Introduction to Containers and Kubernetes

Introduction to Containers and Kubernetes

An introductory talk on containers in general and Kubernetes specifically

Terrence Ryan

June 08, 2017
Tweet

More Decks by Terrence Ryan

Other Decks in Technology

Transcript

  1. ‹#› @tpryan Matrix from Hell Dev 1 Laptop Dev 2

    Laptop QA Stage Production OS ? ? ? ? ? Frontend ? ? ? ? ? Services ? ? ? ? ? Database ? ? ? ? ? Logs ? ? ? ? ?
  2. ‹#› @tpryan Matrix from Hell Dev 1 Laptop Dev 2

    Laptop QA Stage Production OS OS X Windows Debian Debian Debian Frontend nginx (homebrew) nginx (download) nginx (apt-get) nginx (apt-get) nginx (apt-get) Services php (homebrew) php (download) php (apt-get) php (apt-get) php (apt-get) Database mysql (download) mysql (download) mysql (apt-get) mysql (apt-get) mysql (apt-get) Logs /usr/local/etc/nginx/logs/ C:\nginx-1.9.5\logs /var/log/nginx/ /var/log/nginx/ /var/log/nginx/
  3. ‹#› @tpryan It worked fine in dev It worked fine

    in dev Ops Problem now Ops Problem now
  4. ‹#› @tpryan Matrix from Hell Dev 1 Laptop Dev 2

    Laptop QA Stage Production OS Frontend Services Database Logs
  5. ‹#› @tpryan # BACKEND FROM ubuntu:12.04 ADD ./mysql-setup.sh /tmp/mysql-setup.sh RUN

    /bin/sh /tmp/mysql-setup.sh EXPOSE 3306 CMD ["/usr/sbin/mysqld"]
  6. ‹#› @tpryan # FRONTEND AND SERVICES FROM nginx-php-fpm COPY nginx.conf

    /etc/nginx/nginx.conf ADD www /var/www/ # JUST SERVICES FROM nginx-php-fpm COPY nginx.conf /etc/nginx/nginx.conf ADD www /var/www/
  7. ‹#› @tpryan # FRONTEND AND SERVICES FROM nginx-php-fpm COPY nginx.conf

    /etc/nginx/nginx.conf ADD www /var/www/ # FRONTEND FROM nginx COPY nginx.conf /etc/nginx/nginx.conf ADD www /var/www/
  8. ‹#› @tpryan # BACKEND FROM ubuntu:12.04 ADD ./mysql-setup.sh /tmp/mysql-setup.sh RUN

    /bin/sh /tmp/mysql-setup.sh EXPOSE 3306 CMD ["/usr/sbin/mysqld"] # BACKEND FROM ubuntu:12.04 ADD ./mysql-setup.sh /tmp/mysql-setup.sh RUN /bin/sh /tmp/mysql-setup.sh EXPOSE 3306 VOLUME ["/etc/mysql", "/var/lib/mysql"] CMD ["/usr/sbin/mysqld"]
  9. ‹#› @tpryan Kubernetes • Container Orchestration System • Open Source

    • Started by Google • Contributed to by others
  10. ‹#› @tpryan Dockerfiles FROM mysql/mysql-server:5.6 ADD sql/load.sql /docker-entrypoint-initdb.d/load.sql EXPOSE 3306

    DB FROM httpd:2.4 COPY ui /usr/local/apache2/htdocs/ui COPY static /usr/local/apache2/htdocs/static UI FROM php:7.0-apache RUN apt-get update && apt-get install -y php5-mysqlnd RUN docker-php-ext-install mysqli RUN a2enmod rewrite && a2enmod headers && service apache2 restart COPY app/ /var/www/html/ API
  11. ‹#› @tpryan Deployment apiVersion: extensions/v1beta1 kind: Deployment metadata: name: frontend-deployment

    spec: replicas: 4 strategy: type: RollingUpdate template: metadata: labels: layer: ui spec: containers: - name: "frontend" image: "gcr.io/lamp-in-containers/locations-frontend" ports: - name: "http" containerPort: 80 protocol: TCP Pod Replica Set Deployment
  12. ‹#› @tpryan Stateful Set apiVersion: apps/v1beta1 kind: StatefulSet metadata: name:

    db-set spec: serviceName: "mysql" replicas: 1 template: metadata: labels: layer: db spec: terminationGracePeriodSeconds: 0 containers: - name: db image: "gcr.io/lamp-in-containers/locations-db" ports: - containerPort: 3306 name: mysql volumeMounts: - name: mysql-pvc mountPath: /var/lib/mysql volumeClaimTemplates: - metadata: name: mysql-pvc annotations: volume.alpha.kubernetes.io/storage-class: anything spec: accessModes: [ "ReadWriteOnce" ] resources: requests: storage: 1Gi Pod Persistent Volume Claim Stateful Set
  13. ‹#› @tpryan Deployment apiVersion: extensions/v1beta1 kind: Deployment metadata: name: frontend-deployment

    spec: replicas: 4 strategy: type: RollingUpdate template: metadata: labels: layer: ui spec: containers: - name: "frontend" image: "gcr.io/lamp-in-containers/locations-frontend" ports: - name: "http" containerPort: 80 protocol: TCP Pod Label
  14. ‹#› @tpryan Service apiVersion: v1 kind: Service metadata: labels: name:

    frontend name: frontend spec: type: LoadBalancer ports: - port: 80 targetPort: 80 protocol: TCP selector: layer: ui Selector
  15. ‹#› @tpryan ui Pod ui deployment ui Pod ui Pod

    ui Pod ui service (public) api Pod api deployment api service (public) api Pod api Pod db statefulset db service (private) db Pod
  16. ‹#› @tpryan Kubernetes is Open Source We want your help!

    • http://kubernetes.io • https://github.com/kubernetes/kubernetes • irc.freenode.net #google-containers • @kubernetesio
  17. ‹#› @tpryan Roadmap Kubernetes 1.6 Released: March 2017 • Scale

    enhancement - 5000 nodes, 150,000 pods • Advanced Scheduling • Storage Enhancements for
 AWS, Azure, GCP, OpenStack and VMware vSphere • Interesting alpha: • Nvidia GPU support http://blog.kubernetes.io/2017/03/kubernetes-1.6-multi-user-multi-workloads-at-scale.html
  18. ‹#› @tpryan Everything at Google runs on Containers: • Gmail,

    Web Search, Maps, ... • MapReduce, batch, ... • GFS, Colossus, ... • Even Google’s Cloud Platform: VMs run in containers! We launch 2 Billion Containers a week
