Software Architecture, Processes, Organization—and Humans

Architecture, Organization, Processes – and Humans Stefan Tilkov, @stilkov [email protected]
YOW! 18 August 2020

Architecture & Organization

@stilkov Conway’s Law: Organization → Architecture “Organizations which design systems
are constrained to produce systems which are copies of the communication structures of these organizations.” – M.E. Conway

@stilkov Conway’s Law Illustrated

@stilkov Conway Reversal 1: Organization ← Architecture Any particular architecture
approach constraints organizational options – i.e. makes some organizational models simple and others hard to implement.

@stilkov Choosing a particular architecture can be a means of
optimizing for a desired organizational structure. Conway Reversal 2: Organization ← Architecture

@stilkov The “Tilkov wants a law, too” slide The quality
of a system’s architecture is inversely proportional to the number of bottlenecks limiting its evolution, development, and operations

@stilkov The “Tilkov wants a law, too” slide* In a
digital company, architecture, organization & processes can only evolve together *Attempt #2 in case the 1st one doesn’t catch on

@stilkov Let’s talk about patterns

@stilkov Pattern: <Name> Description Approach Consequences … … …

@stilkov Pattern: Microservices Description Approach Consequences Design modules as separate
deployment and operation units, with large degrees of freedom for their implementation Former technical detail (deployment architecture) as first class architectural design principle Network communication as hard-to-cross boundary, enforcing encapsulation Isolation Autonomy Scalability Resilience Speed Experimentation Rapid Feedback Flexibility Replaceability

@stilkov Antipattern: <Name> Description Reasons Consequences … … …

@stilkov Antipattern: Microservices Description Reasons Consequences System made up of
arbitrarily sized, tightly coupled modules communicating over network interfaces Hype-driven architecture Conference-driven development Missing focus on business domain Infrastructure over- engineering “Ripple” effect of changes Complex environment Massive network overhead Performance issues Wild mix of technologies, products & frameworks Hard to understand & maintain (a.k.a. “Distributed Monolith“)

Antipatterns

Antipattern: Conference-driven Architecture

@stilkov Antipattern: Conference-driven Architecture Description Reasons Consequences Hypes are accepted
as gospel, and applied to problems regardless of whether they match requirements or not • Hot and shiny toys! • Community respect • Search for guidance • Occasional successes • Motivated developers • Half-time of solutions matches conference cycle time • Acceptance of architecture directly related to # of conference visits

@stilkov Antipattern: Decoupling Illusion Stakeholder Stakeholder Stakeholder Platform Person

@stilkov Antipattern: Decoupling Illusion Description Reasons Consequences Technical separation into
subsystems/services does not match business domain separation • Technical drivers prioritized over business drivers • Lack of awareness for stakeholder needs • Reuse driver furthers single platform approach • Microservices hype • Technical complexity • Conflicting stakeholder needs require coordination • Organizational bottlenecks due to centralized components with highly concurrent requests

@stilkov Antipattern: Half-hearted Modularization Dev Ops

@stilkov Antipattern: Half-hearted Modularization Description Reasons Consequences Modularization is performed
in one aspect of the lifecycle only • Resistance of one group to participate • Lack of understanding of lifecycle aspects by initiators • Added complexity, limited value • Delivery inhibited by existing processes • New approach might be “burned” for future attempts

@stilkov Antipattern: Solution Centrism Stakeholder Stakeholder Stakeholder Solution

@stilkov Antipattern: Solution Centrism Description Reasons Consequences Implementation solution as
unifying factor • Vendor influence • Experience drives selection of technology • Sunk cost fallacy • Inefficiency due to hammer/nail problem • Bottleneck by definition • Technology, not domain as unifying factor • Developer frustration • Skills shortage in market • Hard to motivate people to train in proprietary tech

@stilkov Antipattern: Domain-last Approach Biz Unit 1 Ops Stakeholder Stakeholder
Stakeholder Biz Unit 2 Biz Unit 3 DB Tech 1 Tech 2 Dev

@stilkov Antipattern: Domain-last Approach Description Reasons Consequences Major driver for
organizational structure is roles and technical capabilities, not business domain • Matches classical company structure • Division of labor in divisions, department, teams • Projects as exceptions to change something that works • Inter-departmental politics over business needs • Conflicting project and disciplinary hierarchies and stakeholders • Blameshifting

Antipattern: Uncreative Chaos

@stilkov Antipattern: Uncreative Chaos Description Reasons Consequences Lack of architectural
structure & repeatable process for architectural decisions • No (effective) centralized governance • Non-technical senior management • Focus on unnecessary standardization • Strong business leaders, weak tech leaders • Redundancy in all aspects • Frequent technology discussions between teams • High integration costs and technical debt • Slow delivery capability due to complexity • Complex and expensive

@stilkov Antipattern: Authoritarian Regime

@stilkov Antipattern: Authoritarian Regime Description Reasons Consequences Centralized decision making,
strong standardization, homogeneous environment • Unpopular decisions (cost savings, product standardization, …) • (Perceived or real) lack of skills in “lower levels” • Possibly due to company culture • Frustration and developer exodus • Lack of innovation & speed because of bottlenecks • Technology paralysis

Patterns

Pattern: Developer Self-Service

@stilkov Pattern: Developer Self-service Description Approach Consequences Project developers can
access allocate resources without asking for permission • API-based access to resources (computation, storage, network, services) • Fine-grained security controls • Rate-limiting • Public, private or hybrid cloud-based • Shorter delivery/ deployment cycles • Support for experimentation • Easier test setup

Pattern: Regulated Market

@stilkov Awesome Shop CMS Archive General Ledger Print Shop HR

Context

Invoicing Accounting Auth Catalog Checkout & Order Search

Invoicing Accounting Auth Catalog Checkout & Order Search Domain Architecture

@stilkov Invoicing Accounting Auth Catalog Checkout & Order Search

@stilkov

@stilkov Macro Architecture

@stilkov Ruby on Rails MySQL Java Spring Boot OSS Product
COTS Java Spring Boot NodeJS ElasticSearch

@stilkov Ruby on Rails MySQL Java Spring Boot OSS Product
COTS Java Spring Boot NodeJS ElasticSearch Micro Architecture

@stilkov number of developers strength of decoupling methods modules components
μservices systems

@stilkov Macro Architecture

@stilkov Pattern: Regulated Market Description Approach Consequences Let “the free
market of ideas” decide what works best, but provide a framework of rules for interoperability • Separate micro & macro architecture • Strictly enforced rules for macro architecture • Loose, minimal governance for micro architecture • Motivated developers • Experimentation with different micro architecture approaches possible • Best-of-breed approach • Local optima

@stilkov Pattern: Autonomous Cells Stakeholder Stakeholder Stakeholder Biz Dev Ops
Biz Dev Ops Biz Dev Ops

@stilkov Pattern: Autonomous Cells Description Approach Consequences Decentralized, domain- focused
cells with maximum authority over all aspects of a set of capabilities • Decisions are made locally on all aspects of a solution • Success is measured via customer-oriented KPIs • Cross-functional team with biz, dev, ops skills • Customer/end user focus • Decentralized delivery capability • Speed as #1 priority • “Full-stack” requirement for developers and other roles • Redundancy instead of centralization

@stilkov Invoicing Accounting Auth Catalog Checkout & Order Search Team
Architecture

Pattern: Evolutionary Architecture

@stilkov Pattern: Evolutionary Architecture Description Approach Consequences Architecture is constructed
so it can evolve as much as possible over the course of (ideally indefinite) time • Separation of large domain into “islands of change” • Design for replacement, not for re-use • Minimization of shared dependencies • Cell metaphor: Renewal over time • Experimentation with different micro architecture approaches possible

@stilkov Pattern: Marketing-based Governance

@stilkov Pattern: Marketing-based Governance Description Approach Consequences Architectural approaches are
evangelized instead of mandated • Disseminate information via blogs, brown-bag sessions, public talks • Architects as communicators • Integration with public/community work • More heterogeneity • Similarity to industry • Decisions made based on a solution’s merit • Bottom-up modernization

Recommendations

1. Acquire domain knowledge and focus on business value

2. Partner with business stakeholders

3. Create evolvable structures

4. Be aware of the interplay between architecture, processes, organization,
and humans

5. Create value – or get out of the way
of those who do as quickly as possible
