Data binding on Android

How to use data binding in real world projects

Useful links:
https://github.com/ErikHellman/DataBindingFormValidation
https://github.com/lisawray/fontbinding
https://github.com/radzio/android-data-binding-recyclerview

https://developer.android.com/topic/libraries/data-binding/index.html
https://medium.com/@georgemount007
https://www.youtube.com/watch?v=DAmMN7m3wLU

Transcript

1. Data binding on Android How to use it in the real world
2. Agenda • What, why, how? • Two-way binding • Custom attributes • Event handlers • Architecture • Tips and tricks
3. What, why, how?
4. What is data binding? • Connect data sources with views • Automatic updates (requires some extra effort) • Common approach in other frameworks • WPF & Windows Phone (C#) • Angular (JavaScript)
5. Why use data binding? • Cleaner code • Simple expressions in views • Powerful custom attributes
6. Getting started – Enable data binding android { ... dataBinding { enabled = true } ... }
7. Getting started – Layout setup <?xml version="1.0" encoding="utf-8"?> <layout xmlns="..."> <data> <variable name="user" type="com.databinding.User"/> </data> <TextView android:text="@{user.firstName}"/> </layout>
8. Getting started – Activity setup @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); DataBindingUtil .setContentView(this, R.layout.activity_main); }
9. Getting started – Activity setup @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); DataBindingUtil .setContentView(this, R.layout.activity_main); } ActivityMainBinding.java
10. Getting started – Activity setup @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); ActivityMainBinding binding = DataBindingUtil .setContentView(this, R.layout.activity_main); User user = new User("George"); binding.setUser(user); }
11. How does it work? • Process layout files • Parse expressions • Generates Java code • Traverses the view hierarchy once to find all views • Keeps a reference to the views
12. Usage • Use it to replace findViewById or Butter Knife @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); ActivityMainBinding binding = DataBindingUtil .setContentView(this, R.layout.activity_main); binding.userName.setText(user.getName()); }
13. Usage • Transforming text android:text="@{String.valueOf(index + 1)}" • Setting views visible based on certain conditions android:visibility="@{user.age < 18 ? View.GONE : View.VISIBLE}" ⚠
14. Usage <ImageView app:imageUrl="@{viewModel.user.pictureUrl}" /> <EditText android:text="@{viewModel.user.name}"/> <EditText android:text="@{viewModel.user.email}"/> <EditText android:text="@{viewModel.user.location}" />
15. Dealing with updates – Option 1 public class User { public final ObservableField<String> firstName = new ObservableField<>(); } user.firstName.set("Louise")
16. Dealing with updates – Option 2 public class User extends BaseObservable { private String lastName; @Bindable public String getLastName() { return lastName; } public void setLastName(String lastName) { this.lastName = lastName; notifyPropertyChanged(BR.lastName); }
17. Dealing with updates - Internals private long mDirtyFlags = 0xffffffffffffffffL; /* flag mapping flag 0 (0x1L): user.firstName flag 1 (0x2L): user flag 2 (0x3L): user.lastName flag 3 (0x4L): null flag mapping end*/
18. Dealing with updates - Internals public void setUser(User user) { updateRegistration(1, user); this.mUser = user; synchronized(this) { mDirtyFlags |= 0x2L; } notifyPropertyChanged(BR.user); super.requestRebind(); }
19. Dealing with updates - Internals protected void executeBindings() { if ((dirtyFlags & 0xeL) != 0) { if (user != null) { // read user.lastName lastNameUser = user.getLastName(); } } }
20. Two-way binding how to handle user input
21. Two-way binding <EditText android:text="@{user.firstName}" … /> <EditText android:text="@={user.firstName}" … />
22. Custom attributes aka binding adapters
23. Custom attributes – image loading @BindingAdapter({"app:imageUrl", "app:error"}) public static void loadImage(ImageView view, String url, Drawable error { Glide.with(view.getContext()) .load(url) .error(error) .into(view); }
24. Custom attributes – image loading @BindingAdapter({"app:imageUrl", "app:error"}) public static void loadImage(ImageView view, String url, Drawable error { Glide.with(view.getContext()) .load(url) .error(error) .into(view); }
25. Custom attributes – image loading @BindingAdapter({"app:imageUrl", "app:error"}) public static void loadImage(ImageView view, String url, Drawable error { Glide.with(view.getContext()) .load(url) .error(error) .into(view); }
26. Custom attributes – font @BindingAdapter({"app:font"}) public static void setFont(TextView textView, String fontName) { textView .setTypeface(FontCache.getInstance(context) .get(fontName)); } <TextView app:font="@{'alegreya'}" /> https://github.com/lisawray/fontbinding
27. Custom attributes – animations @BindingAdapter({"app:animatedVisibility"}) public static void setVisibility(View view, int visibility) { … ObjectAnimator alpha = ObjectAnimator.ofFloat(view, View.ALPHA, startAlpha, endAlpha); … alpha.start(); } Full example: https://medium.com/google-developers/android-data-binding-animations-55f6b5956a64
28. Event handlers
29. Event handlers public class UserViewModel { … public View.OnClickListener clickListener; … } <View android:onClick="@{viewModel.clickListener}" … />
30. Event handlers public class UserViewModel { … public void clickListener(View view) {…} … } <View android:onClick="@{viewModel.clickListener}" … />
31. Event handlers textChangedListener = new TextWatcher() { public void beforeTextChanged … public void onTextChanged … public void afterTextChanged … } <EditText android:addTextChangedListener= "@{viewModel.textChangedListener}"/>
32. Event handlers <EditText android:addTextChangedListener= "@{viewModel.textChangedListener}" … /> <EditText android:afterTextChanged= "@{viewModel.afterTextChanged}" … />
33. Event handlers with parameters public class UserViewModel { public void save(User user) { userRepository.save(user); } } <Button android:onClick= "@{()->userViewModel.save(user)}"/>
34. Architecture
35. MVVM View ViewModel Model
36. Data binding MVVM View ViewModel Model getTasks() callback
37. Tips & tricks
38. RecyclerView public class ViewHolder extends RecyclerView.ViewHolder { private final ListItemBinding listItemBinding; public ViewHolder(ListItemBinding binding) { super(binding.getRoot()); this.listItemBinding = binding; } … }
39. RecyclerView public class ViewHolder extends RecyclerView.ViewHolder { private final ListItemBinding listItemBinding; … public void bind(User user) { listItemBinding.setUser(user); listItemBinding.executePendingBindings(); } }
40. RecyclerView public class UserAdapter extends RecyclerView.Adapter { private List<User> users; … @Override public void onBindViewHolder(ViewHolder holder, int position) { User user = users.get(position); holder.bind(user); } }
41. RecyclerView public class MainActivity extends … { @Override protected void onCreate() { ActivityMainBinding binding = DataBindingUtil .setContentView(this, R.layout.activity_main); binding.users.setLayoutManager( new LinearLayoutManager(this)); binding.users.setAdapter(new UserAdapter(users)); } … }
42. RecyclerView advanced @BindingAdapter("items") public static <T> void setItems(RecyclerView recyclerView, Collection<T> items) { BindingRecyclerViewAdapter<T> adapter = (BindingRecyclerViewAdapter<T>) recyclerView.getAdapter(); adapter.setItems(items); }
43. RecyclerView advanced <android.support.v7.widget.RecyclerView … app:items="@{usersVM.users}" app:itemViewBinder="@{usersVM.itemViewBinder}" app:clickHandler="@{usersVM.click}" app:longClickHandler="@{usersVM.longClick}" /> https://github.com/radzio/android-data-binding-recyclerview
44. String formatting <TextView android:text= "@{@string/greeting(user.firstName)}" /> <resources> <string name="greeting">Hello, %s</string> </resources>
45. Math in expressions <TextView android:padding="@dimen/padding" android:padding="@{@dimen/padding}" android:padding="@{@dimen/padding * 2}" android:padding="@{@dimen/padding + @dimen/padding}" android:padding="@{largeScreen ? @dimen/padding * 2 : @dimen/padding}" />
46. Overriding Android attributes @BindingAdapter("android:layout_margin") public static void setMargin(View view, float margin) { MarginLayoutParams lp = (MarginLayoutParams) view.getLayoutParams(); lp.setMargins(margin, margin, margin, margin); view.setLayoutParams(layoutParams); }
47. Referencing other views <CheckBox android:id="@+id/showName"/> <TextView android:visibility="@{showName.isChecked ? View.VISIBLE : View.GONE}" android:text="@{user.name}"/>
48. Binding conversions @BindingConversion public static int convertBooleanToVisibility(boolean visible) { return visible ? View.VISIBLE : View.GONE; } <TextView … android:visibility="@{user.isAdult}"/>
49. Resources • Official documentation https://developer.android.com/topic/libraries/data-binding/index.html • George Mount https://medium.com/@georgemount007 • Advanced data binding (Google IO 2016) https://www.youtube.com/watch?v=DAmMN7m3wLU
50. Data binding on Android twitter.com/kevinpelgrims kevinpelgrims.com
