Rayon (Rust Belt Rust)

A talk about Rayon from the Rust Belt Rust conference

Transcript

1. Rayon Data Parallelism for Fun and Profit Nicholas Matsakis (nmatsakis on IRC)
2. Want to make parallelization easy 2 fn load_images(paths: &[PathBuf]) -> Vec<Image> { paths.iter() .map(|path| Image::load(path)) .collect() } fn load_images(paths: &[PathBuf]) -> Vec<Image> { paths.par_iter() .map(|path| Image::load(path)) .collect() } For each path… …load an image… …create and return a vector.
3. Want to make parallelization safe 3 fn load_images(paths: &[PathBuf]) -> Vec<Image> { let mut pngs = 0; paths.par_iter() .map(|path| { if path.ends_with(“png”) { pngs += 1; } Image::load(path) }) .collect() } Data-race Will not compile
4. 4 http://blog.faraday.io/saved-by-the-compiler-parallelizing-a-loop-with-rust-and-rayon/
5. 5 Parallel Iterators join() threadpool Basically all safe Safe interface Unsafe impl Unsafe
6. 6 fn load_images(paths: &[PathBuf]) -> Vec<Image> { paths.iter() .map(|path| Image::load(path)) .collect() }
7. 7 fn load_images(paths: &[PathBuf]) -> Vec<Image> { paths.par_iter() .map(|path| Image::load(path)) .collect() }
8. Not quite that simple… 8 (but almost!) 1. No mutating shared state (except for atomics, locks). 2. Some combinators are inherently sequential. 3. Some things aren’t implemented yet.
9. 9 fn load_images(paths: &[PathBuf]) -> Vec<Image> { let mut pngs = 0; paths.par_iter() .map(|path| { if path.ends_with(“png”) { pngs += 1; } Image::load(path) }) .collect() } Data-race Will not compile
10. 10 `c` not shared between iterations! fn increment_all(counts: &mut [u32]) { for c in counts.iter_mut() { *c += 1; } } fn increment_all(counts: &mut [u32]) { paths.par_iter_mut() .for_each(|c| *c += 1); }
11. fn load_images(paths: &[PathBuf]) -> Vec<Image> { let pngs = paths.par_iter() .filter(|p| p.ends_with(“png”)) .map(|_| 1) .sum(); paths.par_iter() .map(|p| Image::load(p)) .collect() } 11
12. 12 But beware: atomics introduce nondeterminism! use std::sync::atomic::{AtomicUsize, Ordering}; fn load_images(paths: &[PathBuf]) -> Vec<Image> { let pngs = AtomicUsize::new(0); paths.par_iter() .map(|path| { if path.ends_with(“png”) { pngs.fetch_add(1, Ordering::SeqCst); } Image::load(path) }) .collect() }
13. 13 3 2 1 12 0 4 5 1 2 1 3 2 1 0 1 3 4 0 3 6 7 8 vec1 vec2 6 2 6 * sum 8 82 fn dot_product(vec1: &[i32], vec2: &[i32]) -> i32 { vec1.iter() .zip(vec2) .map(|(e1, e2)| e1 * e2) .fold(0, |a, b| a + b) // aka .sum() }
14. 14 fn dot_product(vec1: &[i32], vec2: &[i32]) -> i32 { vec1.par_iter() .zip(vec2) .map(|(e1, e2)| e1 * e2) .reduce(|| 0, |a, b| a + b) // aka .sum() } 3 2 1 12 0 4 5 1 2 1 3 2 1 0 1 3 4 0 3 6 7 8 vec1 vec2 sum 20 19 43 39 82
15. 15 Parallel iterators: Mostly like normal iterators, but: • closures cannot mutate shared state • some operations are different For the most part, Rust protects you from surprises.
16. 16 Parallel Iterators join() threadpool
17. The primitive: join() 17 rayon::join(|| do_something(…), || do_something_else(…)); Meaning: maybe execute two closures in parallel. Idea: - add `join` wherever parallelism is possible - let the library decide when it is profitable
18. 18 fn load_images(paths: &[PathBuf]) -> Vec<Image> { paths.par_iter() .map(|path| Image::load(path)) .collect() } Image::load(paths[0]) Image::load(paths[1])
19. Work stealing 19 Cilk: http://supertech.lcs.mit.edu/cilk/ (0..22) Thread A Thread B (0..15) (15..22) (1..15) (queue) (queue) (0..1) (15..22) (15..18) (18..22) (15..16) (16..18) “stolen” (18..22) “stolen”
21. 21 Parallel Iterators join() threadpool Rayon: • Parallelize for fun and profit • Variety of APIs available • Future directions: • more iterators • integrate SIMD, array ops • integrate persistent trees • factor out threadpool
22. 22 Parallel Iterators join() scope() threadpool
23. 23 the scope `s` task `t1` task `t2` rayon::scope(|s| { … s.spawn(move |s| { // task t1 }); s.spawn(move |s| { // task t2 }); … });
24. rayon::scope(|s| { … s.spawn(move |s| { // task t1 s.spawn(move |s| { // task t2 … }); … }); … }); 24 the scope task t1 task t2
25. `not_ok` is freed here 25 the scope task t1 let ok: &[u32]s = &[…]; rayon::scope(|scope| { … let not_ok: &[u32] = &[…]; … scope.spawn(move |scope| { // which variables can t1 use? }); });
26. 26 fn join<A,B>(a: A, b: B) where A: FnOnce() + Send, B: FnOnce() + Send, { rayon::scope(|scope| { scope.spawn(move |_| a()); scope.spawn(move |_| b()); }); } (Real join avoids heap allocation)
27. 27 struct Tree<T> { value: T, children: Vec<Tree<T>>, } impl<T> Tree<T> { fn process_all(&mut self) { process_value(&mut self.value); for child in &mut self.children { child.process_all(); } } }
28. 28 impl<T> Tree<T> { fn process_all(&mut self) where T: Send { rayon::scope(|scope| { for child in &mut self.children { scope.spawn(move |_| child.process_all()); } process_value(&mut self.value); }); } }
29. 29 impl<T> Tree<T> { fn process_all(&mut self) where T: Send { rayon::scope(|scope| { let children = &mut self.children; scope.spawn(move |scope| { for child in &mut children { scope.spawn(move |_| child.process_all()); } }); process_value(&mut self.value); }); } }
30. 30 impl<T: Send> Tree<T> { fn process_all(&mut self) { rayon::scope(|s| self.process_in(s)); } fn process_in<‘s>(&’s mut self, scope: &Scope<‘s>) { let children = &mut self.children; scope.spawn(move |scope| { for child in &mut children { scope.spawn(move |scope| child.process_in(scope)); } }); process_value(&mut self.value); } }
