Kubernetes Auth and Access Control Eric Chiang Software Engineer, CoreOS
@erchiang | github.com/ericchiang -
Why a talk about auth? • Assumption: ◦ You’re all
going to try to set up clusters and have to deal with this. • “Dealing with this” can range from: ◦ Whitelisting some set of nodes. ◦ Multi-tenant environments. -
Agenda 1. Overview of API server auth 2. Understanding users
in Kubernetes 3. Authorization and RBAC 4. Fun stuff: dex demo -
kubelet proxy Internet Kubernetes Worker 1/n Control Plane API Server
Scheduler Controller kubeclt -
kubelet proxy Internet Kubernetes Worker 1/n Control Plane API Server
Scheduler Controller kubeclt -
API server auth: request flow Request comes in: • Authentication
◦ Credentials determine who’s talking to the API server. • Authorization ◦ API server then determines if that user can perform that action. -
Users in Kubernetes • Kubernetes doesn’t have users* ◦ Not
really true, but I find it easier to think this way. -
Users in Kubernetes • Kubernetes doesn’t have users* ◦ Not
really true, but I find it easier to think this way. • “Users” are just strings associated with a request through credentials. ◦ Username=eric ◦ Groups=[“developer”, “gopher”] -
Users in Kubernetes: plugins Admins choose which credential strategies they
support: • x509 client auth • Password files • Bearer token webhooks • etc -
$ openssl x509 -in hi.crt -text -noout Certificate: Data: Version:
3 (0x2) Serial Number: 7920032060917626532 (0x6de99b3280b336a4) Signature Algorithm: sha256WithRSAEncryption Issuer: O=kube-cluster, CN=kube-ca Validity Not Before: Nov 1 19:50:23 2016 GMT Not After : Nov 1 19:50:24 2017 GMT Subject: O=kubelet, CN=kubelet-1 Users in Kubernetes: x509 certs -
$ openssl x509 -in hi.crt -text -noout Certificate: Data: Version:
3 (0x2) Serial Number: 7920032060917626532 (0x6de99b3280b336a4) Signature Algorithm: sha256WithRSAEncryption Issuer: O=kube-cluster, CN=kube-ca Validity Not Before: Nov 1 19:50:23 2016 GMT Not After : Nov 1 19:50:24 2017 GMT Subject: O=kubelet, CN=kubelet-1 Users in Kubernetes: x509 certs -
Users in Kubernetes: x509 certs • Does this client have
a valid client cert? ◦ No: reject request. ◦ Yes: determine username and groups based on certificate attributes. -
Users in Kubernetes: Webhook API Server kubeclt User management system
Authorization: Bearer (token) (token) -
What do these all have in common? • No objects
in the API to interact with these plugins. • Complete managed outside Kubernetes. -
Users in Kubernetes: service accounts • Service accounts are credentials
managed by k8s. • Only users that can be accessed through the k8s API. -
$ kubectl create serviceaccount do-the-robot $ kubectl get serviceaccount do-the-robot
-o yaml apiVersion: v1 kind: ServiceAccount metadata: name: do-the-robot # ... secrets: - name: do-the-robot-token-hlfte Users in Kubernetes: service accounts -
$ kubectl get secrets -o yaml do-the-robot-token-hlfte apiVersion: v1 data:
ca.crt: ( LOT OF DATA ) namespace: ZGVmYXVsdA== token: ( JSON web token signed by API server) kind: Secret type: kubernetes.io/service-account-token metadata: # ... Users in Kubernetes: service accounts -
apiVersion: extensions/v1beta1 kind: Deployment metadata: name: nginx-deployment spec: replicas: 1
template: spec: containers: - name: nginx image: nginx:1.7.9 serviceAccountName: do-the-robot Users in Kubernetes: service accounts -
spec: containers: # ... - mountPath: /var/run/secrets/kubernetes.io/serviceaccount name: do-the-robot-token-hlfte readOnly:
true # ... volumes: - name: do-the-robot-token-hlfte secret: defaultMode: 420 secretName: do-the-robot-token-hlfte Users in Kubernetes: service accounts -
Users in Kubernetes: service accounts • Have weird usernames: ◦
system:serviceaccount:kube-system:default • Just JWTs (signed JSON payloads) -
• Automatically mounted into pods. ◦ Gives each pod credentials
(and an associated user) for talking to the API server. • Only way to create users through the API. ◦ Credentials stored in secrets, be careful! • Can be used from outside the cluster. Users in Kubernetes: service accounts -
Users in Kubernetes: other options • Bearer token webhook ◦
Used by GKE • OpenID Connect (will talk about later) • Static files (for bootstrapping) -
Authorization and RBAC • Authorization uses usernames and group names
to create policy. • Ported from RedHat’s OpenShift. -
Authorization and RBAC • Default: deny all • Contain a
subject, verb, resource, and namespace. ◦ User A can create pods in namespace B. • Cannot: ◦ Refer to a single object in a namespace. ◦ Refer to arbitrary fields in a resource. • Can: ◦ Refer to subresources (e.g. nodes/status) -
Authorization and RBAC • Role • RoleBinding • ClusterRole •
ClusterRoleBinding -
Roles vs Bindings • Roles declare a set of powers.
• Bindings allow users or groups to have those powers. -
kind: ClusterRole apiVersion: rbac.authorization.k8s.io/v1alpha1 metadata: name: secret-reader rules: - apiGroups:
[""] # v1 namespace resources: ["secrets"] verbs: ["get", "watch", "list"] RBAC: Roles -
kind: ClusterRoleBinding apiVersion: rbac.authorization.k8s.io/v1alpha1 metadata: name: read-secrets subjects: - kind:
Group # May be "User", "Group" or "ServiceAccount" name: manager roleRef: kind: ClusterRole name: secret-reader apiVersion: rbac.authorization.k8s.io/v1alpha1 RBAC: Role Bindings -
ClusterRoles vs. Roles • Roles can either exist in a
cluster level or a namespace level. • Cluster role: ◦ Manage one set of roles for your entire cluster. • Role: ◦ Allow “namespace admins” to admin roles just for a namespace. -
ClusterRoleBindings vs. RoleBindings • ClusterRoleBindings grant a user power throughout
the entire cluster. ◦ Can’t refer to a role, only a cluster role. • RoleBindings grant a user power within a namespace. -
RBAC: ClusterRoles vs Roles Namespace Namespace ClusterRole “Read Only” ClusterRole
“Admin” Role “Pod Deleter” ClusterRole w/ ClusterRoleBinding ClusterRole w/ RoleBinding Role w/ RoleBinding -
Authorization and RBAC • BIGGEST GOT YA: you must have
the power of a role to bind a user to that role. ◦ If you don’t have the ability to create secrets, you can’t give someone else that power. • Currently get around this with a bootstrapping flag that lets a user sidestep this. -
Authorization and RBAC: 1.6 • Lots of work done by
@deads2k (RedHat). • Biggest highlight: default roles and role bindings! ◦ Extremely helpful for bootstrapping. ◦ Can mint x509 cert for “cluster-admin” to bootstrap cluster. -
Authorization: other plugins • Webhook! • ABAC policy file. ◦
Another one extremely useful for bootstrapping. -
Dex • Open source: https://github.com/coreos/dex • OpenID Connect server ◦
Protocol is supported as a Kubernetes authentication plugin. • Federated logins ◦ Can login to dex through other identity providers. -
{ "access_token": "HK6E_P6Dh8Y93mRNtsDB1Q", "token_type": "Bearer", "expires_in": 86400, "id_token": "eyJhbGciOiJSUzI1NiIsImtpZCI6IjhiNWI2ZjdmNmQ2YWRiODdkMjRmYWViYzFmZjNmMWEwODk4M jU1MjgifQ.eyJpc3MiOiJodHRwOi8vMTI3LjAuMC4xOjU1NTYvZGV4Iiwic3ViIjoiMDhhODY4NGIt
ZGI4OC00YjczLTkwYTktM2NkMTY2MWY1NDY2IiwiYXVkIjoiZXhhbXBsZS1hcHAiLCJleHAiOjE0Nz gzMjA0NTEsImlhdCI6MTQ3ODIzNDA1MSwiZW1haWwiOiJhZG1pbkBleGFtcGxlLmNvbSIsImVtYWls X3ZlcmlmaWVkIjp0cnVlLCJuYW1lIjoiYWRtaW4ifQ.GQaNO0BAB6PGptumTZAwzHs_JiwLMT_AUkV wRXZhXI0rfj9kn0qC4Z9elXik074kho61FIFiqFRmj-ipP037a1WyGjoNZvZuzlhGqtFNBuOmg0qe5 tYDwAcBQ5UvHMLyiQvBDicEw-SblwBCE67Tl6yPTTMMvXzcw87NbxVSGmAL1njDJ94b1LniwazncAy tdMDTwQSdo3fZi-9mNcFf4UTFvKuhbMxTcjKgMlFx8TnFEFP8qFg5MZoGnclHMlEAjAp5S56xJhYUB D44Ui7H5T6UkiYM8mEtm62mIszQ6FT3ZBoSdyxZTtdJNaHaAmWe8WzQ3eaLrH1ytHDwjzLU4Q" } OpenID Connect Token Response -
{ "access_token": "HK6E_P6Dh8Y93mRNtsDB1Q", "token_type": "Bearer", "expires_in": 86400, "id_token": "eyJhbGciOiJSUzI1NiIsImtpZCI6IjhiNWI2ZjdmNmQ2YWRiODdkMjRmYWViYzFmZjNmMWEwODk4M jU1MjgifQ.eyJpc3MiOiJodHRwOi8vMTI3LjAuMC4xOjU1NTYvZGV4Iiwic3ViIjoiMDhhODY4NGIt
ZGI4OC00YjczLTkwYTktM2NkMTY2MWY1NDY2IiwiYXVkIjoiZXhhbXBsZS1hcHAiLCJleHAiOjE0Nz gzMjA0NTEsImlhdCI6MTQ3ODIzNDA1MSwiZW1haWwiOiJhZG1pbkBleGFtcGxlLmNvbSIsImVtYWls X3ZlcmlmaWVkIjp0cnVlLCJuYW1lIjoiYWRtaW4ifQ.GQaNO0BAB6PGptumTZAwzHs_JiwLMT_AUkV wRXZhXI0rfj9kn0qC4Z9elXik074kho61FIFiqFRmj-ipP037a1WyGjoNZvZuzlhGqtFNBuOmg0qe5 tYDwAcBQ5UvHMLyiQvBDicEw-SblwBCE67Tl6yPTTMMvXzcw87NbxVSGmAL1njDJ94b1LniwazncAy tdMDTwQSdo3fZi-9mNcFf4UTFvKuhbMxTcjKgMlFx8TnFEFP8qFg5MZoGnclHMlEAjAp5S56xJhYUB D44Ui7H5T6UkiYM8mEtm62mIszQ6FT3ZBoSdyxZTtdJNaHaAmWe8WzQ3eaLrH1ytHDwjzLU4Q" } OpenID Connect Token Response -
{ "iss": "https://auth.example.com/dex", "sub": "08a8684b-db88-4b73-90a9-3cd1661f5466", "aud": "example-app", "exp": 1478320451, "iat":
1478234051, "email": "[email protected]", "email_verified": true, "groups": ["developers", "developers"], "name": "admin" } OpenID Connect Token Response -
Dex • Automatic signing key rotation. • Revocation through refresh
tokens. • Lots of login options! -
Dex v2 • Complete rewrite. • Dramatically simpler deployments. ◦
Single scalable binary. • Reworked storage layer. ◦ Can now store state in the Kubernetes API through Third Party Resources. -
Dex v2 • Runs natively on your cluster. • Can
authenticate through backends like Google, GitHub, LDAP, etc with the API server. -
[email protected] @erchiang QUESTIONS? Thanks! We’re hiring: coreos.com/careers Let’s talk! IRC
More events: coreos.com/community LONGER CHAT?
