1. Asynchronous Service-Oriented Design Patterns for Building and Operating Flexible Services
2. @jpignata
5. P ro b l e m Statement
6. “Our Ruby on Rails application is difficult to change.”
9. monolith
11. monorail
12. “Amazon.com started [in 1996] as a monolithic application, running on a Web server, talking to a database on the back end. This application evolved to hold all the business logic, all the display logic, and all the functionality that Amazon eventually became famous for. This went on until 2001 when it became clear that the front-end application couldn’t scale anymore.” http://queue.acm.org/detail.cfm?id=1142065 A Conversation with Werner Vogels
14. Asynchronous Service-Oriented Design
15. message passing
16. a medium is used to exchange messages
17. Patterns
18. Service Mailbox Pattern
19. clients write messages to a queue
20. a service processes messages from the queue
21. FIFO Queue
22. first in, first out
23. queue.enqueue(item)
25. queue.dequeue()
27. Application Service Mailbox Service dequeue enqueue
28. Feature: Message Delivery
29. Best Friends Group
30. "What is up?" "Steve: What is up?"
31. "Heading to drinks." "Tara: Heading to drinks."
32. iOS (APNS) Android (C2DM / GCM) Windows (WPNS) SMS (SIP / SMPP / HTTP)
33. messages should be delivered exactly once
34. messages should be delivered as soon as possible
35. drop messages after 2 hours if undeliverable
36. GroupMe Twilio
37. GroupMe Resque Twilio Redis
38. GroupMe Resque Twilio Redis APNS C2DM
39. throughput choppy and low
40. large number of processes
41. different rates of change
42. Transport Service
43. high-speed eventmachine resque worker
45. GroupMe Redis Transport APNS C2DM GCM SMS WPNS
46. uses a redis list as a queue
47. resque serialization format and key names
48. GroupMe Redis Transport RPUSH resque:queue:apns [serialized item] BLPOP resque:queue:apns
49. redis lists provide the exactly- once semantics required
50. higher, more even throughput
51. easy migration path
52. same redis dependency as resque
53. Event Stream Pattern
54. File
55. log.append(item)
57. log.read(offset, total) [
58. Service Service Service Event Stream Service Service Service Subscribe Publish
59. Feature: News Feed
60. Best Friends Group
61. Pat: Something pithy and funny about the current sporting event 2 Pat: Rails is Benihana.
62. Steve and Tara liked your message: Something pithy and funny about the current sporting event Steve and Tara liked your message: Rails is Benihana.
63. class NewsFeedController < ApplicationController def index render likes: Like.find_all_by_recipient_id(current_user_id), # other locals ... end end
64. slow database queries
65. low-value news feed reads competed for database time
66. unnecessarily real-time
67. News Feed Service
68. Kafka
69. GroupMe Message Service Kafka News Feed Service Relationship Service Cache
70. Apache Kafka is a distributed, high-throughput pub/sub messaging system
71. messages are appended to a topic by a producer
72. consumers iterate through the topic starting at a given byte offset
73. picture a distributed log file that you can write to and tail from other services across the network
74. components publish user events to the event stream
75. the news feed service creates content from these events where necessary
76. multi-consumer
77. rewindable
78. Benefits
79. scalability
80. each process consumes a uniform number of resources
81. infinite horizontal scale is usually a lie
82. services allow us to add targeted capacity
83. the services scale individually
84. agility
85. updates can deployed independently
86. deploys are low-impact because our messaging layer acts as a buffer
87. reusability
88. any component that needs to send messages can use the same interface
89. cheap experimentation
90. data ownership silos naturally form in larger organizations
91. conway’s law
92. “organizations which design systems ... are constrained to produce designs which are copies of the communication structures of these organizations”
93. publishing to event streams can mitigate data silos
94. all notable events within a system are published to an event stream
95. experimental projects can read from the event stream and use the data in unanticipated ways
96. GroupMe Message Service Kafka Experimental Likes Leaderboard Relationship Service Experimental Email Newsletter Experimental Photo Gallery
97. publishing to an event stream reduces the coupling between teams
98. data availability removes barriers to exploration
99. back pressure
100. some partners mandate our maximum delivery rate
101. message-based service boundaries are natural buffers
102. groupme / pace
103. worker = Pace::Worker.new(queue: "sms", jobs_per_second: 100) worker.pause worker.resume worker.pause(0.5)
104. automatic backoff on failure
105. we pause if we exceed a threshold of remote failures to prevent compounding the problem
106. messages are buffered in the queue and flush when the system stablizes
107. since redis’ working set must fit in memory, this must be monitored closely
108. interoperability
109. SMS Provider SIP Receiver SIP Redis Mobile Originated Consumer SMS
110. SMS Provider SIP Receiver SIP Redis Mobile Originated Consumer SMS
111. Concerns
112. monitoring
113. QoS
114. QoS = [msg exited timestamp] - [msg entered timestamp]
115. nginx GroupMe Transport Messaging Provider Message Entered Timestamp Captured Message Exited Timestamp Captured
116. QoS = 1370098106.90963 - 1370098106.493368
117. QoS = ~416ms
119. Queue Size
120. LLEN [queue name]
121. often zero unless failures or throttling requirements have caused the senders to apply back pressure
122. delivery guarantees
123. exactly once at least once at most once
124. business requirements drive what delivery guarantees must be maintained
125. interface synchronization
126. your client and service must agree on the format of the messages
127. ruby objects are used to represent messages and serialize themselves for transport
128. consumers and producers work with the same objects which enforce a consistent interface
129. these clients are shared via a gem which is versioned along with the service
130. failure modes
131. the behavior of your system during failure
132. avoid cascading failure
133. what happens when redis is unavailable?
134. or memory fills up?
135. durability
136. (and performance)
137. redis by default isn’t very durable
138. even with AOF and replication, message loss is still possible
139. kafka doesn’t acknowledge produced messages
140. Learnings
141. you can go a long way with a monolith
142. messaging is a tool for service-oriented systems building
143. there are alternatives to HTTP when designing cooperating systems
144. backgrounded work is a prime candidate for service extraction
145. service extraction provides many of the promised benefits
146. as with all engineering decisions: there are trade-offs to make to realize these benefits
147. you must explicitly plan for failure cases
148. failure is another mode of operation
149. the system must bend but not break
150. you won’t know how broken something is until you measure it
151. look at percentile slices rather than averages
153. you will have to experience system failure to build resilience into the system and your team
154. 18) Failure free operations require experience with failure. Recognizing hazard and successfully manipulating system operations to remain inside the tolerable performance boundaries requires intimate contact with failure. http://www.ctlab.org/documents/How%20Complex%20Systems%20Fail.pdf How Complex Systems Fail
155. we prefer smaller building blocks like redis and kafka over message brokers like rabbitmq, qpid, etc
156. focus on the interfaces between your systems
157. ad-hoc JSON serialization formats are fraught
158. there’s more than one way to do it
159. your mileage will vary
160. http://tx.pignata.com Thank You! @jpignata
161. http://tx.pignata.com Thank You! @jpignata ps we’re hiring!
