Fun with Bluetooth @ code.talks 2017

Time for the browser to get physical. With WebBluetooth the browser can actually take control of all kinds of physical devices in the real world like lightbulbs, robots and even drones. This talk will teach you the basics that you need to get started and will show you some more advanced topics like building your own Bluetooth devices using just JavaScript.

Transcript

1. fun with bluetooth
2. why?
3. progressive
 web apps
4. pwa’s are great !
5. full screen offline support add to home screen push notifications
6. full screen offline support location camera sensors network add to home screen push notifications
7. full screen offline support location camera sensors network add to home screen push notifications
8. ethernet
 & wifi
9. wifi
10. zigbee?

11. ethernet
12. runs a webserver use fetch or
 xmlhttprequest
13. [{ "id":"001788fffe100491", "internalipaddress":"192.168.2.23", "macaddress":"00:17:88:10:04:91", "name":"Philips Hue" }, { "id":"001788fffe09a168", "internalipaddress":"192.168.88.252" }, https://www.meethue.com/api/nupnp 1
14. <root xmlns="urn:schemas-upnp-org:device-1-0"> <specVersion> <major>1</major> <minor>0</minor> </specVersion> <URLBase>http://192.168.2.23:80/</URLBase> <device> <deviceType>urn:schemas-upnp-org:device:Basic:1</deviceT <friendlyName>Philips hue (192.168.2.23)</friendlyName> <manufacturer>Royal Philips Electronics</manufacturer> http://192.168.2.23/description.xml 2
15. http://192.168.2.23/api
 {"devicetype": "hue_pwa#pixel_xl"} 3 [{"success":{"username": "........"}}] User presses physical button on the hub *click* save to local storage
16. 4 { "1": { "state": { "on": true, "bri": 144, "hue": 13088, "sat": 212, "xy": [0.5128,0.4147], "ct": 467, "alert": "none", http://192.168.2.23/api/......../lights
17. http://192.168.2.23/api/......../lights/1/state
 { "hue": 50000, "on": true, "bri": 200 } 5 [ {"success":{"/lights/1/state/bri":200}}, {"success":{"/lights/1/state/on":true}}, {"success":{"/lights/1/state/hue":50000}}
18. *click* *click* *reload* *click*
19. this does
 not work !
20. https only http only no certificate
 for you
21. = network use remote api’s ≠ access to local devices
22. hue remote api Also allow control from
 outside the local network
23. We are currently preparing for release of this remote API which will initially be available to a limited number of partners. “ — Philips
24. We are currently preparing for release of this remote API which will initially be available to a limited number of partners. “ — Philips two years ago very not yet
25. fun with bluetooth problems local networks
26. fun with bluetooth
27. bluetooth sucks
28. classic bluetooth the reason everybody
 hates bluetooth bluetooth low energy vs. control drones and other cool shit
29. bluetooth low energy also known as BLE Bluetooth LE Bluetooth Smart Bluetooth 4
30. playbulb sphere playbulb
31. spherio bb-8
32. parrot mini drone
33. activity tracker
34. the boring theoretical stuff
35. central peripheral
36. central
37. generic attribute profile gatt, because gap was already taken
38. central peripheral client server
39. § i device information light multiple services per device
40. i device information battery flight control
41. i device information battery steering control
42. i device information battery heart rate
43. heart rate i device information battery
44. i device information battery heart rate
45. i device information manufacturer model number serial number hardware revision firmware revision software revision ... multiple characteristics
 per service
46. server service characteristic value array of objects object property value
47. services and characteristics are identified by uuid’s 16 bit or 128 bit
48. 0x180A 0000180A-0000-1000-8000-00805F9B34FB 16 bit 128 bit i device information
49. 0x180F 0000180F-0000-1000-8000-00805F9B34FB 16 bit 128 bit battery
50. not recommended any UUID outside of the range
 xxxxxxxx-0000-1000-8000-00805F9B34FB 16 bit 128 bit light steering control flight c still, everybody does this
51. i device information manufacturer model number serial number hardware revision firmware revision software revision ...
52. i 0x180A 0x2A29 0x2A24 0x2A25 0x2A27 0x2A26 0x2A28 ... bad for readability,
 good for saving bandwidth
53. read write write without response notify each characteristic supports one or more of these
54. every value is an array of bytes no fancy datatypes, just bytes
55. pfew...
57. fun with bluetooth boring facts
 about
58. fun with bluetooth
59. web
 bluetooth api still not the fun part :-(
60. connecting to a device
61. navigator.bluetooth.requestDevice({ filters: [ { namePrefix: 'PLAYBULB' } ], optionalServices: [ 0xff0f ] }) .then(device => device.gatt.connect()) .then(server => server.getPrimaryService(0xff0f)) .then(service => service.getCharacteristic(0xfffc)) .then(characteristic => { return characteristic.writeValue( new Uint8Array([ 0x00, r, g, b ]) ); }) 1 we tell the browser what
 kind of device we want
62. the user selects the actual device
63. navigator.bluetooth.requestDevice({ filters: [ { namePrefix: 'PLAYBULB' } ], optionalServices: [ 0xff0f ] }) .then(device => device.gatt.connect()) .then(server => server.getPrimaryService(0xff0f)) .then(service => service.getCharacteristic(0xfffc)) .then(characteristic => { return characteristic.writeValue( new Uint8Array([ 0x00, r, g, b ]) ); }) 2 connect to the server
64. navigator.bluetooth.requestDevice({ filters: [ { namePrefix: 'PLAYBULB' } ], optionalServices: [ 0xff0f ] }) .then(device => device.gatt.connect()) .then(server => server.getPrimaryService(0xff0f)) .then(service => service.getCharacteristic(0xfffc)) .then(characteristic => { return characteristic.writeValue( new Uint8Array([ 0x00, r, g, b ]) ); }) 3 get the service
65. navigator.bluetooth.requestDevice({ filters: [ { namePrefix: 'PLAYBULB' } ], optionalServices: [ 0xff0f ] }) .then(device => device.gatt.connect()) .then(server => server.getPrimaryService(0xff0f)) .then(service => service.getCharacteristic(0xfffc)) .then(characteristic => { return characteristic.writeValue( new Uint8Array([ 0x00, r, g, b ]) ); }) 4 get the characteristic
66. writing data
67. navigator.bluetooth.requestDevice({ ... }) .then(device => device.gatt.connect()) .then(server => server.getPrimaryService(0xff0f)) .then(service => service.getCharacteristic(0xfffc)) .then(c => { return c.writeValue( new Uint8Array([ 0x00, r, g, b ]) ); }) write some bytes
68. reading data
69. navigator.bluetooth.requestDevice({ ... }) .then(device => device.gatt.connect()) .then(server => server.getPrimaryService(0xff0f)) .then(service => service.getCharacteristic(0xfffc)) .then(c => c.readValue()) .then(value => { let r = value.getUint8(1); let g = value.getUint8(2); let b = value.getUint8(3); }) read some bytes
70. get notified of changes
71. navigator.bluetooth.requestDevice({ ... }) .then(device => device.gatt.connect()) .then(server => server.getPrimaryService(0xff0f)) .then(service => service.getCharacteristic(0xfffc)) .then(c => { c.addEventListener('characteristicvaluechanged', e => { let r = e.target.value.getUint8(1); let g = e.target.value.getUint8(2); let b = e.target.value.getUint8(3); }); c.startNotifications(); }) add event listener don't forget to start listening
72. things you need to know: • the webbluetooth api • promises • typed arrays duh!
73. browser support Chrome Opera Samsung
 (behind flag) Servo
 (soon)
74. browser support Chrome Opera Samsung
 (behind flag) kinda works Servo
 (soon) WebBLE
 for iOS
75. custom characteristics. wtf!
76. writing a value: function(r, g, b) { return new Uint8Array([ 0x00, r, g, b ]); } reading a value: function(buffer) { return {
 r: buffer.getUint8(1),
 g: buffer.getUint8(2),
 b: buffer.getUint8(3)
 } } writing to and reading
 from the same characteristic
77. writing a value: function(r, g, b) { return new Uint8Array([ 0x01, g, 0x01, 0x00, 0x01,
 b, 0x01, r, 0x01, 0x00
 ]); } reading the current
 color is not possible
78. writing a value:
 function(r, g, b) { var buffer = new Uint8Array([
 0xaa, 0x0a, 0xfc, 0x3a, 0x86, 0x01, 0x0d,
 0x06, 0x01, r, g, b, 0x00, 0x00,
 (Math.random() * 1000) & 0xff, 0x55, 0x0d
 ]); for (var i = 1; i < buffer.length - 2; i++) { buffer[15] += buffer[i]; } return buffer; } reading the current
 color is not possible
79. reading a value: add event listener write a specific value get the event with the color 1 2 3 service 0xffe0
 characteristic 0xffe4 service 0xffe5
 characteristic 0xffe9
80. demo finally the fun part
81. warning experimental technology
 setting low expectations
82. warning wifi interference
 lowering them even further
84. https:/ /bulb.blue/tooth/
 https:/ /github.com/NielsLeenheer/BluetoothBulb change the colour
 of a lightbulb
85. https:/ /bricks.blue/tooth/ https:/ /github.com/NielsLeenheer/BluetoothRacer control a lego racer
 using a gamepad use css animations to
 define a path
86. https:/ /webdr.one
 https:/ /github.com/poshaughnessy/web-bluetooth-parrot-drone control a drone
 from your browser
87. https:/ /pulse.blue/tooth/
 https:/ /github.com/NielsLeenheer/BluetoothPulse find out your
 current heartbeat
88. physical web
89. battery lasts years beacon really small
90. broadcast the url
 of a web app easy to open from
 the home screen
91. coming soon automatic web bluetooth
 connection
92. taking it one step further
93. runs javascript physical web beacon supports
 web bluetooth api has a button
94. peripheral
 mode
95. central
 mode
97. fun with bluetooth !
98. questions? @html5test
