They see me pollin, they hatin

They see me pollin, they hatin

Polling is the new WebSocket! In this talk I'll scratch the surface about the state of the real-time web the issues that surrounds it and the lessons we have learned from building Socket.IO, and how we apply them to Engine.IO and Socket.IO 1.0

Arnout Kazemier

March 12, 2013
Tweet

More Decks by Arnout Kazemier

Other Decks in Technology

Transcript

  1. 2

  2. WebSockets? WebSockets? 5 OMG, dude, polling is so 1995! Why

    no WebSockets? WebSockets? OMG, dude, polling is so 1995! Why no WebSockets? WebSockets? OMG, dude, polling is so 1995! Why no WebSockets? WebSockets? OMG, dude, polling is so 1995! Why no
  3. 7 20+ 12+ 12.1+ 6+ 10+ RFC RFC RFC RFC

    RFC Chrome for Android 18+ Firefox for Android 15+ Opera Mobile 12+ RFC RFC RFC Browser supporting latest protocol
  4. 8 4+ 4+ 11+ 4.2+ 10+ Chrome for Android 18+

    Firefox for Android 15+ Opera Mobile 12+ Browser supporting a protocol
  5. ⚠ Using or detecting HTTP proxies crashes Safari < 5.1.4

    and iOS Mobile WebKit This causes full browser crashes or tab crashes. HTTP proxies cannot be detected easily. 10
  6. ⚠ if ( // Target safari browsers $.browser.safari // Not

    chrome && !$.browser.chrome // And correct WebKit version && parseFloat($.browser.version, 0) < 534.54 ) { // Don’t use websockets return; } 11
  7. ⚠ Writing to a closed WebSocket connection can cause a

    crash This happens on Mobile Safari when returning to the page after backgrounding Safari or coming back from a different tab. 13
  8. ⚠ var ws = new WebSocket("wss://localhost:8080/"); ws.onmessage = function message(event)

    { // Wrap sends in a setTimeout out to allow the // readyState to be correctly set to closed setTimeout(function () { ws.send("Sup AmsterdamJS"); }); }; 14
  9. ⚠ var ws = new WebSocket("wss://localhost:8080/"); ws.onmessage = function message(event)

    { // Wrap sends in a setTimeout out to allow the // readyState to be correctly set to closed. But // Only have this delay on mobile devices if (mobile) return setTimeout(function () { ws.send("Sup AmsterdamJS"); }); ws.send("Sup AmsterdamJS"); }; 15
  10. ⚠ 3G, 4G, LTE mobile connections.. dafuq It’s not just

    one mobile provider, it’s a lot of them. They are either running reversed proxies or simply block WebSockets. Shame on you AT&T 16
  11. ⚠ var ua = navigator.userAgent.toLowerCase(); // Detect all possible mobile

    phones to filter out // WebSockets if ( ~ua.indexOf('mobile') || ~ua.indexOf('android') || ~ua.indexOf('ios') || .. and more .. ) { // Don't use WebSockets } 17
  12. ⚠ Pressing ESC in Firefox will close all active network

    connections. Not only during page load, but also after page load. The issue remains the same. This is fixed in Firefox Nightly (20) all other version are affected. 18
  13. ⚠ $('body').keydown(function (e) { // make sure that you capture

    the `esc` key and // prevent it's default action from happening if (e.which === 27) e.preventDefault(); }); 19
  14. ⚠ Be careful when sending UTF-8/16 to Node.js This can

    cause WebSocket connection drops as V8 uses UCS encoding internally instead of modern UTF-16 20
  15. ⚠ var ws = new WebSocket("wss://localhost:8080/"); ws.onopen = function(event) {

    // encode and then unescape all messages that // contain utf 8 or user input. ws.send(unescape(encodeURIComponent( ))); }; 21 shitty emoji’s
  16. ⚠ Firefox cannot connect using ws:// from a HTTPS secured

    server It throws an “SecurityError: The operation is insecure.” error. Firefox 8+ 22
  17. ⚠ Don’t use self signed certificates Just don’t, some browsers

    give you no way of accepting them when using WebSockets. And you look like a cheap d*ck for not buying a proper cert 23
  18. It can’t be worse, right?! Debugging browser compatibility is nothing

    compared to debugging connection blocking ⚠ 24
  19. Enterprise proxy usually block everything except ports: 80, 443, 843

    Virus scanners on the other hand target port 80 ⚠ 26
  20. 27

  21. 31

  22. 5% 6% 3% 86% No Proxy, Success With Proxy, Failed

    With Proxy, Success No Proxy, Failed 36
  23. 70.00 75.00 80.00 85.00 90.00 443 with SSL 80 8080

    443 no SSL Success rate by port number 39
  24. 41 ⇆ Socket.IO Socket.IO aims to make realtime apps possible

    in every browser and mobile device, blurring the differences between the different transport mechanisms. It's care-free real-time 100% in JavaScript.
  25. 42 488 Packages depend on Socket.IO 7,701 Stars on Github

    & 1, 878 on the client. 488 Forks on Github & 363 on the client. 4418 Users on Google Groups. Big community
  26. 43 WebSocket Supports old HIXIE drafts as well as the

    latest RFC specification. FlashSocket Fallback for browser that do not support WebSockets. A Flash file that emulates the WebSocket protocol so you can still bi-directional communication. HTML File Basically it’s a streaming iframe wrapped with some ActiveX magic. Sending data is done through XHR POST. Internet Explorer only, does not do cross domain. XHR Polling Long polling. Cross domain usage depends on the browser. JSONP Polling Injects small scripts in the page for fetching data and uses iframe’s and form posts to send the data to the server.   ⇆ 
  27. 44 ⇆ The --save tells npm to automatically add the

    installed version to your package.json file. Additionally you can also install the socket.io-client module if you want to connect to server from within node.js. npm install socket.io --save
  28. 45 ⇆ var io = require('socket.io').listen(8080); io.sockets.on('connection', function (socket) {

    socket.on('another event', function (data) { // Client emitted a custom event socket.emit('custom event', data); }); socket.on('disconnect', function () { // Socket disconnected }); socket.send('hi there'); // Automatic JSON encoding using a json flag socket.json.send({ foo: 'bar' }); // Broadcast the message/event to every // connected user socket.broadcast.json.send({ foo: 'bar' }); });
  29. 46 ⇆ var io = require('socket.io').listen(8080); io.sockets.on('connection', function (socket) {

    socket.on('another event', function (data) { // Client emitted a custom event socket.emit('custom event', data); }); socket.on('disconnect', function () { // Socket disconnected }); socket.send('hi there'); // Automatic JSON encoding using a json flag socket.json.send({ foo: 'bar' }); // Broadcast the message/event to every // connected user socket.broadcast.json.send({ foo: 'bar' }); }); Creating: The listen method accepts either a HTTP server instance or it will create one for you with listens on the supplied port number
  30. 47 ⇆ var io = require('socket.io').listen(8080); io.sockets.on('connection', function (socket) {

    socket.on('another event', function (data) { // Client emitted a custom event socket.emit('custom event', data); }); socket.on('disconnect', function () { // Socket disconnected }); socket.send('hi there'); // Automatic JSON encoding using a json flag socket.json.send({ foo: 'bar' }); // Broadcast the message/event to every // connected user socket.broadcast.json.send({ foo: 'bar' }); }); Namespaces: the io.sockets points to the default namespace of your socket.io server. One server can have multiple namespaces or “endpoints”.
  31. 48 ⇆ var io = require('socket.io').listen(8080); io.sockets.on('connection', function (socket) {

    socket.on('another event', function (data) { // Client emitted a custom event socket.emit('custom event', data); }); socket.on('disconnect', function () { // Socket disconnected }); socket.send('hi there'); // Automatic JSON encoding using a json flag socket.json.send({ foo: 'bar' }); // Broadcast the message/event to every // connected user socket.broadcast.json.send({ foo: 'bar' }); }); Flags: the broadcast and json are instructions to socket.io on how to send this message. But there are more: - json: Automatically JSON encoding - broadcast: Send message to every connected user except your self. - volatile: Send message, we don’t care if it get’s lost in the transaction. - in(<room>): Send the message to everybody that is in this room.
  32. 49 ⇆ // Connect to a custom domain var socket

    = io.connect('http://domain.com'); socket.on('connect', function () { // Socket connected socket.json.send({ foo: 'bar'}); }); socket.on('custom event', function (data) { // Server emitted a custom event socket.emit('another event', data); }); socket.on('disconnect', function () { // socket disconnected }); socket.send('hi there');
  33. 50 ⇆ // Connect to a custom domain var socket

    = io.connect('http://domain.com'); socket.on('connect', function () { // Socket connected socket.json.send({ foo: 'bar'}); }); socket.on('custom event', function (data) { // Server emitted a custom event socket.emit('another event', data); }); socket.on('disconnect', function () { // socket disconnected }); socket.send('hi there'); Crossdomain: When you don’t supply it with a URL it will connect to page that loads the socket.io code and supply it with a custom domain to do cross domain connections.
  34. 51 Engine.IO Engine.io is the implementation of transport-based cross-browser/cross- device

    bi-directional communication layer for Socket.IO. But it can also be used as standalone server. ⇆
  35. 52 ⇆ var engine = require('engine.io') , server = engine.listen(80)

    server.on('connection', function (socket) { socket.on('message', function () { // New message from the client }); socket.on('close', function () { // Connection closed }); socket.send('utf 8 string'); });
  36. 53 ⇆ var engine = require('engine.io') , server = engine.listen(80)

    server.on('connection', function (socket) { socket.on('message', function () { // New message from the client }); socket.on('close', function () { // Connection closed }); socket.send('utf 8 string'); }); MIA: On the server side there are a couple of differences, it misses a lot of “features” that were build in. Like namespaces, rooms, automatic JSON encoding etc. But in return you get a really low level API
  37. 54 ⇆ var socket = require('engine.io')('ws://localhost'); socket.onopen = function ()

    { socket.onmessage = function (data) { // New message from the server }; socket.onclose = function () { // Connection closed }; }; Component: The Engine.IO client is now component based. Component is a small JavaScript framework that brings node style dependencies and requires to the front-end. MIA: Same as on the server side, it misses a lot of features like no events, json encoding, namespaces, authentication etc.
  38. 57 ⇆ Socket.IO 1.0 Socket.io 1.0 will be build on

    top of Engine.io and will supply the missing features that your used to in socket.io.
  39. Don’t use WebSockets on mobile To much undetectable issues and

    polling works better for network switching and crappy networks. 59
