Abstract UI Concepts

A different way of thinking about writing UI code.

Transcript

2. Abstract
 UI Concepts Sriram Ramani sriramramani@fb.com
3. Giant ListViews
4. Stories
5. Stories
6. Stories
7. Stories
8. SHOCK SPOCK A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user.
9. ListView Recycling
10. ListView Recycling ITEM 1 ITEM 2 ITEM 3 ITEM 4 ITEM 5 ITEM 6 ITEM 7 ITEM 8 ITEM 8 ITEM 8
11. ListView Recycling bind the model measure layout addView getView()
12. ListView Recycling USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME
13. Break the rows
14. SHOCK SPOCK A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user.
15. ListView Recycling USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. USER NAME A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user.
16. public enum ITEM_TYPES { HEADER, CONTENT, SECONDARY_INFO, FEEDBACK_BAR } @Override public int getViewTypeCount() { return ITEM_TYPES.values().length; } @Override public int getItemViewType(int position) { return ITEM_TYPES.values()[position % getViewTypeCount()]; } @Override public View getView(int position, View convertView, ViewGroup parent) { // Bind based on the item type. } 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
17. Advantages ▪ Faster binding time ▪ Less time to measure ▪ Less time to draw each row ▪ More re-usable rows
18. Custom ViewGroups
19. Typical Header
20. Typical Header Shock Spock 2 hr • San Francisco, CA
21. LinearLayout of LinearLayouts
22. LinearLayout weights Shock Spock 2 hr • San Francisco, CA Thumbnail LinearLayout (Outer) Title Subtitle Menu LinearLayout (Inner)
23. LinearLayout weights > LinearLayout (Outer) > Thumbnail > LinearLayout (Inner) > Title > Subtitle > Title > Subtitle > Menu > LinearLayout (Inner) > Title > Subtitle Shock Spock 2 hr • San Francisco, CA
24. RelativeLayout
25. RelativeLayout Shock Spock 2 hr • San Francisco, CA Title Subtitle Thumbnail Menu RelativeLayout
26. RelativeLayout > RelativeLayout > Menu > Thumbnail > Subtitle > Title > Title > Subtitle > Menu > Thumbnail Shock Spock 2 hr • San Francisco, CA
27. Custom ViewGroup
28. Custom ViewGroup > CustomViewGroup > Thumbnail > Menu > Title > Subtitle Shock Spock 2 hr • San Francisco, CA
29. @Override protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) { int widthConstraints = getPaddingLeft() + getPaddingRight(); int heightConstraints = getPaddingTop() + getPaddingBottom(); // Measure the thumbnail. measureChildWithMargins( mThumbnailView, widthMeasureSpec, widthConstraints, heightMeasureSpec, heightConstraints); widthConstraints += mThumbnailView.getMeasuredWidth(); // Measure the title. measureChildWithMargins( mTitleView, widthMeasureSpec, widthConstraints, heightMeasureSpec, heightConstraints); } 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
30. @Override protected void measureChildWithMargins( View child, int parentWidthMeasureSpec, int widthConstraints, int parentHeightMeasureSpec, int heightConstraints) { MarginLayoutParams lp = (MarginLayoutParams) child.getLayoutParams(); int childWidthMeasureSpec = getChildMeasureSpec(parentWidthMeasureSpec, widthConstraints + lp.leftMargin + lp.rightMargin, lp.width); int childHeightMeasureSpec = getChildMeasureSpec(parentHeightMeasureSpec, heightConstraints + lp.topMargin + lp.bottomMargin, lp.height); child.measure(childWidthMeasureSpec, childHeightMeasureSpec); } 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
31. SHOCK SPOCK A piece of text that extends couple of lines. This is the core of the app as this provides the information to the user. 1 2 3 4 5
32. Sub-views
33. Sub-views LinearLayout ImageView TextView Drawable Layout
34. TextViews Bacon ipsum dolor sit amet spare ribs pork tongue, hamburger biltong rump shoulder turkey ham hock beef tri-tip pork chop jerky fatback.
35. TextViews Bacon ipsum dolor sit amet spare ribs pork tongue, hamburger biltong rump shoulder turkey ham hock beef tri-tip pork chop jerky fatback.
36. ListView Recycling ITEM 1 ITEM 2 ITEM 3 ITEM 4 ITEM 5 ITEM 6 ITEM 7 ITEM 8 ITEM 8 ITEM 8
37. @Override public void setText(CharSequence text) { // Store the text. checkForRelayout(); } private void checkForRelayout() { // Make new layout for the new text. makeNewLayout(want, …, width, …); } 1 2 3 4 5 6 7 8 9 10 11 12
38. Text Layout Caching
39. public class TextLayoutView extends View { private Layout mLayout; public void setText(CharSequence text, String key) { Layout layout = SHARED_LAYOUT_CACHE.get(key); if (layout == null) { // Better to do this in onMeasure() mLayout = new StaticLayout(…); } else { mLayout = layout; } } @Override protected void onDraw(Canvas canvas) { super.onDraw(canvas); mLayout.draw(canvas); } } 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
40. Advantages ▪ Less object creation ▪ Layout measuring cost is saved ▪ Works with Spannables too ▪ Can hack it work for ClickableSpans
41. Watch out ▪ Orientation change ▪ Locale change ▪ Same text in a different context / color
42. public class TextLayoutView extends View { private Layout mLayout; public void setText(CharSequence text, String key) { Layout layout = SHARED_LAYOUT_CACHE.get(key); if (layout == null) { // Better to do this in onMeasure() mLayout = new StaticLayout(…); } else { mLayout = layout; } } @Override protected void onDraw(Canvas canvas) { super.onDraw(canvas); mLayout.draw(canvas); } } 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
43. PictureDrawable
44. public class TextLayoutView extends View { private Layout mLayout; private Picture mPicture; private boolean mRecorded = false; @Override protected void onDraw(Canvas canvas) { if (!mRecorded) { Canvas pictureCanvas = mPicture.beginRecording( canvas.getWidth(), canvas.getHeight()); super.onDraw(pictureCanvas); mLayout.draw(pictureCanvas); mPicture.endRecording(); mRecorded = true; } mPicture.draw(canvas); } } 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
45. Sprites
46. Glyphs
47. Texture Atlas
48. Batching & Merging ONE TWO
49. Batching & Merging ONE TWO
50. private void drawAPortion() { // Draw the bitmap. canvas.drawBitmap(mBitmap, mSourceRect, mDestinationRect, null); } 1 2 3 4 5
51. public class SpriteImageView extends ImageView { private WeakReference<Bitmap> mBitmap; @Override public void onDraw(Canvas canvas) { // Get the destination rectangle. getDrawingRect(mDestinationRect); // Draw the bitmap. canvas.drawBitmap(mBitmap.get(), mSourceRect, mDestinationRect, null); } public void setCoordinates(int left, int top, int width, int height) { mSourceRect.set(left, top, left + width, top + height); invalidate(); } } 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
52. Advantages ▪ Pay the cost of reading bitmap once ▪ Need not be in Android resource cache ▪ Less commands sent to GPU ▪ Same texture re-used
53. Color Tinting
54. Glyphs
55. Tinting COLOR FILTER + =
56. PorterDuff Mode SRC_OVER
57. PorterDuff Mode DST_OVER
58. PorterDuff Mode SRC_IN
59. PorterDuff Mode SRC_IN
60. private void tintGlyph(int tintColor) { // Create a color filter. ColorFilter colorFilter = new PorterDuffColorFilter(tintColor, PorterDuff.Mode.SRC_IN); // Set it on the drawable. mDrawable.setColorFilter(colorFilter); } 1 2 3 4 5 6 7 8 9
61. State Changes
62. <selector> <!— Selected —> <item android:state_selected=“true” android:state_enabled=“true” android:color=“@color/blue” /> <!— Enabled —> <item android:state_enabled=“true” android:color=“@color/white” /> <!— Disabled —> <item android:color=“@color/grey” /> </selector> 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
63. public class TintImageView extends ImageView { private ColorStateList mTintColor; @Override protected void drawableStateChanged() { super.drawableStateChanged(); if (mTintColor != null) { // Get the color for the state. int[] state = getDrawableState(); int tintColor = mTintColor.getColorForState(state, 0); // Create a color filter. ColorFilter colorFilter = new PorterDuffColorFilter(tintColor, PorterDuff.Mode.SRC_IN); // Set it on the image. setColorFilter(colorFilter); } } } 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
64. Advantages ▪ Cuts down resources in half (or even more) ▪ Can be combined with sprites ▪ Only one bitmap is loaded even for StateListDrawable
65. That’s all folks!
