The Future of Ruby Performance Tooling

The Future of Ruby Performance Tooling

A presentation I gave at Gotham Ruby Conf 2014 (http://goruco.com) about Ruby Performance Tooling and what we've been doing at Paperless Post. There were a couple videos in the slides so unfortunately those are not included here. Video should be up soon though.

Aaron Quint

June 21, 2014
Tweet

More Decks by Aaron Quint

Other Decks in Programming

Transcript

  1. Connecting Ruby Server HTML DL CSS DL JS DL Images

    JS onLoad() Done 0-10ms 10-30,000ms 30ms 150ms 100-50,000ms
  2. Connecting Ruby Server HTML DL CSS DL JS DL Images

    Sorted by how much control we have to improve
  3. • Specificity (Sp) • Impact (Im) • Difficulty of Operator

    Use (Op) • Readability (Rd) • Realtimedness (Rl) • Special Abilities (SA)
  4. class StatsdSubscriber < ActiveSupport::LogSubscriber attr_reader :event ! def log_action(event) payload

    = event.payload[:controller_data] prefix = “controller.#{payload[:method]}.#{payload[:controller].to_s.gsub(‘::’,'_')}." %w{view db total}.each do |metric| value = payload["#{metric}_runtime".to_sym] Paperless::Statsd.timing("#{prefix}.#{metric}", value) if value Paperless::Statsd.timing("controller.#{metric}", value) if value end end ! end
  5. AS:Notify Sp: 5-10 Im: 5-10 Op: 7 Rd: 2-10 Rl:

    9 • Special Abilities: Graphs! • Good for: p90s, what _layers_ are slow? Trending data. • Not Good for: Giving you details about anything. Easy to misinterpret data.
  6. RblineproF Sp: 9 Im: 9 Op: 8 Rd: 7 Rl:

    3 • Special Abilities: Amazing visibility into dev hotspots • Good for: Diving deep into slow actions. • Not Good for: Discovery or fixing of systematic issues. Real world numbers.
  7. PPprofiler +2 Op +2 Rd • Special Abilities: Tracks local

    improvements. • Good for: Golf. Sharing improvements with team. • Not Good for: Production. This is about local.
  8. $ stackprof ~/Downloads/stackprof-cpu-1402024056.dump ================================== Mode: cpu(1000) Samples: 562 (0.35% miss

    rate) GC: 71 (12.63%) ================================== TOTAL (pct) SAMPLES (pct) FRAME 33 (5.9%) 33 (5.9%) ActiveRecord::Base.scoped_methods 30 (5.3%) 30 (5.3%) ActiveRecord::ConnectionAdapters::PostgreSQLAdapter#… 26 (4.6%) 26 (4.6%) ActiveSupport::CoreExtensions::Hash::Keys#assert_valid_keys 24 (4.3%) 24 (4.3%) block in ActiveRecord::ConnectionAdapters::..#execute 14 (2.5%) 14 (2.5%) block in ActiveSupport::Inflector#singularize 13 (2.3%) 12 (2.1%) block in ActiveSupport::Notifications::Fanout#listeners_for 12 (2.1%) 12 (2.1%) ActiveRecord::Reflection::AssociationReflection#klass 19 (3.4%) 12 (2.1%) ActiveRecord::ConnectionAdapters::ConnectionHandler#… 11 (2.0%) 11 (2.0%) block in ActiveRecord::Base.with_scope 797 (141.8%) 11 (2.0%) ActiveRecord::Base.with_scope 18 (3.2%) 8 (1.4%) ActiveRecord::Base.quote_bound_value 7 (1.2%) 7 (1.2%) Haml::Helpers#preserve 79 (14.1%) 7 (1.2%) block in ActiveRecord::Base.with_scope 6 (1.1%) 6 (1.1%) block (2 levels) in ActiveRecord::Base.connection_handler= 72 (12.8%) 6 (1.1%) block (2 levels) in ActiveRecord::Base.with_scope
  9. StackProF Sp: 4 Im: 2 Op: 3 Rd: 4-6 Rl:

    9 • Special Abilities: FLAMEGRAPHS • Good for: Finding systemic issues in production. • Not Good for: Detailed info about whats slow in YOUR code.
  10. require 'stackprof/remote/middleware' ! enabled = proc do |env| magic_method ||

    Rails.env.development? end ActionController::Dispatcher.middleware.use StackProf::Remote::Middleware, enabled: enabled, logger: Rails.logger
  11. SP::Remote +4 Op +2 Rd +1 Rl • Special Abilities:

    Interactive StackProf • Good for: Easily introspecting a production server. • Not Good for: Development.
  12. $ ./bin/rbtrace -p 8963 -e 'GC.start(full_mark: true); require “objspace”;\ ObjectSpace.dump_all(output:

    File.open(“heap.json","w"))' ! $ ls -lh heap.json -rw-r--r-- 1 aaronquint staff 87M Jun 16 21:52 heap.json
  13. {"address":"0xf583b8", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "bytesize":13, "value":"output_format", "encoding":"UTF-8", "flags":{"wb_protected":true, "old":true,

    "marked":true}} {"address":"0xf583e0", "type":"OBJECT", "class":"0x2471268", "frozen":true, "ivars":3, "references":["0xf58480"], "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58458", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "bytesize":10, "value":"transforms", "encoding":"UTF-8", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58480", "type":"STRING", "class":"0xf11620", "embedded":true, "bytesize":1, "value":"/", "encoding":"UTF-8", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf584d0", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "bytesize":6, "value":"output", "encoding":"UTF-8", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58570", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "bytesize":11, "value":"progressive", "encoding":"UTF-8", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58598", "type":"OBJECT", "class":"0x2470b10", "frozen":true, "ivars":3, "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58610", "type":"OBJECT", "class":"0x24714e8", "frozen":true, "ivars":3, "references":["0xf58638"], "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58638", "type":"STRING", "class":"0xf11620", "embedded":true, "bytesize":3, "value":"api", "encoding":"UTF-8", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58700", "type":"OBJECT", "class":"0x24714e8", "frozen":true, "ivars":3, "references":["0xf58750"], "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58728", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "fstring":true, "bytesize" 8, "value":"ASTERISK", "encoding":"US-ASCII", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58750", "type":"STRING", "class":"0xf11620", "shared":true, "encoding":"UTF-8", "references": ["0xf5f1b8"], "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf587a0", "type":"STRING", "class":"0xf11620", "frozen":true, "bytesize":24, "capacity":48, "value":"ActionController::CgiExt", "encoding":"US-ASCII", "memsize":49, "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf587c8", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "bytesize":5, "value":"strip", "encoding":"UTF-8", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf587f0", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "fstring":true, "bytesize" 9, "value":"SEV_LABEL", "encoding":"US-ASCII", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58840", "type":"OBJECT", "class":"0x2471268", "frozen":true, "ivars":3, "references":["0xf588e0"], "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf588b8", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "fstring":true, "bytesize" 6, "value":"DOLLAR", "encoding":"US-ASCII", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf588e0", "type":"STRING", "class":"0xf11620", "embedded":true, "bytesize":1, "value":"/", "encoding":"UTF-8", "flags":{"wb_protected":true, "old":true, "marked":true}} {"address":"0xf58930", "type":"STRING", "class":"0xf11620", "frozen":true, "embedded":true, "bytesize":12, "value":"version_name", "encoding":"UTF-8", "flags"
  14. ObjecTSpacE Sp: 10 Im: 10 Op: 3 Rd:3 Rl: 2

    • Special Abilities: Every. Object. • Good for: Potential for diagnosing memory issues. • Not Good for: Hard to fetch from running systems.
  15. ObSViewer +2 Rd • Total WIP • The data is

    there, we just need better tools to gain analysis
  16. — The Strategy Use low impact tools to collect data

    from production and high impact tools to measure the relative improvements of iterative changes in development and staging.
  17. THANKS! ! twitter: @aq code: github.com/quirkey ! rblineprof: github.com/tmm1/rblineprof stackprof:

    github.com/tmm1/stackprof ppprofiler: dev.paperlesspost.com stackprof-remote: github.com/quirkey/stackprof-remote objspace_viewer: github.com/quirkey/objspace_viewer
