Anthony Agnew

Voltage Optimisation

Energy Now Expo 2013

February 22, 2013
Tweet

Transcript

  1. Renewables & • The best way to save energy is

    not to use it. “Insulate before you generate” Andy Buchan Biomass, Solar PV, Heat Pumps, Solar Thermal, MVHR, Low Energy Lighting, Underfloor Heating, Wind Turbines, Hydroelectric....
  2. National Grid • Variation in supply – Permissible Supply 207V-253V

    BS EN 50160:2007 • UK National Average 242V • Designed Voltage – EU Standard 220V
  3. Specification & Installation • Specification requirements: – Incoming voltage –

    Annual consumption (kWh) – Maximum demand (kVA) – Price of Electricity (ppu) • Simple Installation Meter Isolator Voltage Optimiser Consumer Unit
  4. Commercial Finance • Energy bills above £20k – supplier finance

    maybe available • Carbon Trust – Efficient Energy Finance “Cost of repayments is always less than the energy savings generated” • Traditional bank debt
  5. Further points • Not Three Phase Motors • Draw more

    power in areas of sub 220V supply – Power critical devices in weak grid areas. • Schools – slower paybacks due to reduced annual usage • Spiking grid Supply, renewables • Transformer integrated VO
  6. “A 230V linear appliance used on a 240V supply will

    take 4.3% more current and will consume almost 9% more energy …” and“… only achieve 55% of its rated life” Institute of Electrical Engineers
