AWS Step Functions は CDK で書こう!

AWS Step Functions は CDK で書こう!

AWS Step FunctionsはAWS CDKで書くと、他のリソースをまとめて作ったり、IAM Policyを書かなくても済んだりします。JSONataにも対応しました。

JAWS DAYS 2025の登壇資料です。

Avatar for Kenji Kono

Kenji Kono

March 05, 2025
Tweet

More Decks by Kenji Kono

Other Decks in Programming

Transcript

  1. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. © 2025, Amazon Web Services, Inc. or its affiliates. All rights reserved. Amazon Confidential and Trademark. AWS Step Functions は CDK で書こう︕ ⾼野 賢司 J A W S D A Y S 2 0 2 5 シニア ソリューション アーキテクト アマゾン ウェブ サービス ジャパン合同会社 2025/2/26
  2. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. • Infrastructure as Code (IaC) の 技術⽀援をリード • Baseline Environment on AWS (BLEA) の 開発コアメンバー https://github.com/aws-samples/baseline-environment-on-aws @konokenj こ う の け ん じ ⾼野 賢司 シニア ソリューション アーキテクト @名古屋 アマゾン ウェブ サービス ジャパン合同会社
  3. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. 3 AWS Step Functions で変数をサポート start Step 1 Step 2 Step 3 Step 4 end “value” : 1 “value” : 1 • Step Functions 内で変数をサポート – アップデート前はステップ間で値を引き渡していく必要 – アップデートにより変数の保存と参照が簡素化 • ワークフローの途中で値の更新が可能 • 変数のスコープ – 変数に格納したのち、後続のステップから参照可能 – 例外として Map, Parallel内の変数はその内部でのみ参照可能
  4. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. JSONPath + Intrinsic Functions + Lambda JSONata JSONata によるデータ変換 • JSONataはOSSのJSON⽤データクエリおよび変換⾔語 • ⽇付・時刻のフォーマット、⽂字列操作、四則演算などが可能 4 "Calculate": { "QueryLanguage": "JSONata-2.0", "Type": "Task", ... "Assign": { "sum.$": "$sum($states.result.Product.(Price * Count))" } } "Get prices and quantities": { "Type": "Task", ... "ResultSelector": { "Prices.$": "$.Product.Price", "Counts.$": "$.Product.Count" }, "ResultPath": "$.productInfo", "Next": "Calculate" }, "Calculate": { "Type": "Task", "Resource": "arn:...:lambda:invoke", "Parameters": { "FunctionName": "lambdaArn", "Payload.$": "$.productInfo" }, "ResultSelector": { "sum.$": "$.Payload.sum" }, "ResultPath": "$.ProductSum", ... } 商品の価格・数量から合計⾦額を計算する例
  5. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. JSONata によるデータ変換 • JSONataはJSONPathと⽐較し変換フィールドの数を減らして⼊出⼒処理を簡略化 5 Task State Input Argument Output Assign Output Variables Action - Service Integration - HTTPS Endpoint - Activity Worker JSONata JSONPath Task State Input Parameters ResultSelector Assign Output Variables Action - Service Integration - HTTPS Endpoint - Activity Worker InputPath ResultPath OutputPath
  6. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. • Step Functions の変数と JSONata データ変換 が CDK でも簡単に使えるようになった • 従来の JSONPath ではステート間での 値の受け渡しが複雑だった • InputPath, Parameters, ResultPath, ResultSelector が Arguments だけになる • ステートマシン内でのデータ操作のための Lambda 関数を減らせる • 各ステートの静的メソッド .jsonata() / .jsonPath() を使うことで 適切なプロパティだけが使える 6 AWS Step Functions L2 コンストラクトでJSONata に対応 aws-cdk v2.178.0 (2025/2/6) https://github.com/aws/aws-cdk/releases/tag/v2.178.0 変数と JSONata を使った AWS Step Functions での開発者エクスペリエンスの簡素化 | Amazon Web Services ブログ https://aws.amazon.com/jp/blogs/news/simplifying-developer- experience-with-variables-and-jsonata-in-aws-step-functions/ new StateMachine(this, 'StateMachine', { definition: workflow, queryLanguage: QueryLanguage.JSONATA, }); TypeScript // コンストラクタでのステート作成(レガシー) new sfn.Pass(this, 'Constructor Pattern', { queryLanguage: sfn.QueryLanguage.JSONATA, // or JSON_PATH }); // 今後はコンストラクタではなく static method の利⽤を推奨 // JSONata sfn.Pass.jsonata(this, 'JSONata Pattern', { outputs: { foo: 'bar' }, }); // JSONPath sfn.Pass.jsonPath(this, 'JSONPath Pattern', { outputPath: '$.status', }); TypeScript ステートマシン全体での設定 ステートごとの設定
  7. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. • S3 バケットや Lambda 関数、ECS クラスタ等 必要なリソースを画面遷移せずに作れる • grant メソッドで IAM ポリシーを自動設定 • JSONata / JSONPath で型定義が分かれている ため使えるプロパティだけが提案される • --hotswap で数秒でデプロイ。 --hotswap-fallback はホットスワップ不可の 場合のみ CloudFormation 経由でデプロイ 7 AWS Step Functions は CDK で書こう︕ # ステートマシンを変更したら CDK でデプロイ npx cdk deploy --all --require-approval=never --hotswap-fallback # そのままテストしよう!! aws s3 cp test.json s3://example/ # AWS CLI のファイル⼊⼒ (file://) を使えば、⼀度実⾏したイベントを再現できる aws stepfunctions start-execution --state-machine-arn *** --input file://testevent.json console Lambda 関数に S3 バケットへの読み取り・書き込み権限を付与 const procFunc = new PythonFunction(this, 'ProcessFunc', { entry: 'backend/etl', runtime: Runtime.PYTHON_3_13, index: 'etl/process.py', }); rawDataBucket.grantRead(procFunc); workBucket.grantReadWrite(procFunc); TypeScript
  8. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. • 自動スキャンは Pro Tier のみ • 検出対象は Amazon CodeGuru Detector Library で確認できる https://docs.aws.amazon.com/codegur u/detector-library/typescript/tags/aws- cdk/ 8 2024/4/30 ⼀般提供開始 (GA) https://aws.amazon.com/about-aws/whats-new/2024/04/amazon-q- developer-generally-available/ Amazon CodeWhisperer にて AI を活⽤した新しいコード修正、 IaC サポート、および Visual Studio との統合提供を開始 https://aws.amazon.com/jp/blogs/news/amazon-codewhisperer-offers-new- ai-powered-code-remediation-iac-support-and-integration-with-visual-studio/ CDK なら Amazon Q Developer で セキュリティスキャン もしてくれるよ
  9. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. 新しく stable になったモジュール • appconfig (v2.130.0) • apigatewayv2 (v2.112.0) • synthetics (v2.99.0) • batch (v2.96.0) • appsync (v2.60.0) 新しい L2 コンストラクト(一部) • ecs.ServiceManagedVolume (v2.122.0) • cloudfront.KeyValueStore (v2.118.0) • stepfunctions.DistributedMap (v2.127.0) • codedeploy.EcsDeploymentGroup (v2.50.0) • codebuild.Fleet (v2.145.0) • codepipeline.Pipeline (PipelineType.V2 / v2.133.0 からデフォルト) 9 CDK の最新情報は X で配信しています AWS CDK の アップデート情報を つぶやいています #cdk_releases * v2.29.0 (2022年6⽉) から https://twitter.com/hashtag/ cdk_releases?src=hashtag_click&f=live Community News https://x.com/konokenj
  10. © 2025, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon Confidential and Trademark. Thank you! © 2025, Amazon Web Services, Inc. or its affiliates. All rights reserved. Amazon Confidential and Trademark. Kenji Kono @konokenj
