Hacking and Profiling Ruby for Performance - RubyKaigi 2023

A RubyKaigi 2023 talk

Transcript

1. Hacking and Pro fi ling Ruby for Performance Daisuke Aritomo (@osyoyu)
2. pp @osyoyu • Daisuke Aritomo (osyoyu, ͓͠ΐʔΏ, ͓͠ΐ͏Ώ) • "osyoyu" is pronounced as "oh show you" • #rubykaigiNOC (Venue Wi-Fi Team) • Software Engineer at Cookpad Inc.
3. Get a free drink from Cookpad's fridge! Cookpad provides RUBY-POWERED FRIDGES to RubyKaigi 2023! Let's make everyday cooking fun together! https://cookpad.careers/
4. Cookpad is doing a look- back RubyKaigi event! 5/18 @ Tokyo • Look back RubyKaigi with
 hands on! • Let's make the next RubyKaigi together Come to Cookpad booth for details https://cookpad.connpass.com/event/282436/
5. About this Talk • How to pro fi le and tune a Ruby webapp • ... you know nothing about, • ... within 8 hours, • ... as part of a performance tuning competition, • for fun!
6. Do you like performance?
 🙋
7. : the performance challenge • Contestants are given a VM and a super-slow webapp • Contestants may request a 60-second benchmark during the contest • Scores and standings are decided based on benchmark results • The goal is to get the best score Benchmarker (scorer) Contestant VM (running a Ruby webapp) benchmark requests
 sent at an intensive rate for 60 seconds
8. Day 2 11:00-
9. The Initial State • 3 VMs (Computing Instances) • Ruby • Sinatra • Puma • Nginx • MySQL • Implementations in other languages • Python, Go, Node.js, ... • Initial performance is designed to be not so different
10. "Make this webapp server as fast as possible -
 but no scaling up nor out."
11. Hack around with Ruby code Run a benchmark, get your score
12. Hack around with Ruby code Run a benchmark, get your score The highest score wins!
13. Will talks/Won't talks • Why Ruby is a great language to compete in ISUCON • How to track down and pro fi le slow code on the CRuby level • What future Rubies need to shine in ISUCON Wills Won't • Con fi guring Nginx, Linux, etc... • Monitoring on the system level • Itamae recipes we made for ISUCON
14. (Almost) Everything is permitted • Add effective RDBMS indexes • Kill N+1 SQL Queries • → user_ids.each {|id| query("select * from users where id = ?", id) } • → query("select * from users where id in (?)", user_ids) • Replace suboptimal algorithms • Utilize Server Resources (cpu, memory) to the last drop • Adding Puma threads/processes • Caching • Upgrading to ruby/ruby master • (Adding VMs and scaling VMs up are prohibited)
15. (Almost) Everything is permitted • Add effective RDBMS indexes • Kill N+1 SQL Queries • → user_ids.each {|id| query("select * from users where id = ?", id) } • → query("select * from users where id in (?)", user_ids) • Replace suboptimal algorithms • Utilize Server Resources (cpu, memory) to the last drop • Adding Puma threads/processes • Caching • Upgrading to ruby/ruby master • (Adding VMs and scaling VMs up are prohibited) But where should we start from?
16. Hack around with Ruby code Run a benchmark, get your score See pro fi ling results,
 think what next
17. Dancing with Ruby
18. Dancing with Ruby • You'll be given 500+ lines of Sinatra code • and need to make it really fast within 8 hours • This is where Ruby really shines
19. Ruby Go • Same code, different language • Save reading time and writing time!
20. The mighty Array, Hash, Enumerable • #map • #each_with_object • #sort_by! • Almost anything is possible • Comes in really handy when
 tacking N+1 queries
 (without ActiveRecord)
21. Monkey patching • Need something in the Standard Library? Build it on site!
22. Monkey patching • Need something in the Standard Library? Build it on site! binding.irb/pry in production • Debugging work fl ow: • Stop real benchmark requests • Write code in binding.irb/pry using real requests • Con fi rm it works • Copy to editor and save (Note: I don't do this at work - just a competition technique 😁)
23. Challenges in Ruby
24. START BENCHMARK
28. • This... happens • It's fi xable, no worries • Let's hope RBS, TypeProf and other projects solve this problem
29. Pro fi ling the accurate bottlenecks Utilizing 100% cpu in Ruby Achieving high concurrency in Ruby Performance Challenges in Ruby
30. Don't guess, measure! • Random improvements will take you nowhere • Spending time to fi x non-real problems is the
 last thing you want to do in an 8-hour timeframe • Accurate pro fi ling is the key
31. Pro fi ler choices • Tracing pro fi lers • Tracks everything, but huge performance impact • ruby-prof based on TracePoint • Sampling pro fi lers • Collects samples every 10-100ms,
 small performance impact • Stackprof (cpu, wall, memory) • based on rb_pro fi le_frames() API • rbspy (wall) • runs as a separate process and reads ruby memory (process_vm_readv(2))
32. Let's pro fi le! Flamegraph Visualizer: jlfwong/speedscope
33. Let's pro fi le! Benchmark window (60 seconds) Time spent in particular handler (space for optimization?) POST /api/condition/...
34. Let's pro fi le! POST /api/condition/... N+1 INSERT query found!
35. Let's pro fi le! POST /api/condition/... N+1 INSERT query found! 👍
36. Flamegraph source: rb_pro fi le_frames() • Stackprof utilizes the rb_pro fi le_frames() API • Returns the call stack that was running when rb_pro fi le_frames() was called • Stackprof calls rb_pro fi le_frames() on SIGPROF (cpu mode) or SIGALRM (wall mode) timers ti me a() a() a() a() b() b() c() 📸 rb_pro fi le_frames() Records call stack [a(), b()]
37. • rb_pro fi le_frames (Stackprof) is inaccurate when I/O comes into action burn_cpu Thread#join No io!?
38. Multithreading in Ruby / GVL • Only 1 Thread can use the CPU at the same time • due to the Global VM Lock (GVL) • I/O ( fi le read/writes, network access, ...) can be performed in the background Thread 1 Thread 2 Thread 3 Release GVL (Do I/O) Release GVL (Do I/O) Acquire GVL Acquire GVL Use CPU Do
 Do
 Use
 Wait Wait
39. Issues in rb_pro fi le_frames() • The current implementation of rb_pro fi le_frames() returns information about the last active Thread (which had the GVL) • Threads doing I/O have low chances to be targeted • Statistics ( fl amegraphs) built from continuous rb_pro fi le_frames() calls may be not accurate, especially when many Threads are doing I/Os • (even in wall mode!) 💥 = Stack frame peeked by rb_pro fi le_frames() Thread 1 Thread 2 Thread 3 Release GVL (Do I/O) Release GVL (Do I/O) Acquire GVL Acquire GVL 💥 = Stack frame peeked by rb_pro fi le_frames()
40. Issues in rb_pro fi le_frames() • Proposal:
 Add rb_thread_pro fi le_frames() API, a per-thread version of rb_pro fi le_frames() • Accepts VALUE thread as arg • https://github.com/ruby/ruby/ pull/7784 Thread 1 Thread 2 Thread 3 Release GVL (Do I/O) Release GVL (Do I/O) Acquire GVL Acquire GVL 💥 = Stack frame peeked by rb_pro fi le_frames()
41. Pro fi ling the accurate bottlenecks Utilizing 100% cpu in Ruby Achieving high concurrency in Ruby Performance Challenges in Ruby
42. Utilizing 100% cpu in Ruby • Only 1 Thread can be active due to the GVL • CPU tasks and I/O can run simultaneously, but conditions are not always ideal • Resources are very limited in ISUCON; we want to squeeze everything out! 4 Ruby processes, 32 threads isn't enough to burn all CPU we want to see this (1 process, 8 threads in Go)
43. Reducing GVL wait • Less Threads = Less races for the GVL • Ok, Let's reduce Threads! • In the ISUCON webapp case, Puma is creating Threads • We can create more processes in place of Threads to keep the number of workers
44. Tuning Puma for 100% cpu • Adding Server (Puma) processes is effective, but consumes more memory • Memory is precious in ISUCON as MySQL lives in the same VM . . . . . . More Processes (better cpu utilization but more memory) More Threads (lesser memory consumption but suboptimal cpu util)
45. wip: Finding the process/thread balance using GVL stats • GVL event hooks were added in Ruby 3.2 • RUBY_INTERNAL_THREAD_EVENT_* • Shopify/gvltools, ivoanjo/gvl-tracing • I integrated this into pro fi ler results • Usable for tuning # of Puma threads? Try adding Puma threads Perfect! Check GVL wait Reduce threads,
 add processes Low enough Somewhat high
46. Pro fi ling the accurate bottlenecks Utilizing 100% cpu in Ruby Achieving high concurrency in Ruby Performance Challenges in Ruby
47. Higher concurrency? • Falcon (socketry/async series) • Event-loop based async I/O for Ruby! • Sadly, we couldn't rewrite everything in 8 hours • Truf fl eRuby • ISUCON VMs didn't have enough memory for Truf fl eRuby 😔 • Arming Ractors for lesser GVL waits • Maybe my next challenge!
48. Does everyone use Ruby? (in ISUCON)
49. Does everyone use Ruby? (in ISUCON)
50. Quals Does everyone use Ruby? (in ISUCON)
51. Quals Finals My team! Does everyone use Ruby? (in ISUCON)
52. Ruby vs. Go • Go: Goroutines • Kind of a lightweight threads - this system makes high concurrency very easy • Go: Concurrency deeply embedded in the ecosystem • Contexts: Ability to cancel no longer needed MySQL queries • Timeouts: Same
53. Wrapping up • It's fun to write Ruby 😉 • Pro fi ling is important! • But it's more important to check if those pro fi les are accurate • Let's do ISUCON!
54. Acknowledgements @s4ichi and @koba789,
 my long-time ISUCON teammates @ko1 and @mame, who gave us many valuable advice
55. Thank you!
