@Swift 2017 - From Zero to Hero: Accessibility for iOS

A quick tour of VoiceOver accessibility support for iOS via a demo application and code examples

Sommer Panage

May 13, 2017
Tweet

More Decks by Sommer Panage

Other Decks in Technology

Transcript

  1. From Zero to Hero: Making your iOS App Accessible to

    VoiceOver and Beyond By Sommer Panage @sommer
  2. Motor • Cerebral palsy • Muscular dystrophy • Multiple sclerosis

    • Broken hand • Using device while driving
  3. Auditory • Deaf • Hard-of-hearing • Mono-audio • Using device

    in noisy area • Using device with no audio
  4. Audit • Turn on VoiceOver • Navigate thru app •

    Look for items that VO skip • Look for items that do not explain: • What it does • Who it is
  5. Issues in our app • Answer buttons need names •

    Can't see our items in the white box!
  6. To follow along in the code go to http:/ /bit.ly/2qctKyb

    or https:/ /github.com/spanage/HelloA11y-Swift ..................................... • master branch for original code without accessibility • a11y branch for accessible code
  7. Issues in our app • "Learn" items don't indicate they're

    tappable We need these items to tell us what they are!
  8. What? Accessibility Traits • myItem.accessibilityTraits • Indicate what an items

    is • Automatically supplied for UIControls • Should use bitwise or (|) to preserve original traits
  9. Common Accessibility Traits • UIAccessibilityTraitButton --> "Tap me!" • UIAccessibilityTraitHeader

    --> Makes nav easier • UIAccessibilityTraitLink -->"I jump around or leave the app" • UIAccessibilityTraitImage --> "I'm an image" • UIAccessibilityTraitAdjustable --> "Swipe up/down to adjust me"
  10. Cell code before func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath)

    -> UITableViewCell { let cell: UITableViewCell switch Section(rawValue: indexPath.section)! { case .items: let mainCell: MainTableViewCell = tableView.dequeueReusableCell( withIdentifier: MainTableViewCell.reuseID, for: indexPath) as! MainTableViewCell mainCell.item = items[indexPath.row] cell = mainCell case .review: let reviewCell: ReviewTableViewCell = tableView.dequeueReusableCell( withIdentifier: ReviewTableViewCell.reuseID, for: indexPath) as! ReviewTableViewCell cell = reviewCell } return cell }
  11. Accessibility Traits are easy! We just need to tell our

    cells to behave to Accessibility like buttons! cell.accessibilityTraits |= UIAccessibilityTraitButton
  12. Cell code after func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath)

    -> UITableViewCell { let cell: UITableViewCell switch Section(rawValue: indexPath.section)! { case .items: let mainCell: MainTableViewCell = tableView.dequeueReusableCell( withIdentifier: MainTableViewCell.reuseID, for: indexPath) as! MainTableViewCell mainCell.item = items[indexPath.row] cell = mainCell case .review: let reviewCell: ReviewTableViewCell = tableView.dequeueReusableCell( withIdentifier: ReviewTableViewCell.reuseID, for: indexPath) as! ReviewTableViewCell cell = reviewCell } // Our cells behave like buttons cell.accessibilityTraits |= UIAccessibilityTraitButton return cell }
  13. Issues in our app • Answer buttons need names We

    need to provide labels for these buttons!
  14. Who? Accessibility Label • myItem.accessibilityLabel • Indicates the name of

    an item / what it does • Automatically supplied for text and cells (generally) • Should be short and clear • Should not contain trait info, i.e. "Answer button"
  15. Button code before let englishButton: UIButton = { let button

    = UIButton(type: .system) button.setBackgroundImage(#imageLiteral(resourceName: "union_jack") .withRenderingMode(.alwaysTemplate), for: .normal) return button }()
  16. Accessibility Label (and Hint) button.accessibilityLabel = "English Answer" button.accessibilityHint =

    "Shows the answer in English" accessibilityLabel Who am I? accessibilityHint More (optional) info on what I do!
  17. Button code after let englishButton: UIButton = { let button

    = UIButton(type: .system) button.setBackgroundImage(#imageLiteral(resourceName: "union_jack") .withRenderingMode(.alwaysTemplate), for: .normal) button.accessibilityLabel = "English Answer" button.accessibilityHint = "Shows the answer in English" return button }()
  18. Issues in our app • Can't see our items in

    the white box! We need to provide custom Accessibility Elements for these lesson drawings!
  19. Custom Accessibility Elements • Sometimes we don't use UIViews (i.e.

    custom drawing) • Create a custom UIAccessibilityElement in a container UIView for each object we want VO to see • Our view must: • have isAccessibilityElement = false • set accessibilityElements to our array of UIAccessibilityElement objects
  20. Custom Accessibility Elements Each UIAccessibilityElement must have an accessibiliyLabel and

    some form of frame: • accessibilityFrame: in screen coordinates • accessibilityFrameInContainerSpace: in container coordinates • accessibilityPath: in screen coordinates
  21. Drawing before protocol Lesson { var english: String { get

    } var chinese: String { get } func draw(in view: UIView) }
  22. Drawing before // Draw a square filled with a given

    color private static let squareDimension: CGFloat = 100 func draw(in view: UIView) { let rect = view.bounds let d = ColorLesson.squareDimension let context = UIGraphicsGetCurrentContext() let color = self.uiColor context?.setFillColor(color.cgColor) context?.setStrokeColor(UIColor.gray.cgColor) context?.setLineWidth(2.0) let x = (rect.width - d) / 2.0 + rect.minX let y = (rect.height - d) / 2.0 + rect.minY let colorRect = CGRect(x: x, y: y, width: d, height: d) context?.fill(colorRect) context?.stroke(colorRect) }
  23. Creating a custom UIAccessibilityElement let element = UIAccessibilityElement( accessibilityContainer: parentView)

    element.accessibilityFrameInContainerSpace = CGRect( x: 0, y: 0, width: 100, height: 100) element.accessibilityLabel = "Box, the color of the sky & ocean" parentView.accessibilityElements = [element]
  24. Drawing after protocol Lesson { var english: String { get

    } var chinese: String { get } func drawAccessibly(in view: UIView) -> [UIAccessibilityElement] }
  25. Drawing after private static let squareDimension: CGFloat = 100 func

    drawAccessibly(in view: UIView) -> [UIAccessibilityElement] { // drawing code here! let element = UIAccessibilityElement(accessibilityContainer: view) element.accessibilityFrameInContainerSpace = colorRect element.accessibilityLabel = accessibilityDescription return [element] }
  26. Drawing after private class LessonView: UIView { // ivars, etc.

    init(lesson: Lesson, drawAccessiblyForLesson: @escaping (Lesson, UIView) -> [UIAccessibilityElement]) { self.lesson = lesson self.drawAccessiblyForLesson = drawAccessiblyForLesson super.init(frame: .zero) isAccessibilityElement = false backgroundColor = .white } override func draw(_ rect: CGRect) { let a11yElements = drawAccessiblyForLesson(lesson, self) accessibilityElements = a11yElements } }
  27. Issues in our app • Not clear that "Got it!"

    goes back We need to (a) add hint to the button and (b) support the default back gesture for VoiceOver
  28. Special accessibility gestures APIs to cusomize • Scrolling announcements (3-finger

    scroll) • Magic Tap (2-finger double tap) • Escape gesture (2-finger Z-shape)
  29. A closer look at Escape • Two-finger Z shape •

    Supported automatically by UINavigationController • Must be manuallys supported for modals via accessibilityPerformEscape()
  30. A closer look at Escape final class AnswerViewController: UIViewController {

    // ivars, init, etc... override func viewDidLoad() { super.viewDidLoad() doneButton.addTarget(self, action: #selector(didSelectDone), for: .touchUpInside) // setup views here... } @objc private func didSelectDone() { dismiss(animated: true, completion: nil) } override func accessibilityPerformEscape() -> Bool { didSelectDone() return true } }
  31. Issues in our app • No audio differentiation of review

    items We need to provide a way to navigate by shape, color, or number!
  32. The Rotor: new power in iOS 10 • Primarily for

    navigation • Navigate by headings, words, letters, etc. • iOS 10 lets us add our own navigation keys
  33. Navigation by Rotor • Select item, e.g. "colors" • Swipe

    up, down to go to preverious/next item • Matches the expereince of sighted users, who can use color to visually scan for different cell types
  34. Rotor code final class ReviewViewController: UIViewController { // ivars, etc.

    init(items: [ReviewItem]) { // sort items alphabetically in Engish self.items = items.sorted { itemA, itemB in itemA.englishText < itemB.englishText } super.init(nibName: nil, bundle: nil) // other setup... setupRotors() } }
  35. Rotor code private func setupRotors() { let categories = Set(items.map

    { $0.rotorCategory }) let rotors = categories.map { category in UIAccessibilityCustomRotor(name: category, itemSearch: { (predicate) -> UIAccessibilityCustomRotorItemResult? in guard !self.items.isEmpty else { return nil } let forward = predicate.searchDirection == .next // figure out starting point var currentIndex = forward ? -1 : self.items.count if let cell = predicate.currentItem.targetElement as? UITableViewCell { currentIndex = self.tableView.indexPath(for: cell)?.row ?? currentIndex } // helper for search func next(index: Int) -> Int { return forward ? index + 1 : index - 1 } var index = next(index: currentIndex) while index >= 0 && index < self.items.count { if self.items[index].rotorCategory == category { let indexPath = IndexPath(row: index, section: 0) self.tableView.scrollToRow(at: indexPath, at: .none, animated: false) let cell = self.tableView.cellForRow(at: indexPath)! return UIAccessibilityCustomRotorItemResult(targetElement: cell, targetRange: nil) } index = next(index: index) } return nil }) } accessibilityCustomRotors = rotors }
  36. Rotor code private func setupRotors() { let categories = Set(items.map

    { $0.rotorCategory }) let rotors = categories.map { category in // create a rotor for each category } accessibilityCustomRotors = rotors }
  37. Rotor code UIAccessibilityCustomRotor(name: category, itemSearch: { (predicate) -> UIAccessibilityCustomRotorItemResult? in

    guard !self.items.isEmpty else { return nil } let forward = predicate.searchDirection == .next // figure out starting point var currentIndex = forward ? -1 : self.items.count if let cell = predicate.currentItem.targetElement as? UITableViewCell { currentIndex = self.tableView.indexPath(for: cell)?.row ?? currentIndex } // ... and more ... })
  38. Rotor code // helper for search func next(index: Int) ->

    Int { return forward ? index + 1 : index - 1 } var index = next(index: currentIndex) while index >= 0 && index < self.items.count { if self.items[index].rotorCategory == category { let indexPath = IndexPath(row: index, section: 0) self.tableView.scrollToRow(at: indexPath, at: .none, animated: false) let cell = self.tableView.cellForRow(at: indexPath)! return UIAccessibilityCustomRotorItemResult(targetElement: cell, targetRange: nil) } index = next(index: index) } return nil
  39. Rotor code, explained 1. Determine if you're going forwards or

    backwards 2. Figure out your starting point 3. Search from your starting point to find the next item that matches the rotor selection. 4. Return the item wrapped as a UIAccessibilityCustomRotorItemR esult or nil if there's no such item
  40. Summary 1. Accessibility helps all users overcome challeneges 2. Audit

    your app! 3. Basic accessibility - labels and traits! 4. Advanced accessibility - gestures and rotors!
