Single sign-on for mobile native applications

Single sign-on for mobile native applications

Slides for the NDC Oslo 2014 session on mobile authentication and authorization.
Video available at https://vimeo.com/97349269. Demos available at https://github.com/pmhsfelix/ndc-oslo-14-mobile-auth.

Pedro Felix

June 04, 2014
Tweet

More Decks by Pedro Felix

Other Decks in Programming

Transcript

  1. Outline • Token based access control circa 2014 • Mobile

    clients • Single sign-on for mobile clients • Hybrid clients 2
  2. • Teacher at the Lisbon Polytechnic Institute • Independent Consultant

    • Web APIs, Identity and Access Control • Co-author of Designing Evolvable Web APIs with ASP.NET, O’Reilly, 2014 whoami 3
  3. Token based authorization 6 Client App Resource Server access_token GET

    /resource HTTP/1.1 Authorization: Bearer the.access.token
  4. Token based authorization 7 Client App Resource Server access_token GET

    /resource HTTP/1.1 Authorization: Bearer the.access.token POST /resource HTTP/1.1 Content-Type: application/x-www-form-urlencoded access_token=the.access.token
  5. Token based authorization 8 Client App Resource Server access_token GET

    /resource HTTP/1.1 Authorization: Bearer the.access.token POST /resource HTTP/1.1 Content-Type: application/x-www-form-urlencoded access_token=the.access.token GET /resource?access_token=the.access.token HTTP/1.1
  6. Cast of characters 11 Client App Resource Server Authorization Server

    Client Application User Authorization Server Token Management Resource Server
  7. Protocols - OAuth 2.0 flows 12 Client App Resource Server

    Authorization Server Token Endpoint password username
  8. Protocols - OAuth 2.0 flows 13 Client App Resource Server

    Authorization Server Token Endpoint access_token password username access_token
  9. Protocols - OAuth 2.0 flows 14 Client App Resource Server

    Authorization Server Token Endpoint User- Agent Authorization request Authz Endpoint Requires browser or WebView
  10. State of the art – OAuth 2.0 flows 15 Client

    App Resource Server Authorization Server Token Endpoint User- Agent Authz Endpoint Out-of-protocol interaction User Authentication (e.g. username+password or federated) Consent
  11. State of the art – OAuth 2.0 flows 16 Client

    App Resource Server Authorization Server Token Endpoint User- Agent Authz Endpoint code access_token or access_token
  12. State of the art – OAuth 2.0 flows 17 Client

    App Resource Server Authorization Server Token Endpoint User- Agent Authz Endpoint access_token Client credentials code code access_token or access_token
  13. Authorization Server Using OAuth 2.0 for authentication • Use a

    custom “user info resource” • E.g. GitHub • GET /user • { … “email”: “[email protected]” …} • Live ID • GET /v5.0/me 18 Client App Resource Server Token Endpoint Authz Endpoint access_token User Info resource [email protected]
  14. Authorization Server Using OAuth 2.0 for authentication • Use a

    custom “user info resource” • E.g. GitHub • GET /user • { … “email”: “[email protected]” …} • Live ID • GET /v5.0/me 19 Client App Resource Server Token Endpoint Authz Endpoint access_token User Info resource [email protected] Beware of using bearer access tokens for authentication! Token audience checking
  15. OpenID Connect • Identity layer on top of OAuth 2.0

    20 Client App Resource Server Authorization Server Token Endpoint User- Agent Authz Endpoint access_token access_token access_token
  16. OpenID Connect 21 Client App Resource Server Authorization Server Token

    Endpoint User- Agent Authz Endpoint access_token access_token access_token JWT ID token JWT ID token UserInfo resource User claims • Identity layer on top of OAuth 2.0
  17. JWT – JSON Web Token 22 Client App Resource Server

    Authorization Server Token Endpoint User- Agent Authz Endpoint access_token access_token access_token JWT ID token JWT ID token UserInfo resource User claims in http://openid.net/connect/ eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9.eyJpc3MiOiJodHRwOi8v aXNzdWVyLndlYmFwaWJvb2submV0IiwiYXVkIjoiaHR0cDovL2V4 YW1wbGUubmV0IiwibmJmIjoxMzc2NTcxNzAxLCJleHAiOjEzNzY 1NzIwMDEsInN1YiI6ImFsaWNlQHdlYmFwaWJvb2submV0IiwiZ W1haWwiOiJhbGljZUB3ZWJhcGlib29rLm5ldCIsIm5hbWUiOiJBb GljZSJ9.fCO6l0k_hey40kqEVuvMfiM8LeXJtsYLfNWBOvwbU-I
  18. JWT – JSON Web Token 23 Client App Resource Server

    Authorization Server Token Endpoint User- Agent Token Endpoint access_token access_token access_token JWT ID token JWT ID token UserInfo resource User claims in http://openid.net/connect/ { "typ":"JWT", "alg":"HS256“ } { "iss":"http://issuer.webapibook.net", "aud":"http://example.net", "nbf":1376571701, "exp":1376572001, "sub":"[email protected]", "email":"[email protected]", "name":"Alice“ }
  19. OpenID Connect 24 Client App Resource Server Authorization Server Token

    Endpoint User- Agent Authz Endpoint access_token access_token access_token JWT ID token JWT ID token UserInfo resource User claims in http://openid.net/connect/ ID Tokens piggybacked on the OAuth 2.0 messages Standard UserInfo endpoint Standard claims and scopes Session management (e.g. logout)
  20. Clients running on server • Easy to • Host redirect

    endpoints • Store secrets 25 Client App Resource Server Authorization Server Token Endpoint Authz Endpoint UserInfo resource User- Agent
  21. Clients running on mobile devices 26 Client App Resource Server

    Authorization Server Token Endpoint Authz Endpoint UserInfo resource • Challenges • Host redirect endpoints • Store secrets
  22. Resource Owner Password Credentials 27 Native UI Resource Server Authorization

    Server Token Endpoint Authz Endpoint UserInfo resource password username access_token password username
  23. Resource Owner Password Credentials 28 Native UI Resource Server Authorization

    Server Token Endpoint Authz Endpoint UserInfo resource password username access_token password username  Better UX  Simpler  Limited to username-password authentication (e.g. no 2FA, no federation)  Password inserted in the app UI  Assumes trust relation between client and RS/AS
  24. Token/code flows 29 Native UI Resource Server Authorization Server Token

    Endpoint Authz Endpoint UserInfo resource ? code access_token or
  25. Token/code flows using system browser 30 Native UI Resource Server

    Authorization Server Token Endpoint Authz Endpoint UserInfo resource System browser code access_token or
  26. Token/code flows using system browser 31 Native UI Resource Server

    Authorization Server Token Endpoint Authz Endpoint UserInfo resource System browser code access_token or  Customizable authentication and consent flows  Credential usage isolated from the App  Takes the User out of the App context Use of redirect URI with custom scheme
  27. Token/code flows using Web Views 32 Native UI Resource Server

    Authorization Server Token Endpoint Authz Endpoint UserInfo resource Embedded WebView code access_token or
  28. Token/code flows using Web Views 33 Native UI Resource Server

    Authorization Server Token Endpoint Authz Endpoint UserInfo resource Embedded WebView code access_token or  Customizable authentication and consent flows  User remains in the App context  Credential usage not isolated from the App Custom WebView code to detected redirect
  29. Demo • Using a WebView to authenticate with GitHub •

    Custom code to detect redirect URI • e.g. “https://localhost” • Embedded clientsecret • Not a secret anymore • Beware of stored cookies • Logout 35
  30. Multiple authentications • Multiple apps that require authentication • Imply

    multiple authentication ceremonies • Can it be better? Can we have SSO for mobile apps? 36
  31. Web SSO 40 User- Agent Identity Provider Web Site 1

    (Relying Party) Identity Token aud = 1 cookie
  32. Web SSO 41 User- Agent Identity Provider Web Site (Relying

    Party) cookie Web Site 2 (Relying Party)
  33. Web SSO 42 User- Agent Identity Provider Web Site (Relying

    Party) cookie cookie Web Site 2 (Relying Party)
  34. Web SSO 43 User- Agent Identity Provider Web Site (Relying

    Party) cookie cookie Web Site 2 (Relying Party) Identity Token aud = 2
  35. Mobile SSO 44 Token Agent App 1 (Relying Party) Authorization

    Server Token Endpoint UserInfo resource
  36. Mobile SSO 45 Token Agent App 1 (Relying Party) password

    username Authorization Server Token Endpoint UserInfo resource
  37. Mobile SSO 46 Token Agent App 1 (Relying Party) Authorization

    Server Token Endpoint UserInfo resource password username Primary Token
  38. Mobile SSO 47 Token Agent App 1 (Relying Party) Authorization

    Server Token Endpoint UserInfo resource Primary Token tokens Primary Token
  39. Mobile SSO 48 Token Agent App 1 (Relying Party) Authorization

    Server Token Endpoint UserInfo resource Primary Token Consent tokens
  40. Mobile SSO 49 Token Agent Web Site (Relying Party) Authorization

    Server Token Endpoint UserInfo resource Primary Token App 2 (Relying Party)
  41. Mobile SSO 50 Token Agent Web Site (Relying Party) Authorization

    Server Token Endpoint UserInfo resource Primary Token Primary Token App 2 (Relying Party) tokens Consent
  42. Mobile SSO 51 Token Agent App 1 (Relying Party) Authorization

    Server Token Endpoint UserInfo resource Primary Token App 2 (Relying Party) tokens
  43. Mobile SSO 52 ? App 1 (Relying Party) Authorization Server

    Token Endpoint UserInfo resource Primary Token App 2 (Relying Party) Native inter-process communication and authentication E.g. based on package name and certificate
  44. Mobile SSO 53 Token Agent App 1 (Relying Party) Authorization

    Server Token Endpoint UserInfo resource Primary Token App 2 (Relying Party) User credentials and consent
  45. Mobile SSO 54 ? App 1 (Relying Party) Authorization Server

    Token Endpoint UserInfo resource Primary Token App 2 (Relying Party) Custom protocol
  46. Mobile SSO 55 ? App 1 (Relying Party) Authorization Server

    Token Endpoint UserInfo resource Primary Token App 2 (Relying Party) Long term primary credential
  47. 56 Play Services and AccManager App 1 (Relying Party) Google

    Services Token Endpoint UserInfo resource Android and Google Play Services SDK
  48. Android and Google • Play services library • File >

    Import > Android > Existing Android Code Into … • {adt-path}\sdk\extras\google\google_play_services\libproject • Obtain debugging certificate • keytool -exportcert -alias androiddebugkey -keystore %USERPROFILE%\.android\debug.keystore -list –v 57
  49. Native client provisioning 1. Go to Google API Console 2.

    Create project 3. Provision Android client 58 Used for intra-device authentication
  50. User selection (1/2) • AccountPicker.newChooseAccountIntent to obtain an Intent 59

    Intent chooseAccountIntent = AccountPicker .newChooseAccountIntent( null, null, new String[] { GoogleAuthUtil.GOOGLE_ACCOUNT_TYPE }, true, null, null, null, null); startActivityForResult(chooseAccountIntent, MY_CHOOSE_ACTIVITY);
  51. User selection (2/2) • Fetch the email from the result

    Intent 60 @Override protected void onActivityResult( int requestCode, int resultCode, Intent data) { if (resultCode == RESULT_OK) { if (requestCode == MY_CHOOSE_ACTIVITY) { String email = data .getStringExtra(AccountManager.KEY_ACCOUNT_NAME);
  52. Obtain token (1/2) • GoogleAuthUtil.getToken • Given: email and scope

    • Returns: token • Blocking operation • Scope defines the goal of the request • E.g. “oauth2:openid email profile” 61 String scope = "oauth2:openid email profile"; String token = GoogleAuthUtil .getToken(MainActivity.this, email, scope, null);
  53. Obtain token (2/2) • GoogleAuthUtil.getToken • May require User interaction

    • Signaled via exception • Use exception’s Intent • Call getToken again 62 } catch (UserRecoverableAuthException recoverableException) { Intent recoveryIntent = recoverableException.getIntent(); MainActivity.this .startActivityForResult(recoveryIntent,continueRequestType);
  54. 66 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) How does device-side authenticates to server-side?
  55. 67 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) How does device-side authenticates to server-side? “It’s Alice, trust me”
  56. 68 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) How does device-side authenticates to server-side? Using the device-side access token?
  57. 69 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) How does device-side authenticates to server-side? Using a ID token, issued to device-side?
  58. 70 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) How does device-side authenticates to server-side? Using a ID token, issued to server-side 
  59. 71 Play Services Client App (device side) Authorization Server Token

    Endpoint UserInfo resource Client App (server side) Get JWT ID token to server’s client_id ID_TOKEN_SCOPE = "audience:server:client_id:86…";
  60. 73 Play Services Client App (device side) Authorization Server Token

    Endpoint UserInfo resource Client App (server side) JWT ID token
  61. 75 Play Services Client App (device side) Authorization Server Token

    Endpoint UserInfo resource Client App (server side) JWT ID token aud azp iss sub email
  62. Cross client ID token { "iss": "accounts.google.com", "id": "104107606523710296052", "sub":

    "104107606523710296052", "azp": "86…983-ov2…v4k.apps…..com", "email": "[email protected]", "email_verified": true, "aud": "862…983-16j…im3.apps…..com", "verified_email": true, "cid": "862…983-ov2…v4k.apps…..com", "iat": 1401010427, "exp": 1401014327 } 76 The android app client_id The server app client_id
  63. 77 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) How does server-side accesses protected resource? Namely, while user offline Resource Server
  64. 78 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) How does server-side accesses protected resource? Namely, while user offline Get a code and exchange it for a token  Resource Server
  65. 79 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) Resource Server Play Services Get code for server’s client_id private static final String CODE_SCOPE = “oauth2:server:client_id:…”+ “:api_scope:email https://www..../tasks.readonly”;
  66. 80 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) Resource Server Play Services code
  67. 81 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) Resource Server client_secret client_id code code access_token
  68. 82 Client App (device side) Authorization Server Token Endpoint UserInfo

    resource Client App (server side) Resource Server access_token
  69. Custom solution • Scopes prefixes • SDK to interact with

    token agent • Protocol between Token Agent and Authz Server • There are other custom solutions • E.g. Facebook 84
  70. 85

  71. OpenID Connect Native Token Agent • NAPPS • Token Agent

    (TA) • Device-side representative of the Authz Server (AS) • Apps request tokens to TA • TA uses code flow to obtain a primary token from AS • Includes • User authentication • User consent • TA obtains application metadata from AS • TA obtains secondary tokens, using primary token 86
  72. OpenID Connect Native Token Agent • Communication between apps and

    TA • On Android, using Intents and Activities • Delegation to server side? • Device identity? 87
  73. Resources • RFCs 6749 and 6750 • Google https://developers.google.com/+/mobile/android/sign-in •

    NAPPS http://hg.openid.net/napps/wiki/Home • Designing Evolvable Web APIs with ASP.NET One chapter on OAuth 2.0 and OpenID Connect • https://github.com/pmhsfelix • Thank you! 88
