Cassandra Setup for Java Developers

Cassandra Setup for Java Developers

NoSQL presentation slides for The Developers Conference 2016 (http://www.thedevelopersconference.com.br) Apache Cassandra setup for Java Developers

Bruno Tinoco

July 08, 2016
Tweet

More Decks by Bruno Tinoco

Other Decks in Programming

Transcript

  1. GFT Group 03.09.2015 3 Who I am and What I

    do INTRODUCTION GFT Group is a business change and technology consultancy trusted by the world’s leading financial services institutions bringing together advisory, creative and technology capabilities with innovation culture and specialist knowledge of the finance sector. Bruno Tinoco §  Father and Java Developer with more than 15 years of software development experience using the JavaEE platform for different companies from Financial to Travel and Distribution industries. §  Currently working as a Software Engineer at GFT Group for DeustcheBank projects. Previously I worked as IT Architect at IBM GBS projects. §  Follow us §  https://twitter.com/gft_br §  https://twitter.com/brunocrt
  2. GFT Group 03.09.2015 4 What is the thing about Cassandra

    INTRODUCTION §  Distributed Database (CAP) §  Fault tolerant cluster §  Nominated master §  Native JSON §  Distributed hash table (Partition Keys) §  Replication factor §  Tunable consistency (ONE,QUORUM, ALL) Schema Keyspace Column Family Table ~ Row Key (Partition key Clustering column) Primary key §  No JOINS §  No Foreign keys §  No rollback/locking §  Eventual/Tunable Consistence SQL CQL
  3. GFT Group 03.09.2015 5 Downloading, Installing, Configuring & Running SETUP

    http://cassandra.apache.org (Current latest version 3.7) apache-cassandra-3.7-bin.tar.gz (34MB) cassandra.yaml ./bin/cassandra data logs export JAVA_HOME export MAX_HEAP_SIZE=“1024M” export HEAP_NEWSIZE=“400M” Cassandra = v2.2 – Java 7 Cassandra > v3.0 – Java 8
  4. GFT Group 03.09.2015 6 Setup your project HANDS-ON EXPERIENCE Define

    your persistence model Kundera Cassandra Driver <dependency> <groupId> com.impetus.kundera.client </groupId> <artifactId> kundera-cassandra </ artifactId > <version> 3.4 </version> </dependency> Native Queries (CQL) JPA DataStax Driver * <dependency> <groupId> com.datastax.cassandra</groupId> <artifactId> cassandra-driver-core </ artifactId > <version> 3.0.0 </version> </dependency> * Also supports object mapping through cassandra-driver-mapping You can starting mapping your entity classes using standard JPA annotations… You must to learn the driver API and create the schema yourself first X Others Hector Pelops Astyanax
  5. GFT Group 03.09.2015 7 Setup your tools HANDS-ON EXPERIENCE § 

    CQLSH §  DataStax DevCenter §  DataStax OpsCenter (Monitoring)
  6. GFT Group 03.09.2015 8 How about data modelling HANDS-ON EXPERIENCE

    §  Think about sorted Maps §  Data Types (List, Json) §  N-to-N Relationships SortedMap<RowKey, SortedMap<ColumnKey, ColumnValue>
  7. GFT Group 03.09.2015 9 Keep in mind HANDS-ON EXPERIENCE § 

    First your Use Case (UI needs) §  Do not try to normalize data (Hardest part) §  Define carefully your partition key (Performance)
  8. GFT Group 03.09.2015 10 More Information... REFERENCES Cassandra Community (Forum,

    Tutorials) http://www.planetcassandra.org/ Apache Cassandra Home (Download) https://cassandra.apache.org/ Netflix Cassandra benchmark http://techblog.netflix.com/2011/11/benchmarking-cassandra-scalability-on.html DataStax Documentation (Tutorials, Guide, Sample code) https://docs.datastax.com/
  9. GFT Group 03.09.2015 12 CREATING OBJECTS §  Keyspace §  CREATE

    KEYSPACE demo WITH replication = { 'class': 'SimpleStrategy', 'replication_factor': '1' }; §  Table §  CREATE TABLE users ( firstname text, lastname text, age int, email text, city text, PRIMARY KEY (lastname)); §  Queries §  SELECT… / INSERT… §  Indexes §  CREATE INDEX… §  Structure §  DESC… BASIC COMMANDS
  10. GFT Group 03.09.2015 13 CQLSH §  Interactive mode (shell) § 

    $CASSANDRA_HOME/bin/cqlsh localhost –u user –p user123 §  clqsh> §  Execute mode §  $CASSANDRA_HOME/bin/cqlsh localhost –u user –p user123 –e “SELECT * from demo.users” §  File mode §  $CASSANDRA_HOME/bin/cqlsh localhost –u user –p user123 –f my_cql_commands.cql TOOLS Python script that comes with the default Cassandra a installation
  11. GFT Group 03.09.2015 14 DataStax DevCenter §  Free tool GUI

    for connect on Cassandra clusters TOOLS
  12. GFT Group 03.09.2015 15 DataStax Driver §  Support both Binary

    (CQL) and Thrift Protocols §  Connection Pool §  Supports Annotation (Tables/Indexes/Types) §  Supports Native Cassandra concepts JAVA DRIVERS
  13. GFT Group 03.09.2015 16 Kundera Driver §  JPA Compliant § 

    Annotation based §  Auto schema creation §  Connection Pool §  Support other NoSQL databases (ie. Mongo) JAVA DRIVERS
  14. GFT Group 03.09.2015 17 Other Drivers §  Hector The most

    stable of the Java APIs, ready for prime-time. §  Astyanax A clean Java API from Netflix. It isn't as widely used as Hector, but it is solid. §  Pelops §  PlayORM (ORM without the constraints?) It looks like it is trying to solve the impedance mismatch between traditional JPA-based ORMs and NoSQL by introducing JQL. It looks promising. Decision Considerations §  Low latency overhead, Asynch API, and reliability/stability for production environment. (e.g. a more user-friendly APIs that can be had in the DAL that wraps the client). §  Connection pooling and partition awareness are some other good feature to have. §  Able to detect any new nodes that got added. §  Good Support as well (as pointed by dean below) JAVA DRIVERS
