES HAVE ALREADY BEEN CREATED Dahi Handi by Ramnath Bhat under CC2.0 license https://www.flickr.com/photos/ramnath1971/7943196628
  17. Ansible Roles are the moving parts of a playbook Roles

    are how we should be organising a playbook Grouping content by roles allows easy sharing of roles with other users By using roles_path configuration variable, roles can be downloaded from git, Ansible Galaxy and stored in one location, to use with multiple playbooks ANSIBLE PLAYBOOK IS MADE UP OF ROLES ROLES CAN EASILY BE ADDED TO A PLAYBOOK FOR MAXIMUM FLEXIBILITY
  18. Notable projects to get started with, right now Hardening Framework

    - Server Hardening Framework Ansible role for DISA STIG OpenStack-Ansible - Host Security Hardening CIS Ansible Role against CentOS/RHEL Linux Security Hardening with OpenSCAP and Ansible First Five Minutes on a Server with Ansible WHERE DO WE FIND REFERENCE ANSIBLE PLAYBOOKS GREAT NEWS IS THAT THERE ARE MANY HARDENING PROJECTS ALREADY Dahi Handi by Ramnath Bhat under CC2.0 license https://www.flickr.com/photos/ramnath1971/7943196628
  19. ANSIBLE GALAXY IS LIKE GITHUB BUT FOR ROLES GALAXY IS

    NOW OSS, SO THAT YOU CAN SETUP PRIVATE GALAXY SERVERS $ ansible-galaxy \ search hardening $ ansible-galaxy \ install username.rolename Galaxy is an online tool to manage Ansible roles Using the CLI client, roles can be searched for and installed with just one command Galaxy is like the central repository information for roles Galaxy offers automated testing of roles as well
  20. OUR SECURITY REQUIREMENTS DERIVED (3/5) A repeatable hardening process Dev/QA/Prod

    should be configured identically but with different passwords used This process should be automated to minimise the effort required to setup a new secure environment. A process for deploying all new software updates and patches in a timely manner to each deployed environment Consider running scans and doing audits periodically to help detect future misconfigurations or missing patches Basically taken from https://www.owasp.org/index.php/Top_10_2013-A5-Security_Misconfiguration
  21. CONTINUOUS MONITORING FOR SECURITY ANSIBLE CAN BECOME PART OF YOUR

    CI/CD WORKFLOW Integrate with your favourite CI/CD tool Schedule regular runs against the targets as specified Get information on when your run (build) failed and why Get granular control to secure credentials and secrets and get Role Based Access Control (RBAC) as well Jenkins logo from https://jenkins.io/ Go.cd logo from https://go.cd Ansible Tower logo from https://ansible.com Rundeck logo from https://xebialabs.com
  22. OUR SECURITY REQUIREMENTS DERIVED (5/5) A repeatable hardening process Dev/QA/Prod

    should be configured identically but with different passwords used This process should be automated to minimise the effort required to setup a new secure environment. A process for deploying all new software updates and patches in a timely manner to each deployed environment Consider running scans and doing audits periodically to help detect future misconfigurations or missing patches Basically taken from https://www.owasp.org/index.php/Top_10_2013-A5-Security_Misconfiguration
  23. TAKEAWAYS AND CONCLUSION 1. Using Ansible (and others) we can

    build a security automation workflow 2. Since the security part is codified in documents, we can do version control 3. A lot of work has already been done in finding out the best practices 4. For Ansible, using the above mentioned best practices, there are already multitude of playbooks and roles available on github and Ansible Galaxy 5. Using CI/CD tools like Jenkins/Go.cd or specialised software like Ansible Tower/ Rundeck we can repeatedly schedule Ansible playbooks and monitor their outcome
  24. BONUS TAKEAWAY - FREE EBOOK https://github.com/appsecco/alldaydevops-shua Ebook in PDF/Mobi/Epub format

    Will keep it updated and add more integrations Available with the presentation and other materials at the above mentioned github repo
