Node-RED in 2022

Slides from my keynote talk at Node-RED Con 2022

Transcript

1. @knolleary Node-RED in 2022
2. @knolleary twitter.com github.com /knolleary twitch.tv • Nick O’Leary • Node-RED Project Lead • Founder & CTO FlowForge Inc. About Me
3. @knolleary Node-RED in 2022 (so far) releases 876 20 14 commits contributors
4. @knolleary
5. @knolleary nodered.org/about/releases
6. @knolleary nodered.org/about/releases
7. @knolleary npm install node-red 2015 2019 2020 2021 2022 2016 2017 2018
8. @knolleary 2018 2019 2020 2021 2022 Discourse Growth Pageviews
9. @knolleary 2018 2019 2020 2021 2022 Discourse Growth Monthly Sign-ups
10. @knolleary 237,960,000 Pulls of the nodered/node-red Docker Image since October 2019
11. @knolleary 238,041,586 Pulls of the nodered/node-red Docker Image since October 2019
12. @knolleary Node Growth Modules shared on flows.nodered.org Modules using @scoped/name 2014 2015 2016 2017 2018 2019 2020 2021 2022
13. @knolleary Scorecards Introduced in January 2022 Generated when a node is updated on the library 878 nodes added/updated that now have scorecards
14. @knolleary Low # dependencies No known bad packages No out-of-date dependencies Unique node names Includes examples Has known license Provides bugs/repo url Packaging naming Identifies min NR version Identifies min Node.js version Scorecard results % of nodes with scorecards passing the check
15. @knolleary Low # dependencies No known bad packages No out-of-date dependencies Unique node names Includes examples Has known license Provides bugs/repo url Packaging naming Identifies min NR version Identifies min Node.js version Scorecard results % of nodes with scorecards passing the check
16. @knolleary Node-RED 3.0
17. @knolleary • Dropped support for Node 12.x • Monaco Text Editor now default • Context Menu • Junctions • Continuous Search • Default Node Names • Debug Path Tooltip • Editing Stopped Flows • Dynamic Link Call Nodes Node-RED 3.0 https://nodered.org/blog/2022/07/14/version-3-0-released
18. @knolleary Context Menu Quick access to common actions. Easier to discover what is available.
19. @knolleary Junctions
20. @knolleary Debug Path Tooltip Quickly find nodes that are logging to the Debug sidebar, wherever they are.
21. @knolleary Continuous Search Navigate search results from the workspace toolbar
22. @knolleary • Dropped support for Node 12.x • Monaco Text Editor now default • Context Menu • Junctions • Continuous Search • Default Node Names • Debug Path Tooltip • Editing Stopped Flows • Dynamic Link Call Nodes Node-RED 3.0 https://nodered.org/blog/2022/07/14/version-3-0-released
23. @knolleary What’s Next?
24. @knolleary • Locking Flows • URL Linking to Individual Nodes • Global Environment Variable management • Splitting Flow File • Better Environment Variable Workflow Currently Under Development/Discussion
25. @knolleary Locking Flows Add the ability to lock a flow to prevent it being modified. Prevent accidental changes to critical parts of your application. Will also allow a better user-experience for read-only users. Discussion: https://github.com/node-red/designs/discussions/78 Status: In development - target 3.1.0
26. @knolleary Add the ability to set globally scoped environment variables within the editor Removes the need to edit settings.js to add new env vars to the whole application Adds a new global-config configuration node. This could become home to other global configuration options that become exportable with the flows. Global Environment Variables Discussion: https://github.com/node-red/designs/discussions/76 Status: In development
27. @knolleary Splitting Flow File An item that has been on the backlog for a long time. Increasing amount of feedback on challenges of managing Flow File in git and handling merges. Lots of custom solutions developed by the community - but something we should look at ourselves. Discussion: TBD Status: TBD
28. @knolleary http://localhost:1880/#flow/1234 URL Linking to Individual Nodes Discussion: https://github.com/node-red/designs/discussions/79 Status: PR #3870 merged - will be in 3.1.0 Node-RED already supports linking to a flow/subflow
29. @knolleary http://localhost:1880/#node/1234 http://localhost:1880/#group/1234 URL Linking to Individual Nodes Discussion: https://github.com/node-red/designs/discussions/79 Status: PR #3870 merged - will be in 3.1.0 Node-RED already supports linking to a flow/subflow This adds ability to link to individual node or group
30. @knolleary http://localhost:1880/#flow/1234/edit http://localhost:1880/#node/1234/edit http://localhost:1880/#group/1234/edit URL Linking to Individual Nodes Discussion: https://github.com/node-red/designs/discussions/79 Status: PR #3870 merged - will be in 3.1.0 Node-RED already supports linking to a flow/subflow This adds ability to link to individual node or group You can also link to the edit dialog.
31. @knolleary http://localhost:1880/#node/1234 URL Linking to Individual Nodes Discussion: https://github.com/node-red/designs/discussions/79 Status: PR #3870 merged - will be in 3.1.0 Node-RED already supports linking to a flow/subflow This adds ability to link to individual node or group You can also link to the edit dialog. Button in Info Sidebar copies link for the current selected object to the clipboard
32. @knolleary • Create tests for your flows within the editor • Testing Sidebar lets you define test suites and test cases • Individual node behaviour can then be customised per-test case, letting you simulate different behaviours - for example, faking the response of an HTTP Request to test edge cases • Run tests from the sidebar, or on the command-line Node-RED Flow Testing Framework coming soon-ish… Initial design sketches from January 2020
33. @knolleary • Weekly Node-RED LiveStream Monday 8pm (UK) https://twitch.tv/knolleary Thank You
