The Giving Tree

DOM Talk given at EmpireJS 2015

Transcript

1. The Giving Tree @markwunsch
3. The Ash Yggdrasil Friedrich Wilhelm Heine, 1886
4. Document Object Model
5. Document Object Model (DOM) Level 1 Specification http://www.w3.org/TR/REC-DOM-Level-1/ In the DOM, documents have a logical structure which is very much like a tree; to be more precise, it is like a “forest” or “grove”, which can contain more than one tree. However, the DOM does not specify that documents must be implemented as a tree or a grove, nor does it specify how the relationships among objects be implemented.
6. What the Document Object Model is not • “…it does not implement all of ‘Dynamic HTML’.” • “The Document Object Model is not a binary specification.” • “The Document Object Model is not a way of persisting objects to XML or HTML.” • “The Document Object Model is not a set of data structures, it is an object model that specifies interfaces.” • “The Document Object Model does not define ‘the true inner semantics’ of XML or HTML.” • “The Document Object Model…is not a competitor to the Component Object Model (COM).”
7. $
8. Closer to the METAL
9. window.document
10. TreeWalker
11. document.createTreeWalker()
12. createTreeWalker(root, whatToShow, filter) root, whatToShow, filter
13. Document Object Model (DOM) Level 2 Traversal and Range Specification http://www.w3.org/TR/DOM-Level-2-Traversal-Range/ TreeWalker objects are used to navigate a document tree or subtree using the view of the document defined by their whatToShow flags and filter (if any).
14. depth first pre-order
15. HEADER HGROUP H2 H1 SECTION FOOTER DIV BODY 1 2 3 4 5 6 7 8
16. var walker = document.createTreeWalker( document.body, NodeFilter.SHOW_ELEMENT, function (n) { return NodeFilter.FILTER_ACCEPT; }); do { doSomething(walker.currentNode); } while (walker.nextNode());
17. function getLegitTextNodes(el, f) { var blacklist = [‘SCRIPT’,‘OPTION’,‘TEXTAREA’], filter = function (node) { var parentName = node.parentElement.nodeName.toUpperCase(); if (blacklist.indexOf(parentName) >= 0) { return NodeFilter.FILTER_REJECT; } if (!node.NodeValue.trim().length) { return NodeFilter.FILTER_SKIP; } return NodeFilter.FILTER_ACCEPT; }, walker = document.createTreeWalker( el, NodeFilter.SHOW_TEXT, filter); while(walker.nextNode()) f(walker.currentNode); } https://gist.github.com/mwunsch/4710561
18. console.log("digraph El {"); do { var parentEl = walker.currentNode.parentElement; if (parentEl) { console.log(“\t\""+ vizLabel(parentEl)+”\"->\""+ vizLabel(walker.currentNode)+ "\";"); } else { console.log(“\t\""+ vizLabel(walker.currentNode)+ "\";"); } } while (walker.nextNode()); console.log("}"); https://gist.github.com/mwunsch/6b538a0352cae834457a
19. $ phantomjs viz.js http://2015.empirejs.org/ | dot -Tpng empire.png https://gist.github.com/mwunsch/6b538a0352cae834457a
20. https://gist.github.com/mwunsch/6b538a0352cae834457a
21. DocumentFragment
22. document.createDocumentFragment()
23. DocumentFragment is a “lightweight” or “minimal” Document object. It is very common to want to be able to extract a portion of a document’s tree or to create a new fragment of a document. Document Object Model (DOM) Level 1 Specification http://www.w3.org/TR/REC-DOM-Level-1/
24. When a DocumentFragment is inserted into a Document…the children of the DocumentFragment and not the DocumentFragment itself are inserted into the Node. Document Object Model (DOM) Level 1 Specification http://www.w3.org/TR/REC-DOM-Level-1/
25. <div class="grid-thumb" id="grid-thumb-viv9"> <a class="item-link" href="…"> <div class="grid-thumb-images"> <img class="current" alt="…" width="270" height="405" src="…"> </div> <div class="grid-thumb-info"> <div class="thumb-designer upper">Vivienne…</div> <div class="thumb-name subtitle">Julia Dress</div> <div class="thumb-price thumb-price-default subtitle-strong"> $275 rental </div> <div class="thumb-retail subtitle"> $1739 retail </div> </div> </a> <div class="favorite-wrapper heart-wrapper"> <div class="thumb-heart" title="Add to Favorites"></div> </div> </div> https://gist.github.com/mwunsch/29bca83eaf7649873900
26. var el = document.getElementById("grid-thumb-viv9"), frag = document.createDocumentFragment(), walker = walkerFactory(document.body), fragWalker = walkerFactory(frag), diffs = [], diff; https://gist.github.com/mwunsch/29bca83eaf7649873900 frag.appendChild(el.cloneNode(true)); frag.querySelector(".thumb-price").textContent = "$285 rental"; while (walker.nextNode() && fragWalker.nextNode()) { if (!walker.currentNode.isEqualNode(fragWalker.currentNode)) { diffs.push([walker.currentNode, fragWalker.currentNode]); } }
27. do { diff = diffs.pop(); if (diff[0].isEqualNode(diff[1])) break; if (diff[0].parentNode) { diff[0].parentNode.replaceChild( diff[1].cloneNode(true), diff[0]); } } while (diffs.length) https://gist.github.com/mwunsch/29bca83eaf7649873900
28. do { diff = diffs.pop() if (diff[0].isEqualNode(diff[1])) break if (diff[0].parentNode) { diff[0].parentNode.replaceChild( diff[1].cloneNode(true) diff[0]) } } while (diffs.length) https://gist.github.com/mwunsch/29bca83eaf7649873900 CO NSIDERED HARM FUL
29. FUNCTIONAL PEARL GÉRARD HUET INRIA Rocquencourt, France The Zipper
30. HEADER HGROUP H2 H1 SECTION FOOTER DIV BODY
31. HEADER HGROUP H1 SECTION FOOTER DIV BODY H2
32. HEADER HGROUP H1 SECTION FOOTER DIV BODY H2
33. var el = document.getElementById("grid-thumb-viv9"), loc = new Zipper(el); var designer = location .goDown() .goDown() .goRight() .goDown(); https://gist.github.com/mwunsch/d46a4ebde8567e2e5102 >> Zipper { tree: div.thumb-designer, crumb: Breadcrumb }
34. $
35. Further Reading • DOM Living Standard: https://dom.spec.whatwg.org/ • Range: https://developer.mozilla.org/en-US/docs/Web/API/Range • HTMLBars: https://github.com/tildeio/htmlbars • [WIP] Implement Glimmer Engine: https://github.com/emberjs/ ember.js/pull/10501 • React Reconciliation: https://facebook.github.io/react/docs/ reconciliation.html • Lee Byron, Immutable Data and React: https://youtu.be/I7IdS-PbEgI
36. Dante and Virgil Penetrating the Forest William Blake, 1824–27
37. ^D
