Advanced A/B Testing

While A/B test is a very known and familiar methodology for conducting experiments on production when you do that on a large scale it has many challenges in the organization level and operational level.

At Wix we are practicing continuous delivery for over 4 years. Conducting A/B tests and writing feature toggles is at the core of our development process. However when doing so on a large scale, with over 1000 experiments every month, it holds many challenges and affect everyone in the company, from developers, product managers, QA, marketing and management.

In this talk we will explain what is the lifecycle of an experiment, some of the challenges we faced and the effect on our development process.

How an experiment begins its life
How an experiment is defined
How do you let non technical people control the experiment while preventing mistakes
How an experiment go live, what is the lifecycle of an experiment from beginning to end
What is the difference between client and server experiments
How do you keep the user experience and not confuse them
How does it affect the development process
How can QA test an environment that changes every 9 minutes
How can support help users when every user may be part of different experiment
How can we find if an experiment is causing errors when you have millions of permutations [at least 2(number of active experiments)]
What are the effects of always having multiple experiments on system architecture
What are the development patterns when working with AB test

At Wix we have developed our 3rd generation experiment system called PETRI, which is (will be) open sourced, that helps us maintain some order in a chaotic system that keep changing. We will also explain how PETRI works, what are the patterns in conducting experiments that will have a minimal effect on performance and user experience.

Transcript

1. Experimenting on Humans Aviran Mordo Head of Back-end Engineering @aviranm www.linkedin.com/in/aviran www.aviransplace.com Sagy Rozman Back-end Guild master www.linkedin.com/in/sagyrozman @sagyrozman
3. Wix In Numbers •  Over 55M users + 1M new users/month •  Static storage is >1.5Pb of data •  3 data centers + 3 clouds (Google, Amazon, Azure) •  1.5B HTTP requests/day •  900 people work at Wix, of which ~ 300 in R&D
4. 1542 (A/B Tests in 3 months)
5. •  Basic A/B testing •  Experiment driven development •  PETRI – Wix’s 3rd generation open source experiment system •  Challenges and best practices •  How to (code samples) Agenda
6. 11:31 A/B Test
7. To B or NOT to B? A B
8. Home page results
 (How many registered)
9. Experiment Driven Development
10. This is the Wix editor
11. Our gallery manager What can we improve?
12. Is this better?
13. Don’t be a loser
14. Product Experiments Toggles & Reporting Infrastructure
15. How do you know what is running?
16. If I “know” it is better, do I really need to test it? Why so many?
18. Sign-up Choose Template Edit site Publish Premium The theory
19. Result = Fail
20. Intent matters
21. •  EVERY new feature is A/B tested •  We open the new feature to a % of users ◦  Measure success ◦  If it is better, we keep it ◦  If worse, we check why and improve •  If flawed, the impact is just for % of our users Conclusion
22. Start with 50% / 50% ?
24. • New code can have bugs • Conversion can drop • Usage can drop • Unexpected cross test dependencies Sh*t happens (Test could fail)
25. •  Language •  GEO •  Browser •  User-agent •  OS Minimize affected users
 (in case of failure)
 Gradual exposure (percentage of…) •  Company employees •  User roles •  Any other criteria you have (extendable) •  All users
26. • First time visitors = Never visited wix.com • New registered users = Untainted users Not all users are equal
27. We need that feature …and failure is not an option
28. Defensive Testing
29. Adding a mobile view
30. First trial failed

 Performance had to be improved
31. Halting the test results in loss of data.

 What can we do about it?


32. Solution – Pause the experiment! •  Maintain NEW experience for already exposed users •  No additional users will be exposed to the NEW feature
33. PETRI’s pause implementation • Use cookies to persist assignment ◦  If user changes browser assignment is unknown • Server side persistence solves this ◦  You pay in performance & scalability
34. Decision Keep feature Drop feature Improve code & resume experiment Keep backwards compatibility for exposed users forever? Migrate users to another equivalent feature Drop it all together (users lose data/ work)
35. The road to success
36. •  Numbers look good but sample size is small •  We need more data! •  Expand Reaching statistical significance
 25% 50% 75% 100% 75% 50% 25% 0% Control Group (A) Test Group (B)
37. Keep user experience consistent Control Group (A) Test Group (B)
38. •  Signed-in user (Editor) ◦  Test group assignment is determined by the user ID ◦  Guarantee toss persistency across browsers •  Anonymous user (Home page) ◦  Test group assignment is randomly determined ◦  Can not guarantee persistent experience if changing browser •  11% of Wix users use more than one desktop browser Keeping persistent UX
39. There is MORE than one
40. # of active experiment Possible # of states 10 1024 20 1,048,576 30 1,073,741,824 Possible states >= 2^(# experiments) Wix has ~200 active experiments = 1.606938e+60
41. A/B testing introduces complexity
42. •  Override options (URL parameters, cookies, headers…) •  Near real time user BI tools •  Integrated developer tools in the product Support tools


43. Define Code Experiment Expand Merge code Close
44. •  Spec = Experiment template (in the code) ◦  Define test groups ◦  Mandatory limitations (filters, user types) ◦  Scope = Group of related experiments (usually by product) •  Why is it needed ◦  Type safety ◦  Preventing human errors (typos, user types) ◦  Controlled by the developer (developer knows about the context) ◦  Conducting experiments in batch Define spec
45. public class ExampleSpecDefinition extends SpecDefinition { @Override protected ExperimentSpecBuilder customize(ExperimentSpecBuilder builder) { return builder .withOwner("OWNERS_EMAIL_ADDRESS") .withScopes(aScopeDefinitionForAllUserTypes( "SOME_SCOPE")) .withTestGroups(asList("Group A", "Group B")); } } Spec code snippet
46. •  Experiment = “If” statement in the code Conducting experiment final String result = laboratory.conductExperiment(key, fallback, new StringConverter()); if (result.equals("group a")) // execute group a's logic else if (result.equals("group b")) // execute group b's logic // in case conducting the experiment failed - the fallback value is returned // in this case you would usually execute the 'old' logic
47. •  Upload the specs to Petri server ◦  Enables to define an experiment instance Upload spec { "creationDate" : "2014-01-09T13:11:26.846Z", "updateDate" : "2014-01-09T13:11:26.846Z", "scopes" : [ { "name" : "html-editor", "onlyForLoggedInUsers" : true }, { "name" : "html-viewer", "onlyForLoggedInUsers" : false } ], "testGroups" : [ "old", "new" ], "persistent" : true, "key" : "clientExperimentFullFlow1", "owner" : "" }
48. Start new experiment (limited population)
49. Manage experiment states
50. 1.  Convert A/B Test to Feature Toggle (100% ON) 2.  Merge the code 3.  Close the experiment 4.  Remove experiment instance Ending successful experiment
51. • Define spec • Use Petri client to conduct experiment in the code (defaults to old) • Sync spec • Open experiment • Manage experiment state • End experiment Experiment lifecycle
52. Petri is more than just an A/B test framework Feature toggle A/B Test Personalization Internal testing Continuous deployment Jira integration Experiments Dynamic configuration QA Automated testing
53. •  Expose features internally to company employees •  Enable continuous deployment with feature toggles •  Select assignment by sites (not only by users) •  Automatic selection of winning group* •  Exposing feature to #n of users* •  Integration with Jira * Planned feature Other things we (will) do with Petri
54. Petri is now an open source project https://github.com/wix/petri
55. Q&A Aviran Mordo Head of Back-end Engineering @aviranm www.linkedin.com/in/aviran www.aviransplace.com https://github.com/wix/petri http://goo.gl/L7pHnd Sagy Rozman Back-end Guild master www.linkedin.com/in/sagyrozman @sagyrozman
56. Credits http://upload.wikimedia.org/wikipedia/commons/b/b2/Fiber_optics_testing.jpg http://goo.gl/nEiepT https://www.flickr.com/photos/ilo_oli/2421536836 https://www.flickr.com/photos/dexxus/5791228117 http://goo.gl/SdeJ0o https://www.flickr.com/photos/112923805@N05/15005456062 https://www.flickr.com/photos/wiertz/8537791164 https://www.flickr.com/photos/laenulfean/5943132296 https://www.flickr.com/photos/torek/3470257377 https://www.flickr.com/photos/i5design/5393934753 https://www.flickr.com/photos/argonavigo/5320119828
57. •  Modeled experiment lifecycle •  Open source (developed using TDD from day 1) •  Running at scale on production •  No deployment necessary •  Both back-end and front-end experiment •  Flexible architecture Why Petri
58. PERTI Server Your app Laboratory DB Logs
