Advanced Animations & ConstraintLayout

Advanced animations with ConstraintLayout

Transcript

1. Advanced Animations & ConstraintLayout Nicolas Roard @camaelon John Hoford @johnhoford .droidconSF 2017
2. Overview
3. Android Studio
4. ConstraintLayout
5. Where are we now
6. Where are we now Android Studio 3.0 just shipped!
7. Where are we now Android Studio 3.0 just shipped! ConstraintLayout 1.0.2 stable
8. Where are we now Android Studio 3.0 just shipped! ConstraintLayout 1.0.2 stable ConstraintLayout 1.1 beta 3
9. ConstraintLayout
10. ConstraintLayout Relative positioning
11. ConstraintLayout Relative positioning
12. ConstraintLayout Center positioning & bias
13. ConstraintLayout Center positioning & bias
14. ConstraintLayout Ratio
15. ConstraintLayout Ratio
16. ConstraintLayout Chains
17. ConstraintLayout Chains
18. ConstraintLayout Guidelines
19. ConstraintLayout Guidelines
20. Constraints Vocabulary • Relative positioning • Center + bias • Dimension (e.g. ratio) • Group behavior (chains) • Helper objects (guidelines)
21. Direct Manipulation
22. Direct Manipulation Change parameters 1
23. Direct Manipulation Change parameters 1 Use TransitionManager 2
24. Direct Manipulation //Find the view you are over and set minimum height View child = layout.getChildAt(current); B
25. Direct Manipulation //Find the view you are over and set minimum height View child = layout.getChildAt(current); B child.setMinimumHeight(400); C
26. Direct Manipulation //Find the view you are over and set minimum height TransitionManager.beginDelayedTransition(layout); A View child = layout.getChildAt(current); B child.setMinimumHeight(400); C
27. Direct Manipulation //Find the view you are over and set minimum height TransitionManager.beginDelayedTransition(layout); A View child = layout.getChildAt(current); B child.setMinimumHeight(400); C
28. Direct Manipulation //Find the view you are over and set minimum height TransitionManager.beginDelayedTransition(layout); A View child = layout.getChildAt(current); B child.setMinimumHeight(400); C
29. Use of GONE
30. Use of GONE
31. More examples Huyen Tue Dao’s talk at ChicagoRoboto: Cool ConstraintLayout https://speakerdeck.com/queencodemonkey/chicago-roboto-2017-cool- constraintlayout http://chicagoroboto.com/session-videos/
32. Guideline Manipulation
33. Direct Manipulation : Guideline
34. Direct Manipulation : Guideline Guideline are powerful elements
35. Direct Manipulation : Guideline Guideline are powerful elements Specify exact positioning or percent value
36. Direct Manipulation : Guideline Guideline are powerful elements Specify exact positioning or percent value Parameterize a layout via guidelines
37. Guidelines can be your Layout Parameters
39. final Guideline guideline = findViewById(R.id.guideline);
40. final Guideline guideline = findViewById(R.id.guideline); final int end = ((LayoutParams) guideline.getLayoutParams()).guideEnd;
41. final Guideline guideline = findViewById(R.id.guideline); final int end = ((LayoutParams) guideline.getLayoutParams()).guideEnd; ValueAnimator anim = ValueAnimator.ofInt(0, end); anim.addUpdateListener((animator) -> { }); anim.start();
42. final Guideline guideline = findViewById(R.id.guideline); final int end = ((LayoutParams) guideline.getLayoutParams()).guideEnd; ValueAnimator anim = ValueAnimator.ofInt(0, end); anim.addUpdateListener((animator) -> { LayoutParams lp = (LayoutParams) guideline.getLayoutParams(); lp.guideEnd = (Integer) animator.getAnimatedValue(); guideline.setLayoutParams(lp); }); anim.start();
43. final Guideline guideline = findViewById(R.id.guideline); final int end = ((LayoutParams) guideline.getLayoutParams()).guideEnd; ValueAnimator anim = ValueAnimator.ofInt(0, end); anim.setDuration(2000); anim.setInterpolator(new BounceInterpolator()); anim.addUpdateListener((animator) -> { LayoutParams lp = (LayoutParams) guideline.getLayoutParams(); lp.guideEnd = (Integer) animator.getAnimatedValue(); guideline.setLayoutParams(lp); }); anim.start();
44. final Guideline guideline = findViewById(R.id.guideline); final int end = ((LayoutParams) guideline.getLayoutParams()).guideEnd; ObjectAnimator anim = ObjectAnimator.ofInt(g, "GuidelineEnd", 0, end); anim.setDuration(2000); anim.setInterpolator(new BounceInterpolator()); anim.start(); New in 1.1
47. Parallax Effect
49. base.setOnTouchListener(new View.OnTouchListener() { public boolean onTouch(View view, MotionEvent motionEvent) { switch (motionEvent.getActionMasked( )) { case MotionEvent.ACTION_MOVE: break; } A return true; } B });
50. base.setOnTouchListener(new View.OnTouchListener() { public boolean onTouch(View view, MotionEvent motionEvent) { switch (motionEvent.getActionMasked( )) { case MotionEvent.ACTION_MOVE: LayoutParams params = (LayoutParams) guideline.getLayoutParams(); params.guideBegin = (int) motionEvent.getX(); guideline.setLayoutParams(params); break; } A return true; } B });
51. Guideline Manipulation
52. Guideline Manipulation
53. Parallax Effect
54. Parallax Effect
55. Parallax Effect
56. recyclerView.addOnScrollListener(object : RecyclerView.OnScrollListener() { override fun onScrolled(recyclerView: RecyclerView?, dx: Int, dy: Int) { super.onScrolled(recyclerView, dx, dy) a} })
57. recyclerView.addOnScrollListener(object : RecyclerView.OnScrollListener() { override fun onScrolled(recyclerView: RecyclerView?, dx: Int, dy: Int) { super.onScrolled(recyclerView, dx, dy) val manager = recyclerView!!.layoutManager as LinearLayoutManager val position = manager.findFirstVisibleItemPosition() val lastPosition = manager.findLastVisibleItemPosition() val offsetX = recyclerView.computeHorizontalScrollOffset() for (i in 0..lastPosition - position) { val layout = manager.findViewByPosition(position + i) as ConstraintLayout val guideline = layout.findViewById<Guideline>(R.id.guideline) val params = guideline.layoutParams as ConstraintLayout.LayoutParams val w = recyclerView.width val deltaPos = offsetX - (position + i) * w val percent = deltaPos / w.toFloat() params.guidePercent = Math.max(0.3f, Math.min(0.7f, 0.5f - percent)) guideline.layoutParams = params } a} })
58. Parallax Effect
59. Parallax Effect
60. recyclerView.addOnScrollListener(object : RecyclerView.OnScrollListener() { override fun onScrolled(recyclerView: RecyclerView?, dx: Int, dy: Int) { super.onScrolled(recyclerView, dx, dy) val manager = recyclerView!!.layoutManager as LinearLayoutManager val position = manager.findFirstVisibleItemPosition() val lastPosition = manager.findLastVisibleItemPosition() val offsetX = recyclerView.computeHorizontalScrollOffset() for (i in 0..lastPosition - position) { val layout = manager.findViewByPosition(position + i) as ConstraintLayout val guideline = layout.findViewById<Guideline>(R.id.guideline) val params = guideline.layoutParams as ConstraintLayout.LayoutParams val w = recyclerView.width val deltaPos = offsetX - (position + i) * w val percent = deltaPos / w.toFloat() params.guidePercent = Math.max(0.3f, Math.min(0.7f, 0.5f - percent)) guideline.layoutParams = params } a} })
61. recyclerView.addOnScrollListener(object : RecyclerView.OnScrollListener() { override fun onScrolled(recyclerView: RecyclerView?, dx: Int, dy: Int) { super.onScrolled(recyclerView, dx, dy) val manager = recyclerView!!.layoutManager as LinearLayoutManager val position = manager.findFirstVisibleItemPosition() val lastPosition = manager.findLastVisibleItemPosition() val offsetX = recyclerView.computeHorizontalScrollOffset() for (i in 0..lastPosition - position) { val layout = manager.findViewByPosition(position + i) as ConstraintLayout val guideline = layout.findViewById<Guideline>(R.id.guideline) val params = guideline.layoutParams as ConstraintLayout.LayoutParams val w = recyclerView.width val deltaPos = offsetX - (position + i) * w val percent = deltaPos / w.toFloat() params.guidePercent = Math.max(0.3f, Math.min(0.7f, 0.5f + percent)) guideline.layoutParams = params } a} })
62. Parallax Effect: inversion
63. Parallax Effect: inversion
64. ConstraintSet
65. ConstraintSet Contains all your constraints
66. ConstraintSet Contains all your constraints Programming API
67. ConstraintSet Contains all your constraints Programming API Clone from live layout or XML
68. Initializing a ConstraintSet Layout resource set.clone(context, R.layout.main) Live layout set.clone(findViewById(R.id.main)) XML file set.load(context, R.xml.main)
69. Applying a ConstraintSet set.applyTo(layout)
70. ConstraintSet
71. ConstraintSet ConstraintSet mConstraintSet1 = new ConstraintSet(); // create a Constraint Set ConstraintSet mConstraintSet2 = new ConstraintSet(); // create a Constraint Set Initialization
72. ConstraintSet ConstraintSet mConstraintSet1 = new ConstraintSet(); // create a Constraint Set ConstraintSet mConstraintSet2 = new ConstraintSet(); // create a Constraint Set mConstraintSet2.clone(context, R.layout.state2); // get constraints from layout setContentView(R.layout.state1); mConstraintLayout = (ConstraintLayout) findViewById(R.id.activity_main); mConstraintSet1.clone(mConstraintLayout); // get constraints from ConstraintSet Initialization onCreate
73. ConstraintSet ConstraintSet mConstraintSet1 = new ConstraintSet(); // create a Constraint Set ConstraintSet mConstraintSet2 = new ConstraintSet(); // create a Constraint Set mConstraintSet2.clone(context, R.layout.state2); // get constraints from layout setContentView(R.layout.state1); mConstraintLayout = (ConstraintLayout) findViewById(R.id.activity_main); mConstraintSet1.clone(mConstraintLayout); // get constraints from ConstraintSet mConstraintSet1.applyTo(mConstraintLayout); Initialization onCreate To change state
74. ConstraintSet ConstraintSet mConstraintSet1 = new ConstraintSet(); // create a Constraint Set ConstraintSet mConstraintSet2 = new ConstraintSet(); // create a Constraint Set mConstraintSet2.clone(context, R.layout.state2); // get constraints from layout setContentView(R.layout.state1); mConstraintLayout = (ConstraintLayout) findViewById(R.id.activity_main); mConstraintSet1.clone(mConstraintLayout); // get constraints from ConstraintSet TransitionManager.beginDelayedTransition(mConstraintLayout); mConstraintSet1.applyTo(mConstraintLayout); Initialization onCreate To change state
75. Build two layouts
76. Build two layouts
77. Build two layouts
78. Build two layouts
79. Add Custom Transition static public class MyTransition extends TransitionSet { { setDuration(1000); setOrdering(ORDERING_SEQUENTIAL); addTransition(new TransitionSet() { { addTransition(new Fade(Fade.OUT)); addTransition(new ChangeBounds()); } }); addTransition(new Fade(Fade.IN)); } } private void animate(ConstraintLayout cl, ConstraintSet set) { TransitionManager.beginDelayedTransition(cl, new MyTransition()); set.applyTo(cl); }
80. Add Custom Transition static public class MyTransition extends TransitionSet { { setDuration(1000); setOrdering(ORDERING_SEQUENTIAL); addTransition(new TransitionSet() { { addTransition(new Fade(Fade.OUT)); addTransition(new ChangeBounds()); } }); addTransition(new Fade(Fade.IN)); } } private void animate(ConstraintLayout cl, ConstraintSet set) { TransitionManager.beginDelayedTransition(cl, new MyTransition()); set.applyTo(cl); }
81. Custom Transition 2 static public class MyTransition extends TransitionSet { { setDuration(1000); setOrdering(ORDERING_SEQUENTIAL); addTransition(new TransitionSet() { { addTransition(new Fade(Fade.OUT)); addTransition(new ChangeBounds()); addTransition(new Fade(Fade.IN)); } }); } } private void animate(ConstraintLayout cl, ConstraintSet set) { TransitionManager.beginDelayedTransition(cl, new MyTransition()); set.applyTo(cl); }
82. Custom Transition 2 static public class MyTransition extends TransitionSet { { setDuration(1000); setOrdering(ORDERING_SEQUENTIAL); addTransition(new TransitionSet() { { addTransition(new Fade(Fade.OUT)); addTransition(new ChangeBounds()); addTransition(new Fade(Fade.IN)); } }); } } private void animate(ConstraintLayout cl, ConstraintSet set) { TransitionManager.beginDelayedTransition(cl, new MyTransition()); set.applyTo(cl); }
83. Add Custom Transition static public class MyTransition extends TransitionSet { { setDuration(1000); setOrdering(ORDERING_SEQUENTIAL); addTransition(new TransitionSet() { { addTransition(new Fade(Fade.OUT)); ChangeBounds move = new ChangeBounds(); move.setInterpolator(new BounceInterpolator()); addTransition(move); } }); addTransition(new Fade(Fade.IN)); } }
84. Add Custom Transition static public class MyTransition extends TransitionSet { { setDuration(1000); setOrdering(ORDERING_SEQUENTIAL); addTransition(new TransitionSet() { { addTransition(new Fade(Fade.OUT)); ChangeBounds move = new ChangeBounds(); move.setInterpolator(new BounceInterpolator()); addTransition(move); } }); addTransition(new Fade(Fade.IN)); } }
85. Add Custom Transition Very custom…
86. Add Custom Transition Very custom…
87. Collapsible Toolbar
90. Collapsible Toolbar CoordinatorLayout AppBarLayout CollapsingToolbarLayout
91. ConstraintLayout Collapsible Toolbar CoordinatorLayout AppBarLayout
92. XML <android.support.design.widget.CoordinatorLayout … > <android.support.design.widget.AppBarLayout android:id="@+id/app_bar" android:layout_width="match_parent" android:layout_height="@dimen/app_bar_height" android:fitsSystemWindows=“false" … > <android.support.design.widget.CollapsingToolbarLayout android:id=“@+id/toolbar_layout" … > </android.support.design.widget.AppBarLayout> <include layout="@layout/content_scrolling" /> <android.support.design.widget.FloatingActionButton /> </android.support.design.widget.CoordinatorLayout>
93. <android.support.design.widget.CoordinatorLayout … > <android.support.design.widget.AppBarLayout android:id="@+id/app_bar" android:layout_width="match_parent" android:layout_height="@dimen/app_bar_height" android:fitsSystemWindows=“false" … > <android.support.constraint.ConstraintLayout android:id=“@+id/toolbar_layout" … > </android.support.design.widget.AppBarLayout> <include layout="@layout/content_scrolling" /> <android.support.design.widget.FloatingActionButton /> </android.support.design.widget.CoordinatorLayout> XML
94. <android.support.design.widget.CoordinatorLayout … > <android.support.design.widget.AppBarLayout android:id="@+id/app_bar" android:layout_width="match_parent" android:layout_height="@dimen/app_bar_height" android:fitsSystemWindows=“false" … > <include layout=“@+id/toolbar" /> </android.support.design.widget.AppBarLayout> <include layout="@layout/content_scrolling" /> <android.support.design.widget.FloatingActionButton /> </android.support.design.widget.CoordinatorLayout> XML
99. XML <android.support.constraint.ConstraintLayout android:id="@+id/constraintToolbar" android:layout_width="match_parent" android:layout_height="match_parent" android:fitsSystemWindows="true" android:minHeight="40dp" app:layout_scrollFlags="enterAlways|snap">
100. XML <android.support.constraint.ConstraintLayout android:id="@+id/constraintToolbar" android:layout_width="match_parent" android:layout_height="match_parent" android:fitsSystemWindows="true" android:minHeight="40dp" app:layout_scrollFlags="scroll|enterAlways|snap|exitUntilCollapsed">
103. Using ConstraintSet …& Kotlin
104. Open ConstraintSet Closed ConstraintSet open.xml closed.xml
105. class NoAnimCollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mTransitionThreshold = 0.35f private var mLastPosition : Int = 0 private var mToolbarOpen = true private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() override fun onAttachedToWindow() { super.onAttachedToWindow() if (parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) mToolbarOpen = true } } }
108. class NoAnimCollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mTransitionThreshold = 0.35f private var mLastPosition : Int = 0 private var mToolbarOpen = true private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() override fun onAttachedToWindow() { super.onAttachedToWindow() if (parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) mToolbarOpen = true } } } Subclass of ConstraintLayout Implements OnOffsetChangedListener 1 2
109. class NoAnimCollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mTransitionThreshold = 0.35f private var mLastPosition : Int = 0 private var mToolbarOpen = true private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() override fun onAttachedToWindow() { super.onAttachedToWindow() if (parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) mToolbarOpen = true } } } appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) Implements OnOffsetChangedListener 3 Load the ConstraintSet 4
110. class NoAnimCollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mTransitionThreshold = 0.35f private var mLastPosition : Int = 0 private var mToolbarOpen = true private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() override fun onAttachedToWindow() { super.onAttachedToWindow() if (parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) mToolbarOpen = true } } } Offset the Content 5 val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params)
111. class NoAnimCollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mTransitionThreshold = 0.35f private var mLastPosition : Int = 0 private var mToolbarOpen = true private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() override fun onAttachedToWindow() { super.onAttachedToWindow() if (parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) mToolbarOpen = true } } } Toggle the ConstraintSet 6 if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) mToolbarOpen = true }
114. Adding some animation…
115. Animating content
116. class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } }
117. class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } }
118. class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } }
119. class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } }
120. Animating background
121. Animating the alpha channel mBackground = findViewById(R.id.background) … showImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 0f, 1f) showImageAnimator?.duration = 600 … showImageAnimator?.start()
122. Now all together!
123. class CollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mLastPosition : Int = 0 private var mToolbarOpen = true private var mTransitionThreshold = 0.35f private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() private var mBackground: ImageView? = null private var mTitle : TextView? = null private var mIcon : ImageView? = null private var mTranslationTitle : AnimationHelper? = null private var mTranslationIcon : AnimationHelper? = null private var showImageAnimator : Animator? = null private var hideImageAnimator : Animator? = null class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } } override fun onAttachedToWindow() { super.onAttachedToWindow() if (false && parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) mBackground = findViewById(R.id.background) mTitle = findViewById(R.id.name) mIcon = findViewById(R.id.icon) showImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 0f, 1f) showImageAnimator?.duration = 600 hideImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 1f, 0f) hideImageAnimator?.duration = 600 } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) hideImageAnimator?.start() mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) showImageAnimator?.start() mToolbarOpen = true } } override fun onLayout(changed: Boolean, left: Int, top: Int, right: Int, bottom: Int) { super.onLayout(changed, left, top, right, bottom) if (mTitle != null && mTranslationTitle == null) { mTranslationTitle = AnimationHelper(mTitle!!) } if (mIcon != null && mTranslationIcon == null) { mTranslationIcon = AnimationHelper(mIcon!!) } mTranslationTitle?.evaluate() mTranslationIcon?.evaluate() } } AnimationHelper 1
124. class CollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mLastPosition : Int = 0 private var mToolbarOpen = true private var mTransitionThreshold = 0.35f private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() private var mBackground: ImageView? = null private var mTitle : TextView? = null private var mIcon : ImageView? = null private var mTranslationTitle : AnimationHelper? = null private var mTranslationIcon : AnimationHelper? = null private var showImageAnimator : Animator? = null private var hideImageAnimator : Animator? = null class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } } override fun onAttachedToWindow() { super.onAttachedToWindow() if (false && parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) mBackground = findViewById(R.id.background) mTitle = findViewById(R.id.name) mIcon = findViewById(R.id.icon) showImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 0f, 1f) showImageAnimator?.duration = 600 hideImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 1f, 0f) hideImageAnimator?.duration = 600 } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) hideImageAnimator?.start() mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) showImageAnimator?.start() mToolbarOpen = true } } override fun onLayout(changed: Boolean, left: Int, top: Int, right: Int, bottom: Int) { super.onLayout(changed, left, top, right, bottom) if (mTitle != null && mTranslationTitle == null) { mTranslationTitle = AnimationHelper(mTitle!!) } if (mIcon != null && mTranslationIcon == null) { mTranslationIcon = AnimationHelper(mIcon!!) } mTranslationTitle?.evaluate() mTranslationIcon?.evaluate() } } onLayout 2 override fun onLayout(changed: Boolean, left: Int, top: Int, right: Int, bottom: Int) { super.onLayout(changed, left, top, right, bottom) if (mTitle != null && mTranslationTitle == null) { mTranslationTitle = AnimationHelper(mTitle!!) } if (mIcon != null && mTranslationIcon == null) { mTranslationIcon = AnimationHelper(mIcon!!) } mTranslationTitle?.evaluate() mTranslationIcon?.evaluate() }
125. class CollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mLastPosition : Int = 0 private var mToolbarOpen = true private var mTransitionThreshold = 0.35f private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() private var mBackground: ImageView? = null private var mTitle : TextView? = null private var mIcon : ImageView? = null private var mTranslationTitle : AnimationHelper? = null private var mTranslationIcon : AnimationHelper? = null private var showImageAnimator : Animator? = null private var hideImageAnimator : Animator? = null class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } } override fun onAttachedToWindow() { super.onAttachedToWindow() if (false && parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) mBackground = findViewById(R.id.background) mTitle = findViewById(R.id.name) mIcon = findViewById(R.id.icon) showImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 0f, 1f) showImageAnimator?.duration = 600 hideImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 1f, 0f) hideImageAnimator?.duration = 600 } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) hideImageAnimator?.start() mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) showImageAnimator?.start() mToolbarOpen = true } } override fun onLayout(changed: Boolean, left: Int, top: Int, right: Int, bottom: Int) { super.onLayout(changed, left, top, right, bottom) if (mTitle != null && mTranslationTitle == null) { mTranslationTitle = AnimationHelper(mTitle!!) } if (mIcon != null && mTranslationIcon == null) { mTranslationIcon = AnimationHelper(mIcon!!) } mTranslationTitle?.evaluate() mTranslationIcon?.evaluate() } } onLayout 2 override fun onLayout(changed: Boolean, left: Int, top: Int, right: Int, bottom: Int) { super.onLayout(changed, left, top, right, bottom) if (mTitle != null && mTranslationTitle == null) { mTranslationTitle = AnimationHelper(mTitle!!) } if (mIcon != null && mTranslationIcon == null) { mTranslationIcon = AnimationHelper(mIcon!!) } mTranslationTitle?.evaluate() mTranslationIcon?.evaluate() }
126. class CollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mLastPosition : Int = 0 private var mToolbarOpen = true private var mTransitionThreshold = 0.35f private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() private var mBackground: ImageView? = null private var mTitle : TextView? = null private var mIcon : ImageView? = null private var mTranslationTitle : AnimationHelper? = null private var mTranslationIcon : AnimationHelper? = null private var showImageAnimator : Animator? = null private var hideImageAnimator : Animator? = null class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } } override fun onAttachedToWindow() { super.onAttachedToWindow() if (false && parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) mBackground = findViewById(R.id.background) mTitle = findViewById(R.id.name) mIcon = findViewById(R.id.icon) showImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 0f, 1f) showImageAnimator?.duration = 600 hideImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 1f, 0f) hideImageAnimator?.duration = 600 } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) hideImageAnimator?.start() mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) showImageAnimator?.start() mToolbarOpen = true } } override fun onLayout(changed: Boolean, left: Int, top: Int, right: Int, bottom: Int) { super.onLayout(changed, left, top, right, bottom) if (mTitle != null && mTranslationTitle == null) { mTranslationTitle = AnimationHelper(mTitle!!) } if (mIcon != null && mTranslationIcon == null) { mTranslationIcon = AnimationHelper(mIcon!!) } mTranslationTitle?.evaluate() mTranslationIcon?.evaluate() } } onLayout 2 override fun onLayout(changed: Boolean, left: Int, top: Int, right: Int, bottom: Int) { super.onLayout(changed, left, top, right, bottom) if (mTitle != null && mTranslationTitle == null) { mTranslationTitle = AnimationHelper(mTitle!!) } if (mIcon != null && mTranslationIcon == null) { mTranslationIcon = AnimationHelper(mIcon!!) } mTranslationTitle?.evaluate() mTranslationIcon?.evaluate() }
127. class CollapsibleConstraintLayout : ConstraintLayout, AppBarLayout.OnOffsetChangedListener { constructor(context: Context) : this(context, null) constructor(context: Context, attrs: AttributeSet?) : this(context, attrs, 0) constructor(context: Context, attrs: AttributeSet?, defStyleAttr: Int) : super(context, attrs, defStyleAttr) {} private var mLastPosition : Int = 0 private var mToolbarOpen = true private var mTransitionThreshold = 0.35f private val mOpenToolbarSet: ConstraintSet = ConstraintSet() private val mCloseToolbarSet: ConstraintSet = ConstraintSet() private var mBackground: ImageView? = null private var mTitle : TextView? = null private var mIcon : ImageView? = null private var mTranslationTitle : AnimationHelper? = null private var mTranslationIcon : AnimationHelper? = null private var showImageAnimator : Animator? = null private var hideImageAnimator : Animator? = null class AnimationHelper(view : View){ var initialValue = 0 var target = view init { initialValue = target.left } fun evaluate() { if (initialValue != target.left) { var delta = (initialValue - target.left).toFloat() val anim = ObjectAnimator.ofFloat(target, "translationX", delta, 0f) anim.duration = 400 anim.start() initialValue = target.left } } } override fun onAttachedToWindow() { super.onAttachedToWindow() if (false && parent is AppBarLayout) { var appBarLayout = parent as AppBarLayout appBarLayout.addOnOffsetChangedListener(this) mOpenToolbarSet.clone(context, R.layout.open) mCloseToolbarSet.clone(context, R.layout.close) mBackground = findViewById(R.id.background) mTitle = findViewById(R.id.name) mIcon = findViewById(R.id.icon) showImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 0f, 1f) showImageAnimator?.duration = 600 hideImageAnimator = ObjectAnimator.ofFloat(mBackground, "alpha", 1f, 0f) hideImageAnimator?.duration = 600 } } override fun onOffsetChanged(appBarLayout: AppBarLayout?, verticalOffset: Int) { if (mLastPosition == verticalOffset) { return } mLastPosition = verticalOffset val progress = Math.abs(verticalOffset / appBarLayout?.getHeight()?.toFloat()!!) val params = getLayoutParams() as AppBarLayout.LayoutParams params.topMargin = -verticalOffset setLayoutParams(params) if (mToolbarOpen && progress > mTransitionThreshold) { mCloseToolbarSet.applyTo(this) hideImageAnimator?.start() mToolbarOpen = false } else if (!mToolbarOpen && progress < mTransitionThreshold) { mOpenToolbarSet.applyTo(this) showImageAnimator?.start() mToolbarOpen = true } } override fun onLayout(changed: Boolean, left: Int, top: Int, right: Int, bottom: Int) { super.onLayout(changed, left, top, right, bottom) if (mTitle != null && mTranslationTitle == null) { mTranslationTitle = AnimationHelper(mTitle!!) } if (mIcon != null && mTranslationIcon == null) { mTranslationIcon = AnimationHelper(mIcon!!) } mTranslationTitle?.evaluate() mTranslationIcon?.evaluate() } } animating background alpha 3
130. Collapsible Layout Summary • Use ConstraintLayout / ConstraintSet for flexibility • Piggy-back on CoordinatorLayout / AppBarLayout • Kotlin! • ObjectAnimator for property animation
131. Helpers & Decorators
132. Helpers ConstraintHelper
133. Helpers ConstraintHelper View 1 View 2 View 3
134. Helpers ConstraintHelper Barrier Group
135. Example StaggeredAnimationGroup from Bartosz Lipiński https://github.com/blipinsk/StaggeredAnimationGroup
136. Example StaggeredAnimationGroup from Bartosz Lipiński https://github.com/blipinsk/StaggeredAnimationGroup
137. Decorators ConstraintHelper Decorator
138. Decorator
139. Decorator ConstraintHelper + View
140. Decorator ConstraintHelper + View Gather draw operations in a single place
141. Decorator ConstraintHelper + View Gather draw operations in a single place Draw something depending on multiple views
142. Decorator public class MetaballsDecorator extends Decorator { public void updatePostLayout(ConstraintLayout container) { int[] ids = getReferencedIds(); final int count = ids.length; for (int i = 0; i < count; i++) { View view = container.getViewById(ids[i]); // do something } } @Override public void onDraw(Canvas canvas) { // do something } }
143. Decorator Canvas ImageViews
144. Decorator Canvas ImageViews
145. Decorator Canvas ImageViews
146. Decorator: Metaballs
147. Decorator: Metaballs
148. Decorator: Metaballs
149. Decorator: Metaballs
150. Let’s sum it all up…
151. Let’s sum it all up… ConstraintLayout allows very flexible, declarative positioning
152. Let’s sum it all up… ConstraintLayout allows very flexible, declarative positioning You can directly modify parameters to change your layout
153. Let’s sum it all up… ConstraintLayout allows very flexible, declarative positioning You can directly modify parameters to change your layout Guidelines are a great entry point for customizing your layout
154. Let’s sum it all up… ConstraintLayout allows very flexible, declarative positioning You can directly modify parameters to change your layout Guidelines are a great entry point for customizing your layout ConstraintSet allows you to easily manage multiple states of your layout
155. Let’s sum it all up… ConstraintLayout allows very flexible, declarative positioning You can directly modify parameters to change your layout Guidelines are a great entry point for customizing your layout ConstraintSet allows you to easily manage multiple states of your layout TransitionManager will animate a lot for you automatically
156. Let’s sum it all up… ConstraintLayout allows very flexible, declarative positioning You can directly modify parameters to change your layout Guidelines are a great entry point for customizing your layout ConstraintSet allows you to easily manage multiple states of your layout TransitionManager will animate a lot for you automatically Property animations still very useful!
157. Let’s sum it all up… ConstraintLayout allows very flexible, declarative positioning You can directly modify parameters to change your layout Guidelines are a great entry point for customizing your layout ConstraintSet allows you to easily manage multiple states of your layout TransitionManager will animate a lot for you automatically Property animations still very useful! Decorators are great for capturing cross-views rendering
158. Thank you! Nicolas Roard @camaelon John Hoford @johnhoford .droidconSF 2017
159. Documentation • http://www.constraintlayout.com • https://developer.android.com/reference/android/support/ constraint/package-summary.html • https://developer.android.com/training/constraint-layout/index.html • https://codelabs.developers.google.com/codelabs/constraint-layout • https://medium.com/google-developers/building-interfaces-with- constraintlayout-3958fa38a9f7
160. Documentation • http://www.constraintlayout.com • https://developer.android.com/reference/android/support/ constraint/package-summary.html • https://developer.android.com/training/constraint-layout/index.html • https://codelabs.developers.google.com/codelabs/constraint-layout • https://medium.com/google-developers/building-interfaces-with- constraintlayout-3958fa38a9f7
