What's new in Android Q UI

Check out the new UI features in Android Q. The presentation covers: Foldables, Bubbles, the new ShareSheet, Gesture Navigation, Dark Theme and Settings Panels.

Transcript

1. Murat Yener @yenerm What’s new in Android UI @manuelvicnt Manuel Vivo
2. Murat Yener @yenerm What’s new in Android UI @manuelvicnt Manuel Vivo
3. Foldables Bubbles Share Sheet Gestural Navigation & Edge to Edge Dark Theme Settings Panels What the
4. Foldables
5. Foldables 2 categories: - Fold in - Fold out
6. Tablets Chrome OS
7. Follow best practices to support all the different form factors - Handling Configuration Changes - Resizability
8. Configuration Changes Your app should restore the same state and location the user was in before folding or unfolding.
9. Resizability android:resizeableActivity compat mode
10. New aspect ratios maxAspectRatio available now
11. Multi-resume In multi-window, all top focusable activities in visible stacks are now in the RESUMED state
 onTopResumedActivityChanged(boolean) Resumed Resumed Resumed
12. Resources Even if your app is resumed, it might disconnect from shared resources: - Camera - Mic - etc. Handle resource loss gracefully
13. Consider Drag & Drop For text and images
14. Testing Emulators available in Android Studio 3.5 Test how your app reacts to: - Configuration changes - Multi-window and multi-resume - Resizing and new screen ratios
15. Tablets Multi-resume Compat mode Configuration Changes
16. Resources - Building apps for Foldables doc https://developer.android.com/preview/features/foldables - Drag & drop documentation https://developer.android.com/guide/topics/ui/drag-drop - Build Apps for Foldable, Multi-Display, and Large-Screen Devices IO 2019 video https://www.youtube.com/watch?v=8uQEzv3upy8
17. Bubbles
18. Bubbles
19. Bubbles !Over the notification shade !On the lock screen !Over the keyboard !Over PIP !Over each other
20. SYSTEM_ALERT_WINDOW !Read your screen !Put UI on screen (anywhere, anytime…) !Autogranted (since M)
21. Bubbles !Built into the Notification system !Floats on top of other app content !Can be expanded (to reveal app functionality and information) !Can be collapsed/stacked (when not being used) !Looks like a notification on lock screen and always-on-display
22. Bubbles Users can opt-out!
23. Opt-out? !Block - notifications are not blocked, but they will never appear as bubbles !Allow - all notifications sent with BubbleMetaData will appear as bubbles
24. <activity android:name=".bubbles.BubbleActivity" android:theme="@style/AppTheme.NoActionBar" android:label="@string/title_activity_bubble" android:allowEmbedded="true" android:documentLaunchMode="always" android:resizeableActivity="true" />
25. <activity android:name=".bubbles.BubbleActivity" android:theme="@style/AppTheme.NoActionBar" android:label="@string/title_activity_bubble" android:allowEmbedded="true" android:documentLaunchMode="always" android:resizeableActivity="true" />
26. <activity android:name=".bubbles.BubbleActivity" android:theme="@style/AppTheme.NoActionBar" android:label="@string/title_activity_bubble" android:allowEmbedded="true" android:documentLaunchMode="always" android:resizeableActivity="true" />
27. // Create notification val chatBot = Person.Builder() .setBot(true) .setName("BubbleBot") .setImportant(true) .build() val builder = Notification.Builder(context, CHANNEL_ID) .setContentIntent(contentIntent) .setSmallIcon(smallIcon) .setBubbleMetadata(bubbleData) .addPerson(chatBot)
28. // Create bubble intent val target = Intent(context, BubbleActivity::class.java) val bubbleIntent = PendingIntent.getActivity(context, 0, target, 0 /* flags */) // Create bubble metadata val bubbleData = Notification.BubbleMetadata.Builder() .setDesiredHeight(600) .setIcon(Icon.createWithResource(context, R.drawable.icon)) .setIntent(bubbleIntent) .build()
29. // Create bubble intent val target = Intent(context, BubbleActivity::class.java) val bubbleIntent = PendingIntent.getActivity(context, 0, target, 0 /* flags */) // Create bubble metadata val bubbleData = Notification.BubbleMetadata.Builder() .setDesiredHeight(600) .setIcon(Icon.createWithResource(context, R.drawable.icon)) .setIntent(bubbleIntent) .build()
30. // Create bubble intent val target = Intent(context, BubbleActivity::class.java) val bubbleIntent = PendingIntent.getActivity(context, 0, target, 0 /* flags */) // Create bubble metadata val bubbleData = Notification.BubbleMetadata.Builder() .setDesiredHeight(600) .setIcon(Icon.createWithResource(context, R.drawable.icon)) .setIntent(bubbleIntent) .build()
31. // Create bubble intent val target = Intent(context, BubbleActivity::class.java) val bubbleIntent = PendingIntent.getActivity(context, 0, target, 0 /* flags */) // Create bubble metadata val bubbleData = Notification.BubbleMetadata.Builder() .setDesiredHeight(600) .setIcon(Icon.createWithResource(context, R.drawable.icon)) .setIntent(bubbleIntent) .build()
32. // Create bubble intent val target = Intent(context, BubbleActivity::class.java) val bubbleIntent = PendingIntent.getActivity(context, 0, target, 0 /* flags */) // Create bubble metadata val bubbleData = Notification.BubbleMetadata.Builder() .setDesiredHeight(600) .setIcon(Icon.createWithResource(context, R.drawable.icon)) .setIntent(bubbleIntent) .build()
33. // Create bubble intent val target = Intent(context, BubbleActivity::class.java) val bubbleIntent = PendingIntent.getActivity(context, 0, target, 0 /* flags */) // Create bubble metadata val bubbleData = Notification.BubbleMetadata.Builder() .setDesiredHeight(600) .setIcon(Icon.createWithResource(context, R.drawable.icon)) .setIntent(bubbleIntent) .build()
34. // Create notification val chatBot = Person.Builder() .setBot(true) .setName("BubbleBot") .setImportant(true) .build() val builder = Notification.Builder(context, CHANNEL_ID) .setContentIntent(contentIntent) .setSmallIcon(smallIcon) .setBubbleMetadata(bubbleData) .addPerson(chatBot)
35. //Create an expanded bubble val bubbleMetadata = Notification.BubbleMetadata.Builder() .setDesiredHeight(600) .setIntent(bubbleIntent) .setAutoExpandBubble(true) .setSuppressInitialNotification(true) .build()
36. Best Practices !Bubbles take up space and cover other apps. Use it only when, ongoing conversations, important notifications !Users can opt-out. Make sure your bubble notification works as a normal notification as well. !Processes that are launched from a bubble stays in the bubbles (task stack). Keep it simple and task specific.
37. Resources - Feature documentation https://developer.android.com/preview/features/bubbles - Sample code https://github.com/googlesamples/android-Bubbles
38. ShareSheet
39. New Share Sheet New content preview Better Direct Share
40. Content Preview Intent’s ClipData Intent.EXTRA_TEXT Intent.EXTRA_TITLE
41. Direct Share Shows app-specific options in the Sharesheet
42. New Direct Share API Old API is deprecated Publish Sharing Shortcuts in advance with the ShortcutManager API ShortcutInfo API supports Sharing Shortcuts
43. New Direct Share API Backwards compatible using the sharetarget androidX library Up to 8 share targets
44. shortcuts.xml file included in the AndroidManifest.xml file <shortcuts xmlns:android="http://schemas.android.com/apk/res/android" <share-target android:targetClass="com.example.android.directshare.SendMessageActivity"> <data android:mimeType="text/plain" /> <category android:name="com.example.android.directshare.category.TEXT_SHARE_TARGET" /> </share-target> </shortcuts>
45. shortcuts.xml file included in the AndroidManifest.xml file <shortcuts xmlns:android="http://schemas.android.com/apk/res/android" <share-target android:targetClass="com.example.android.directshare.SendMessageActivity"> <data android:mimeType="text/plain" /> <category android:name="com.example.android.directshare.category.TEXT_SHARE_TARGET" /> </share-target> </shortcuts>
46. shortcuts.xml file included in the AndroidManifest.xml file <shortcuts xmlns:android="http://schemas.android.com/apk/res/android" <share-target android:targetClass="com.example.android.directshare.SendMessageActivity"> <data android:mimeType="text/plain" /> <category android:name="com.example.android.directshare.category.TEXT_SHARE_TARGET" /> </share-target> </shortcuts>
47. shortcuts.xml file included in the AndroidManifest.xml file <shortcuts xmlns:android="http://schemas.android.com/apk/res/android" <share-target android:targetClass="com.example.android.directshare.SendMessageActivity"> <data android:mimeType="text/plain" /> <category android:name="com.example.android.directshare.category.TEXT_SHARE_TARGET" /> </share-target> </shortcuts>
48. PublishSharingShortcuts.kt val categories = setOf( "com.example.android.directshare.category.TEXT_SHARE_TARGET" ) val shortcut = ShortcutInfoCompat.Builder(context, "contactID") .setShortLabel(“Jason") .setIcon(IconCompat.createWithResource(context, R.mipmap.ic_jason)) .setIntent(Intent(Intent.ACTION_DEFAULT)) .setCategories(categories) .build() ShortcutManagerCompat.addDynamicShortcuts(context, listOf(shortcut))
49. PublishSharingShortcuts.kt val categories = setOf( "com.example.android.directshare.category.TEXT_SHARE_TARGET" ) val shortcut = ShortcutInfoCompat.Builder(context, "contactID") .setShortLabel(“Jason") .setIcon(IconCompat.createWithResource(context, R.mipmap.ic_jason)) .setIntent(Intent(Intent.ACTION_DEFAULT)) .setCategories(categories) .build() ShortcutManagerCompat.addDynamicShortcuts(context, listOf(shortcut))
50. PublishSharingShortcuts.kt val categories = setOf( "com.example.android.directshare.category.TEXT_SHARE_TARGET" ) val shortcut = ShortcutInfoCompat.Builder(context, "contactID") .setShortLabel(“Jason") .setIcon(IconCompat.createWithResource(context, R.mipmap.ic_jason)) .setIntent(Intent(Intent.ACTION_DEFAULT)) .setCategories(categories) .build() ShortcutManagerCompat.addDynamicShortcuts(context, listOf(shortcut))
51. PublishSharingShortcuts.kt val categories = setOf( "com.example.android.directshare.category.TEXT_SHARE_TARGET" ) val shortcut = ShortcutInfoCompat.Builder(context, "contactID") .setShortLabel(“Jason") .setIcon(IconCompat.createWithResource(context, R.mipmap.ic_jason)) .setIntent(Intent(Intent.ACTION_DEFAULT)) .setCategories(categories) .build() ShortcutManagerCompat.addDynamicShortcuts(context, listOf(shortcut))
52. AndroidManifest.xml // Add dependency -> androidx.sharetarget:sharetarget:1.0.0-alpha02 // This goes to the Activity that will handle the share intent <meta-data android:name="android.service.chooser.chooser_target_service" android:value="androidx.sharetarget.ChooserTargetServiceCompat" />
53. AndroidManifest.xml // Add dependency -> androidx.sharetarget:sharetarget:1.0.0-alpha02 // This goes to the Activity that will handle the share intent <meta-data android:name="android.service.chooser.chooser_target_service" android:value="androidx.sharetarget.ChooserTargetServiceCompat" />
54. Custom Targets Encourage sharing within your app Your custom Intents via EXTRA_INITIAL_INTENTS Your custom ChooserTargets via EXTRA_CHOOSER_TARGETS
55. Resources - Direct Share to an Android app codelab https://codelabs.developers.google.com/codelabs/android-direct-share/index.html - Sharing Improvements documentation https://developer.android.com/preview/features/sharing - New ShareSheet in Android Q video https://www.youtube.com/watch?v=qsKVL4FSHVI
56. & Edge to Edge Display Gestural Navigation
58. Wait why? What’s happening?! 10:00 !Great devices with beautiful screens! !Each with own gestures !Hard for developers !Unifying the ecosystem !3-button navigation?
59. How? !Make your app edge to edge 10:00
60. !Make your app edge to edge !Use insets to modify your UI !Use gesture exclusion zones for controls on the edges How? 10:00
61. Edge to Edge
62. Edge to Edge From Q and onwards the system is responsible for recoloring system buttons and handles Recoloring can be dynamic adaption or static coloring depending on device specs. Older platforms, use translucent nav bar color
63. Edge to Edge 1. Change system bar colors
64. <!-- values-29/themes.xml: --> <style name="AppTheme" parent="..."> <item name=“android:statusBarColor”> @android:color/transparent </item> <item name="android:navigationBarColor"> @android:color/transparent </item> </style>
65. Edge to Edge 1. Change system bar colors 2. Request to be laid out fullscreen
66. //onCreate view.systemUiVisibility = //lay out as if nav bar is hidden View.SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION or //lay out for worst case the app can expect //as a continuous state View.SYSTEM_UI_FLAG_LAYOUT_STABLE or //lay out behind the status bar (optional) View.SYSTEM_UI_FLAG_LAYOUT_FULLSCREEN
67. Edge to Edge 1. Change system bar colors 2. Request to be laid out fullscreen 3. Use insets to avoid overlaps WindowInsets.getWindowSystemInsets() clickable WindowInsets.getSystemGestureInsets() dragables
68. Insets Horizontal controls on right and left edges Vertical controls on bottom edge ^ ^ X
69. // get the current peek height val curHeight = behavior.peekHeight ViewCompat.setOnApplyWindowInsetsListener(view) { v, insets -> val gestureInsets = insets.getSystemGestureInsets() //increase original height with inset behavior.peekHeight = gestureInsets.bottom + curHeight insets } ^ ^
70. Gesture Exclusion Rects • Drag handles that start on the edges
 of the screen • Sliders or seek bars • Pull-out sheets on the left/right edges
71. val loc = IntArray(2) slider.getLocationOnScreen(loc) val rect1 = Rect(0, loc[1], /*exclusion width*/, loc[1] + slider.height) val rect2 = Rect(loc[0] + slider.width - /*exclusion width*/, loc[1], loc[0] + slider.width, loc[1] + slider.height) //Call on onDraw or onLayout setSystemGestureExclusionRects(view, listOf(rect1, rect2))
72. val loc = IntArray(2) slider.getLocationOnScreen(loc) val rect1 = Rect(0, loc[1], /*exclusion width*/, loc[1] + slider.height) val rect2 = Rect(loc[0] + slider.width - /*exclusion width*/, loc[1], loc[0] + slider.width, loc[1] + slider.height) //Call on onDraw or onLayout setSystemGestureExclusionRects(view, listOf(rect1, rect2))
73. val loc = IntArray(2) slider.getLocationOnScreen(loc) val rect1 = Rect(0, loc[1], /*exclusion width*/, loc[1] + slider.height) val rect2 = Rect(loc[0] + slider.width - /*exclusion width*/, loc[1], loc[0] + slider.width, loc[1] + slider.height) //Call on onDraw or onLayout setSystemGestureExclusionRects(view, listOf(rect1, rect2))
74. Don’t create a exclusion zone for whole side • Horizontal carousels that span the entire width of the screen • ViewPagers • Drawers (1.1.0 alpha2)
75. Resources - Documentation https://developer.android.com/preview/features/gesturalnav - Gestural Navigation DevByte https://youtu.be/Ljtz7T8R_Hk - Edge-to-Edge DevByte https://youtu.be/Nf-fP2u9vjI - WindowInsets https://chris.banes.dev/2019/04/12/insets-listeners-to-layouts/
76. Dark Theme
77. Dark Theme
78. System Settings Applies to ALL apps
79. Users will expect your app to support Dark Theme
80. Two ways to implement it 1. Custom theme (recommended) AppCompat and MaterialComponents library 2. Force Dark
81. Extend a DayNight theme It enables the -night resource qualifier while in Dark Theme. Custom Dark Theme
82. styles.xml <style name=“MyTheme" parent=“@style/Theme.AppCompat.DayNight”> ... </style>
83. styles.xml <style name=“MyTheme” parent=“@style/Theme.MaterialComponents.DayNight”> ... </style>
84. res/values/colors.xml <color name=“text_primary”>#000000</color> res/values-night/colors.xml <color name=“text_primary">#FFFFFF</color>
85. res/values/colors.xml <color name=“text_primary”>#000000</color> res/values-night/colors.xml <color name=“text_primary”>#FFFFFF</color> your_view.xml <TextView ... textColor= “@color/text_primary“ />
86. Use Theme attributes your_view.xml <ConstraintLayout ... background= "#ffffff" /> <TextView ... textColor= "#000000" />
87. Use Theme attributes your_view.xml <ConstraintLayout ... background= "?attr/colorSurface" /> <TextView ... textColor= "?android:attr/textColorPrimary" />
88. DayNight theme Tell the system what theme to use AppCompatDelegate.setDefaultNightMode(mode: Int) Note: Values are not persisted
89. Reply
90. Automatically convert your app to Dark Theme Force Dark
91. Automatically convert your app to Dark Theme Force Dark
92. styles.xml <style name="MyTheme" parent=“@style/Theme.AppCompat.DayNight”> <item name="android:forceDarkAllowed">true</item> </style>
93. MyActivity.kt myView.setForceDarkAllowed(false)
94. Force Dark Custom Theme
95. Resources - Code sample https://github.com/googlesamples/android-DarkTheme - Documentation https://developer.android.com/preview/features/darktheme - Dark Theme & Gesture Navigation IO 2019 Talk https://www.youtube.com/watch?v=OCHEjeLC_UY
96. Settings Panels
97. Settings Panels
98. Go to settings to…
99. Ask to leave the app?
100. Settings.Panel.* •ACTION_INTERNET_CONNECTIVITY •ACTION_WIFI •ACTION_NFC •ACTION_VOLUME
101. Code val panelIntent = Intent(Settings.Panel.ACTION_WIFI) startActivityForResult(panelIntent)
102. Resources - Feature overview https://developer.android.com/preview/features#settings-panels - API documentation https://developer.android.com/reference/kotlin/android/provider/ Settings.Panel.html
103. Thanks! Q uestions? Murat Yener @yenerm @manuelvicnt Manuel Vivo
