Modular HTML & CSS Workshop

Shay Howe
September 27, 2012

Modular HTML & CSS Workshop

All too often writing HTML and CSS is an afterthought. Its the work that happens after design is finalized and the product has been developed. Its a necessary task in the process to building a website. Wrong.

HTML and CSS are the backbone to every website, and are equally as important as any design or development. In this workshop you will learn how to write modular HTML and CSS, and how reuse code to build maintainable websites. After spending some time playing with legos and writing some of code attendees will be able to better organize their code, develop modular styles, and work with CSS specificity.

The workshop is geared towards intermediate front end developers, with a love of legos, looking grow their skill set. A laptop and good attitude are preferred.

Shay Howe

September 27, 2012
Tweet

More Decks by Shay Howe

Other Decks in Design

Transcript

  1. @shayhowe Modular HTML & CSS 1. The Problem 2. Groundwork

    3. Assembling Layout 4. Accommodating Content 5. Onward OUR SCHEDULE
  2. @shayhowe Modular HTML & CSS COMMON PROBLEMS • Websites have

    difficulty scaling • Code becomes brittle • Files and code bases begin to swell
  3. @shayhowe Modular HTML & CSS WHAT’S WRONG • Best practices

    aren’t exactly best practices • Standards need to evolve
  4. @shayhowe Modular HTML & CSS BEST BAD PRACTICES • Avoid

    extra elements • Avoid classes • Leverage type selectors • Leverage descendent selectors
  5. @shayhowe Modular HTML & CSS BEST BAD PRACTICES Avoiding classes

    section  ul#nav  li  {...} section:nth-­‐child(2)  div:nth-­‐child(7)  >  a  {...} Leveraging selectors a.btn  {...} #main  a.btn  {...} #main  div.feature  a.btn  {...}
  6. @shayhowe Modular HTML & CSS BEST BAD PRACTICES Bad #contact

     li:nth-­‐child(1)  input, #contact  li:nth-­‐child(2)  input  {    width:  160px; } #contact  li:nth-­‐child(3)  textarea  {    width:  280px; }
  7. @shayhowe Modular HTML & CSS BEST BAD PRACTICES Good .col-­‐1

     {    width:  160px; } .col-­‐2  {    width:  280px; }
  8. @shayhowe Modular HTML & CSS SPECIFICITY? • Specificity determines which

    styles are applied • Each selector has a specificity weight • High specificity beats low specificity • Low specificity is key
  9. @shayhowe Modular HTML & CSS MEASURING SPECIFICITY Formula • IDs,

    Classes/Pseudo-classes/Attributes, Elements High Specificity (Bad) #primary  #main  div.gallery  figure.media IDs: 2, Classes: 2, Elements: 2 — Compiled: 2–2–2 Low Specificity (Good) .gallery-­‐media IDs: 0, Classes: 1, Elements: 0 — Compiled: 0–1–0
  10. @shayhowe Modular HTML & CSS WATCH SPECIFICITY • Be explicit

    • Keep specificity low • Never use IDs or !important • Avoid nested selectors (#main  .spotlight  strong  span)
  11. @shayhowe Modular HTML & CSS WATCH SPECIFICITY Bad #primary  #main

     div.gallery  {    text-­‐transform:  uppercase; } #primary  #main  div.gallery  figure.media  {    background:  #ccc; }
  12. @shayhowe Modular HTML & CSS WATCH SPECIFICITY Good .gallery  {

       text-­‐transform:  uppercase; } .gallery-­‐media  {    background:  #ccc; }
  13. @shayhowe Modular HTML & CSS METHODOLOGIES OOCSS • Object-Oriented CSS

    From Nicole Sullivan – oocss.org SMACSS • Scalable and Modular Architecture for CSS From Jonathan Snook – smacss.com
  14. @shayhowe Modular HTML & CSS REUSE CODE • Do not

    duplicate code • Remove old code • Defer loading subsequent styles
  15. @shayhowe Modular HTML & CSS REUSE CODE Bad .news  {

       background:  #eee;    color:  #666; } .social  {    background:  #eee;    color:  #666; }
  16. @shayhowe Modular HTML & CSS REUSE CODE Good .news, .social

     {    background:  #eee;    color:  #666; } Better .feat-­‐box  {    background:  #eee;    color:  #666; }
  17. @shayhowe Modular HTML & CSS USE CLASSES • Write understandable

    class names • Avoid unnecessary nesting • Use same strength specificity
  18. @shayhowe Modular HTML & CSS USE CLASSES Bad .feat-­‐box  .callout

     .pr  {    font-­‐size:  12px; } .feat-­‐box  .callout  .pr  .un  {    color:  #39f; }
  19. @shayhowe Modular HTML & CSS USE CLASSES Good .feat-­‐box  .price

     {    font-­‐size:  12px; } .feat-­‐box  .unit  {    color:  #39f; }
  20. @shayhowe Modular HTML & CSS USE CLASSES Bad .btn.large  {

       font-­‐size:  24px;        padding:  15px  30px; } <div  class="btn  large">...</div>
  21. @shayhowe Modular HTML & CSS USE CLASSES Good .btn-­‐large  {

       font-­‐size:  24px;    padding:  15px  30px; } <div  class="btn-­‐large">...</div>
  22. @shayhowe Modular HTML & CSS ABSTRACT STRUCTURE • Separate presentation

    (or theme) from layout • Create an object layer for layout • Create a skin layer for theme • Use a grid
  23. @shayhowe Modular HTML & CSS ABSTRACT STRUCTURE Bad .news  {

       background:  #eee;    color:  #666;    margin:  0  10px;    width:  400px; } <div  class="news">...</div>
  24. @shayhowe Modular HTML & CSS ABSTRACT STRUCTURE Good .grid-­‐4  {

       margin:  0  10px;    width:  400px; } .feat-­‐box  {    background:  #eee;    color:  #666; } <div  class="grid-­‐4  feat-­‐box">...</div>
  25. @shayhowe Modular HTML & CSS TRANSPARENTIZE ELEMENTS • Stylize elements

    to be transparent • Keep visual properties apart from layout properties
  26. @shayhowe Modular HTML & CSS TRANSPARENTIZE ELEMENTS Bad .pagination  {

       border-­‐radius:  5px;    border:  1px  solid  #eee;    margin:  0  10px;    width:  620px; } <ul  class="pagination">...</ul>
  27. @shayhowe Modular HTML & CSS TRANSPARENTIZE ELEMENTS Good .grid-­‐8  {

       margin:  0  10px;    width:  620px; } .offset-­‐box  {    border-­‐radius:  5px;    border:  1px  solid  #eee; } <ul  class="grid-­‐8  offset-­‐box">...</ul>
  28. @shayhowe Modular HTML & CSS CREATE ADAPTABLE LAYOUTS • Height

    and width should be flexible • Height should extend with content • Width should extend with a grid
  29. @shayhowe Modular HTML & CSS CREATE ADAPTABLE LAYOUTS Bad #main

     {    float:  left;    margin:  0  10px;    width:  620px; } #aside  {    float:  left;    margin:  0  10px;    width:  300px; }
  30. @shayhowe Modular HTML & CSS CREATE ADAPTABLE LAYOUTS Good .grid-­‐4,

    .grid-­‐8  {    float:  left;    margin:  0  10px; } .grid-­‐4  {    width:  300px; } .grid-­‐8  {    width:  620px; }
  31. @shayhowe Modular HTML & CSS SEPARATE CONTENT • Separate content

    from container • Stylize content regardless of container
  32. @shayhowe Modular HTML & CSS SEPARATE CONTENT Bad .alert  {

       background:  #f2dede;    border-­‐radius:  10px;    color:  #b94a48;    padding:  10px  20px; } <div  class="alert">...</div>
  33. @shayhowe Modular HTML & CSS SEPARATE CONTENT Good .alert  {

       border-­‐radius:  10px;    padding:  10px  20px; } .alert-­‐error  {    background:  #f2dede;    color:  #b94a48; } <div  class="alert  alert-­‐error">...</div>
  34. @shayhowe Modular HTML & CSS AVOID PARENT DEPENDENCY • Remove

    parent container dependency • Decouple CSS from HTML • Create components to be used anywhere
  35. @shayhowe Modular HTML & CSS AVOID PARENT DEPENDENCY Bad .feat-­‐box

     {    background:  #eee; } article  .feat-­‐box  {    background:  #fff; } <article>    <div  class="feat-­‐box">...</div> </article>
  36. @shayhowe Modular HTML & CSS AVOID PARENT DEPENDENCY Good .feat-­‐box

     {    background:  #eee; } .feat-­‐box-­‐alt  {    background:  #fff; } <article>    <div  class="feat-­‐box-­‐alt">...</div> </article>
  37. @shayhowe Modular HTML & CSS FAVOR SEMANTICS • Allow elements

    to adapt • Uses individual classes to extend modules
  38. @shayhowe Modular HTML & CSS FAVOR SEMANTICS Bad .feat-­‐box  h2

     {    color:  #f60;    font:  18px  Helvetica,  sans-­‐serif; } <div  class="feat-­‐box">    <h2>...</h2> </div>
  39. @shayhowe Modular HTML & CSS FAVOR SEMANTICS Good .feat-­‐subhead  {

       color:  #f60;    font:  18px  Helvetica,  sans-­‐serif; } <div  class="feat-­‐box">    <h2  class="feat-­‐subhead">...</h2> </div>
  40. @shayhowe Modular HTML & CSS APPROACH • Stop thinking about

    pages • Start thinking about components • Take visual inventory
  41. @shayhowe Modular HTML & CSS THEMES • Decouple HTML and

    CSS • Separate presentation from layout • Separate content from container • Extend elements with classes
  42. @shayhowe Modular HTML & CSS OUTCOMES • Maintainability! • Reusable

    code, less duplication • Flexibility and extensibility • Improved standards
  43. @shayhowe Modular HTML & CSS WHAT’S NEXT Build a styleguide

    • Twitter Bootstrap, Zurb Foundation Review methodologies • OOCSS, SMACSS Test your code • CSS Lint, Inspector, PageSpeed
