VLANs

© 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential
Presentation_ID 1 Chapter 6: VLANs Routing and Switching Essentials v6.0

Presentation_ID 2 © 2008 Cisco Systems, Inc. All rights reserved.
Cisco Confidential Chapter 6 - Sections & Objectives 6.1 VLAN Segmentation • Explain the purpose of VLANs in a switched network. • Explain how a switch forwards frames based on VLAN configuration in a multi- switch environment. 6.2 VLAN Implementations • Configure a switch port to be assigned to a VLAN based on requirements. • Configure a trunk port on a LAN switch. • Troubleshoot VLAN and trunk configurations in a switched network. 6.3 Inter-VLAN Routing Using Routers • Describe the two options for configuring Inter-VLAN routing. • Configure Legacy Inter-VLAN Routing. • Configure Router-on-a-Stick Inter-VLAN Routing

Presentation_ID 3 6.1 VLAN Segmentation

Cisco Confidential Overview of VLANs VLAN Definitions

Cisco Confidential Overview of VLANs VLAN Definitions (cont.) VLANs allow an administrator to segment networks based on factors such as function, project team, or application, without regard for the physical location of the user or device. VLANs enable the implementation of access and security policies according to specific groupings of users. A VLAN is a logical partition of a Layer 2 network. Multiple partitions can be created, allowing for multiple VLANs to co-exist. Each VLAN is a broadcast domain, usually with its own IP network. VLANs are mutually isolated, and packets can only pass between them via a router. The partitioning of the Layer 2 network takes place inside a Layer 2 device, usually via a switch. The hosts grouped within a VLAN are unaware of the VLAN’s existence.

Cisco Confidential Overview of VLANs Benefits of VLANs

Cisco Confidential Overview of VLANs Types of VLANs Data VLAN – user generated traffic Default VLAN – all switch ports become part of this VLAN until switch is configured, show vlan brief Native VLAN – used for untagged traffic Management VLAN – used to access management capabilities

Cisco Confidential Overview of VLANs Types of VLANs (cont.)

Cisco Confidential Overview of VLANs Voice VLANs

Cisco Confidential Overview of VLANs Voice VLANs (cont.) VoIP traffic is time-sensitive and requires: • Assured bandwidth to ensure voice quality. • Transmission priority over other types of network traffic. • Ability to be routed around congested areas on the network. • Delay of less than 150 ms across the network. The voice VLAN feature enables access ports to carry IP voice traffic from an IP phone.

Cisco Confidential VLANs in a Multi-Switched Environment VLAN Trunks The links between switches S1 and S2, and S1 and S3 are configured to transmit traffic coming from VLANs 10, 20, 30, and 99 across the network. This network could not function without VLAN trunks.

Cisco Confidential VLANs in a Multi-Switched Environment VLAN Trunks (cont.) A VLAN trunk is a point-to-point link that carries more than one VLAN. A VLAN trunk is usually established between switches so same-VLAN devices can communicate, even if physically connected to different switches. A VLAN trunk is not associated to any VLANs; neither is the trunk ports used to establish the trunk link. Cisco IOS supports IEEE802.1q, a popular VLAN trunk protocol.

Cisco Confidential VLANs in a Multi-Switched Environment Controlling Broadcast Domains with VLANs

Cisco Confidential VLANs in a Multi-Switched Environment Controlling Broadcast Domains with VLANs VLANs can be used to limit the reach of broadcast frames. A VLAN is a broadcast domain of its own. A broadcast frame sent by a device in a specific VLAN is forwarded within that VLAN only. VLANs help control the reach of broadcast frames and their impact in the network. Unicast and multicast frames are forwarded within the originating VLAN.

Cisco Confidential VLANs in a Multi-Switched Environment Tagging Ethernet Frames for VLAN Identification Frame tagging is the process of adding a VLAN identification header to the frame. It is used to properly transmit multiple VLAN frames through a trunk link. Switches tag frames to identify the VLAN to which they belong. Different tagging protocols exist; IEEE 802.1Q is a vey popular example. The protocol defines the structure of the tagging header added to the frame. Switches add VLAN tags to the frames before placing them into trunk links and remove the tags before forwarding frames through non-trunk ports. When properly tagged, the frames can transverse any number of switches via trunk links and still be forwarded within the correct VLAN at the destination.

Cisco Confidential VLANs in a Multi-Switched Environment Tagging Ethernet Frames for VLAN Identification (cont.)

Cisco Confidential VLANs in a Multi-Switched Environment Native VLANs and 802.1Q Tagging Control traffic sent on the native VLAN should not be tagged. Frames received untagged, remain untagged and are placed in the native VLAN when forwarded. If there are no ports associated to the native VLAN and no other trunk links, an untagged frame is dropped. When configuring a switch port on a Cisco switch, configure devices so that they do not send tagged frames on the native VLAN. In Cisco switches, the native VLAN is VLAN 1, by default.

Cisco Confidential VLANs in a Multi-Switched Environment Voice VLAN Tagging

Cisco Confidential VLANs in a Multi-Switched Environment Activity – Predict Switch Behavior Scenario 1: PC 1 sends a broadcast. Scenario 2: PC 2 sends a broadcast. Scenario 3: PC 3 sends a broadcast.

Presentation_ID 21 6.2 VLAN Implementations

Cisco Confidential VLAN Assignment VLAN Ranges on Catalyst Switches Cisco Catalyst 2960 and 3560 Series switches support over 4,000 VLANs. VLANs are split into two categories: • Normal range VLANs • VLAN numbers from 1 to 1,005 • Configurations stored in the vlan.dat (in the flash memory) • IDs 1002 through 1005 are reserved for Token Ring and Fiber Distributed Data Interface (FDDI) VLANs, automatically created and cannot be removed • Extended Range VLANs • VLAN numbers from 1,006 to 4,096 • Configurations stored in the running configuration (NVRAM) • VLAN Trunking Protocol (VTP) does not learn extended VLANs

Cisco Confidential VLAN Assignment VLAN Ranges on Catalyst Switches (cont.) Normal Range VLANs

Cisco Confidential VLAN Assignment Creating a VLAN

Cisco Confidential VLAN Assignment Assigning Ports to VLANs

Cisco Confidential VLAN Assignment Changing VLAN Port Membership Remove VLAN Assignment Interface F0/18 was previously assigned to VLAN 20 which is still active, F0/18 reset to VLAN1

Cisco Confidential VLAN Assignment Changing VLAN Port Membership (cont.)

Cisco Confidential VLAN Assignment Deleting VLANs The entire vlan.dat file can be deleted using the delete flash:vlan.dat privileged EXEC mode command Abbreviated command version (delete vlan.dat) can be used if the vlan.dat file has not been moved from its default location

Cisco Confidential VLAN Assignment Verifying VLAN Information

Cisco Confidential VLAN Assignment Verifying VLAN Information (cont.)

Cisco Confidential VLAN Trunks Configuring IEEE 802.1q Trunk Links

Cisco Confidential VLAN Assignment Configuring IEEE 802.1q Trunk Links (cont.)

Cisco Confidential VLAN Trunks Resetting the Trunk to Default State

Cisco Confidential VLAN Trunks Resetting the Trunk to Default State (cont.)

Cisco Confidential VLAN Trunks Verifying Trunk Configuration

Cisco Confidential Troubleshoot VLANs and Trunks IP Addressing Issues with VLANs It is a common practice to associate a VLAN with an IP network. Because different IP networks only communicate through a router, all devices within a VLAN must be part of the same IP network to communicate. The figure displays that PC1 cannot communicate to the server because it has a wrong IP address configured.

Cisco Confidential Troubleshoot VLANs and Trunks Missing VLANs If all the IP address mismatches have been solved, but the device still cannot connect, check if the VLAN exists in the switch.

Cisco Confidential Troubleshoot VLANs and Trunks Missing VLANs (cont.) If the VLAN to which a port belongs is deleted, the port becomes inactive. All ports belonging to the VLAN that was deleted are unable to communicate with the rest of the network. Not functional until the missing VLAN is created using the vlan vlan_id global configuration.

Cisco Confidential Troubleshoot VLANs and Trunks Introduction to Troubleshooting Trunks Note: To solve a native VLAN mismatch, configure the native VLAN to be the same VLAN on both sides of the link.

Cisco Confidential Troubleshoot VLANs and Trunks Common Problems with Trunks Trunking issues are usually associated with incorrect configurations. The most common type of trunk configuration errors are: Native VLAN mismatches Trunk mode mismatches Allowed VLANs on trunks If a trunk problem is detected, the best practice guidelines recommend to troubleshoot in the order shown above.

Cisco Confidential Troubleshoot VLANs and Trunks Common Problems with Trunks (cont.)

Cisco Confidential Troubleshoot VLANs and Trunks Incorrect Port Mode

Cisco Confidential Troubleshoot VLANs and Trunks Incorrect VLAN List

Cisco Confidential Troubleshoot VLANs and Trunks Incorrect VLAN List (cont.) VLANs must be allowed in the trunk before their frames can be transmitted across the link. Use the switchport trunk allowed vlan command to specify which VLANs are allowed in a trunk link. Use the show interfaces trunk command to ensure the correct VLANs are permitted in a trunk.

Presentation_ID 46 6.3 Inter-VLAN Routing Using Routers

Cisco Confidential Inter-VLAN Routing Operation What is Inter-VLAN Routing? Layer 2 switches cannot forward traffic between VLANs without the assistance of a router. Inter-VLAN routing is a process for forwarding network traffic from one VLAN to another, using a router.

Cisco Confidential Inter-VLAN Routing Operation Legacy Inter-VLAN Routing In the past: Actual routers were used to route between VLANs. Each VLAN was connected to a different physical router interface. Packets would arrive on the router through one interface, be routed and leave through another. Because the router interfaces were connected to VLANs and had IP addresses from that specific VLAN, routing between VLANs was achieved. Large networks with large number of VLANs required many router interfaces.

Cisco Confidential Inter-VLAN Routing Operation Legacy Inter-VLAN Routing (cont.) In this example, the router was configured with two separate physical interfaces to interact with the different VLANs and perform the routing.

Cisco Confidential Inter-VLAN Routing Operation Router-on-a-Stick Inter-VLAN Routing The router-on-a-stick approach uses only one of the router’s physical interface. One of the router’s physical interfaces is configured as a 802.1Q trunk port so it can understand VLAN tags. Logical subinterfaces are created; one subinterface per VLAN. Each subinterface is configured with an IP address from the VLAN it represents. VLAN members (hosts) are configured to use the subinterface address as a default gateway.

Cisco Confidential Inter-VLAN Routing Operation Router-on-a-Stick Inter-VLAN Routing (cont.) Router interface configured to operate as a trunk link and is connected to a trunked switch port. The router performs inter-VLAN routing by accepting VLAN-tagged traffic on the trunk interface coming from the adjacent switch, and then, internally routing between the VLANs using subinterfaces. The router then forwards the routed traffic, VLAN-tagged for the destination VLAN, out the same physical interface as it used to receive the traffic.

Cisco Confidential Inter-VLAN Routing Operation Identify the Types of Inter-VLAN Routing Activity Legacy or Router-on-a-Stick?

Cisco Confidential Inter-VLAN Routing Operation Identify the Types of Inter-VLAN Routing Activity (cont.) Legacy or Router-on-a-Stick?

Cisco Confidential Configure Legacy Inter-VLAN Routing Configure Legacy Inter-VLAN Routing: Preparation Legacy inter-VLAN routing requires routers to have multiple physical interfaces. Each one of the router’s physical interfaces is connected to a unique VLAN. Each interface is also configured with an IP address for the subnet associated with the particular VLAN. Network devices use the router as a gateway to access the devices connected to the other VLANs.

Cisco Confidential Configure Legacy Inter-VLAN Routing Configure Legacy Inter-VLAN Routing: Switch Configuration

Cisco Confidential Configure Legacy Inter-VLAN Routing Configure Legacy Inter-VLAN Routing: Router Interface Configuration

Cisco Confidential Configure Router-on-a-Stick Inter-VLAN Routing Configure Router-on-a Stick: Preparation An alternative to legacy inter-VLAN routing is to use VLAN trunking and subinterfaces. VLAN trunking allows a single physical router interface to route traffic for multiple VLANs. The physical interface of the router must be connected to a trunk link on the adjacent switch. On the router, subinterfaces are created for each unique VLAN. Each subinterface is assigned an IP address specific to its subnet or VLAN and is also configured to tag frames for that VLAN.

Cisco Confidential Configure Router-on-a-Stick Inter-VLAN Routing Configure Router-on-a Stick: Switch Configuration

Cisco Confidential Configure Router-on-a-Stick Inter-VLAN Routing Configure Router-on-a Stick: Router Subinterface Configuration

Cisco Confidential Configure Router-on-a-Stick Inter-VLAN Routing Configure Router-on-a Stick: Verifying Subinterfaces

Cisco Confidential Configure Router-on-a-Stick Inter-VLAN Routing Configure Router-on-a Stick: Verifying Subinterfaces (cont.)

Cisco Confidential Configure Router-on-a-Stick Inter-VLAN Routing Configure Router-on-a Stick: Verifying Routing Access to devices on remote VLANs can be tested using the ping command. The ping command sends an ICMP echo request to the destination address. When a host receives an ICMP echo request, it responds with an ICMP echo reply. Tracert is a useful utility for confirming the routed path taken between two devices.

Presentation_ID 63 6.4 Chapter Summary

Cisco Confidential • Explain the purpose of VLANs in a switched network. • Explain how a switch forwards frames based on VLAN configuration in a multi-switch environment. • Configure a switch port to be assigned to a VLAN based on requirements. • Configure a trunk port on a LAN switch. • Troubleshoot VLAN and trunk configurations in a switched network. • Describe the two options for configuring inter-VLAN routing. • Configure Legacy Inter-VLAN Routing. • Configure Router-on-a-Stick Inter-VLAN Routing Chapter Summary Summary
