Building a Distributed Data Processing Pipeline Using Spring Cloud Data Flow
In this talk I will introduce you to Spring Cloud Data Flow, a tool set for building cloud-native JVM applications as a distributed data processing pipeline. We will take a look at some of the common patterns for processing data streams using Spring Boot applications that consume and produce streams of messages.
We will then dive into a microservice example project of a cloud-native data processing application built using Spring Boot and Spring Cloud Data Flow. Using this example project, I'll show you how to use a container scheduler to spin up a microservice cluster on a development machine that processes a stream of tweets in a data flow pipeline.
Kenny Bastani
November 02, 2015
Transcript
73 slides
-
© 2014 Pivotal Software, Inc. All rights reserved. Distributed Data
Processing with Spring Cloud Data Flow Kenny Bastani Spring Developer Advocate 1 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Kenny Bastani 3 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Agenda 4 1 Agenda 2 Microservices 3 What is Spring Boot? 4 What is Spring Cloud? 5 Lattice - Cloud Native Platform 6 Spring Cloud Data Flow 7 Streaming Analytics Example (Twitter) 9. Demo -
© 2014 Pivotal Software, Inc. All rights reserved. Microservices “Kind
of like a head ache, but more of them.” 5 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Quick Explanation of Microservices • Each team gets one database and one service • Shared caches are platform provided services that are shared for consistency 6 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani 7 -
© 2014 Pivotal Software, Inc. All rights reserved. Cloud Native
Microservices 8 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Cloud-native Microservice Deployment • Each microservice can be containerized with their application dependencies • Containers get scheduled on virtual machines with an allotted resource policy 9 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Auto-scaling • An elastic runtime handles auto-scaling of VMs with cloud providers • Microservices should be load balanced vertically and not horizontally 10 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Composition & Orchestration • Each microservice needs to communicate outside containers • Service discovery provides an automatic method for finding other service dependencies 11 -
© 2014 Pivotal Software, Inc. All rights reserved. Spring Boot
A JVM micro-framework for building microservices 12 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani What is Spring Boot? 13 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Spring Boot Roles 14 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Automatic Configuration • An application class is annotated with @SpringBootApplication • Additional annotations are added to indicate the role of the Spring Boot application 15 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Spring Boot for Microservices 16 -
© 2014 Pivotal Software, Inc. All rights reserved. Spring Cloud
A toolset designed for building distributed systems 17 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani What is Spring Cloud? • Spring Cloud provides a way to turn Spring Boot microservices into distributed applications 18 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani What is Spring Cloud? 19 ✴ Service Discovery ✴ API Gateway ✴ Circuit Breakers ✴ Distributed Tracing -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Service Discovery & Configuration Service 20 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Configuration Service 21 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Service Discovery 22 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani API Gateway 23 -
© 2014 Pivotal Software, Inc. All rights reserved. But what
about deployments? 24 -
© 2014 Pivotal Software, Inc. All rights reserved. Lattice A
cloud-native platform for deploying and scaling containers in production 25 -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Containers, containers, containers • Lattice helps you manage Docker container deployments on clusters of VMs • Choose the cloud provider you want, deploys containers from Docker hub 26 -
© 2014 Pivotal Software, Inc. All rights reserved. Spring Cloud
Data Flow Java microservices that process data in a pipeline 27 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Spring Cloud Data Flow • What is Spring Cloud Data Flow? – Spring Cloud Data Flow is a data processing pipeline that uses Spring Boot microservices – Each Spring Boot microservice takes in a message and produces a message, containing the data that you're processing 28 -
© 2014 Pivotal Software, Inc. All rights reserved. How do
we design a data processing pipeline? 29 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Start with understanding your source data • What do you want to measure? – Trending analytics in real time 30 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Understand the function of your pipeline • What does an individual message contain? – A single tweet 31 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Understand what you want to measure • What do you want to filter? – A set of hash tags in the body of a Tweet 32 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Understand the outputs • What do I want to measure over time? – The velocity of hash tag counts from tweets every second 33 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani What is the result of our measurements? • A graph that shows the velocity of each tweet and its hash tags over time • Real time streaming analytics so we can make fast informed decisions 34 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Data Processing Pipeline Example 35 Source Process Filter Counter Data Data Filter messages Transformation Increment counters Ingest messages Database -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Scalable distributed data processing 36 Source Process Filter Counter Data Data Filter messages Transformation Increment counters Ingest messages Source Filter Process Counter Database -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Input and output channels • Each Spring Boot microservice has an input channel and an output channel 37 Spring Boot Service Input Channel Output Channel Microservice Message queue Message queue -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Input and output channels 38 Spring Boot Service Input Channel Output Channel Microservice Message queue Message queue Message Message Messages Messages -
© 2015 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Building Real-time Analytics on Twitter hash tags 39 -
© 2014 Pivotal Software, Inc. All rights reserved. Setting up
a data processing pipeline 40 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani We want to build something like this: 41 Source Process Filter Counter Data Data Filter messages Transformation Increment counters Ingest messages Source Filter Process Counter Database -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Responsibility of a source module • Ingest data from multiple sources, such as a streaming REST API endpoint or HDFS • Transform a stream into discrete messages that are uniformly distributed, such as an individual tweet • Output those messages to an output channel for the next service to process 43 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Ingesting tweets • We start by building a Spring Boot source module that imports tweets from Twitter 44 Data Tweet Ingest tweets Source Module -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Visualize the tweet source module 45 Spring Boot Streaming Endpoint Output Channel Source Module Twitter API Twitter stream Message Message Tweets Twitter Stream Service Channel: twitter-stream -
© 2014 Pivotal Software, Inc. All rights reserved. Adding a
filter module 46 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Responsibility of a filter module • Filter messages from the source module • Filters noise to increase quality of measurements in down stream modules • Example: – I only want to measure tweets containing the hash tag #java2days 47 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Visualizing the filter module 48 Spring Boot Input Channel Output Channel Only tweets containing: #java2days Message Message Tweets Filter Service Channel: twitter-stream Channel: processor-stream -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Our pipeline now looks like: 49 Source Filter Data Tweets #java2days Twitter Stream API Twitter Stream Filter Tweets … -
© 2014 Pivotal Software, Inc. All rights reserved. Adding a
processor module 50 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Responsibility of a processor module • Take a filtered stream of messages and produce multiple output messages by transforming the payload into multiple dimensions of attributes • For example: – Take a #java2days tweet and parse the other hash tags and output one message per hash tag – #java2days -> (#Java, #SpringBoot, #JavaEE) 51 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Processor module 52 Spring Boot Input Channel Output Channel “… #java2days …" -> #Java, #SpringBoot, #JavaEE… Message Message #java2days Tweets Processor Service Channel: processor-stream Channel: counter-stream -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Our pipeline now looks like: 53 Source Filter Data Tweets #java2days Twitter Stream API Twitter Stream Filter Tweets Filter #Java, #SpringBoot… Process Hash tags … -
© 2014 Pivotal Software, Inc. All rights reserved. Adding a
counter module 54 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Responsibility of a counter module • Take messages from an input channel and output an increment to multiple buckets that count message attributes over time • Save the results to a sink, for example a Redis database • Use Spring Cloud Data Flow admin tool to measure tweets over time 55 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Counter module 56 Spring Boot Input Channel Redis DB Increment counts for hashtags: #Java -> +1, #SpringBoot -> +1 Message Message Hash tags Counter Service Channel: counter-stream #Java: 201 #SpringBoot: 120 #JavaEE: 111 Counter Metrics: -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Our pipeline now looks like: 57 Source Filter Data Tweets #java2days Twitter Stream API Twitter Stream Filter Tweets Filter #Java, #SpringBoot… Process Hash tags Filter #Java: 201 #SpringBoot: 123 Increment Counter Metrics Redis Tweets Tweets Hash tags -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Scaling our pipeline • Services in the pipeline can be scaled up and down automatically to handle the load and prevent bottlenecks 58 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Auto-scaling 59 Source Process Filter Counter Filter Process 5,121 Filter 52 Filter 23 1 4 2 1 Scale up Scale down Instances: Instances: Instances: Instances: -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Auto-scaling 60 Source Process Filter Counter Filter Process 123 Filter 412 121 1 3 3 1 Scale down Scale up Instances: Instances: Instances: Instances: Process -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Goal of auto-scaling • Keep the data processing pipeline uniform to prevent bottlenecks • Optimize the instance count on cloud providers so that cost can be predicted and optimized 61 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Sinking messages into counters • Each message in the pipeline has an opportunity to increase multiple counters • Counters are like buckets, and we can increment those buckets with a name and timestamp 62 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Twitter Analytics Demo • We’re going to brave the demo gods • Wish me luck • First, let’s review the steps for the demo (in case it fails) 63 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani What we will demo: 64 Source Filter Data Tweets All tweets Twitter Stream API Twitter Stream Filter Tweets Filter #Fun, #Awesome… Process Hash tags Filter #Fun: 201 #Awesome: 123 Increment Counter Metrics Redis Tweets Tweets Hash tags -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Let’s go through the steps • Start a Redis server • Start the twitter streaming module • Start the filter module • Start the processor module • Start the counter module • Start Spring Cloud Data Flow Admin UI 65 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Start Redis Server 66 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Start Twitter Stream Module 67 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Start the Filter Module 68 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Start the Processor Module 69 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Start the Counter Module 70 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Start Spring Cloud Data Flow Admin UI 71 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Navigate to the Admin UI 72 -
© 2014 Pivotal Software, Inc. All rights reserved. Follow me
on Twitter: @kennybastani Thanks! Questions? http://start.spring.io/ 73
