  1. WHO AM I • Hung-Wei Chiu (邱宏瑋) • [email protected]

    hwchiu.com • Experience • Software Engineer at Linker Netowrks • Software Engineer at Synology (2014~2017) • Co-Found of SDNDS-TW • Open Source experience • SDN related projects (mininet, ONOS, Floodlight, awesome-sdn)
  2. OUTLINE • Before SDN • Open Source Networking • Open

    Compute Project • What is SDN and ONF • Experiment • ONOS • OVS • Mininet
  3. 4

  4. 5

  5. OPEN COMPUTER PROJECT • OCP • Founded 2011 • Global

    community for Open IT hardware Network Storage Telco Data Center Server Open Rack Hardware Management
  6. OCP, NETWORKING (SCOPE) • Fully disaggregated and open networking HW

    & SW • Operating System – Linux based operating system & developer tools, and ReST API’s • Fully automated configuration management & bare metal provisioning • Universal & Multi-Form Factor Switch motherboard hardware • Fully open integration & connectivity • Energy efficient power & cooling designs • Software Defined Networking (SDN)
  7. SUB PROJECTS • Subprojects of OCP Networking • Open Network

    Install Environment (ONIE) • Open Network Linux (ONL)
  8. EXAMPLE: WEDGE 100 Facebook Design CPU intel/AMD/… ASIC Broadcom/Mellanox/… Hardware

    Software NOS: Open Network Linux Forwarding Agent: FBOSS BMC: OpenBMC Switch as a Server
  9. OCP NETWORKING SOFTWARE • Switch Abstraction Interface – SAI •

    Define API to provide a vendor-independent way of controlling forwarding elements, such as a switching ASIC, and NPU or a software switch in a uniform manner. • Open Network Linux – ONL • Linux distribution (Debian) with added driver and configuration for running bare metal switches. • Open Optical Monitoring – OOM • Contents of optical module EEEROM accessible to python programmers. • Open Network Install Environment – ONIE • Open install environment for bare metal network switch • ONIE enable a bare metal network switch ecosystem where end users have a choice among different network operation systems
  10. BUILDING ON BARE METAL Bare metal switch Bare metal switch

    U-Boot & ONIE Bare metal switch U-Boot & ONIE Network OS Bare metal switch U-Boot & ONIE Network OS Application Bare metal switch Bare metal server U-Boot & PXE Bare metal server U-Boot & PXE Linux,Windows, etc Bare metal server U-Boot & PXE Linux,Windows, etc Application Server Switch
  11. WHITE BOX SWITCH MODEL Switch Data Plane Control Plane Applications

    Switch Data Plane Switch Data Plane Linux OS Applications Switch Control Plane Applications Control Protocol Traditional Switch SDN-based System Open Networking Switch
  12. SDN • Software-Defined Networking (SDN) • The physical separation of

    the network control plane from the forwarding plane, and where a control plane controls several devices.
  13. THE SDN ARCHITECTURE • DIRECTLY PROGRAMMABLE • AGILE • CENTRALLY

    MANAGED • PROGRAMMATICALLY CONFIGURED • OPEN STANDARDS-BASED AND VENDOR-NEUTRAL
  14. BASIC MODEL OF SDN • Service Customer • Manage-control network

    services via SDN controller • Send/receive data using network resources. • Network/Service Provider
  15. ONF • Open Networking Foundation • Non-profit organization • Led

    consortium driving transformation of network infrastructure. • Serves as the umbrella for a number of projects building solutions • Leveraging network disaggregation • White box economics • Open source software • Software defined standards
  16. 27

  17. THE ECOSYSTEM • 200+ Members Strong Vibrant Operator Led Consortium

    Positioned for Success • PARTNER • COLLABORATING INNOVATOR • INNOVATOR • COLLABORATOR
  18. THE ECOSYSTEM Partner Innovator 110+ Volunteer Volunteers Collaborator Operators (7)

    Vendors (10) 70+ 100s ONF (& Stanford) Guru Parulkar Network Operators AT&T Andre Fuetsch – CTO Google Urs Hölzle – SVP NTT Comm Dai Kashiwa – Director Comcast Rob Howald– VP Verizon Srini Kalapala – VP China Unicom Shao Guanglu - SVP Research & Vendor Community Nick McKeown Stanford Fabian Schneider NEC New ONF Board Including 14 Operators: Argela/Turk Telecom Microsoft China Mobile Swisscom SK Telecom Telecom Italia ECI Telecom Telefonica Facebook TELUS Globe Telecom Vodafone Goldman Sachs Yahoo
  19. ONF’S SCOPE Disaggregated boxes: Packet switch, ROADM, eNodeB, OLT, RAN

    … Programmable Forwarding Plane Open Source: ONAP, Open-O, Open Source MANO Global Orchestrators New ONF Scope of Focus Control Plane ONOS Control (OpenFlow, P4) Config (NetConf/Yang, OpenConfig) Alternative Controllers (e.g. ODL) Solutions Platforms M- CORD R- CORD E-CORD CORD VNFs Alternative VNF Frameworks (e.g. OPNFV) Service APIs: TOSCA, RESTful Network Intent-Based APIs Standards & Interworking APIs
  20. 32

  21. THE REAL SOFTWARE ABOUT SDN • SDN Controller • ONOS

    • The Switch • Software switch: Open vSwitch • Testing • Network emulator: mininet
  22. WHAT IS ONOS? • Open Network Operating System (ONOS) •

    An open source SDN network operation system • SDN controller
  23. ARCHITECTURAL TENETS • High-availability, scalability and performance • Strong abstractions

    and simplicity to develops apps and solutions • Protocol and device behavior independence • Separation of concerns and modularity
  24. OPENFLOW • Appear in 2008 • The most famous northbound

    API in SDN • OpenFlow not equal SDN • Just a communication protocol in SDN. • Defined how control plan talk to forward plan.
  25. OPENFLOW RULE L2 headers L3 headers L4 headers Switch port

    • Forward/Flood • Drop • Modify header • Local • Forward to Controller Packer bytes/counts Match Action Statistics
  26. L2 FORWARDING src_MAC L3 headers L4 headers Switch port dst_MAC

    Action * * 00:11:32:aa:bb:cc * * Forward port 6 src_MAC L3 headers L4 headers Switch port dst_MAC Action * * * * * Normal
  27. L3 FORWARDING L2 headers dst_ip L4 headers Switch port src_ip

    Action 1 * 140.113.123.234 140.114.123.234 * Forward port 4
  28. HISTORY • 2008 • First paper about OpenFlow (SDN) •

    OpenFlow: enabling innovation in campus networks • Nick McKeown setup a Nicira company • Open vSwitch + OpenFlow = NVP (NetworkVirtualization Platform)
  29. INTRODUCTION • Hypervisors need to bridge traffic. • We can

    use Linux bridge do it. • So,Why do we need Open vSwitch • Targeted multi-server virtualization. • Responding to network dynamics • Maintenance of logical tags • Hardware integration
  30. FEATURES • IPv6 • LACP • Three mode (balance-scp/tcp, active/passive)

    • STP/RSTP • VLAN • Overlay Network • VXLan/GRE/Geneve/NVGRE • OpenFlow • OVSDB • DPDK
  31. SYSTEM VIEW User Space Kernel Space ovs-vsctl ovs- dpctl ovs-

    ofctl OpenvSwitch eth0 eth1 L2 forwarding L3 routing ACL/Firewall NAT/Port forwarding
  32. ALL IN ONE • Iptables/ebtables won’t work anymore • Packet

    won’t pass netfilter now. • Use Openflow to control packets. • Also support some complicated operation in native port (without openflow) • VLAN • Bonding • Overlay network
  33. HOW OPEN VSWITCH WORKS. • Control Packets by OpenFlow •

    Support different port types • Bonding • Overlay netwokrs • VLAN/MPLS • Some features support by linux kernel • Traffic Control (Queue) • Conntrack • NAT
  34. WHO CONTROL RULES • For OpenvSwitch, you can use following

    approaches • Command line tool • ovs-ofctl add-flows • Openflow controller • Push openflow rules via tcp
  35. COMMAND LINE • ovs-ofctl add-flow br1 “xxxxxxxxxxxxxxxxxxxxxxxx” • ovs-ofctl add-flows

    br1 filename • You can put all flows in a file and inert them at once. • ovs-ofctl del-flows br1 “xxxxxxx”
  36. SDN CONTROLLER • SDN Brain • Centralized control all SDN

    network devices. • Communicate with network devices via northbound API • OpenFlow/SNMP/OVSDB/NetConf/gRPC • OpenFlow != SDN again.
  37. Rules Data Plane Network Devices (OVS) Controller (ONOS) NAT Routing

    Firewall Rules Data Plane Network Devices (OVS) Rules Data Plane Network Devices (OVS) Control Plane
  38. OPEN VSWITCH • Support connection mode • Standalone • Without

    Controller, OVS has a default rules. • Controller • Need to setup controller’s IP:Port
  39. STANDALONE MODE • Default rules is • Match: any •

    Do: action:Normal • Normal means L2 forwarding. • Open vSwitch will be same as the Linux Bridge if it’s in standalone mode.
  40. HOW TO USE OPEN VSWITCH • Create ovs bridge (we

    call it datapath) • ovs-vsctl add-br br0 • Attach existing port to OVS • ovs-vsctl add-port br0 eth0 • Dump flows • ovs-ofctl dump-flows br0
  41. WHAT • Mininet is a network emulator • Mininiet create

    a realistic virtul network, running real kernel, switch and application code, on a single machine (VM, cloud or natvie)
  42. WHY • For Developer • Testing controller • Testing applications

    • Testing before deploy • Compare to real environment • Flexible • Scalable
  43. HOW IT WORKS • Run many OpenvSwitch in your host.

    • Also run many hosts in your host (network namespace) • Connect all of them • Network topology.
  44. MININET • Click the miniet icon to simulate a network

    topology and connect all switches to ONOS controller. • Switch to the ONOS GUI and you can see six switches there. • Use ‘l’ to show the switch id. • In the mininet terminal, type h11 ping h41 • In the ONOS Gui, type ‘h’ to show host.
  45. ONOS • Click the ONOS terminal icon to start ONOS

    CLI • Type “apps –a –s “ to see all activated applications. • Type “app activate org.onospro\ject.fwd” to enable forwarding function for ONOS. • Back to miniet prompt and you can see the ping works now. • You can also see second hosts on ONOS GUI.
  46. MININT • Useful command • links • link s2 s11

    down (down the link and you can see that change it ONOS GUI) • nodes • node name + ${common command} • h11 ifconfig • iperf h11 h4 • Use iperf to generate traffic.
  47. ONOS • Commands • Show devices • devices • Show

    links • links • Show know hosts • hosts • Show flow rules • flows • Show shortest paths between each node • Paths {node1} {node2}
  48. OVS • You can also create new tab and type

    following command to see ovs status. • sudo ovs-vsctl show • sudo ovs-ofctl dump-flows s11
  49. SDNDS + CLOUD NATIVE USER GROUP • Do you have

    interested in • SDN • Ceph • OpenStack • Kubernetes • Join this meetup to learn more about. • https://www.meetup.com/Cloud-Native-User-Group-Taiwan/events/245495423/
  50. Q&A
