Turbocharged: Writing High Performance C# and ....

Turbocharged: Writing High Performance C# and .NET Code (60 mins)

Steve Gordon

April 26, 2019
Tweet

More Decks by Steve Gordon

Other Decks in Technology

Transcript

  1. @stevejgordon www.stevejgordon.co.uk • What is performance? • Measuring application and

    code performance • Span<T>, ReadOnlySpan<T> and Memory<T> • ArrayPool • System.IO.Pipelines and ReadOnlySequence<T> • .NET Core 3.0 JSON APIs
  2. @stevejgordon www.stevejgordon.co.uk • Visual Studio Diagnostic Tools (debugging) • Visual

    Studio Profiling / PerfView / dotTrace / dotMemory • ILSpy / JustDecompile / dotPeek • Production metrics and monitoring
  3. @stevejgordon www.stevejgordon.co.uk • Library for .NET (micro)benchmarking • High precision

    measurements • Extra data and output available using diagnosers • Compare performance on different platforms, architectures, JIT versions and GC Modes • Used extensively in CoreFx, CoreClr and ASP.NET Core • https://benchmarkdotnet.org • https://github.com/dotnet/BenchmarkDotNet
  4. @stevejgordon www.stevejgordon.co.uk namespace BenchmarkExample { public class Program { public

    static void Main(string[] args) => _ = BenchmarkRunner.Run<NameParserBenchmarks>(); } [MemoryDiagnoser] public class NameParserBenchmarks { private const string FullName = "Steve J Gordon"; private static readonly NameParser Parser = new NameParser(); [Benchmark] public void GetLastName() { Parser.GetLastName(FullName); } } }
  5. @stevejgordon www.stevejgordon.co.uk namespace BenchmarkExample { public class Program { public

    static void Main(string[] args) => _ = BenchmarkRunner.Run<NameParserBenchmarks>(); } [MemoryDiagnoser] public class NameParserBenchmarks { private const string FullName = "Steve J Gordon"; private static readonly NameParser Parser = new NameParser(); [Benchmark] public void GetLastName() { Parser.GetLastName(FullName); } } }
  6. @stevejgordon www.stevejgordon.co.uk namespace BenchmarkExample { public class Program { public

    static void Main(string[] args) => _ = BenchmarkRunner.Run<NameParserBenchmarks>(); } [MemoryDiagnoser] public class NameParserBenchmarks { private const string FullName = "Steve J Gordon"; private static readonly NameParser Parser = new NameParser(); [Benchmark] public void GetLastName() { Parser.GetLastName(FullName); } } }
  7. @stevejgordon www.stevejgordon.co.uk namespace BenchmarkExample { public class Program { public

    static void Main(string[] args) => _ = BenchmarkRunner.Run<NameParserBenchmarks>(); } [MemoryDiagnoser] public class NameParserBenchmarks { private const string FullName = "Steve J Gordon"; private static readonly NameParser Parser = new NameParser(); [Benchmark] public void GetLastName() { Parser.GetLastName(FullName); } } }
  8. @stevejgordon www.stevejgordon.co.uk namespace BenchmarkExample { public class Program { public

    static void Main(string[] args) => _ = BenchmarkRunner.Run<NameParserBenchmarks>(); } [MemoryDiagnoser] public class NameParserBenchmarks { private const string FullName = "Steve J Gordon"; private static readonly NameParser Parser = new NameParser(); [Benchmark] public void GetLastName() { Parser.GetLastName(FullName); } } }
  9. @stevejgordon www.stevejgordon.co.uk // * Summary * BenchmarkDotNet=v0.11.5, OS=Windows 10.0.18362 Intel

    Core i7-6700 CPU 3.40GHz (Skylake), 1 CPU, 8 logical and 4 physical cores .NET Core SDK=3.0.100 [Host] : .NET Core 3.0.0 (CoreCLR 4.700.19.46205, CoreFX 4.700.19.46214), 64bit RyuJIT DefaultJob : .NET Core 3.0.0 (CoreCLR 4.700.19.46205, CoreFX 4.700.19.46214), 64bit RyuJIT Method | Mean | Error | StdDev | Median | Gen 0 | Gen 1 | Gen 2 | Allocated | ------------ |-----------:|-----------:|-----------:|-----------:|-------:|-------:|-------:|----------:| GetLastName | 163.18 ns | 3.1903 ns | 4.2590 ns | 161.87 ns | 0.0379 | - | - | 160 B | (1 / 0.0379) x 1000 = 26,385.2 operations before Gen 0 collection.
  10. @stevejgordon www.stevejgordon.co.uk • System.Memory package. Built into .NET Core 2.1.

    • Provides a read/write 'view' onto a contiguous region of memory • Heap (Managed objects) – e.g. Arrays, Strings • Stack (via stackalloc) • Native/Unmanaged (P/Invoke) • Index / Iterate to modify the memory within the Span • Almost no overhead
  11. @stevejgordon www.stevejgordon.co.uk [MemoryDiagnoser] public class ArrayBenchmarks { private int[] _myArray;

    [Params(100, 1000, 10000)] public int Size { get; set; } [GlobalSetup] public void Setup() { _myArray = new int[Size]; for (var i = 0; i < Size; i++) _myArray[i] = i; } … }
  12. @stevejgordon www.stevejgordon.co.uk [MemoryDiagnoser] public class ArrayBenchmarks { private int[] _myArray;

    [Params(100, 1000, 10000)] public int Size { get; set; } [GlobalSetup] public void Setup() { _myArray = new int[Size]; for (var i = 0; i < Size; i++) _myArray[i] = i; } … }
  13. @stevejgordon www.stevejgordon.co.uk [MemoryDiagnoser] public class ArrayBenchmarks { private int[] _myArray;

    [Params(100, 1000, 10000)] public int Size { get; set; } [GlobalSetup] public void Setup() { _myArray = new int[Size]; for (var i = 0; i < Size; i++) _myArray[i] = i; } … }
  14. @stevejgordon www.stevejgordon.co.uk [MemoryDiagnoser] public class ArrayBenchmarks { private int[] _myArray;

    [Params(100, 1000, 10000)] public int Size { get; set; } [GlobalSetup] public void Setup() { _myArray = new int[Size]; for (var i = 0; i < Size; i++) _myArray[i] = i; } … }
  15. @stevejgordon www.stevejgordon.co.uk [MemoryDiagnoser] public class ArrayBenchmarks { … [Benchmark(Baseline =

    true)] public int[] Original() => _myArray.Skip(Size / 2).Take(Size / 4).ToArray(); … }
  16. @stevejgordon www.stevejgordon.co.uk | Method | Size | Mean | Ratio

    | Gen 0 | Gen 1 | Gen 2 | Allocated | |----------- |------ |---------------:|------:|-------:|-------:|------:|----------:| | Original | 100 | 154.9018 ns | 1.00 | 0.0534 | - | - | 224 B | | | | | | | | | | | Original | 1000 | 727.2669 ns | 1.00 | 0.2670 | - | - | 1120 B | | | | | | | | | | | Original | 10000 | 7,332.0136 ns | 1.00 | 2.4109 | - | - | 10120 B |
  17. @stevejgordon www.stevejgordon.co.uk [MemoryDiagnoser] public class ArrayBenchmarks { … [Benchmark] public

    int[] ArrayCopy() { var newArray = new int[Size / 4]; Array.Copy(_myArray, Size / 2, newArray, 0, Size / 4); return newArray; } … }
  18. @stevejgordon www.stevejgordon.co.uk | Method | Size | Mean | Ratio

    | Gen 0 | Gen 1 | Gen 2 | Allocated | |----------- |------ |---------------:|-------:|-------:|-------:|------:|----------:| | Original | 100 | 154.9018 ns | 1.000 | 0.0534 | - | - | 224 B | | ArrayCopy | 100 | 24.5267 ns | 0.159 | 0.0051 | - | - | 128 B | | | | | | | | | | | Original | 1000 | 727.2669 ns | 1.000 | 0.2670 | - | - | 1120 B | | ArrayCopy | 1000 | 104.7282 ns | 0.142 | 0.1627 | - | - | 1024 B | | | | | | | | | | | Original | 10000 | 7,332.0136 ns | 1.000 | 2.4109 | - | - | 10120 B | | ArrayCopy | 10000 | 801.1695 ns | 0.109 | 1.5917 | - | - | 10024 B |
  19. @stevejgordon www.stevejgordon.co.uk [MemoryDiagnoser] public class ArrayBenchmarks { … [Benchmark] public

    Span<int> Span() => _myArray.AsSpan().Slice(Size / 2, Size / 4); … }
  20. @stevejgordon www.stevejgordon.co.uk | Method | Size | Mean | Ratio

    | Gen 0 | Gen 1 | Gen 2 | Allocated | |----------- |------ |---------------:|-------:|-------:|-------:|------:|----------:| | Original | 100 | 154.9018 ns | 1.000 | 0.0534 | - | - | 224 B | | ArrayCopy | 100 | 24.5267 ns | 0.159 | 0.0051 | - | - | 128 B | | Span | 100 | 0.9233 ns | 0.006 | - | - | - | - | | | | | | | | | | | Original | 1000 | 727.2669 ns | 1.000 | 0.2670 | - | - | 1120 B | | ArrayCopy | 1000 | 104.7282 ns | 0.142 | 0.1627 | - | - | 1024 B | | Span | 1000 | 0.9016 ns | 0.000 | - | - | - | - | | | | | | | | | | | Original | 10000 | 7,332.0136 ns | 1.000 | 2.4109 | - | - | 10120 B | | ArrayCopy | 10000 | 801.1695 ns | 0.109 | 1.5917 | - | - | 10024 B | | Span | 10000 | 0.9095 ns | 0.000 | - | - | - | - |
  21. @stevejgordon www.stevejgordon.co.uk S ReadOnlySpan<char> t e v e J G

    o r d o n ReadOnlySpan<char>.Slice(start: 8) ReadOnlySpan<char> span = "Steve J Gordon".AsSpan(); G o r d o n
  22. @stevejgordon www.stevejgordon.co.uk • It's a stack only Value Type (ref

    struct) – Cannot live on the heap • Requires C# 7.2+ for ref struct feature • Cannot be boxed • Cannot be a field in a class or standard (non ref) struct • Cannot be used as an argument or local variable inside async methods • Cannot be captured by lambda expressions • Cannot be used as a generic type argument
  23. @stevejgordon www.stevejgordon.co.uk • Similar to Span<T> but can live on

    the heap • A readonly struct but not a ref struct • Slightly slower to slice into Memory<T> • Call its Span property to get a Span over the same data
  24. @stevejgordon www.stevejgordon.co.uk // CS4012 Parameters or locals of type 'Span<byte>'

    cannot be declared // in async methods or lambda expressions. private async Task SomethingAsync(Span<byte> data) { ... // Would be nice to do something with the Span here await Task.Delay(1000); }
  25. @stevejgordon www.stevejgordon.co.uk private async Task SomethingAsync(Memory<byte> data) { Memory<byte> dataSliced

    = data.Slice(0, 100); await Task.Delay(1000); } private void SomethingNotAsync(Span<byte> data) { // some code }
  26. @stevejgordon www.stevejgordon.co.uk private async Task SomethingAsync(Memory<byte> data) { // CS4012

    Parameters or locals of type 'Span<byte>' cannot be declared // in async methods or lambda expressions. var span = data.Span.Slice(1); SomethingNotAsync(span); await Task.Delay(1000); } private void SomethingNotAsync(Span<byte> data) { // some code }
  27. @stevejgordon www.stevejgordon.co.uk Microservice which: 1. Reads SQS message 2. Deserialise

    the JSON message 3. Stores a copy of the message to S3 using an object key derived from properties of the message. S3ObjectKeyGenerator
  28. @stevejgordon www.stevejgordon.co.uk | Method | Mean |Ratio | Gen 0

    | Gen 1 | Gen 2 | Allocated | |------------- |-----------:|-----:|----------:|----------:|----------:|----------:| | Original | 1,088.0 ns | 1.00 | 0.1812 | - | - | 1144 B | | SpanBased | 449.0 ns | 0.41 | 0.0305 | - | - | 192 B | | StringCreate | 442.9 ns | 0.41 | 0.0305 | - | - | 192 B | ~2.5x Faster ~6x Less Allocations 18 million messages: Reduction of 17GB of allocations daily Removes approx. 2711 Gen 0 collections (562 vs. 3273)
  29. @stevejgordon www.stevejgordon.co.uk • Pool of arrays for re-use • Found

    in System.Buffers • ArrayPool<T>.Shared.Rent(int length) • You are likely to get an array larger than your minimum size • ArrayPool<T>.Shared.Return(T[] array, bool clearArray = false) • Warning: By default returned arrays are not cleared! • https://adamsitnik.com/Array-Pool/
  30. @stevejgordon www.stevejgordon.co.uk public class Processor { public void DoSomeWorkVeryOften() {

    var buffer = new byte[1000]; // allocates DoSomethingWithBuffer(buffer); } private void DoSomethingWithBuffer(byte[] buffer) { // use the array } }
  31. @stevejgordon www.stevejgordon.co.uk public class Processor { public void DoSomeWorkVeryOften() {

    var buffer = new byte[1000]; // allocates DoSomethingWithBuffer(buffer); } private void DoSomethingWithBuffer(byte[] buffer) { // use the array } }
  32. @stevejgordon www.stevejgordon.co.uk public class Processor { public void DoSomeWorkVeryOften() {

    var arrayPool = ArrayPool<byte>.Shared; var buffer = arrayPool.Rent(1000); DoSomethingWithBuffer(buffer); } private void DoSomethingWithBuffer(byte[] buffer) { // use the array } }
  33. @stevejgordon www.stevejgordon.co.uk public class Processor { public void DoSomeWorkVeryOften() {

    var arrayPool = ArrayPool<byte>.Shared; var buffer = arrayPool.Rent(1000); try { DoSomethingWithBuffer(buffer); } finally { arrayPool.Return(buffer); } } private void DoSomethingWithBuffer(byte[] buffer) { // use the array } }
  34. @stevejgordon www.stevejgordon.co.uk | Method | SizeInBytes | Mean | Gen

    0 | Gen 1 | Gen 2 | Allocated | |-------------- |------------ |--------------:|--------:|--------:|--------:|----------:| | RentAndReturn | 20 | 29.397 ns | - | - | - | - | | Allocate | 20 | 6.563 ns | 0.0115 | - | - | 48 B | | RentAndReturn | 100 | 28.797 ns | - | - | - | - | | Allocate | 100 | 13.349 ns | 0.0306 | - | - | 128 B | | RentAndReturn | 1000 | 33.807 ns | - | - | - | - | | Allocate | 1000 | 84.908 ns | 0.2447 | - | - | 1024 B | | RentAndReturn | 10000 | 35.387 ns | - | - | - | - | | Allocate | 10000 | 978.090 ns | 2.3918 | - | - | 10024 B | | RentAndReturn | 100000 | 31.615 ns | - | - | - | - | | Allocate | 100000 | 12,875.858 ns | 31.2347 | 31.2347 | 31.2347 | 100024 B |
  35. @stevejgordon www.stevejgordon.co.uk • Created by ASP.NET team to improve Kestrel

    requests per second. • Improves I/O performance scenarios (~2x vs. streams) • Removes common hard to write, boilerplate code • Unlike streams, pipelines manages buffers for you from ArrayPool • Two sides to a pipe, PipeWriter and PipeReader
  36. @stevejgordon www.stevejgordon.co.uk PipeWriter : IBufferWriter<byte> Pipe PipeReader Memory<byte> m =

    pw.GetMemory(); … pw.Advance(1000) await pw.FlushAsync() ReadResult r = await reader.ReadAsync(); ReadOnlySequence<byte> b = r.Buffer;
  37. @stevejgordon www.stevejgordon.co.uk Microservice which: 1. Retrieves S3 object (TSV file)

    from AWS 2. Decompresses file 3. Parses TSV to get 3 of 25 columns for each row 4. Indexes data to ElasticSearch CloudFrontParser
  38. @stevejgordon www.stevejgordon.co.uk | Method | Mean |Ratio | Gen 0

    | Gen 1 | Gen 2 | Allocated | |---------- |-----------:|-----:|----------:|----------:|----------:|----------:| | Original | 3,636.6 ms | 1.00 | 1051000.0 | 227000.0 | 93000.0 | 2.59 KB | | Optimised | 486.8 ms | 0.14 | 36000.0 | 17000.0 | 1000.0 | 2.77 KB | Over 7x Faster Allocations ??? ¯\_(ツ)_/¯
  39. @stevejgordon www.stevejgordon.co.uk | Method | Mean |Ratio | Gen 0

    | Gen 1 | Gen 2 | Allocated | |---------- |-----------:|-----:|----------:|----------:|----------:|-----------:| | Original | 8,500.9 ms | 1.00 | 1548000.0 | 267000.0 | 109000.0 | 7205.44 MB | | Optimised | 957.5 ms | 0.11 | 43000.0 | 20000.0 | 2000.0 | 242.41 MB |
  40. @stevejgordon www.stevejgordon.co.uk • In the box JSON APIs - System.Text.Json

    • Low-Level – Utf8JsonReader and Utf8JsonWriter • Mid-Level – JsonDocument • High-Level – JsonSerializer and JsonDeserializer
  41. @stevejgordon www.stevejgordon.co.uk Microservice which: 1. Perform ElasticSearch Bulk Index 2.

    Deserialise JSON response to check for errors 3. Return a list of the IDs which errored BulkResponseParser
  42. @stevejgordon www.stevejgordon.co.uk | Method | Mean | Ratio | Gen

    0 | Gen 1 | Gen 2 | Allocated | |---------- |-------------:|------:|---------:|-------:|-------:|-----------:| | Original | 386,514.8 ns | 1.000 | 26.3672 | 0.4883 | - | 111408 B | | Optimised | 485.3 ns | 0.001 | 0.0181 | 0.0010 | - | 80 B | | Method | Mean | Ratio | Gen 0 | Gen 1 | Gen 2 | Allocated | |---------- |-------------:|------:|---------:|-------:|-------:|-----------:| | Original | 428,500 ns | 1.00 | 27.3428 | 0.4883 | - | 114.30 KB | | Optimised | 141,900 ns | 0.33 | 3.6621 | 0.2441 | - | 15.77 KB |
  43. @stevejgordon www.stevejgordon.co.uk • Identify a quick win • Use a

    scientific approach to demonstrate gains • Put gains into a monetary value • Cost to benefit ratio
  44. @stevejgordon www.stevejgordon.co.uk This work is a small part of a

    much bigger potential gain For a single microservice handling 18 million messages per day Reduction of at least 50% of allocations. Potential to at least double per instance throughput At least 1 less VM needed per year saving $1,700
  45. @stevejgordon www.stevejgordon.co.uk • Measure, don't assume! • Be scientific; make

    small changes each time and measure again • Focus on hot paths • Don't copy memory, slice it! Span<T> is less complex than it may first seem. • Use ArrayPools where appropriate to reduce array allocations • Consider Pipelines for I/O scenarios • Consider new Utf8Json APIs for high-performance JSON parsing
