前⾔言 • 環境 • Glibc - 2.24 • Kernel -
4.8.0-59 • 64 • 內容會以 32 位元為主,較好說明與理理解 2 -
Outline • Background Knowledge • Stack Frame • Function Calling
Convention • Buffer Overflow • Exploit • Shellcode • Return to text • Return to libc • Bypass stack guard 3 -
Stack Frame • Stack: LIFO (Last In First Out) Last
Second First Last Second First PUSH POP Low Address High Address Stack growth 4 -
Function Call & Stack 1. Call Function 2. Back to
main to continue execution 5 -
Function Call & Stack • Function 跑完後,程式需要回到原本呼叫 function 的下⼀一 ⾏行行去執⾏行行,⽽而程式就是利利⽤用
stack 來來記錄下⼀一⾏行行指令 Back to here to continue Jump to 0x0804840b to execute Func 6 -
Function Call & Stack • Caller Part • ESP: Stack
Pointer • void Func(int a, int b) • … Stack ESP growth Low High push b push a call Func 7 -
Function Call & Stack • Caller Part • ESP: Stack
Pointer • void Func(int a, int b) • … b Stack ESP growth Low High push b push a call Func 8 -
Function Call & Stack • Caller Part • ESP: Stack
Pointer • void Func(int a, int b) • … a b Stack ESP growth Low High push b push a call Func 9 -
Function Call & Stack • Caller Part • Return Address:
call Func 下⼀一⾏行行 指令的位址 • void Func(int a, int b) • … Return Address a b Stack ESP growth Low High push b push a call Func 10 -
Function Call & Stack • Callee Part • 此時的 EBP
記錄著 main stack frame base 的位址 • void Func(int a, int b) char buf[12]; Previous ebp Return Address a b Stack ESP growth Low High push ebp mov ebp, esp sub esp, 0xc ======= Main Stack Frame Func Stack Frame 11 -
Function Call & Stack • Callee Part • 此時的 EBP
記錄著 Func stack frame base 的位址 • void Func(int a, int b) char buf[12]; Previous ebp Return Address a b Stack EBP = ESP growth Low High push ebp mov ebp, esp sub esp, 0xc ======= Main Stack Frame Func Stack Frame 12 -
Function Call & Stack • Callee Part • void Func(int
a, int b) char buf[12]; buf[0]~[3] buf[4]~[7] buf[8]~[11] Previous ebp Return Address a b Stack EBP growth Low High push ebp mov ebp, esp sub esp, 0xc 13 ESP buffer -
Function Call & Stack • void Func(int a, int b)
char buf[12]; buf[0]~[3] buf[4]~[7] buf[8]~[11] Previous ebp Return Address a b Stack EBP growth Low High push ebp mov ebp, esp sub esp, 0xc … 14 buffer EBP + 0x4 EBP + 0x8 EBP + 0xc EBP - 0x4 EBP - 0x8 EBP - 0xc -
Buffer Overflow • Unsafe Function • gets -> fgets •
scanf -> never use scanf(“%s”) • strcpy -> strncpy • … • Buffer Overflow 其實有很多種,根據不同的 memory 位址有不同的稱呼 • stack overflow • heap overflow 16 -
Stack Overflow • void Func(int a, int b) char buf[12];
gets(buf); buf[0]~[3] buf[4]~[7] buf[8]~[11] Previous ebp Return Address a b Stack EBP growth Low High 17 ESP buffer -
Stack Overflow • aaaaaaaaaaaa(a * 12) aaaa aaaa aaaa Previous
ebp Return Address a b Stack EBP growth Low High 18 ESP buffer -
Stack Overflow 19 aaaa aaaa aaaa aaaa aaaa aaaa aaaa
aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa aaaaaaaaaa growth Low High buffer Stack -
Stack Overflow • aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa (a*100) aaaa(pre
ebp) aaaa(ret addr) aaaa aaaa Stack ESP = EBP growth Low High 21 … mov esp, ebp pop ebp ret -
Stack Overflow • aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa (a*100) aaaa(ret
addr) aaaa aaaa Stack ESP growth Low High 22 … mov esp, ebp pop ebp ; ebp == 0x61616161 ret -
Stack Overflow • aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaa (a*100) aaaa
aaaa Stack ESP growth Low High 23 … mov esp, ebp pop ebp ; ebp == 0x61616161 ret (pop eip) ; eip == 0x61616161 -
Stack Overflow • 計算 offset • 中間少了了 d & e
• stack alignment 26 aaaa bbbb cccc ffff gggg hhhh iiii EBP growth High buffer EBP + 0x4 EBP + 0x8 EBP + 0xc EBP - 0x4 EBP - 0x8 EBP - 0xc Stack Low -
Stack Overflow • 計算 offset • 通靈 • ⽤用 gdb
• cyclic in pwntools 27 aaaa bbbb cccc ffff gggg hhhh iiii EBP growth High buffer EBP + 0x4 EBP + 0x8 EBP + 0xc EBP - 0x4 EBP - 0x8 EBP - 0xc Stack Low -
Stack Overflow • 蓋到 return address 所 需的 offset •
12 (buf) • 8 (alignment) • 4 (ebp) • 12 + 8 + 4 = 24 bytes 28 aaaa bbbb cccc ffff gggg hhhh iiii EBP growth High buffer EBP + 0x4 EBP + 0x8 EBP + 0xc EBP - 0x4 EBP - 0x8 EBP - 0xc Stack Low -
Exploit • Shellcode • Return to text • Return to
libc • Bypass stack guard 29 -
Exploit • Shellcode • 其實就是⼀一段 machine code,⽽而 machine code 就是
CPU 可以直接解讀的資料 • 把 input data 當成 code 來來跑 • 長得⼤大概像這樣 30 \x31\xc0\x50\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\x31\xd2\xb0\x0b\xcd\x80 -
Exploit • Shellcode • 這段 shellcode 翻成 assembly 就會是 31
\x31\xc0\x50\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\x31\xd2\xb0\x0b\xcd\x80 -
Exploit • Shellcode • 找⼀一個 buffer 把 shellcode 寫上去 •
利利⽤用 buffer overflow 把 return address 覆寫, 讓程式跳到 shellcode 上去執⾏行行 32 aaaa aaaa aaaa aaaa \xc0\x9f\x04\x08 a b Stack EBP growth Low High ESP buffer 0x08049fc0 shellcode -
Protection • DEP (Data Execution Prevention) • ASLR (Address Space
Layout Randomization) • Stack Guard (Stack Canary) • RELRO (Relocation Read Only) • PIE (Position Independent Executable) 33 -
• DEP (Data Execution Prevention) • 放在 data buffer 上的
shellcode 沒有執⾏行行的權限 • ❌ stack • ❌ heap • ❌ .data • ❌ .bss 34 Protection -
• DEP (Data Execution Prevention) • DEP 開啟/關閉 • gcc
-z execstack • execstack --set-execstack • execstack --clear-execstack • 檢查 Program Header - GNU_STACK • 35 Protection readelf --program-headers ${binary} -
• ASLR (Address Space Layout Randomization) • Depends on system
• Linux - • 預設是 2 • 0 - 關掉 ASLR • 1 - stack, shared library, mmap() • 2 - 除了了 1 的保護之外還加上 brk() 所管理理的記憶體位址 36 Protection cat /proc/sys/kernel/randomize_va_space -
• Stack Guard (Stack Canary) • ⼀一個亂數,在 function call 時放上
stack • 在 return address & ebp 被 push 上 stack 後,再放上 去 • 在 return 前檢查 canary 是不是正確的 37 Protection -
• Stack Guard (Stack Canary) • 開啟/關閉 • gcc -fstack-protector
/ gcc -fno-stack-protector • 檢查 function symbol • 38 Protection readelf -s ${binary} | grep __stack_chk_fail -
• RELRO (Relocation Read Only) • Disable • .got /
.got.plt 可寫 • Partial • .got.plt 可寫 • Full • .got / .got.plt 不可寫 • 在 load time 時就把所有 library function 解析完 42 Protection -
• RELRO (Relocation Read Only) • Default 是 Partial •
開啟 Full / 關閉 • gcc -Wl,-z,relro,-z,now / gcc -Wl,-z,norelro • 檢查 dynamic tag • DT_BIND_NOW - Full • GNU_RELRO - Partial 43 Protection -
• PIE (Position Independent Executable) • 預設不會開啟 (GCC 6 以前)
• 開啟的話,text & data 段也會是受 ASLR 影響,造成撰 寫 exploit 時更更困難 44 Protection -
• PIE (Position Independent Executable) • 開啟 / 關閉 •
gcc -fPIC -pie / gcc -no-pie • 檢查 ELF header • DYN (shared object file) 45 Protection readelf -h ${binary} | grep Type -
Exploit • Shellcode • Return to text • Return to
libc • Bypass stack guard 47 -
Exploit • Return to text • 利利⽤用程式本⾝身的 code (⼀一定可執⾏行行) •
沒有 PIE 的保護下,code 的位置是固定的 49 -
Exploit 51 aaaa aaaa …. aaaa aaaa(ebp) 0x804846d(ret addr) aaaa
aaaa growth Low High buffer Stack -
• Return to text • Endianness (位元組順序) • 在 x86
的架構下,是 little endian Exploit 53 Low High Low High -
• Return to text • 在⼤大多數情況下 binary 內有的 code 無法完成整個
exploit • Return to libc + ROP Exploit 54 -
Exploit • Shellcode • Return to text • Return to
libc • Linking • Lazy Binding • Bypass stack guard 55 -
Linking 56 hello.c Preprocess Compilation Assembly Linking hello.c Preprocess Compilation
Assembly Linking libc.a Static Dynamic hello.o hello.o -
• Linking • 靜態連結 Static Linking • ⼀一開始就會直接把所有 library function
的 machine code 放在 ELF 中 • 動態連結 Dynamic Linking • 把 library function 標記為⼀一個動態連結的符號 • shared object 跟著執⾏行行檔⼀一起載入記憶體 Linking 57 -
• 因此,dynamic linking 的 ELF 使⽤用了了 lazy binding 這個機 制,第⼀一次呼叫
library function 的時候才會去解析出真正 的位址 Lazy Binding 60 -
• ELF 使⽤用 PLT (Procedure Linkage Table) 的⽅方式來來實作 Lazy Binding
61 <Foo@plt>: 0x400450: jmp Foo@got 0x400456: push n 0x40045b: push module ID 0x400461: jmp _dl_runtime_resolve <Foo@got>: 0x400456 -
• ELF 使⽤用 PLT (Procedure Linkage Table) 的⽅方式來來實作 Lazy Binding
62 <Foo@plt>: 0x400450: jmp Foo@got 0x400456: push n 0x40045b: push module ID 0x400461: jmp _dl_runtime_resolve <Foo@got>: 0x400456 -
• ELF 使⽤用 PLT (Procedure Linkage Table) 的⽅方式來來實作 Lazy Binding
63 <Foo@plt>: 0x400450: jmp Foo@got 0x400456: push n 0x40045b: push module ID 0x400461: jmp _dl_runtime_resolve <Foo@got>: 0x400456 -
• ELF 使⽤用 PLT (Procedure Linkage Table) 的⽅方式來來實作 Lazy Binding
64 <Foo@plt>: 0x400450: jmp Foo@got 0x400456: push n 0x40045b: push module ID 0x400461: jmp _dl_runtime_resolve <Foo@got>: 0x400456 -
• ELF 使⽤用 PLT (Procedure Linkage Table) 的⽅方式來來實作 Lazy Binding
65 <Foo@plt>: 0x400450: jmp Foo@got 0x400456: push n 0x40045b: push module ID 0x400461: jmp _dl_runtime_resolve <Foo@got>: 0x7ffff7a66666 0x7ffff7a66666 <Foo>: … -
• ELF 使⽤用 PLT (Procedure Linkage Table) 的⽅方式來來實作 Lazy Binding
66 <Foo@plt>: 0x400450: jmp Foo@got 0x400456: push n 0x40045b: push module ID 0x400461: jmp _dl_runtime_resolve <Foo@got>: 0x7ffff7a66666 0x7ffff7a66666 <Foo>: … -
• ELF 使⽤用 PLT (Procedure Linkage Table) 的⽅方式來來實作 • n
• Foo 在 .rel.plt 的索引 • module ID • 引⽤用的 library name Lazy Binding 67 <Foo@plt>: 0x400450: jmp Foo@got 0x400456: push n 0x40045b: push module ID 0x400461: jmp _dl_runtime_resolve -
• ELF 使⽤用 PLT (Procedure Linkage Table) 的⽅方式來來實作 • Reuse
code Lazy Binding 68 <PLT0>: 0x400440: push module ID 0x400446: jmp _dl_runtime_resolve <Foo@plt>: 0x400450: jmp Foo@got 0x400456: push n 0x40045b: jmp PLT0 -
• Return to libc • 除了了 binary 本⾝身的 code,shared library
的 code 也可以 利利⽤用 • system • execve • … Exploit 70 -
• Return to libc • 因為 ASLR 的緣故,libc 每次載入位址不固定,需要搭配 information
leak • 拿到某個在 libc 裡的位址便便可以算出此次的 base address • 之後就可以加上想要的 function offset 隨意使⽤用任⼀一 library function • 在同⼀一個 libc 裡,function offset 是固定的 Exploit 71 -
• Return to libc • 尋找 libc address • GOT
• stack • e.g., return address of main • heap • e.g., main_arena Exploit 72 -
• Return to libc • 尋找 library function offset Exploit
73 readelf -s /path/of/libc | grep ${function_name} -
• Return to libc • 獲得 libc base 之後 •
在 stack 上偽造 function call • GOT hijack • … Exploit 74 -
• Return to libc • 在 stack 上偽造 function call
• 限制 • overflow • 任意寫 Exploit 75 aaaa aaaa aaaa aaaa system (ret addr) fake return address address of “/bin/sh” Stack growth Low High ESP buffer Fake Frame -
• Return to libc • GOT hijack • 限制 •
任意寫 • gets(buf) -> system(buf) Exploit 76 <gets@plt>: 0x400450: jmp gets@got 0x400456: push n 0x40045b: jmp PLT0 <gets@got>: 0x7ffff7a6dead 0x7ffff7a6dead <system>: … -
Exploit • Shellcode • Return to text • Return to
libc • Linking • Lazy Binding • Bypass stack guard 77 -
Exploit • Bypass stack guard • leak canary • GOT
hijack • … 78 -
Exploit • Bypass stack guard • leak canary • 某些
function 在讀完輸入之後不會放上 null byte,可 以利利⽤用這點去做 information leak (canary, libc, stack) • read() • strcpy() • strncpy() 79 -
• Bypass stack guard • leak canary • canary 的尾端⼀一定是
null byte Exploit 80 0xdead1200 (canary) ebp return address arg1 arg2 Stack growth Low High ESP buffer -
• Bypass stack guard • leak canary • 這時如果有個輸出 function
(e.g., printf(“%s”, buf)),程 式便便會從 buf 開頭⼀一路路印, 直到遇到 null byte • a*12 + 0x61 + 0x12 + 0xad + 0xde + … Exploit 81 aaaa aaaa aaaa 0xdead1261 (canary) ebp return address arg1 arg2 Stack growth Low High ESP buffer -
• Bypass stack guard • GOT hijack • 限制 •
任意寫 • 將 __stack_chk_fail 的 GOT entry 內容改掉,這時可以根據修改的內容決定不同的利利⽤用⽅方式 • NOP • 直接 overflow,疊 ROP • one_gadget • system • 偽造 function call (不需要疊 return address) • … Exploit 82 -
Reference • http://l4ys.tw/ROP_bamboofox.pdf • AngelBoy • 程式設計師的⾃自我修養 • https://goo.gl/wKFGfn •
https://en.wikipedia.org/wiki/ Executable_space_protection#Windows • https://en.wikipedia.org/wiki/ Address_space_layout_randomization 83
