SSO & SOA

Transcript

1. SOA SSO & @MattKetmo PHPTour Lyon 2014
2. Service Oriented Architecture “Developing a single application as a suite of small services, each running in its own process and communicating with lightweight mechanisms” #EventDriven #DistributedSystem
4. /me Matthieu Moquet @MattKetmo Developer at …for almost 3 years
5. Back to 2011…
6. Covoiturage.fr 1 monolithic PHP app o Core website o Web mobile o B2B platform o Backoffice tools o Web views (mobile apps) o External widgets
7. Plain Old PHP No Dependency Injection No functional tests High coupling …hard to maintain
9. # wc -l lib.trip.php 3678 …longest method: 1000+ lines
11. get rid of the TECHNICAL DEBT
12. started from scratch since 2012
13. 2.0
14. Let’s embrace best practices
15. 1 bundle BlablacarAppBundle BlablacarBlogBundle BlablacarFaqBundle BlablacarTripBundle BlablacarUserBundle ... N bundles OR
16. Services & Controllers §  Should controllers access the repository? §  How should I split my services? §  Is ContainerAware that bad? §  How to organize my Business Layer?
17. Where should I put my Model & Doctrine entities?
18. Forms Should I map my entities with my forms?
19. Validation §  Should I map validation with entities? §  Should I use groups?
20. Translations §  Catalogue message? §  Should I use key identifiers or phrases? §  How to name the keys?
21. Route naming homepage blablacar_homepage blablacar_main_homepage
22. Events §  Listen on Doctrine events? §  Create your own? ACTION / PRE_ACTION / POST_ACTION ? §  Subscribers VS. Listeners
23. Design When you don’t have full-time designer, then Bootstrap(2) FTW
24. With a few developers… At the beginning, you need to start quickly, (but you take time to write conventions). Legacy App New App
25. Then you hire new people
26. How many developers to be more efficient?
27. More code means…
28. Heavy Container
29. $ app/console cache:warmup Warming up the cache for the dev env with debug true
31. $ app/console assetic:dump Dumping all dev assets. Debug mode is on. 23:00:32 [file+] /path/to/web/css/0e781b6.css 23:00:35 [file+] /path/to/web/css/0e781b6_part_1_bootstrap_1.css 23:00:35 [file+] /path/to/web/css/0e781b6_part_2_buttons_1.css 23:00:35 [file+] /path/to/web/css/0e781b6_part_2_card_2.css 23:00:35 [file+] /path/to/web/css/0e781b6_part_2_form_3.css 23:00:35 [file+] /path/to/web/css/0e781b6_part_2_grid_4.css 23:00:36 [file+] /path/to/web/css/0e781b6_part_2_list_5.css 23:00:36 [file+] /path/to/web/css/0e781b6_part_2_navbar_6.css 23:00:36 [file+] /path/to/web/css/0e781b6_part_2_panel_7.css 23:00:37 [file+] /path/to/web/css/0e781b6_part_2_vcard_9.css 23:00:37 [file+] /path/to/web/js/e66598b.js 23:00:37 [file+] /path/to/web/js/e66598b_jquery_1.js 23:00:37 [file+] /path/to/web/js/e66598b_bootstrap_2.js 23:00:37 [file+] /path/to/web/js/e66598b_script_3.js
33. $ phpunit -c app ........................... .............. (63/975) .......................... ............... (126/975) .............. ........................... (189/975) .......F................ ................. (252/975) .............F....
34. Changed few lines of code? Run the full test suite!
36. Optimize test execution time Invest in parallelization processes Split TestSuite in VMs (on AWS) Run 1h tests in 10min
37. One big projet makes your team less reactive How often do you deploy your main project?
38. https://code.facebook.com/posts/218678814984400/scaling-mercurial-at-facebook/
39. Changing foundations is expensive What if we want to change…
40. What if we want to change The backend framework? We don’t plan to change it, and we couldn’t
41. What if we want to change The testing framework? We won’t rewrite the whole test suite. But we can use several frameworks at the same time (eg. Behat)
42. What if we want to change The frontend framework? Well, we are stuck with Bootstrap2. Updating to Bootstrap3 or rewriting our own will take time.
43. What if we want to change The assets builder? Assetic took too long to compile all assets. We moved to asset management with Grunt.
44. What if we want to change The data layer? Actually frontend servers make MySQL queries. But in the long term, it’s not a good practice (see coming slides).
45. We’ll ALWAYS have technical debt. We must LIMIT it as much as possible.
46. Think as small as possible µServices The secret to building large apps is never build large apps. Break your application into small pieces. Then, assemble those testable, bite-sized pieces into your big application — Justin Meyer
47. 3 patterns to build a better software architecture…
48. Request-Response
49. Request-Response GET your resources synchronously Data Layer
50. Request-Response $user = $this ->get('my.repository.user') ->find(1337);
51. Request-Response $mysql->query('...')
52. Request-Response Id   Firstname   Lastname   Pseudo   Email   Birthday   1337   Ma'hieu   Moquet   Ma'Ketmo   ma'hieu@moquet.net   1988-­‐12-­‐17
53. Request-Response However front-end servers should NOT access the database directly It should fetch normalized data from an internal service API for the win!
54. Request-Response GET /users/123 Do you speak REST ? Better versioning & normalization
55. Request-Response …or you may speak: § SOAP § XML-RPC § Protobuffer § Thrift § etc.
56. Request-Response Even RabbitMQ can be used for synchronous requests scrutinizer-ci/rabbitmq src/Scrutinizer/RabbitMQ/Rpc http://www.rabbitmq.com/tutorials/tutorial-six-python.html
57. Request-Response
58. Command(Handler)
59. Command $cmd = FooCommand('bar'); $handler = FooCommandHandler(); $handler->execute($cmd); Do not expect a return value
60. Command Perfect for asynchronous jobs §  Send e-mails / SMS / PUSH notifications §  Image processing §  Data indexation §  Saving complex data §  etc.
61. Command publish consume RabbitMQ   DIRECT  rou<ng
62. Command publish consume Easy  scaling
63. Command Service is accessible via a queueing system only (not REST) §  RabbitMQ §  ActiveMQ §  Beanstalkd §  Gearman §  … More at http://queues.io
64. Sending Newsletters publish 100k messages Create an army of workers in AWS consume send mails message payload = emails address + content App Scheduler (Java + Quartz) Worker NL @10am segment X Get users of segment X (Scroll ElasticSearch)
65. PubSub Obverser / Event Dispatcher
66. PubSub $dispatcher = new EventDispatcher();! ! // Listen using an object or a callback! $listener = new AcmeListener();! $dispatcher->addListener('foobar', array($listener, 'onFoobar'));! ! $dispatcher->addListener('foobar', function (Event $event) {! // do something else with the events! });! ! // Dispatch event! $dispatcher->dispatch('foobar', $event);! Example with the Symfony EventDispatcher
67. PubSub Notify your infrastructure of every business events Publish events without knowing who is listening Create services without any core changes
68. PubSub pub RabbitMQ   TOPIC  rou<ng   sub user.register user.edit_bio user.register user.edit_bio user.edit_bio
69. PubSub Use Case BI
70. user.register user.edit_bio user.left_rating user.post_trip ... Data Warehouse Log every business events in Hadoop
71. user.register user.edit_bio user.left_rating user.post_trip ... user.register user.post_trip ... Meanwhile… RealTime Dashboard Log every business events in ElasticSearch
73. ReqRes — Command — PubSub Message Broker RabbitMQ removes hard link between services
74. Now we have the keys to start a distributed architecture let’s start decoupling our application… Front-end desktop + mobile Hard to split in several projects (need to delegate jobs) API For mobile apps & partners Backoffice Set of administration tools Workers Already decoupled from the core app
75. Backoffice A set of independent tools Easy to split
76. Backoffice — CRUD Some tools are just data manipulation: – User Management – Blog – FAQ GET /users PUT /users/123 Data Layer
77. Backoffice — Moderation Manage user « data » which need to be moderated user.upload_avatar user.edit_bio user.left_rating UI to check data manually Auto detect spam & non compliant data Machine Learning data.received data.treated send mails
78. Backoffice — URL Shortener Some tools are completely independent https://www.blablacar.com/register SHORTEN No data shared with core business
79. Authentication Splitting our backoffice in many apps should not be a pain for the UX
80. Let’s build a Single Sign-On service
81. Single Sign On “SSO is a method allowing a user to access multiple applications, making only a single authentication.”
82. STARTING POINT LDAP
83. Single Sign ONCE example.org/app app.example.org Simple Case: Shared Host / Shared Domain
85. « OAuth is an open standard for authorization […] to access server resources on behalf of a resource owner » — Wikipedia
86. OAuth2 Grant Types Authorization Code Connect-like workflow Implicit Grant (Direct Token) Usefull for JS app Password flow Trusted app (client credentials) Client Credentials Basic (use of client id + secret)
87. OAuth2
88. Do It Yourself with
89. From LDAP to OAuth Given I am on the login page Then I should login with my LDAP credentials App LDAP Login
90. There is a bundle for that
91. FR3DLdapBundle
92. FR3DLdapBundle/config.yml # LDAP Configuration! fr3d_ldap:! driver:! host: "%ldap_host%"! username: "%ldap_username%"! password: "%ldap_password%"! baseDn: "%ldap_username%"! user:! baseDn: "%ldap_user_dn%"! filter: "%ldap_user_filter%"! attributes:! - { ldap_attr: "uid", user_method: "setUsername" }! - { ldap_attr: "cn", user_method: "setName" }! - { ldap_attr: "mail", user_method: "setEmail" }! service:! user_manager: "acme.user_manager"!
93. From LDAP to OAuth Given I am on "/me" with "user" access token Then I should get "user" resources in JSON App LDAP OAuth2 API
94. There is a bundle for that
95. FOSOAuthServerBundle
96. FOSOAuthServerBundle/ security.yml firewalls:! api:! pattern: ^/api! fos_oauth: true! stateless: true
97. From LDAP to OAuth App LDAP OAuth2 API Login
98. Enforce security PO said, this SSO entry-point should be a top-notch secure app
99. There ARE bundles for THAT
100. SchebTwoFactorBundle SpomkyIpFilterBundle CCDNUserSecurityBundle NelmioSecurityBundle …
101. App LDAP OAuth2 2FA FW
102. What about the client?
103. Of course, there is a bundle for that
104. HWIOAuthBundle
106. # HWI OAuth Configuration! hwi_oauth:! firewall_name: "main"! resource_owners:! acme_sso:! type: "oauth2"! client_id: "%client_id%"! client_secret: "%client_secret%"! access_token_url: "%base_url%/oauth/v2/token"! authorization_url: "%base_url%/oauth/v2/auth"! infos_url: "%base_url%/api/me”! paths:! identifier: "id"! nickname: "username"! realname: "name"! email: "email"!
107. UX — We don’t really need this login form
108. UX — We don’t really need a one-button page
109. 302 Found UX — Get transparent login process
110. OAuth is all about authorization, not authentication Watch out for weaknesses & attacks
111. GET /api/me { "id": 1337, "firstname": "Matthieu", "lastname": "Moquet", "nickname": "MattKetmo" } (the cheat)
112. CSRF http://example.org?redirect_uri=xxxx&state=yyyy session[state] === params[state]. http://tools.ietf.org/html/draft-ietf-oauth-v2-27#section-10.12
113. Cover Redirect (is a joke) http://homakov.blogspot.fr/2014/05/covert-redirect-faq.html
114. id_token Multiple Response Type Encoding Practices. Provides an assertion of the identity of the Resource Owner. http://openid.bitbucket.org/oauth-v2-multiple-response-types-1_0.html
115. However if OAuth2 is not designed to be an SSO protocol, what should I use?
116. OAuth1.a
117. It seems Symfony have a bundle for everything…
118. BazingaOAuthServerBundle
120. SAML (Security Assertion Markup Language) SAML is an XML-based protocol that uses security tokens containing assertions to pass information about a principal between an identity provider, and a consumer. There are bundles/lib for that (but not maintained, see impl.) §  pdias/FOSSamlBundle §  aerialship/SamlSPBundle §  chtitux/sfSAMLPlugin (symfony1)
121. CAS (Central Authentication Service) Example of client implementation BeSimple/BeSimpleSsoAuthBundle
122. h"ps://github.com/BeSimple/BeSimpleSsoAuthBundle/blob/master/Resources/doc/protocols.md
123. JWT (JSON Web Token) Payload signed server-side with a JSON Web Signature (JWS). auth.   signed token request
124. JWT (JSON Web Token) Sign payload using a secret key auth.   signed token request
125. firebase/php-jwt curl –H "Authorization: Bearer eyJ0eXAiOiJKV..." example.org $key = "s3cr3t_key"; $token = array( "sub" => "mattketmo", "aud" => "http://example.com", "exp" => 1356999524, ); $jwt = JWT::encode($token, $key);  // eyJ0eXAiOiJKV...
126. namshi/jose OpenSSL + cookies // Auth (SSO) $privateKey = openssl_pkey_get_private("file://private.key"); $jws = new JWS('RS256'); $jws->setPayload([$userId]); $jws->sign($privateKey) setcookie('identity', $jws->getTokenString()); // Client App $jws = JWS::load($_COOKIE['identity']); $publicKey = openssl_pkey_get_public("/public.key"); if ($jws->isValid($publicKey)) { $payload = $jws->getPayload(); $userId = $payload['id']; }
127. OAuth2 + JWT http://tools.ietf.org/html/draft-ietf-oauth-jwt-bearer-08
128. OpenID Connect Feb. 2014 — openid.net/connect/
130. Core app is now lightweight o Tiny container (less services/listeners) o Test suite is smaller o Forget about technical debt
131. Choose the right tools for the task Backend / Frontend / Datastore / …
132. Make experiments
133. Work faster No more bottleneck & dependencies with other dev teams
134. BE EFFICIENT AVOID REPETITIVE PROCESSES
135. Install dev environment in less than 1h
136. Bootstrap everything composer create-project blablacar/backoffice-app git clone git@git.example.org/worker-skeleton.git via git or via composer
137. Enforce reusable components { "require": { "blablacar/monolog": "~1.0", "blablacar/scheduler-client": "~1.1", "blablacar/redis-client": "~1.2", "blablacar/rabbit-mq-admin-toolkit": "dev-master" } }
138. Be ready for production Don’t loose time in configuration setup Parameters for $ENV Config template for $PROJECT Config file for $PROJECT/$ENV Centralized build tool to generate a project configuration file for any environment (local / dev / staging / prod)
139. Never miss a log
140. Don’t be lost in translations Open-sourced a tool to manage your project translations easily More information tomorrow, 9:45
141. Thank you Slides available at moquet.net/talks/phptour-2014-sso-soa Leave feedbacks @MattKetmo
