Introduction to bhyve

Introduction to bhyve

Takuya ASADA

March 12, 2014
Tweet

More Decks by Takuya ASADA

Other Decks in Technology

Transcript

  1. What is bhyve? • bhyve is a hypervisor introduced in

    FreeBSD • Similar to Linux KVM, runs on host OS • BSD License • Developed by Peter Grehan and Neel Natu
  2. bhyve features • Required Intel VT-x and EPT (Nehalem or

    later)
 AMD support in progress • Does not support BIOS/UEFI for now
 UEFI support in progress • Minimal device emulation support:
 virtio-blk, virtio-net, COM port + α • Supported guest OS:
 FreeBSD/amd64, i386, Linux/x86_64, OpenBSD/amd64
  3. How to use it? kldload vmm.ko /usr/sbin/bhyveload -m ${mem} -d

    ${disk} ${name} /usr/sbin/bhyve -c ${cpus} -m ${mem} \
 -s 0,hostbridge -s 2,virtio-blk,${disk} \
 -s 3,virtio-net,${tap} -s 31,lpc -l com1,stdio vm0
  4. How to run Linux? • bhyve OS Loader(/usr/sbin/bhyveload) only supports

    FreeBSD
 You need another OS Loader to support other OSs • grub2-bhyve is the solution • It’s modified version grub2, runs on host OS (FreeBSD) • Can load Linux and OpenBSD • Available in ports & pkg!
  5. Difference between container and hypervisor • Jail is container •

    It’s virtualize OS environment on kernel level • bhyve is hypervisor • It virtualizes whole machine • Totally different approach
  6. Container • Process in jail is just a normal process

    for the kernel • The kernel do some tricks to isolate environments between jails • Lightweight, less-overhead • Share one kernel with all jails
 → If the kernel panics, all jails
 will die • You cannot install another OS
 (No Windows, No Linux!) jail2 jail1 Kernel Disk NIC proc ess proc ess proc ess
  7. Hypervisor • Hypervisor virtualizes a machine • From guest OS,

    it looks like real hardware • Virtual machine is a normal process for host OS • Does not share kernel, it is completely isolated • You can run Full OS inside of the VM → Windows! Linux! Kernel Disk NIC Hypervisor proc ess vm1 Kernel Disk NI C proc ess vm2 Kernel Disk NI C proc ess
  8. How hypervisor virtualize machine? • To make complete virtual machine,

    you need to virtualize following things: • CPU • Memory (Address Space) • I/O
  9. CPU Virtualization:
 Emulate entire CPU? • Like QEMU • You

    can emulate the entire CPU operation on a normal process • Very slow, not a really useful choice for virtualization QEMU mov dx,3FBh mov al,128 out dx,al $16 FNVMB UPS SVO WJSUVBM EFWJDF OS QIZTJDB MEFWJDF QIZTJD BM $16 IO
  10. CPU Virtualization: Direct execution? • You want run guest instructions

    directly on a real CPU since you are virtualizing x86 on x86 • You need to avoid executing some instructions which modify system global state, or perform I/O (called sensitive instructions) • If you execute these instructions on a real CPU, it may break host OS state such as directly accessing a HW device
  11. Perform I/O on VM • You need to avoid access

    to real HW from VM • Need to prevent execution of the instruction GuestOS Virtual CPU Real Display outb
  12. Perform IO on VM • You can trap them by

    executing in lower privileged mode • However, on x86, there are some instructions which are impossible to trap
 because these are nonprivileged instructions GuestOS Virtual CPU outb Virtual Display trap!
  13. Software techniques to virtualize x86 • Binary translation (old VMware):

    interpret & modify guest OS’s instructions on-the-fly
 → Runs fast, but implementation is very complex • Paravirtualization (old Xen): Modify guest OS for
 the hypervisor
 → Runs fast, but is impossible to run unmodified OS’s • We want an easier & better solution
 → HW assisted virtualization!
  14. Hardware assisted virtualization(Intel VT-x) • New CPU mode:
 VMX

    root mode (hypervisor) / VMX non-root mode (guest) • If some event needs to emulate in the hypervisor,
 CPU stops guest, exit to hypervisor → VMExit • You don’t need complex software techniques
 You don’t have to modify the guest OS User (Ring 3) Kernel (Ring 0) User (Ring 3) Kernel (Ring 0) VMX root mode VMX non-root mode VMEntry VMExit
  15. Memory Virtualization • If you run guest OS natively, memory

    address translation become problematic • If GuestB loads Page table A, virtual page 1 translate to Host physical page 1
 but you meant Host physical page 5 1SPDFTT"  1SPDFTT#   (VFTUQIZTJDBMNFNPSZ 2 1 3 4 1 1 2 1 3 2 4 1BHFUBCMF" 1BHFUBCMF# (VFTU"    2 1 3 4 1 1 2 1 3 2 4 )PTUQIZTJDBMNFNPSZ 2 1 7 3 4 5 6 8 1SPDFTT" 1SPDFTT# (VFTUQIZTJDBMNFNPSZ 1BHFUBCMF" 1BHFUBCMF# (VFTU#
  16. Shadow Paging • Trap page table loading/modifying, create “Shadow Page

    Table”, tell physical page number to the MMU • A software trick that works well, but is slow    2 1 3 4 1 2 2 1 3 2 4 2 1 7 3 4 5 6 8 1 5 2 1 7 2 8 1SPDFTT" 1SPDFTT# (VFTUQIZTJDBMNFNPSZ 1BHFUBCMF" 1BHFUBCMF# (VFTU" )PTUQIZTJDBMNFNPSZ 1BHFUBCMF" 1BHFUBCMF#
  17. Nested Paging (Intel EPT) • HW assisted memory virtualization! •

    You will have Guest physical : Host physical translation table • MMU translates address by two step (Nested)    2 1 3 4 1 2 2 1 3 2 4 2 1 7 3 4 5 6 8 1 5 2 6 &15" 3 7 4 8 1SPDFTT" 1SPDFTT# (VFTUQIZTJDBMNFNPSZ 1BHFUBCMF" 1BHFUBCMF# (VFTU" )PTUQIZTJDBMNFNPSZ
  18. I/O Virtualization • To run unmodified OSs, you’ll need to

    emulate all devices what you have on the real hardware • SATA, NIC(e1000), USB(ehci), VGA(Cirrus), Interrupt controller(LAPIC, IO-APIC), Clock(HPET), COM port… • Emulating real devices is not very fast because it causes lot of VMExits, not ideal for for virtualization
  19. Paravirtual I/O • Virtual I/O device is designed for VM

    use • Much faster than emulating real devices • Required device driver on guest OS • De-facto standard: virtio-blk, virtio-net
  20. PCI Device passthrough • If you attach a real HW

    device on a VM, you will have a problem with DMA • Because the device requires physical address for DMA but the guest OS doesn’t know the Host physical address • Address translator for the devices: IOMMU(Intel VT-d) • Translates guest physical to host physical using a translation table 1IZTJDBMNFNPSZ 2 1 7 3 4 5 6 8 PCI %FWJDFT DMA! 5 1 6 2 7 3 8 4 IOMMU USBOTMBUJPOUBCMF 1SPDFTT"  1SPDFTT#   (VFTUQIZTJDBM NFNPSZ 2 1 3 4 1 2 2 1 3 2 4 1BHFUBCMF" 1BHFUBCMF# (VFTU" 1 5 2 6 &15" 3 7 4 8
  21. How bhyve virtualize machine? • CPU: HW-assisted virtualization (Intel VT-x)

    • Memory: HW-assisted memory virtualization (Intel EPT) • IO: virtio, PCI passthrough, +α • Uses HW assisted features
  22. bhyve overview • bhyveload: loads
 guest OS • bhyve: userland

    part of Hypervisor, emulates devices • bhyvectl: a management tool • libvmmapi: userland API • vmm.ko: kernel part of Hypervisor FreeBSD kernel bhyveload bhyve /dev/vmm/${vm_name} WNNLP (VFTU LFSOFM $SFBUF7.JOTUBODF MPBEHVFTULFSOFM 3VO7.JOTUBDF H D N I C Console %JTLJNBHF UBQEFWJDF TUEJOTUEPVU bhyvectl libvmmapi %FTUSPZ7. JOTUBODF mmap/ioctl
  23. vmm.ko • All VT-x features only accessible in kernel mode,

    vmm.ko handles it • Most important work of vmm.ko is CPU mode switching between hypervisor/guest • Provides interface for userland via /dev/ vmm/${vmname} • Each vmm device file contains each VM instance state
  24. /dev/vmm/${vmname} interfaces • create/destroy
 Can create/destroy device file via sysctl


    hw.vmm.create, hw.vmm.destroy • read/write/mmap
 Can access guest memory area by standard syscall (Which means you even can dump guest memory by dd command) • ioctl
 Provides various operations to VM
  25. /dev/vmm/${vmname} ioctls • VM_MAP_MEMORY: Maps guest memory area at requested

    size • VM_SET/GET_REGISTER: Access registers • VM_RUN: Run guest machine, until virtual devices accessed (or some other trap happened)
  26. libvmmapi • wrapper library of /dev/vmm operations • vm_create(name)→ sysctl(“hw.vmm.create”,

    name) • vm_set_register(reg, val) → ioctl(VM_SET_REGISTER, reg, val)
  27. bhyveload • bhyve uses OS loader instead of BIOS/UEFI, to

    load guest OS • FreeBSD bootloader ported to userland: userboot • bhyveload runs host OS, to initialize guest OS • Once it called, it does following things: • Parse UFS on diskimage, find kernel • Load kernel to guest memory area • Initialize Page Table • Create GDT, IDT, LDT • Initialize special registers to get ready for 64bit mode • Guest machine can starts from kernel entry point, with 64bit mode
  28. bhyve • bhyve command is the userland part of the

    hypervisor • It invokes ioctl(VM_RUN) to run GuestOS • Emulates virtual devices • Provides user interface(no GUI for now)
  29. main loop in bhyve while (1) { ioctl(VM_RUN, &vmexit); switch

    (vmexit.exit_code) { case IOPORT_ACCESS: emulate_device(vmexit.ioport);
 …
 } }
