  1. Written by: Matt Butcher Illustrated by: Bailey Beougher Designed by:

    Karen Chu Brought to you by... Illustration of Goldie is based on the Go Gopher designed by Renee French
  2. Once upon a time, there was an app named Phippy.

    She was a simple app written in PHP and had just one page. She lived on a hosting provider and she shared her environment with scary other apps she didn’t know, and didn’t care to associate with. She wished she had her own environment; just her and a webserver she could call home.
  3. An app has an environment that it relies upon to

    run. For a PHP app, that environment might include a webserver, a readable file system, and the PHP engine itself.
  4. One day, a kindly whale came along. He suggested that

    little Phippy might be happier living in a container and so she moved. The container was nice, but… it was a little bit like having a fancy living room floating in the middle of the ocean.
  5. A container provides an isolated context in which an app,

    together with its environment, can run. But isolated containers often need to be managed and connected to the external world. Shared file systems, networking, scheduling, load balancing, and distribution are all challenges.
  6. The whale shrugged his shoulders. “Sorry, kid,” he said, and

    disappeared beneath the ocean’s surface. But before Phippy could even begin to despair, a captain appeared on the horizon, piloting a gigantic ship. The ship was made of dozens of rafts all lashed together, but from the outside, it looked like one huge boat. “Hello there, little app! My name is Captain Kube,” said the wise old captain.
  7. “Kubernetes” is the Greek word for a ship’s captain. The

    words Cybernetic and Gubernatorial are derived from “Kubernetes”. Led by Google, the Kubernetes project focuses on building a robust platform for running thousands of containers in production.
  8. “I’m Phippy,” said the little app. “Nice to make your

    acquaintance,” said the Captain as he gave her a name tag.
  9. Kubernetes uses labels as “nametags” to identify things. Labels are

    open-ended. You can use them to indicate roles, stability, or other important attributes.
  10. Captain Kube suggested that the app might like to move

    her container to a pod on board the ship. Phippy happily moved her container aboard. It felt like home.
  11. A pod represents a runnable unit of work. Usually, a

    single container runs inside of a pod. But for cases where a few containers are tightly coupled, you may opt to run more than one container inside of the same Pod. Kubernetes takes on the work of connecting your pod to the network and the rest of the Kubernetes environment.
  12. Phippy had some unusual interests– she was really into genetics

    and sheep. And so she asked the captain, “What if I want to clone myself… On demand… Any number of times?” “That’s easy,” said the captain as he introduced her to the replication controllers.
  13. Replication controllers provide a method for managing an arbitrary number

    of pods. A replication controller contains a pod template, which can be replicated any number of times. Through the replication controller, Kubernetes will manage your pods’ lifecycle, including scaling up and down, rolling deployments, and monitoring.
  14. For many days and nights, the little app was happy

    with her pod and happy with her replicas. But only having yourself for company is not all it’s cracked up to be…even if there are N copies of yourself. Captain Kube smiled benevolently, “I have just the thing.” No sooner had he spoken than a tunnel opened between Phippy’s replication controller and the rest of the ship. With a hearty laugh, Captain Kube said, “Even when your clones come and go, this tunnel will stay here so you can discover other pods, and they can discover you!”
  15. A service tells the rest of the Kubernetes environment (including

    other pods and replication controllers) what services your application provides. While pods come and go, the service IP addresses and ports remain the same. Other applications can find your service through Kurbernetes service discovery.
  16. Phippy began to explore the rest of the ship. It

    wasn’t long before Phippy met Goldie and they became the best of friends. One day, Goldie did something extraordinary. She gave Phippy a present. Phippy took one look and the saddest of sad tears escaped her eye. “Why are you so sad?” asked Goldie. “I love the present, but I have nowhere to put it!” sniffled Phippy. But Goldie knew what to do, “Why not put it in a volume?”
  17. A volume represents a location where containers can access and

    store information. The volume appears as part of the local filesystem. Volumes may be backed by local storage, Ceph, Gluster, Elastic Block Storage, or a number of other storage backends.
  18. Phippy loved life aboard Captain Kube’s ship and she enjoyed

    the company of her new friends (every replicated pod of Goldie was equally delightful). But as she thought back to her days on the scary hosted provider, she began to wonder if perhaps she could also have a little privacy. “It sounds like what you need,” said Captain Kube, “is a namespace.”
  19. A namespace functions as a grouping mechanism inside of Kubernetes.

    Services, pods, replication controllers, and volumes can easily cooperate within a namespace, and the namespace provides a degree of isolation from other parts of the cluster.
  20. Life was good aboard Captain Kube’s boat. Together with her

    new friends, Phippy sailed the seas. She had many grand adventures, but most importantly, Phippy had found her home. And so Phippy lived happily ever after.
