Membangun Modern App dengan Jetpack & Android Architecture Component - SIGMATECH

Record : https://youtu.be/VVeVD9lUMuU

Transcript

1. Membangun Modern App dengan Jetpack & Android Architecture Component Ahmad Arif Faizin Curriculum Developer - Dicoding Indonesia
2. Our Company Mercury is the closest planet to the Sun and the smallest one in the Solar System—it’s only a bit larger than the Moon. The planet’s name has nothing to do with the liquid metal, since it was named after the Roman messenger god, Mercury
3. Table of Contents Modern App 01 Android Jetpack 02 Architecture Layer 03 Android Architecture Component 04
4. Modern App 01
6. “Classic” Android Development
7. Classic Development Java As programming language Eclipse As IDE APK As distribution file
8. “Modern” Android Development
9. Classic Development
10. Kotlin Benefit
11. Dynamic Delivery with AAB (Android App Bundle)
12. Android Jetpack 02
13. Android Jetpack? Kiri, Kanan, L1, L2, R1, R2, Atas, Bawah, Kiri, Kanan
15. Android Jetpack
16. Jetpack Growing
17. Highlighted Libraries
18. Jetpack Compose
19. Paging
20. Material Design 3
21. Architecture Layer 03
22. Hindari short-term hack! • Mendesain aplikasi hanya untuk perangkat tertentu saja • Copy paste kode ke dalam file Anda secara membabi buta • Menuliskan secara hardcode untuk string yang tampil • Menempatkan semua business logic dalam file Activity
24. Mengapa Perlu Architecture? • Separation of Concern (SoC), memisahkan business logic dan ui logic. • Memudahkan developer untuk saling berkolaborasi. • Kode jadi lebih mudah dites. • Menghemat waktu dan mengurangi technical debt saat project berkembang.
25. Recommended app architecture
26. UI Layer
27. Unidirectional Data Flow (UDF)
28. Data Layer
29. Data Layer
30. Best Practice • Jangan jadikan activity, services, & broadcast sebagai sumber data. • Buat batasan yang jelas antar module. • Expose sedikit mungkin data pada setiap module. • Pertimbangkan cara membuat setiap modul dapat diuji secara terpisah. • Jangan menulis kode yang sama berulang-ulang (boilerplate) • Sebisa mungkin simpan data yang relevan dan terbaru. • Tetapkan satu sumber data sebagai single source of truth.
31. Android Architecture Component 04
32. Komponen AAC
33. Komponen AAC • ViewModel - Handle data ke UI dan mengatasi configuration change • LiveData - data holder yang lifecycle-aware dan bisa di-observe secara real-time untuk mendapatkan data terbaru • Repository - untuk mengatur beberapa sumber data (network, database, cache) • Room - abstraksi di atas SQLite, untuk simpan database dengan lebih simple dan mudah
34. Contoh Bad Code : All in One Activity class MainActivity : AppCompatActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) ... btnCalculate.setOnClickListener { val length = edtLength.text.toString().toDouble() val width = edtWidth.text.toString().toDouble() val height = edtHeight.text.toString().toDouble() //business logic in Activity (DON’T!) val volume = length * width * height tvResult.text = volume.toString() } } }
35. Separation of Concerns
36. Membuat Model dan ViewModel class MainRepository { fun getVolume(length:Double, width:Double, height:Double): Double { return length * width * height } } MainRepository.kt class MainViewModel : ViewModel() { var result = 0.0 var mainRepo = MainRepository() fun calculate(width: Double, height: Double, length: Double) { result = mainRepo.getVolume(width, height, length) } } MainViewModel.kt
37. Contoh Good Code : Menerapkan ViewModel class MainActivity : AppCompatActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) ... val viewModel=ViewModelProvider(this).get(MainViewModel::class.java) tvResult.text = viewModel.result.toString() btnCalculate.setOnClickListener { val length = edtLength.text.toString().toDouble() val width = edtWidth.text.toString().toDouble() val height = edtHeight.text.toString().toDouble() viewModel.calculate(width, height, length) //no business logic in Activity (DO!) } } }
38. —Robert C. Martin ““Good architecture makes the system easy to understand, easy to develop, easy to maintain, and easy to deploy.”
39. Resources • https://d.android.com/mad • https://d.android.com/jetpack • https://goo.gle/mad-architecture
40. CREDITS: This presentation template was created by Slidesgo, including icons by Flaticon, and infographics & images by Freepik Thanks Do you have any questions? arif@dicoding.com 0857 4048 2440 https://instagram.com/arif_faizin arifaizin.medium.com Please keep this slide for attribution
