Wix Architecture At Scale

QCon London 2014.
In this talk I will go over Wix's architecture, how we evolved our system to be highly available even at the worst case scenarios when everything can break, how we built a self-healing eventual consistency system for website data distribution and will show some of the patterns we use that helps us render 45M websites while maintaining a relatively low number of servers.

Transcript

1. Aviran Mordo Head of Back-End Engineering @ Wix @aviranm linkedin.com/in/aviran aviransplace.com Wix Architecture at Scale
3. Wix in Numbers Over 45,000,000 users 1M new users/month Static storage is >800TB of data 1.5TB new files/day 3 data centers + 2 clouds (Google, Amazon) 300 servers 700M HTTP requests/day 600 people work at Wix, of which ~ 200 in R&D
4. Initial Architecture Built for fast development Stateful login (Tomcat session), Ehcache, file uploads No consideration for performance, scalability and testing Intended for short-term use Tomcat, Hibernate, custom web framework Lighttpd (file serving) MySQL DB Wix (Tomcat)
5. The Monolithic Giant One monolithic server that handled everything Dependency between features Changes in unrelated areas of the system caused deployment of the whole system Failure in unrelated areas will cause system wide downtime
6. Breaking the System Apart
7. Concerns and SLA Data Validation Security / Authentication Data consistency Lots of data Edit websites High availability High performance Lots of static files Very high traffic volume Viewport optimization Cacheable data Serving Media High availability High performance High traffic volume Long tail View sites, created by Wix editor
8. Wix Segmentation 1. Editor Segment 3. Public Segment 2. Media Segment Networking
9. Making SOA Guidelines Each service has its own database (if one is needed) Only one service can write to a specific DB There may be additional read-only services that directly accesses the DB (for performance reasons) Services are stateless No DB transactions Cache is not a building block, but an optimization
10. 1. Editor Segment
11. Editor Server Immutable JSON pages (~2.5M / day) Site revisions Active – standby MySQL cross datacenters Editor Server MySQL Active Sites MySQL Archive
13. Protect The Data Protect against DB outage with fast recovery = replication Protect against data poisoning/corruption = revisions / backup Make the data available at all times = data distribution to multiple locations / providers
14. Browser Editor Server Static Grid Notify Google Cloud Storage MySQL Active Sites MySQL Archive Notify Saving Editor Data Archive (Amazon) Archive (Google) Save Page(s) 200 OK Upload Save Page DC replication Download Page MySQL Archive MySQL Active Sites
15. Browser Editor Server Static Grid Save Page(s) Save Page Upload Notify Download Page Google Cloud Storage MySQL Archive MySQL Active Sites MySQL Archive DC replication Notify Self Healing Process Archive (Amazon) Archive (Google) MySQL Active Sites 200 OK
16. No DB Transactions Save each page (JSON) as an atomic operation Page ID is a content based hash (immutable/idempotent) Finalize transaction by sending site header (list of pages) Can generate orphaned pages, not a problem in practice
17. 2. Media Segment
18. Prospero – Wix Media Storage 800TB user media files 3M files uploaded daily 500M metadata records Dynamic media processing • Picture resize, crop and sharpen “on the fly” • Watermark • Audio format conversion
19. Prospero Eventual consistent distributed file system Multi datacenter aware Automatic fallback cross DC Run on commodity servers & cloud
20. x36 T x36 T x32 Austin Prospero – Wix Media Manager get image.jpg First fallback Second fallback If not in CDN Google Cloud x36 T x36 T x32 Tampa CDN
21. 3. Public Segment
22. Public Segment Roles Routing (resolve URLs) Dispatching (to a renderer) Rendering (HTML,XML,TXT) Public Server HTML Renderer HTML SEO Renderer Flash Renderer Sitemap Renderer Robots.txt Renderer www.example.com Flash SEO Renderer
23. Public SLA Response time <100ms at peak traffic
24. Publish A Site Publish site header (a map of pages for a site) Publish routing table Publish site header / routes Editor Segment Public Segment
25. Built For Speed Minimize out-of-service hops (2 DB, 1 RPC) Lookup tables are cached in memory, updated every 5 minutes Denormalized data – optimize for read by primary key (MySQL) Minimize business logic
26. How a Page Gets Rendered Bootstrap HTML template that contains only data Only JavaScript imports JSON data (site-header + dynamic data) No “real” HTML view
27. Offload rendering work to the browser
28. The average Intel Core i750 can push up to 7 GFLOPS without overclocking
29. Why JSON? Easy to parse in JavaScript and Java/Scala Fairly compact text format Highly compressible (5:1 even for small payloads) Easy to fix rendering bugs (just deploy a new client code)
30. Minimum Number of Public Servers Needed to Serve 45M Sites 4
31. Public SLA Be Available 99.99999%
32. Serving a Site – Sunny Day Archive CDN Statics Browser http://example.wix.com Store HTML to cache HTTP Request Notify site view LB Public Renderer HTML Resources / Media HTTP Request
33. Serving a Site – DC Lost Archive CDN Statics Browser http://example.wix.com LB Public Renderer LB Public Renderer Change DNS HTTP Request
34. Serving a Site – Public Lost Archive CDN Statics Browser http://example.wix.com LB Public Renderer Get Cached HTML Version HTML HTTP Request
35. Living in the Browser Archive CDN Statics Browser http://example.wix.com LB Public Renderer Editor Fallback JSON / Media HTML HTTP Request Fallback
36. Summary Identify your critical path and concerns Build redundancy in critical path (for availability) De-normalize data (for performance) Minimize out-of-process hops (for performance) Take advantage of client’s CPU power
38. Aviran Mordo Head of Back-End Engineering @ Wix @aviranm linkedin.com/in/aviran aviransplace.com Q&A http://goo.gl/Oo3lGr
