Understanding Streaming Data and Analytics with Apache Kafka®
Ricardo Ferreira
October 01, 2020
Transcript
58 slides
-
Understanding streaming data and analytics with apache kafka® @riferrei |
@apachekafka | @elastic -
About me @riferrei | @apachekafka | @elastic • RICARDO FERREIRA
• Developer advocate • Elastic community team • Kafka summit pc member • [email protected] • [email protected] -
@riferrei | @apachekafka | @elastic ”there were lots of databases
and other systems built to store data, but what was missing in our architecture was something that would help us to handle continuous flows of data.” – jay kreps Origins of apache kafka -
@riferrei | @apachekafka | @elastic Event-driven architecture Job change recommendation
engine Search engine Email service -
@riferrei | @apachekafka | @elastic SQL SQL SQL Recommendation engine
Search engine Email service database LOG IMPLEMENT WITH a DATABASE -
@riferrei | @apachekafka | @elastic Databases CAN’T handle events database
1000x more volume Non-transactional events Transactional events LOG -
@riferrei | @apachekafka | @elastic ARE DATABASES LIMITED? YES THEY
ARE. WHY DO WE HAVE TO MOVE DATA FROM ONE DB TO ANOTHER JUST for ANALYTICS? -
“The truth is the log. The database is a cache
of a subset of the log.” — pat helland Immutability changes everything http://cidrdb.org/cidr2015/Papers/CIDR15_Paper16.pdf -
@riferrei | @apachekafka | @elastic log as first-class citizen database
LOG 0 1 2 3 4 5 6 7 8 LOG reads writes Destination System a (time = 1) Destination System b (time = 3) -
@riferrei | @apachekafka | @elastic SOLUTION: BUILD A COMMIT LOG
Commit LOG User tracking Historical data Operational metrics Nosql database Graph database Sql database ... HADOOP Elastic search grafana Machine learning REC. ENGINE SEARCH SECURITY EMAIL SOCIAL GRAPH microservices -
@riferrei | @apachekafka | @elastic ”WE’VE COME TO THINK OF
KAFKA AS A STREAMING PLATFORM: A SYSTEM THAT LETS YOU PUBLISH AND SUBSCRIBE TO STREAMS OF DATA, STORE THEM, AND PROCESS THEM, AND THAT IS EXACTLY WHAT APACHE KAFKA IS BUILT TO BE.” – jay kreps Origins of apache kafka -
@riferrei | @apachekafka | @elastic ORIGINS OF APACHE KAFKA Databases
Messaging Batch Expensive Time Consuming Difficult to Scale No Persistence After Consumption No Replay Highly Scalable Durable Persistent Ordered Fast (Low Latency) -
@riferrei | @apachekafka | @elastic ORIGINS OF APACHE KAFKA Databases
Messaging Batch Expensive Time Consuming Difficult to Scale No Persistence After Consumption No Replay Highly Scalable Durable Persistent Ordered Fast (Low Latency) Highly Scalable Durable Persistent Ordered Fast (Low Latency) Distributed Commit log -
@riferrei | @apachekafka | @elastic ORIGINS OF APACHE KAFKA Databases
Messaging Batch Expensive Time Consuming Difficult to Scale No Persistence After Consumption No Replay Highly Scalable Durable Persistent Ordered Fast (Low Latency) Highly Scalable Durable Persistent Ordered Fast (Low Latency) Stream processing Continuous flows Scalable integration Distributed Streaming platform -
@riferrei | @apachekafka | @elastic ”the ability to combine these
three areas – to bring all the streams of data together across all the use cases – is what makes the idea of a streaming platform so appealing to people” – jay kreps Origins of apache kafka -
01 Data Streams with messaging 02 Data analytics with stream
processing 03 Sophisticated STORAGE SYSTEM Distributed streaming platform -
@riferrei | @apachekafka | @elastic producer Messaging as you know
it consumer broker write push -
@riferrei | @apachekafka | @elastic producer Kafka does messaging different
consumer broker write pull -
@riferrei | @apachekafka | @elastic Kafka does messaging different broker
pull Group 1 Group 2 Group 3 pull pull queueing Pub/sub -
@riferrei | @apachekafka | @elastic Kafka does messaging different 0
1 2 3 4 5 6 7 topic 0 1 2 3 Partition 1 4 5 6 7 Partition 2 -
@riferrei | @apachekafka | @elastic Kafka does messaging different 0
1 2 3 Partition 1 4 5 6 7 Partition 2 8 9 Partition 3 producer write consumer consumer consumer pull pull pull -
@riferrei | @apachekafka | @elastic Kafka does messaging different 0
1 2 3 Partition 1 4 5 6 7 Partition 2 8 9 Partition 3 producer Key 002 -
@riferrei | @apachekafka | @elastic Kafka does messaging different producer
write consumer pull Bytes serialize deserialize -
@riferrei | @apachekafka | @elastic producer Kafka does messaging different
broker write 250gb 250gb 500gb Data is always Persistent -
@riferrei | @apachekafka | @elastic How to process data streams?
consumer broker 1) pull number of records < 4 12 number of records > 5 9 3) write 2) process -
@riferrei | @apachekafka | @elastic How to process data streams?
consumer broker 1) pull 3) write What IF WE COULD HAVE A Processing LAYER FOR THE DATA STREAMS? number of records < 4 12 number of records > 5 9 2) process -
@riferrei | @apachekafka | @elastic Using stream processors producer consumer
broker write pull Stream processors -
@riferrei | @apachekafka | @elastic Scalable data integration broker Stream
processors connectors -
@riferrei | @apachekafka | @elastic Kafka as a storage system
Broker 1 250gb 250gb 500gb 1tb storage Broker 2 500gb 500gb 500gb 1.5tb storage Cluster storage → 2.5tb Elastic storage -
@riferrei | @apachekafka | @elastic Kafka as a storage system
Broker 1 250gb 250gb 500gb 1tb storage Broker 2 500gb 500gb 500gb 1.5tb storage Partition-level replication Partition 1 Partition 2 Partition 2 -
@riferrei | @apachekafka | @elastic Kafka as a storage system
Commit LOG consumer Polling 100 records consumer Constant time performance Time spent: 1 MS Polling 100 records Time spent: 1 MS Commit LOG 5kb 5tb -
@riferrei | @apachekafka | @elastic Kafka as a storage system
Optimized for massive reads Broker 1 250gb 250gb 500gb 1tb storage pagecache nic consumer Kafka uses the sendfile api to: - Bypass pagecache to kernel space - Bypass kernel space to user buffer - Bypass user buffer to kernel space - Bypass kernel space to socket buffer Partition 1 Partition 2 -
@riferrei | @apachekafka | @elastic Kafka as a storage system
File management in kafka Partition 0 Partition 1 Partition 2 Segment 0 Segment 1 + Segment 2 + 0000Seg1.log 0000Seg1.index -
@riferrei | @apachekafka | @elastic STREAMING PAC-MAN Api gateway Lambda
function Kafka (MSK) Ksqldb (ecs) Kafka (MSK) scoreboard https://github.com/riferrei/streaming-pacman-aws -
@riferrei | @apachekafka | @elastic 2. Name yourself 1. Get
the game Streaming pac-man -
@riferrei | @apachekafka | @elastic Api gateway Lambda function scoreboard
Redis cache push From kafka to the world -
From kafka to the world @riferrei | @apachekafka | @elastic
Amazon alexa Lambda function scoreboard Redis cache push -
@riferrei | @apachekafka | @elastic Your code Ksqldb (ECS) pull
Kafka (MSK) From kafka to the world
