1. Android development with Jetpack Compose
2. Android GDE
 🛠 Individual Consultant
 🔊 Speaker
 🌎 Globe Tro tt er
 🍻 Beer enthusiast 🎯https:/ /androiddev.social/@aditlal 🔗aditlal.dev
3. This work is licensed under the Apache 2.0 License
5. Jetpack Compose / jet ·pak kuhm· powz / noun Jetpack Compose is a declarative & modern toolkit for building native Android UI. It simpli fi es and accelerates UI development on Android.
6. Why do we need Compose? What does it solve and how?
7. Before Compose UI Toolkit is tied to the OS State Management is tricky Lots of context switching Simple things still require a lot of code
8. With Compose UI Toolkit is independent to the OS 🪄 State Management is built in🥳 Lots of context switching 🎉 So rt ed code logic 🚀
10. Activity class MainActivity : ComponentActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { . . . } } }
11. Activity class MainActivity : ComponentActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { . . . } } }
12. setContent public fun ComponentActivity.setContent( parent: CompositionContext? = null, content: @Composable () - > Unit ) { / / some magic code🪄 } }
13. What are we gonna learn today?
14. TOPIC TIME(in hr:mins) Thinking in Compose 0:05 Modifiers 0:20 Layouts 0:30 State management 0:45 SideEffects 1:00 Codelab - idea Today’s Schedule
15. Imperative
16. <ConstraintLayout> <ImageView /> <TextView /> <TextView /> </ ConstraintLayout> Imperative
17. View Group View Imperative
18. val textView = findViewById(R.id.textView) Imperative
19. textView.text = ... Imperative val textView = findViewById(R.id.textView)
20. Declarative UI
21. ✓ Declarative UI is cleaner, more readable, and more performant than Imperative UI. ✓ Compose allows you to do more with less code compared to XML. ✓ Compose is Intuitive. This means that you just need to tell Compose what you want to show the user. ✓ Compose is compatible with all your existing code: you can call Compose code from Views and Views from Compose. Also integrated with many Jetpack Libraries. ✓ Compose improves your build time and APK size. Declarative UI Compose
22. Hello Adit Declarative UI
23. @Composable fun Greeting(name: String) { } Declarative UI
24. @Composable fun Greeting(name: String) { Text(text = "Hello $name!") } Hello Adit Declarative UI
25. Update state? Hello Mike Declarative UI
26. Modifiers
27. Text ( modifier = Modifier .padding(10.dp), text = "Hello World" ) Hello World Modifiers
28. Text ( modifier = Modifier . background (Color.Green), text = "Hello World" ) Hello World .padding(10.dp) Modifiers
29. Text ( modifier = Modifier . border( width = 2.dp, color = Color.Green ), text = "Hello World" ) Hello World .padding(10.dp) Modifiers
30. Text ( modifier = Modifier text = "Hello World" ) Hello World Order ma tt ers . border( width = 2.dp, color = Color.Green ) .padding(10.dp) .padding(10.dp), Modifiers
31. Hello World Text ( modifier = Modifier . border( width = 2.dp, color = Color.Green ), text = "Hello World" ) .padding(10.dp) Order ma tt ers Modifiers
32. Hello World Text ( modifier = Modifier .border( width = 2.dp, color = Color.Green ) .background(Color.Green), text = "Hello World" ) .padding(10.dp) Modifiers
33. h tt ps://developer.android.com/jetpack/compose/modi fi ers-list
34. Layouts
35. Column
36. Column { } Column
37. Column { Text ( "Hello Text ( "Hello Text ( "Hello } World" ) World" ) World" ) Hello World Hello World Hello World Column Column { }
38. Column( verticalArrangement = ) } { X Y Column Arrangement.Center
39. Hello World Hello World Hello World Column Column( verticalArrangement = ) } { Arrangement.SpaceBetween
40. Column( horizontalAlignment = ) } { X Y Column
41. Hello World Hello World Hello World Column Column( horizontalAlignment = ) } { Alignment.End
42. Column Column( horizontalAlignment = ) } { Alignment.CenterHorizontally Hello World Hello World Hello World
43. Row
44. Row { Text ( “Hello" ) Text ( "World" ) Text ( “!" ) HelloWorld! } Row
45. Row( horizontalArrangement = ) } { X Y Row
46. Hello World ! Row Row( horizontalArrangement = ) } { Arrangement.SpaceBetween
47. Row( verticalAlignment = ) } { X Y Row
48. HelloWorld! Row Row( verticalAlignment = ) } { Alignment.CenterVertically
49. Column Row Ve rt ical Arrangement Horizontal Arrangement Horizontal Alignment Ve rt ical Alignment Row & Column
50. Row & Column
51. Row { Image(…) } Row & Column
52. Row { Image(…) Column { } } Row & Column
53. Row { Image(…) Column { Text ( “…” ) Text ( “…” ) } } Row & Column
54. Box
55. Box { Image(…) } Box
56. Box { Image(…) Column { Text(…) Text(…) } } Box
57. Box } Box { Image(…) Column(Modifier.align(Alignment.BottomEnd)) { Text(…) Text(…) }
58. List
59. fun EmployeeListView (items: List<Item>) { LazyColumn { } } List @Composable
60. @Composable fun EmployeeListView (items: List<Item>) { LazyColumn { items (items) { item -> } } } List
61. @Composable fun EmployeeListView (items: List<Item>) { LazyColumn { items (items) { item -> ItemRow(item) } } } List
62. Slot Layouts
63. Scaffold(topBar = {}) { } Slot Layouts
64. Home Slot Layouts Text(text = “Home") Scaffold(topBar = { { } })
65. Hello World Slot Layouts Text(text = “Home") Scaffold(topBar = { { } }) Home Text(text = “Hello World”)
66. • Column • Row • Box • Sca ff old Layouts
67. Layout modifiers
68. Layout modifiers
69. Column { Hello World Hello World } Text( text = "Hello World”, modifier = Modifier.background(Color.Green) ) Text( text = "Hello World”, modifier = Modifier.background(Color.Green) ) Layout modifiers
70. Column ( Modifier .background(Color.Green) .fillMaxWidth() ) { } Hello World Hello World Text( text = "Hello World”, modifier = Modifier.background(Color.Green) ) Text( text = "Hello World”, modifier = Modifier.background(Color.Green) ) Layout modifiers
71. Hello World Hello World Column ( Modifier .background(Color.Green) .fillMaxSize() ) { } Text( text = "Hello World”, modifier = Modifier.background(Color.Green) ) Text( text = "Hello World”, modifier = Modifier.background(Color.Green) ) Layout modifiers
72. Hello World Hello World 200dp Column ( Modifier .background(Color.Green) .width(200.dp) ) { } Text( text = "Hello World”, modifier = Modifier.background(Color.Green) ) Text( text = "Hello World”, modifier = Modifier.background(Color.Green) ) Layout modifiers
73. State management
74. • Setup state using mutableStateOf State management
75. 0 + - State management
76. val counter by remember { mutableStateOf(0) 0 } State management
77. Column { Text ( text = counter.toString() 0 ) ... } State management
78. Button ( ) { onClick = { counter ++ } 0 Text ( text = "+" ) } + - State management
79. Button ( ) { onClick = { counter -- } 0 Text ( text = “-" ) } + - State management
80. Composable UI-Redraw Event Recomposition
81. Val counter by remember { mutableStateOf(0) 0 } + - Recomposition
82. Search State management
83. View Model Event Search Search View State management
84. SideEffects
85. • Work outside of composable function • Open new screen when tapping bu tt on • Show no network message SideEffects
86. A side effect of composition that must be reversed or cleaned up if the DisposableEffect leaves the composition. It is an error to call DisposableEffect without at least one key parameter. Schedule effect to run when the current composition completes successfully and applies changes. SideEffect can be used to apply side effects to objects managed by the composition that are not backed by snapshots so as not to leave those objects in an inconsistent state if the current composition operation fails. When LaunchedEffect enters the composition it will launch the block into the composition's CoroutineContext. The coroutine will be canceled and re-launched when LaunchedEffect is recomposed with a different key1. The coroutine will be canceled when the LaunchedEffect leaves the composition. LaunchedEffect SideEffect DisposableEffect SideEffects
87. A side effect of composition that must be reversed or cleaned up if the DisposableEffect leaves the composition. It is an error to call DisposableEffect without at least one key parameter. Schedule effect to run when the current composition completes successfully and applies changes. SideEffect can be used to apply side effects to objects managed by the composition that are not backed by snapshots so as not to leave those objects in an inconsistent state if the current composition operation fails. When LaunchedEffect enters the composition it will launch the block into the composition's CoroutineContext. The coroutine will be canceled and re-launched when LaunchedEffect is recomposed with a different key1. The coroutine will be canceled when the LaunchedEffect leaves the composition. LaunchedEffect SideEffect DisposableEffect SideEffects
88. • Triggers on fi rst composition or key change @Composable fun HomeView () { var counter by remember { mutableStateOf ( 0 ) } } LaunchedEffect
89. • Triggers on fi rst composition or key change @Composable fun HomeView () { var counter by remember { mutableStateOf ( 0 ) } } LaunchedEffect { while(true) { counter ++ } } LaunchedEffect
90. • Triggers on fi rst composition or key change @Composable fun HomeView () { var counter by remember { mutableStateOf ( 0 ) } } LaunchedEffect { while(true) { counter ++ } } delay(2000) LaunchedEffect
91. • Triggers on fi rst composition or key change @Composable fun HomeView () { var counter by remember { mutableStateOf ( 0 ) } } LaunchedEffect(key1 = Unit){ while(true) { counter ++ } } delay(2000) LaunchedEffect
92. Schedule effect to run when the current composition completes successfully and applies changes. SideEffect can be used to apply side effects to objects managed by the composition that are not backed by snapshots so as not to leave those objects in an inconsistent state if the current composition operation fails. When LaunchedEffect enters the composition it will launch the block into the composition's CoroutineContext. The coroutine will be canceled and re-launched when LaunchedEffect is recomposed with a different key1. The coroutine will be canceled when the LaunchedEffect leaves the composition. LaunchedEffect SideEffect SideEffects A side effect of composition that must be reversed or cleaned up if the DisposableEffect leaves the composition. It is an error to call DisposableEffect without at least one key parameter. DisposableEffect
93. • Calls SideE ff ect when we want conditional e ff ect @Composable fun SearchBar() { } val focusRequester = remember { FocusRequester() } SideEffect { if(focused && !isSearchDummy) focusRequester.requestFocus() } SideEffect
94. A side effect of composition that must be reversed or cleaned up if the DisposableEffect leaves the composition. It is an error to call DisposableEffect without at least one key parameter. Schedule effect to run when the current composition completes successfully and applies changes. SideEffect can be used to apply side effects to objects managed by the composition that are not backed by snapshots so as not to leave those objects in an inconsistent state if the current composition operation fails. When LaunchedEffect enters the composition it will launch the block into the composition's CoroutineContext. The coroutine will be canceled and re-launched when LaunchedEffect is recomposed with a different key1. The coroutine will be canceled when the LaunchedEffect leaves the composition. LaunchedEffect SideEffect DisposableEffect SideEffects
95. DisposableEffect • Calls onDispose on terminate @Composable fun HomeView() { DisposableEffect (...) { onDispose { callback.remove() } } }
97. Code class MainActivity : ComponentActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { NotesApplicationTheme { / / A surface container using the 'background' color from the theme Surface( modif i er = Modif i er.f i llMaxSize(), color = MaterialTheme.colors.background ) { Greeting("Android") } } } }
98. Code class MainActivity : ComponentActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { NotesApplicationTheme { / / A surface container using the 'background' color from the theme Surface( modif i er = Modif i er.f i llMaxSize(), color = MaterialTheme.colors.background ) { Greeting("Android") } } } }
99. Code class MainActivity : ComponentActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { NotesApplicationTheme { / / A surface container using the 'background' color from the theme Surface( modif i er = Modif i er.f i llMaxSize(), color = MaterialTheme.colors.background ) { Greeting("Android") } } } }
100. Code class MainActivity : ComponentActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { NotesApplicationTheme { / / A surface container using the 'background' color from the theme Surface( modif i er = Modif i er.f i llMaxSize(), color = MaterialTheme.colors.background ) { Greeting("Android") } } } }
101. Code class MainActivity : ComponentActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { NotesApplicationTheme { / / A surface container using the 'background' color from the theme Surface( modif i er = Modif i er.f i llMaxSize(), color = MaterialTheme.colors.background ) { Greeting("Android") } } } }
102. Composable @Composable fun Greeting(name: String) { Text(text = "Hello $name!") } @Preview(showBackground = true) @Composable fun DefaultPreview() { NotesApplicationTheme { Greeting("Android") } }
103. Demo https://developer.android.com/codelabs/jetpack-compose-basics
104. https://github.com/aldefy/Andromeda
 https://bit.ly/3Nic0JF - Sample catalog app

 Andromeda is an open-source Jetpack Compose design system. A collection of guidelines and components can be used to create amazing compose app user experiences. Foundations introduce Andromeda tokens and principles while Components provide the bolts and nuts that make Andromeda Compose wrapped apps tick. Check out
105. Thats all folks! https://linktr.ee/aldefy
