Indexing Timeseries with Samza and Druid

Transcript

1. INDEXING TIME SERIES STREAMS
   WITH SAMZA AND DRUID GIAN MERLINO · DRUID DEVELOPER · SAMZA USER
3. THE PROBLEM
4. THE PROBLEM
5. THE PROBLEM
6. THE PROBLEM ‣ Business intelligence for ad-tech ‣ Arbitrary and interactive exploration ‣ Multi-tenancy: thousands of concurrent users ‣ Recency: explore current data, alert on major changes ‣ Efficiency: each event is individually very low-value
7. THE PROBLEM ‣ Questions lead to more questions ‣ Interested not just in what happened, but why ‣ Dig into the dataset using filters, aggregates, and comparisons ‣ All interesting queries cannot be determined upfront
8. EXPLORING TIME SERIES
9. DRUID ‣ Druid project started in 2011, went open source in 2012 ‣ Designed for low latency ingestion and ad-hoc aggregations ‣ Designed for keeping around a lot of history (years are ok) ‣ Growing Community • ~90 contributors • Used in production at numerous large and small organizations
10. TIME SERIES DATA ‣ Unifying feature: some notion of “event timestamp” ‣ Questions are often time-oriented ‣ Monitoring: Plot CPU usage over the past 3 days, in 5-min buckets ‣ Web analytics: How many unique users today? ‣ BI: Which accounts had large revenue deltas this week over last week? ‣ Performance: What was the 99%ile latency over the past hour?
11. 2014 REALTIME INGESTION >500K EVENTS / SECOND AVERAGE >1M EVENTS / SECOND PEAK 10 – 100K EVENTS / SECOND / CORE DRUID IN PRODUCTION
12. 2014 0.0 0.5 1.0 1.5 0 1 2 3 4 0 5 10 15 20 90%ile 95%ile 99%ile Feb 03 Feb 10 Feb 17 Feb 24 time query time (seconds) datasource a b c d e f g h Query latency percentiles QUERY LATENCY (500MS AVERAGE) 90% < 1S 95% < 5S 99% < 10S DRUID IN PRODUCTION
13. ONE WEIRD TRICK FOR FAST QUERIES ‣ Doctors hate it! ‣ Time-partitioned immutable shards ‣ Global index of time interval to shards ‣ Each shard contains indexes for fast boolean filtering ‣ Each shard is column-oriented and compressed ‣ Compute partial results locally and merge hierarchically
14. DRUID INGESTION ‣ Must have denormalized, flat data ‣ Druid cannot do stateful processing at ingestion time ‣ …like stream-stream joins ‣ …or user session reconstruction ‣ …or a bunch of other useful things! ‣ Many Druid users need an ETL pipeline
15. STREAMING DATA PIPELINES
16. OUR GOALS ‣ Input data: impressions, clicks, ID-to-name mappings ‣ Output: enhanced impressions ‣ Steps ‣ Join impressions with clicks ->“is_clicked” ‣ Look up IDs to names -> “publisher_name”, … ‣ Dissect user agent -> “browser”, “os”, … ‣ Lots of other additions
17. PIPELINE Impressions Clicks Druid ?
18. PIPELINE Impressions Partition 0 {key: 186bd591-9442-48f0, publisher: foo, …} {key: 9b5e2cd2-a8ac-4232, publisher: qux, …} … Partition 1 {key: 1079026c-7151-4871, publisher: baz, …} … Clicks Partition 0 … Partition 1 {key: 186bd591-9442-48f0} …
19. PIPELINE Impressions Clicks Druid
20. PIPELINE Impressions Clicks Shuffled Shuffle Druid
21. PIPELINE Shuffled Partition 0 {type: impression, key: 186bd591-9442-48f0, publisher: foo, …} {type: impression, key: 1079026c-7151-4871, publisher: baz, …} {type: click, key: 186bd591-9442-48f0} … Partition 1 {type: impression, key: 9b5e2cd2-a8ac-4232, publisher: qux, …} …
22. PIPELINE Impressions Clicks Shuffled Shuffle Druid
23. PIPELINE Impressions Clicks Shuffled Joined Shuffle Join Druid
24. PIPELINE Joined Partition 0 {key: 186bd591-9442-48f0, is_clicked: true, publisher: foo, …} {key: 1079026c-7151-4871, is_clicked: false, publisher: baz, …} … Partition 1 {key: 9b5e2cd2-a8ac-4232, is_clicked: false, publisher: qux, …} …
25. PIPELINE Impressions Clicks Shuffled Joined Shuffle Join Druid
26. PIPELINE Impressions Clicks Shuffled Joined Shuffle Join Enhance & Output Druid
27. ALTERNATIVE PIPELINE Impressions Clicks Shuffled Joined Shuffle Join Enhance Druid Enhanced
28. OPERATIONS
29. NICE THINGS ABOUT SAMZA ‣ Multi-tenancy: one main thread per container ‣ Robustness: isolated containers limit slowness and failure ‣ Visibility ‣ Multistage jobs, lots of metrics per stage ‣ Can inspect the message queue in Kafka ‣ State is simple ‣ Logging and restoring handled for you ‣ Single-threaded programming is nice
30. THINGS TO WATCH OUT FOR ‣ Multitenancy issues on Kafka ‣ Samza state size (affects restore times— a few GB seems ok) ‣ Serialization time can add up ‣ Default task.commit.ms is 60s
31. MONITORING ‣ Kafka partition availability ‣ Kafka disk usage ‣ Samza consumer offsets ‣ Druid drop rate ‣ Druid query latency ‣ System metrics: CPU, network, disk ‣ Event counts at various stages
32. STREAM METRICS
33. STREAM METRICS
34. REPROCESSING
35. WHY REPROCESS DATA? ‣ Bugs in processing code ‣ Imprecise streaming operations ‣ …like using short join windows ‣ Software limitations ‣ …Kafka and Samza can generate duplicate messages ‣ …Druid streaming ingestion is best-effort
36. LAMBDA ARCHITECTURES ‣ Hybrid batch/streaming data pipeline ‣ Batch technologies • Hadoop MapReduce • Spark ‣ Streaming technologies • Samza • Storm • Spark Streaming
37. LAMBDA ARCHITECTURES ‣ Advantages? • Works as advertised • Works with a huge variety of open software • Druid supports batch-replace-by-time-range through Hadoop
38. LAMBDA ARCHITECTURES ‣ Disadvantages? ‣ Need code to run on two very different systems ‣ Maintaining two codebases is perilous ‣ …productivity loss ‣ …code drift ‣ …difficulty training new developers
39. LAMBDA ARCHITECTURES
40. KAPPA ARCHITECTURE ‣ Pure streaming ‣ Reprocess data by replaying the input stream ‣ Doesn’t require operating two systems ‣ Doesn’t overcome software limitations ‣ I don’t have much experience with this
41. DO TRY THIS AT HOME
42. 2013 CORNERSTONES ‣ Druid - druid.io - @druidio ‣ Samza - samza.apache.org - @samzastream ‣ Kafka - kafka.apache.org - @apachekafka
43. GLUE Tranquility Camus / Secor Druid Hadoop indexer
44. GLUE Camus / Secor Druid Hadoop indexer druid-kaka-eight
45. TAKE AWAYS ‣ Consider Kafka for making your streams available ‣ Consider Samza for streaming data integration ‣ Consider Druid for interactive exploration of streams ‣ Metrics, metrics, metrics ‣ Have a reprocessing strategy if you’re interested in historical data
46. THANK YOU
