End-to-End Encryption Saves Lives. You Can Start Saving Lives With Ruby, Too (RubyConf Taiwan 2025 ver.)

Transcript

1. End-to-End Encryption Saves Lives. You Can Start Saving Lives With Ruby, Too Ryo Kajiwara/ 梶原 龍 (sylph01) 2025/8/9 @ RubyConf Taiwan + COSCUP 2025 1
2. Slides are available at: http:/ /bit.ly/4mx0cEq (QR code uses the full Speaker Deck URL) 2
3. Hi! 3
4. I flew from 松山 (MYJ) to 松山 (TSA) again It says Ehime and Matsuyama but this is the SweetMe Hotspring Resort ( 水美温泉會館 ) in Xinbeitou 4
5. I do stuff Play rhythm games (especially DanceDanceRevolution) Play the bassoon/contrabassoon and DJ gear Ride a lot of trains (Rails!) (travelled on 99% of JR) Build keyboards Organized RubyKaigi 2025 as a Local Organizer if anything catches your interest let's talk! 5
6. And I do stuff that is more relevant to this talk: Freelance web developer focused on Digital Identity and Security Worked/ing on writing/editing and implementing standards HTTPS in Local Network CG / Web of Things WG @ W3C, OAuth / Messaging Layer Security WG @ IETF Worked as an Officer of Internet Society Japan Chapter (2020-23) 6
7. The Usual Disclaimer Cryptographic API can be very easy to misuse Operational Security is also very difficult I've done my research, but I don't consider myself a cryptography expert a.k.a. "I am not djb" If you're not sure, please have your system audited by a security expert before going to production also I don't have a PhD/Master's degree in this field so yeah... 7
8. Notes on Production Readiness The MLS implementation is still in progress Passes most test vectors Lacks validation on error cases Client implementation is underway Hopefully release 1.0 by the next IETF (2025/11)...? I was aiming for 1.0 before IETF 126 (2025/7) but yeah... 8
10. Part 1: Motivation 10
11. I happen to be known as the SMTP をやめろ -guy SMTP をやめろ = lit. "stop using SMTP"; more like "SMTP is dead" 11
12. SMTP mail lacks two things: 1) Strong identity 2) End-to-end Encryption MLS also helps with the identity part (with the full architecture), but that is service dependent 12
13. End-to-End Encryption = The people who run the service cannot read your messages LINE, Facebook Messenger, Signal, WhatsApp, ... They each have their own version of E2EE Some apps' E2EE are opt-in 13
14. <political> 14
15. E2EE is more important than ever Increasing tension in international affairs Powerful people wanting to control the Internet even in democratic countries! Provides a safe method to communicate under oppression / in war zones 15
16. Hey, but doesn't E2EE help criminals? E2EE is being targeted by authorities even in democratic countries! Even if you ban E2EE, criminals will use it anyways Banning E2EE disproportionately harms vulnerable people 16
17. https:/ /www.internetsociety.org/blog/2024/07/encryption-is-a-preventative-tool-that-protects-children/ 17
18. HTTPS(TLS) also helps criminals, but are you going to ban HTTPS(TLS)? 18
19. </political> 19
20. Messaging Layer Security More interoperable version of doing E2EE MLS provides key exchange Protocol (RFC 9420), Architecture (RFC 9750) Today's topic is the implementation of the Protocol Now we (kinda) have RFC 9420 in Ruby! for MLS Architecture getting an RFC number 20
21. Messaging Layer Security is essentially SMTP をやめろ 21
22. mls gem already exists (for a defunct website...) It exists since 2012, so it predates the 00 Internet-Draft of Messaging Layer Security (2018/2) 22
23. Melos https:/ /github.com/sylph01/melos Taken from a novel that is in most Japanese middle school/high school textbooks 23
25. Part 2: The Protocol 25
26. Basics: Symmetric vs Asymmetric Cryptography Symmetric crypto: one key used for both encryption and decryption Asymmetric crypto: Also known as Public Key Cryptography Alice keeps a pair of keys, public and private Bob can encrypt a plaintext using Alice's Public Key Then Alice decrypts the ciphertext with her Private Key 26
27. Building blocks: HPKE "Encrypt with Public Key, Decrypt with Private Key" , formalized A combination of the following: Key Encapsulation Mechanism (KEM) ( ≒ asymmetric crypto) Key Derivation Function (KDF) ( ≒ hash) Authenticated Encryption with Associated Data (AEAD) (= symmetric crypto) Available in Ruby: hpke gem Seen this? I've talked about this at RubyConf Taiwan 2023 27
28. Security Characteristics Forward Secrecy: messages sent at a certain point in time are secure in the face of later compromise of a group member secure against "harvest now, decrypt later" attack RFC 9420, Section 16.6 28
29. Security Characteristics Post-Compromise Security: messages are secure even if a group member was compromised at some point in the past Each member updates their key so that group secrets are not always encrypted with private keys that have been compromised RFC 9420, Section 16.6 29
30. Security Characteristics RFC 9420, Section 16.6 30
31. 2 person is easy # both party starts with chain key 0 chain_key[0] = "some common secret" # when sending a message... message_key[n] = hmac_sha256(chain_key[n], 0x02) # encrypt the message #(n) using message_key[n] chain_key[n+1] = hmac_sha256(chain_key[n], 0x01) Symmetric Key Ratchet part of the Double Ratchet algorithm 31
32. 3+ person is difficult Extend 2-person method? Number of edges in an n-node complete graph is O(n^2) 32
33. Introducing Your Favorite Data Structure That Turns O(n) Into O(log n): Trees 33
34. Trees with arrays Complete balanced trees can be described with a flat array For example, the tree on the right will be written as: [0, 1, 2, 3, 4, 5, 6, 7, 8, 9, nil, 11, nil, nil, nil] 34
35. Trees with arrays Leaf nodes are always even indexed Parent nodes are always odd indexed We define operations such as left , right , parent , sibling , ... based on the array-based tree's characteristics 35
36. Trees with arrays The algorithms are described in Appendix C of RFC 9420 Also this comes with a serialization/deserialization format! 36
37. 3 Parts to MLS 37
38. Where's the Tree? Users in a group will be assigned a leaf in the ratchet_tree and the secret_tree with the same index. 38
39. Basically You want to agree with other users in the group upon a common secret: epoch_secret[n], where n is the epoch number 39
40. Secret Tree If you have a common secret, the group can derive the same (symmetric) keys for encrypting messages 40
41. Secret Tree def self.populate_tree_impl(suite, tree, index, secret) tree.array[index] = { ... } unless Melos::Tree.leaf?(index) left_secret = Melos::Crypto.expand_with_label(suite, secret, "tree", "left", suite.kdf.n_h) right_secret = Melos::Crypto.expand_with_label(suite, secret, "tree", "right", suite.kdf.n_h) populate_tree_impl(suite, tree, Melos::Tree.left(index), left_secret) populate_tree_impl(suite, tree, Melos::Tree.right(index), right_secret) end end From the base encryption secret, we recursively populate the tree down to its leaves file lib/melos/secret_tree.rb 41
42. Secret Tree The actual ratcheting part: def self.ratchet_application(suite, tree, leaf_index) node_index = leaf_index * 2 generation = tree.array[node_index]['next_application_ratchet_secret_generation'] application_ratchet_secret = tree.array[node_index]['application_ratchet_secret'] application_nonce = Melos::Crypto.derive_tree_secret(suite, application_ratchet_secret, "nonce", generation, suite.hpke.n_n) application_key = Melos::Crypto.derive_tree_secret(suite, application_ratchet_secret, "key", generation, suite.hpke.n_k) next_application_ratchet_secret = Melos::Crypto.derive_tree_secret(suite, application_ratchet_secret, "secret", generation, suite.kdf.n_h) tree.array[node_index]['next_application_ratchet_secret_generation'] = generation + 1 tree.array[node_index]['application_ratchet_secret'] = next_application_ratchet_secret tree.array[node_index]['application_nonce'] = application_nonce tree.array[node_index]['application_key'] = application_key end file lib/melos/secret_tree.rb 42
43. Secret Tree It essentially boils down to this: key = Crypto.derive_tree_secret(ratchet_secret[n], "key", n) nonce = Crypto.derive_tree_secret(ratchet_secret[n], "nonce", n) ratchet_secret[n + 1] = Crypto.derive_tree_secret(ratchet_secret[n], "secret", n) This gives you the key and nonce to encrypt the actual messages. Compare with this (two-party hash ratcheting): chain_key[0] = "some common secret" message_key[n] = hmac_sha256(chain_key[n], 0x02) chain_key[n+1] = hmac_sha256(chain_key[n], 0x01) 43
44. Key Schedule With the last epoch_secret and a common commit_secret , the group can agree upon the next epoch_secret see lib/melos/key_schedule.rb and test/test_key_schedule.rb 44
45. the hardest part: TreeKEM How do we agree upon the same commit_secret ? 45
46. TreeKEM Users are assigned a leaf node Users have their leaf key pair 46
47. TreeKEM When a user wants to update the group secret, user creates an UpdatePath 47
48. TreeKEM User generates a random path_secret at their leaf The parent's path_secret is calculated using the child's path_secret Calculate that up to the root The commit_secret is calculated from the root's path_secret 48
49. TreeKEM path_secret[0] = (random) path_secret[1] = hash(path_secret[0]) path_secret[3] = hash(path_secret[1]) commit_secret = hash(path_secret[7]) where 7 is the root 49
50. TreeKEM When 0 creates its UpdatePath (yellow) We find the copath nodes along the UpdatePath (green) If all ParentNode s in the tree are populated, we encrypt the path secret to the key of its copath node Public keys for parent nodes are derived from path_secret s 50
51. TreeKEM We can see that's possible in a 2-leaf tree 0 creates an UpdatePath, node 1 has a path_secret the path secret is encrypted to 2 's public key node 2 knows the private key, so 2 can decrypt 51
52. TreeKEM What happens if there are blanks in the tree? We calculate the resolution of the copath node to figure out which node's keys are available. Then, we encrypt the path secret of the UpdatePath node to each key 52
53. TreeKEM The resolution of the node indicated left is [3, 2] The indicated node has unmerged leaves so its resolution is itself + list of unmerged leaves 53
54. TreeKEM The resolution of the node indicated left is [3, 2, 9, 14] The resolution is used to figure out the set of keys that are necessary to encrypt to every node under that node 54
55. TreeKEM So actually what you do is: Calculate path_secret s for each node on UpdatePath then encrypt the path_secret s to each key on the resolution of the copath node 55
56. TreeKEM Encrypting the commit_secret itself and sending it to everyone works but it's O(n) (n = # of members) Encrypting the commit_secret along the copath reduces the number of encryptions needed down to O(log n) 56
57. Summary Secret Tree gives you the per- message sender keys based on epoch_secret Key Schedule gives you the next epoch_secret based on current epoch_secret and commit_secret TreeKEM gives you the commit_secret 57
58. Sending Application Messages Application messages (actual messages) are sent in PrivateMessage s framed_content = Melos::Struct::FramedContent.create(...) authenticated_content = Melos::Struct::AuthenticatedContent.create(...) authenticated_content.sign(...) app_message = Melos::Struct::PrivateMessage.protect( authenticated_content, secret_tree, ... ) 58
59. Evolution of a Group A group is updated through messages called proposals and commits Proposals Add and remove users Notifies an update of user's leaf key Injects Pre-Shared Keys Commits will fix those information and advances the group's epoch UpdatePath s are conveyed in the Commit 59
60. Evolution of a Group A Group is created by adding a user's LeafNode into a 0-node group Starts with a random epoch_secret def init_group(node) # single node, a leaf node containing an HPKE PK and credential for the creator @ratchet_tree = [node] @leaf_index = 0 @tree_hash = Melos::Struct::RatchetTree.root_tree_hash(@cipher_suite, @ratchet_tree) @confirmed_transcript_hash = '' @epoch_secret = SecureRandom.random_bytes(@cipher_suite.kdf.n_h) ... @group_initialized = true end lib/group.rb from a work-in-progress version 60
61. Evolution of a Group Users who want to join the group publishes their identity (including its public key) to a Directory using a KeyPackage They will receive a Welcome message that has the group state inside it Figure 2 in RFC 9420 Section 3.2. The Delivery Service is out of scope for this implementation 61
62. Evolution of a Group User A creates an initial group To add User B , A sends an Add proposal adding B , then Commit s A sends a Welcome message to introduce B into the group Same for adding C Figure 3 in RFC 9420 Section 3.2. 62
63. Evolution of a Group When Add ing: Add the leaf_node from the KeyPackage in the proposal to the leftmost empty node Then add the leaf index to intermediate nodes' unmerged list 63
64. Evolution of a Group User B sends an Update proposal notifying the group of its leaf key update Then User A Commit s that update to include it in the epoch advancement Figure 4 in RFC 9420 Section 3.2. 64
65. Evolution of a Group When Update ing: Replace the leaf node of the sender with the leaf_node inside the Update proposal Then blank all nodes on its direct path up to the root Updating the keys regularly gives the Group Post-Compromise Security 65
66. Evolution of a Group When removing a user: Z sends a Remove proposal and a Commit B cannot decrypt the path_secret included in the Commit 's UpdatePath , so B will not know the next epoch_secret 66
67. Evolution of a Group When Remove ing: Blank the specified node in the proposal Then blank all nodes on its direct path up to the root If the right half of the tree is fully empty, the tree is shrunk 3 becomes the new root 67
68. Evolution of a Group When are intermediate parent nodes filled? During the processing of a Commit When processing a Commit , the UpdatePath inside the Commit is merged into the ratchet tree ParentNode s are created based on the UpdatePath content 68
69. Stuff we are omitting here Injection of Pre-Shared Keys Transcript Hashes Hashes that summarize the proposals/commits taken place in the last epoch Signing/Verification of messages There are public messages and private messages 69
71. Part 3: Ongoing/Future work 71
72. Current implementation state Passes most test vectors Updates from RubyKaigi Parsing messages now use a StringIO instead of two String s Moved group state into a Group object Needs a user-friendly client API Needs interoperability testing 72
73. Work-in-progress Client Interface cipher_suite_id = 1 client = Melos::Client.new(cipher_suite_id) # generate key pairs key_package = Melos::KeyPackage.new(client) # create KP to publish to DS leaf_node = key_package.create_leaf_node('credential_name') node = Melos::Struct::Node.new_leaf_node(leaf_node) group = Melos::Group.new(client, 'group_id') group.init_group(node) # create a 1-node group 73
74. Work-in-progress Client Interface client2 = Melos::Client.new(cipher_suite_id) key_package2 = Melos::KeyPackage.new(client2) leaf_node2 = key_package2.create_leaf_node('credential_name2') key_package_message2 = key_package2.create_message(leaf_node2) # User 1 creates add proposal prop = group.create_add_proposal( key_package_message2, client.signature_private_key) # something like this...? commit = create_commit(prop, ...) group.apply_commit(commit) group2.apply_welcome(welcome) 74
75. :contribute-chance: "Refactoring" Wrapping raw values into classes Group is being worked on RatchetTree is now represented as a raw array Interoperability testing Learn other implementations and create test scenarios There is an automated interop suite that uses gRPC :contribute-chance: is a Slack emoji in #ruby-jp used for indicating good first issues 75
76. Works on Ruby's Cryptography Ecosystem 76
77. HPKE using OpenSSL's API HPKE is nice, and OpenSSL itself has APIs that do this Talked about it at RubyConf Taiwan 2023 Haven't worked on it much since 77
78. HPKE using OpenSSL's API But is it a good idea? Protocols need the whole cipher suite Not only encap/decap and open/seal Also want access to constants such as hash/key length OpenSSL's HPKE context remembers which algorithm to use, but to use them separately you have to call them separately 78
79. Example def self.sender_data_key(suite, sender_data_secret, ciphertext) ciphertext_sample = ciphertext[0..(suite.kdf.n_h - 1)] expand_with_label(suite, sender_data_secret, "key", ciphertext_sample, suite.hpke.n_k) end def self.sender_data_nonce(suite, sender_data_secret, ciphertext) ciphertext_sample = ciphertext[0..(suite.kdf.n_h - 1)] expand_with_label(suite, sender_data_secret, "nonce", ciphertext_sample, suite.hpke.n_n) end n_h is hash length, n_k and n_n is the key and nonce length for the symmetric crypto 79
80. EC vs X25519/X448 APIs in OpenSSL Checking correspondence of key pairs def self.signature_key_pair_corresponds?(suite, private_key, public_key) private_pkey = suite.pkey.deserialize_private_signature_key(private_key) public_pkey = suite.pkey.deserialize_public_signature_key(public_key) if suite.pkey.equal?(Melos::Crypto::CipherSuite::X25519) || suite.pkey.equal?(Melos::Crypto::CipherSuite::X448) # is an Edwards curve; check equality of the raw public key private_pkey.raw_public_key == public_pkey.raw_public_key else # is an EC; check equality of the public key Point private_pkey.public_key == public_pkey.public_key end end 80
81. EC vs X25519/X448 APIs in OpenSSL Getting EC public/private keys in UncompressedPointRepresentation form def self.derive_key_pair(suite, secret) pkey = suite.hpke.kem.derive_key_pair(secret) if suite.pkey.equal?(Melos::Crypto::CipherSuite::X25519) || suite.pkey.equal?(Melos::Crypto::CipherSuite::X448) # is an Edwards curve [pkey.raw_private_key, pkey.raw_public_key] else # is an EC [pkey.private_key.to_s(2), pkey.public_key.to_bn.to_s(2)] end end 81
82. Additional features in OpenSSL OpenSSL 3.5.0 ships with post-quantum cryptography ML-KEM, ML-DSA, SLH-DSA There is an Internet-Draft that adds ML-KEM in MLS 82
83. Q: MLS is E2EE so client-side, right? Ruby is server-side lang lol 83
84. A: NO Ruby is not just Rails We have ruby-wasm 84
85. Grand Unifying Cryptography API Different platforms depend on different cryptographic libraries Desktop: OpenSSL Compatible (to an extent) with LibreSSL, BoringSSL, and the like Browser: Web Crypto API Embedded: Mbed TLS, wolfSSL, ... We have Mbed TLS support in PicoRuby Can we have a unified API wrapper for these libraries? Actually ruby-wasm has OpenSSL compiled in wasm, but doing it through browser APIs is faster 85
86. Grand Unifying Cryptography API Very quick example of calling Web Crypto API's random number generator require "js" array = JS::eval('return new Uint8Array(16)') JS.global[:window][:crypto].getRandomValues(array) p array 86
88. Conclusion 88
89. Why do you need End-to-End Encryption in Ruby? Because... This is a DanceDanceRevolution reference. see: MAX.(period), Over the "Period" 89
90. Ruby needs them to stay relevant or else people would just use Python, Go, Rust, whatever the cool kids use these days Actually, Python doesn't have an MLS implementation yet, so it's a win for Ruby 90
91. Ruby needs Freedom on the Internet and the Free Internet needs Ruby free as in freedom 91
92. Takeaways We have interoperable ways of doing E2EE We (kinda) have this in Ruby too Please use secure messaging in your daily life 92
93. Shoutouts The Messaging Layer Security Working Group @ IETF Protocol implementers in Ruby (the list is growing!) RubyConf Taiwan 2025 Organizers 93
94. Questions? / Comments? Twitter: @s01 or Fediverse: @s01@ruby.social also find me in the venue / at drinkups! I will be at the Official Code Party 94
96. (extra slides from RK version) 96
97. It's not just a pack and unpack MLS has variable length vectors and optional values in their structs struct { opaque group_id<V>; uint64 epoch; ContentType content_type; opaque authenticated_data<V>; opaque encrypted_sender_data<V>; opaque ciphertext<V>; } PrivateMessage; 97
98. Variable length vectors struct { uint32 fixed<0..255>; opaque variable<V>; } StructWithVectors; Based on variable-length integer encoding in RFC 9000, Section 16 2-bit prefix if 00 , length is encoded with 6 bits if 01 , length is encoded with 14 bits if 11 , length is encoded with 30 bits 98
99. Optional values struct { uint8 present; select (present) { case 0: struct{}; case 1: T value; }; } optional<T>; 99
100. Define structs like this class Melos::Struct::PrivateMessage < Melos::Struct::Base attr_reader :group_id, :epoch, :content_type, :authenticated_data, :encrypted_sender_data, :ciphertext STRUCT = [ [:group_id, :vec], [:epoch, :uint64], [:content_type, :uint8], [:authenticated_data, :vec], [:encrypted_sender_data, :vec], [:ciphertext, :vec] ] 100
101. Melos::Struct::Base #initialize , .new_and_rest : deserializer #raw : serializer These operate based on the STRUCT constant of the class lib/melos/struct/base.rb 101
102. Deserialize each element like this def deserialize_elem(buf, type, type_param) case type when :uint8 value = buf.byteslice(0, 1).unpack1('C') buf = buf.byteslice(1..) when :uint16 value = buf.byteslice(0, 2).unpack1('S>') buf = buf.byteslice(2..) (snip) when :vec value, buf = Melos::Vec.parse_vec(buf) (snip) lib/melos/struct/base.rb; I'm likely rewriting this with a StringIO instead of using strings as buffers 102
103. Sometimes a class is nested class Melos::Struct::FramedContent < Melos::Struct::Base (snip) STRUCT = [ [:group_id, :vec], [:epoch, :uint64], [:sender, :class, Melos::Struct::Sender], [:authenticated_data, :vec], [:content_type, :uint8], (snip) ] lib/melos/struct/structs.rb 103
104. So we recursively call new when :class value, buf = type_param.send(:new_and_rest, buf) when :classes # prefix, length = buf.get_prefix_and_length # puts "#{prefix}, #{length}" vec, buf = Melos::Vec.parse_vec(buf) value = [] while (vec.bytesize > 0) current_instance, vec = type_param.send(:new_and_rest, vec) value << current_instance end lib/melos/struct/structs.rb 104
105. We sometimes have values that depend on other values class Melos::Struct::Sender < Melos::Struct::Base attr_reader :sender_type, :leaf_index, :sender_index STRUCT = [ [:sender_type, :uint8], [:leaf_index, :select, ->(ctx){ctx[:sender_type] == 0x01}, :uint32], [:sender_index, :select, ->(ctx){ctx[:sender_type] == 0x02}, :uint32], ] lib/melos/struct/structs.rb 105
106. We call the Proc with the current context to handle that def deserialize_select_elem_with_context( buf, context, predicate, type, type_param) if predicate.(context) deserialize_elem(buf, type, type_param) else [nil, buf] end end lib/melos/struct/base.rb 106
