  1. ハードウェア記述言語Chiselを もっと活用するためのDiplomacy概説 Chisel & Diplomacy Deep Dive FPGA開発日記 著者 :

    msyksphinz FPGA Development Diary Author @msyksphinz_dev https://msyksphinz.hatenablog.com RISC-V Day Tokyo 2020 (Nov.5 - Nov.6)
  2. Do you use Chisel? • Hardware Construction language based on

    Scala. • Not High-level synthesis Language • Used in SiFive’s RISC-V IP • Rocket-Chip • https://github.com/chipsalliance/rocket-chip • BOOM • https://github.com/riscv-boom/riscv-boom
  3. What part of Chisel is Good? Software-like description using Scala

    syntax. Many Verilog engineers get confused with “unique” description from Scala. FIR Filter: How to write it?
  4. Written by Sophisticated Chisel Engineer class MyManyDynamicElementVecFir(length: Int) extends Module

    { val io = IO(new Bundle { val in = Input(UInt(8.W)) val valid = Input(Bool()) val out = Output(UInt(8.W)) val consts = Input(Vec(length, UInt(8.W))) }) val taps = Seq(io.in) ++ Seq.fill(io.consts.length - 1)(RegInit(0.U(8.W))) taps.zip(taps.tail).foreach { case (a, b) => when (io.valid) { b := a } } io.out := taps.zip(io.consts).map { case (a, b) => a * b }.reduce(_ + _) https://github.com/freechipsproject/chisel-bootcamp/blob/master/2.5_exercise.ipynb
  5. Why you use Chisel?  In recent years, the period

    during technology is "state-of-the-art" is:  Much shorter than the latency required for engineer’s design.  Can it take two or three years to make an AI chip?  High mix, Low volume is one of the trends in DSA era.  Agile hardware design is a big importance of the future HW design.  What is the “complexity” of Hardware Design? How to Manage complex Module Networks in Design? 設計中悪いんだけどバスの スレーブ数1つ増えたから Hey, spec is changed. # of bus slave is changed. え... じゃあバスArbiterもう一回 接続し直さなきゃ いけないんじゃないですか... Oh, it means we must redesign bus arbiter again ...? 線が一本増えるだけでしょ?(違うわ) よろしくたのむよ You only adding one signal. Only few minutes you need.
  6. Parameter Passing with Diplomacy Parameter from Master to Slave Parameter

    from Slave to Master https://carrv.github.io/2017/slides/cook-diplomacy-carrv2017-slides.pdf Elaboration Parameter Negotiation Framework for generating parameterized protocol implementation. FIRRTL Verilog Diplomacy is implemented on Scala, it’s not function of Chisel itself! Fallacy: Diplomacy itself not needed to any bus, TileLink neither AXI.
  7. How to realize rapid HW development? Many HW configuration from

    one design, using Diplomacy! Core Core Core Memory Memory Core Core Memory Core Core Cache Core Core Memory Core Core Cache Core Core Core Core Cache Cache Core Core Memory Core Core Cache Core Core Core Core Cache Cache Core Diplomacy
  8. LazyModule (AdderDriver) LazyModuleImp AdderDriverNode (SourceNode) Logic LazyModule (AdderDriver) LazyModuleImp Logic

    AdderDriverNode (SourceNode) LazyModule LazyModuleImp Logic AdderNode (NexusNode) LazyModule LazyModuleImp Logic AdderMonitor (SinkNode) UpWardParam(width:Int) class AdderDriver(width: Int, numOutputs: Int) (implicit p: Parameters) extends LazyModule { val node = new AdderDriverNode(Seq.fill(numOutputs) (DownwardParam(width))) lazy val module = new LazyModuleImp(this) { // check that node parameters converge after negotiation val negotiatedWidths = node.edges.out.map(_.width) require(negotiatedWidths.forall(_ == negotiatedWidths.head), "outputs must all have agreed on same width") val finalWidth = negotiatedWidths.head // generate random addend // (notice the use of the negotiated width) val randomAddend = FibonacciLFSR.maxPeriod(finalWidth) // drive signals node.out.foreach { case (addend, _) => addend := randomAddend } } override lazy val desiredName = "AdderDriver" } Name of LazyModule Node: Connecting to each node LazyModuleImp
  9. Using GraphML for Diplomacy object Generator { final def main(args:

    Array[String]) { val p = (new Default2Config).toInstance // val p = (new Default1Config).toInstance Driver.emitVerilog( new TestHarness()(p) ) ElaborationArtefacts.files.foreach { case (extension, contents) => val f = new File(".", "TestHarness." + extension) val fw = new FileWriter(f) fw.write(contents()) fw.close } } }
  10. Configurable Parameterization using Config/Parameter Rocket-Chip Configuration Files : (main/scala/system/Configs.scala) class

    BaseConfig extends Config( new WithDefaultMemPort() ++ new WithDefaultMMIOPort() ++ new WithDefaultSlavePort() ++ new WithTimebase(BigInt(1000000)) ++ // 1 MHz new WithDTS("freechips,rocketchip-unknown", Nil) ++ new WithNExtTopInterrupts(2) ++ new BaseSubsystemConfig() ) class DefaultConfig extends Config(new WithNBigCores(1) ++ new WithCoherentBusTopology ++ new BaseConfig) class DefaultBufferlessConfig extends Config(new WithBufferlessBroadcastHub ++ new DefaultConfig) class DefaultSmallConfig extends Config(new WithNSmallCores(1) ++ new WithCoherentBusTopology ++ new BaseConfig) class DefaultRV32Config extends Config(new WithRV32 ++ new DefaultConfig) class DualBankConfig extends Config(new WithNBanks(2) ++ new DefaultConfig) class DualCoreConfig extends Config(new WithNBigCores(2) ++ new WithCoherentBusTopology ++ new BaseConfig) class DualChannelConfig extends Config(new WithNMemoryChannels(2) ++ new DefaultConfig) class EightChannelConfig extends Config(new WithNMemoryChannels(8) ++ new DefaultConfig) class DualChannelDualBankConfig extends Config( new WithNMemoryChannels(2) ++ new WithNBanks(4) ++ new DefaultConfig) class RoccExampleConfig extends Config(new WithRoccExample ++ new DefaultConfig) VM Support Main Pipeline FPU DIV I-cache Configuration D-cache Configuration I/F
  11. Parameter Passing with “Config” class Default1Config extends Config( new Bus32BitConfig

    ++ new IfuConnectConfig ) class Default2Config extends Config( new BaseConfig ++ new Bus64BitConfig ++ new IfuNotConnectConfig ) class Bus64BitConfig extends Config((site, here, up) => { case BusWidthBytes => 64 / 8 case AddrSize => 0x200 * here(BusWidthBytes) }) class IfuConnectConfig extends Config((site, here, up) => { case ConnectIfu => true }) case object BusWidthBytes extends Field[Int] case object ConnectIfu extends Field[Boolean] case object AddrSize extends Field[Int] class core_complex(txns: Int)(implicit p: Parameters) extends LazyModule { val xbar = LazyModule(new TLXbar) val memory = LazyModule(new TLRAM(AddressSet(0x0, p(AddrSize)-1), beatBytes = p(BusWidthBytes))) object Generator { final def main(args: Array[String]) { val p = (new Default2Config).toInstance Driver.emitVerilog( new TestHarness()(p) )
  12. Parameter Passing with “Config” class Default1Config extends Config( new Bus32BitConfig

    ++ new IfuConnectConfig ) class Default2Config extends Config( new BaseConfig ++ new Bus64BitConfig ++ new IfuNotConnectConfig ) class Bus64BitConfig extends Config((site, here, up) => { case BusWidthBytes => 64 / 8 case AddrSize => 0x200 * here(BusWidthBytes) }) class IfuConnectConfig extends Config((site, here, up) => { case ConnectIfu => true }) case object BusWidthBytes extends Field[Int] case object ConnectIfu extends Field[Boolean] case object AddrSize extends Field[Int] class core_complex(txns: Int)(implicit p: Parameters) extends LazyModule { val xbar = LazyModule(new TLXbar) val memory = LazyModule(new TLRAM(AddressSet(0x0, p(AddrSize)-1), beatBytes = p(BusWidthBytes))) object Generator { final def main(args: Array[String]) { val p = (new Default2Config).toInstance Driver.emitVerilog( new TestHarness()(p) )
