almost every distributed computing problem ‣ MapReduce over your raw data is flexible but slow ‣ Hadoop is not optimized for query latency ‣ To optimize queries, we need a query layer
optimize for? • Revenue over time broken down by demographic • Top publishers by clicks over the last month • Number of unique visitors broken down by any dimension • Not dumping the entire dataset • Not examining individual events
rows / second / core 1 day of summarized aggregates 60M+ rows 1 query over 1 week, 16 cores ~5 seconds Page load with 20 queries over a week of data long time
a NoSQL store II. NOSQL - THE SETUP ts gender age revenue 1 M 18 $0.15 1 F 25 $1.03 1 F 18 $0.01 Key Value 1 revenue=$1.19 1,M revenue=$0.15 1,F revenue=$1.04 1,18 revenue=$0.16 1,25 revenue=$1.03 1,M,18 revenue=$0.15 1,F,18 revenue=$0.01 1,F,25 revenue=$1.03
key ‣ Inflexible • not aggregated, not available ‣ Not continuously updated • aggregate first, then display ‣ Processing scales exponentially II. NOSQL - THE RESULTS
2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53 ...
deleted 2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53 ‣ Shard data by time ‣ Immutable chunks of data called “segments” Segment 2011-01-01T02/2011-01-01T03 Segment 2011-01-01T01/2011-01-01T02 Segment 2011-01-01T00/2011-01-01T01
No contention between reads and writes ‣ One thread scans one segment ‣ Multiple threads can access same underlying data ‣ Segment sizes -> computation completes in 100s of ms ‣ Simplifies distribution & replication
Compression! ‣ Indexes! timestamp page language city country ... added deleted 2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53 ...
Bieber -> 0, Ke$ha -> 1 ‣ Store • page -> [0 0 0 1 1 1] • language -> [0 0 0 0 0 0] timestamp page language city country ... added deleted 2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53 ...
-> [111000] ‣ Ke$ha -> [3, 4, 5] -> [000111] timestamp page language city country ... added deleted 2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53 ...
Boolean operations directly on compressed indices • Less memory => faster scan rates ‣ More details • http://ricerca.mat.uniroma3.it/users/colanton/concise.html • http://roaringbitmap.org/
Druid gave us arbitrary data exploration & fast queries ‣ But what about data freshness? • Batch loading is slow! • We want “real-time” • Alerts, operational monitoring, etc.
in memory in a write-optimized data structure ‣ Periodically persist collected events to disk (converting to a read-optimized format) ‣ Query data as soon as it is ingested REAL-TIME NODES
your own modules and extend Druid • Add your own complex metrics (cardinality estimation, approximate histograms and quantiles, approximate top-K algorithms, etc.) • Add your own proprietary modules
many different companies • In production at multiple companies, we’re hoping for more! • Ad-tech, network traffic, operations, activity streams, etc. • Support through community forums and IRC • We love contributions!
0 5 10 15 20 90%ile 95%ile 99%ile Feb 03 Feb 10 Feb 17 Feb 24 time query time (seconds) datasource a b c d e f g h Query latency percentiles QUERY LATENCY (500MS AVERAGE) 95% < 1S 99% < 10S DRUID IN PRODUCTION
large amounts of data • You need analytics (not key value store) • You want to do your analysis on data as it’s happening (realtime) • You need availability, extensibility and flexibility
