Goruco 2015: Building and Testing Resilient Applications

Transcript

1. Building and Testing Resilient Applications Simon Eskildsen, Goruco 2015, NYC @Sirupsen 1
3. Shopify 3 165,000+ ACTIVE SHOPIFY MERCHANTS $8 BILLION+ CUMULATIVE GMV 200+ DEVELOPERS 500+ SERVERS 2 DATACENTERS Ruby on Rails ONE OF THE LARGEST RAILS DEPLOYMENTS IN THE WORLD 3000+ CONTAINERS RUNNING AT ANY TIME 10,000+ MAX CHECKOUTS PER MINUTE 12+ DEPLOYS PER DAY 300M unique visits/month LEAGUE OF APPLE, EBAY AND AMAZON
4. 4 Building reliable bridges in large distributed systems
5. 5 Most important effort for peace of mind
6. 6 The Holidays and The Catastrophic Fall of 2014
7. 7 Resiliency Building reliable systems from unreliable components
8. (Micro)service equation 8 Uptime = AN Number of services Availability per service Final availability
9. 9 Availability 70 80 90 100 Services 10 50 100 500 1000 99.98 99.99 99.999 99.95
10. Even monolithic services easily have tens of dependencies: RDBMS, Redis, Memcached, ElasticSearch, S3, CDN, APIs, Mailing, CRM, … 10
11. 11 Application should be designed to handle fallbacks
13. search sessions carts mysql-shard cdn
14. Avoid HTTP 500 for single service failing .. or suffer the faith of the (micro)service equation
15. Sessions data store unavailable Customer signed out
16. 16 Naïve session code def index @user = fetch_user @posts = Post.all end private def fetch_user # accesses potentially two data stores: # session + data store that stores user User.find(session[:user_id]) end
17. 17 Resilient session code def index @user = fetch_user @posts = Post.all end private def fetch_user User.find(session[:user_id]) # return nil if session store is down # in this example sessions are in Redis rescue Redis::BaseError nil end
18. How do we test it? 18 Mocks are client specific and easily covers as many bugs as it uncovers Production testing means it’s too late and difficult to reproduce Network-level simulation in development and test environments would give full, reproducible confidence
19. 19 https://github.com/shopify/toxiproxy Toxiproxy[:mysql_master].downstream(:latency, latency: 1000).apply do Shop.first # this takes at least 1s end Toxiproxy[/redis/].down do session[:user_id] # this will throw an exception end Simulate TCP conditions with Toxiproxy
21. 21 def test_storefront_resilient_sessions Toxiproxy[:redis_sessions].down do get '/' assert_response :success end end
22. I’m lost. How do I get an overview of my application? 22
23. 23 Checkout Admin Storefront MySQL Shard Unavailable Unavailable Degraded MySQL Master Available Unavailable Available Kafka Available Degraded Available External HTTP API Degraded Available Unavailable redis-sessions Unavailable Unavailable Degraded Resiliency Matrix
24. Write a Toxiproxy test for each cell 24 # test/integration/resiliency_matrix_test.rb def test_section_a_mq_a_down Toxiproxy[:message_queue_a].down do get '/section_a' assert_response :success end end def test_section_b_datastore_b Toxiproxy[:datastore_b].down do get '/section_b' assert_response 500 end end # ... and every other cell
25. Beware of non-resilient dependencies 25 # https://github. com/rails/rails/blob/master/activerecord/lib/active_record/query_cache.rb#L30- 45 def call(env) connection = ActiveRecord::Base.connection enabled = connection.query_cache_enabled connection_id = ActiveRecord::Base.connection_id connection.enable_query_cache! response = @app.call(env) response[2] = Rack::BodyProxy.new(response[2]) do restore_query_cache_settings(connection_id, enabled) end response rescue Exception => e restore_query_cache_settings(connection_id, enabled) raise e end
26. 26 Another example class Product def tags redis.smembers("product:#{id}:tags") end end
27. 27 Slightly better class Product def tags redis.smembers("product:#{id}:tags") rescue Redis::BaseError => e ErrorReporter.log(e) [] end end
28. Rescues in high level code smells of leaky abstraction 28
29. 29 Decorators class PersistentSet def to_a redis.smembers(key) rescue Redis::BaseError [] end def include?(value) redis.sismember(key, value) rescue Redis::BaseError false end end
30. With fallbacks the system is still vulnerable to slowness. ECONNREFUSED is a luxury in distributed systems, slowness is the killer. 30
31. Little’s law
32. /impacted 500ms /ok 20ms /ok 20ms /impacted 500ms
33. 33 0.001s 0.01s 0.002s 0.01s 0.01s 0.01s 0.01s 0.01s 400 RPS Infrastructure operating normally
34. 34 0.001s 0.01s 0.020s 0.10s 0.10s 0.10s 0.10s 0.10s 40 RPS Database latency increases by 10x, throughput drops 10x
35. Timeouts not good enough 35 Response time suffers—even if timeout is low Little’s law: capacity reduced Need ways to fail even faster! Setting timeouts problematic, super low (<10ms) for frequent resources doesn’t account for natural outliers
36. Your resiliency reference 36
37. Strong heuristics for failing fast 37 Circuit breakers makes clients fail fast once they’ve failed repeatedly Bulkheads controls the access to resources, especially handy if you have high timeouts for some components
38. Circuit Breakers 38 Start RPC Circuit.open? Driver.query(timeout=200ms) Driver.failure? Throw Exception End RPC NO markFailure() markSuccess() YES YES NO
39. Circuit Breakers 39 Gives your failing components room to breathe Fails fast after several timeouts If some timeouts are high circuit breakers don’t help much. Capacity reduced until they kick in.
40. Bulkheads 40 40 2 tickets 1 ticket
41. Bulkheads 41 41 1 tickets 1 ticket SLOW
42. Bulkheads 42 42 0 tickets 1 ticket SLOW
43. Bulkheads 43 43 0 tickets 1 ticket REJECTED SLOW
44. Bulkheads 44 44 0 tickets 0 tickets SLOW
45. Bulkheads 45 Mental model is a thread pool—but useful in process- based servers Ensures controlled access to resources under increase in response time; easy to reason about impact Fails faster than circuit breakers when timeout is high
46. Circuit Breakers, Bulkheads and Timeouts complement each other well to fail fast! 46
47. Do I need Circuit Breakers and Bulkheads? 47 Less critical for evented (especially) and multithreaded servers You’ve observed these problems in production (you’re now equipped to) High timeouts to some data stores and/or services because of legitimate outliers
48. 48 Resiliency Toolkits netflix/hystrix shopify/semian twitter/finagle
50. Resiliency Maturity Pyramid 50 No resiliency effort Testing with mocks Toxiproxy tests and matrix Resiliency Patterns Production Practise Days (Games) Kill Nodes (Chaos Monkey) Latency Monkey Application-Specific Fallbacks Region Gorilla
51. Final remarks 51 Draw your resiliency matrix, write Toxiproxy tests and implement application-specific fallbacks Not everyone needs circuit breakers and bulkheads, this may be premature for your application Be careful when introducing new dependencies
52. 52 More examples and docs in Semian and Toxiproxy docs http://github.com/shopify/semian https://github.com/shopify/toxiproxy http://www.shopify.com/technology/16906928-building-and- testing-resilient-ruby-on-rails-applications
53. Thank you! 53 Simon Eskildsen, Shopify @Sirupsen
